WERTHEIM SE2000 User manual

Carpet Shampooer
SE2000
Carpet Shampooer SE2000
User Manual

Water Release Trigger
Cable Reel Hook
Power Cable and Plug (not shown)
Clean Water Tank Lever (not shown)
Clean Water Tank
On/Off Switch
Release Pedal (not shown)
Suction Nozzle and Brush
Base
Dirty Water Tank
Dirty Water Tank Handle
Unit Body
Handle
1
2
3
4
5
6
7
8
9
10
11
12
13
Features
Specications
Wattage: 700W
Dirty Water Tank Capacity: 2L
Noise Level: <83 dBa
Power Cable Length: 5.8m
Weight: 6.2Kg
5
4
10
8
6
11
12
13
9
7
1
2
3

Carpet Shampooer SE2000
1
INTRODUCTION
Congratulations on the purchase of your new Wertheim carpet
shampooer. There are many useful features built into your carpet
shampooer and we recommend that you carefully read this instruction
manual so that you may take best advantage of them.
Due to our program of continuous product improvement and
innovation, sometimes the product you buy may differ slightly from the
one shown on this product carton/manual.

2
BEFORE YOU BEGIN
Please read these instructions thoroughly
The cleaner must be operated in accordance with these instructions
and used only for domestic household cleaning to remove DRY dirt and
dust from household.
This will ensure you obtain full benet from your new cleaner. Keep this
instruction manual in a handy place for future reference.
Precautionary measures:
1. Do not operate the carpet shampooer too close
to heaters, radiators, and other hot surfaces.
2. Before inserting the plug into the wall, make sure
your hands are dry.
3. When you want to pull the plug from the wall, do not
use the power cable, gently pull the plug from the
power socket.

Carpet Shampooer SE2000
3
SAFETY INSTRUCTIONS
IMPORTANT! Always switch the appliance off and remove
the plug from the electricity supply before cleaning
your appliance, when not in use, or attempting any
maintenance task.
The cleaner must only be connected to an AC supply
at the voltage shown on the rating plate. This cleaner
should only be used for its intended purpose as described
in these instructions. Never operate the carpet washer
cleaner without lters.
1. This appliance is not intended for use by persons (including children)
with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a person responsible
for their safety
2. Children should be supervised to ensure that they do not play with the
appliance.
3. If the power cord is damaged it must be replaced by an authorized
service agent or similarly qualied persons.
4. Carpets should be dry vacuumed thoroughly before washing. Use a
vacuum cleaner with a power brush for best results.
5. If using an extension cord please make sure that it is of an approved
type and that it is fully extended. Failure to do so could cause your
cleaner to overheat and damage it.
6. Do not run the appliance over the power cable and power socket on
the oor.
7. Do not place cleaner on stairs or furniture, as it may result in injury or
damage Do not handle the plug or carpet washer with wet hands.

4
SAFETY INSTRUCTIONS (CONT’D)
8. Do not put any objects into the openings or operate with the openings
blocked. Keep them free of anything that may reduce air ow
9. Keep hair, loose clothing, ngers and all parts of the body away from
openings and moving parts.
10. Do not use this cleaner and accessories on hard oors. Using this
machine on hard oors may scratch or damage your oor.
11. Do not use the carpet washer on any glowing, burning or smoking
particles.
12. Do not use without the solution tank and dirty water tank in place.
13. Turn off all controls before unplugging.
14. Do not store cleaner with solution in tanks.
15. Do not use to pick up ammable or combustible liquids such as
petrol or use in areas where they may be present
16. Only use the cleaning solution provided by Godfreys.
17. Do not use any high-foaming solutions as an excessive amount of
foam impairs the functioning of the shampooer. If unsuitable
cleaning solutions are used, this will void warranty.
FAULTS!
Consult the trouble shooting guide in this manual if your carpet washer
fails to operate properly.
Do not continue to use this appliance if it appears to be faulty or the
supply cord is damaged. If a fault can’t be rectied, please return to
the point of purchase.
Caution!
The cleaning head contains electrical connection. The cleaning head
is not a serviceable part. Please return the product to your nearest
Godfreys store if the cleaning head is faulty.

Carpet Shampooer SE2000
5
INSTRUCTIONS FOR USE
Before You Begin Cleaning
IMPORTANT: Do not use the carpet shampooer as a dry vacuum.
Note: Vacuum carpet thoroughly. Use a vacuum cleaner with a
powerbrush for best results.
Note: Remove as much furniture from the room as possible. If unable to
remove the furniture, place plastic or foil under and around the legs until
the carpet has dried completely.
1. For heavily soiled areas, additional applications may be necessary.
2. Allow plenty of time for carpet to dry thoroughly.
3. Wipe cleaning solution from woodwork and wood to prevent
any damage.
4. Try not to walk on carpet until it is completely dry.
5. After carpet is thoroughly dry, vacuum the carpet using a vacuum
cleaner with a powerbrush.
6. Before cleaning, determine an exit path, making sure not to walk over
previously cleaned areas.
Check for Colour Fastness
Before cleaning the carpet, test for colour fastness. Dampen a white
cloth with solution. Test a small area of carpet in a closet. Gently rub the
cloth over the carpet. Check each colour for colour bleeding. If the
cloth remains clean, it should be safe to clean the carpet.

6
Attaching the handle to the appliance
1. Take the handle and unscrew both screws
from the bottom ends of the handle.
Note: You will need a phillips head screwdriver.
2. Insert the handle onto the adapter of the
unit body and screw the screws back into
the boreholes.
INSTRUCTIONS FOR USE
THE APPLIANCE SHOULD BE SWITCHED OFF AND DISCONNECTED
FROM THE POWER SUPPLY BEFORE YOU START TO ASSEMBLE.
Assembling the Water Tanks
Assembling Your Cleaner
1. Lay the dirty water tank in the base of the unit
and fold down the handle of the tank until it
audibly engages.
2. Insert the fresh water tank into the unit body. First
insert the valve into the round depression on the
backside of the appliance and then press the
top of the tank against the centrepiece until it
audibly engages.
3. Turn the lower hooks of the cable reel
downward and wrap the power cable around
both hooks of the cable reel.

Carpet Shampooer SE2000
7
Filling the Water Tank
1. Hold the fresh water tank by the handle
and pull up the unlocking lever. The tank is
released from the locking mechanism.
2. Remove the fresh water tank from the
appliance.
3. Unscrew the ring cap on the bottom of
the tank and remove the valve together
with the water hose.
4. Add solution into the tank. Note: The dosage
of the cleaning solution.
5. Fill the fresh water tank up to the MAX lling
line with warm water (max. 38°C). Preferably
use distilled water to prevent calcication.
6. Then close the tank using the valve and ring
cap.
7. Insert the fresh water tank into the
centrepiece.
Using the Extractor
IMPORTANT: Never leave the appliance unattended with the power on.
Turn off when emptying and lling tanks. Do not oversaturate the carpet.
Note: Cleaning solution may leak out of the shampooer once it is

8
INSTRUCTIONS FOR USE (cont’d)
1. Press down the shampooer, unlocking the
pedal and set the handle to a comfortable
position.
2. Using your foot, press the on/off switch to turn
on the appliance.
3. Run the shampooer to a corner of the carpet.
4. Push the shampooer forward along the carpet border and depress
the button for emitting the cleaning solution. This will apply and brush
the cleaning solution into the carpet. In the process, walk next to the
shampooer. Do not step on the wet carpet! Once you have arrived at the
other end of the carpet, release the button.
5. Repeat above steps The dirty water will be vacuumed up.
6. Start the next strip slightly overlapping the cleaned carpet strip. Work with
even forward and backward movements up to the other edge of the
carpet. In the event of stubborn dirt, go over a strip of the carpet several
times if necessary.
7. When the dirty water tank is lled to the max ll line, it must be emptied. If
you would like to empty the dirty water tank, ll up the fresh water tank or
nished cleaning, switch off the appliance by pressing the on/off switch,
lay it on the prepared cloth, and bring the handle to the upright position.
Note: Do not store or transport the appliance when liquid is still in the tanks.
8. Remove the power plug from the power socket.
deactivated. For this reason, have a cloth laid out that you can place the
shampooer on after use.

Carpet Shampooer SE2000
9
MAINTENANCE
WARNING: Always unplug power cord from electrical outlet
before performing any maintenance task on the carpet
shampooer.
Emptying the Water Tanks
IMPORTANT: Do not wash lters in the washing machine, hand wash only.
Only air dry the lters and do not in use a hair dryer.
Note: Cleaning solution may leak out of the shampooer once it is
deactivated. For this reason, have a cloth laid out that you can place the
shampooer on after use.
1. Pull up the dirty water tank handle and remove the tank from the base of
the appliance.
2. The cap is on the back of the tank. Turn it 90° counterclockwise to open it.
3. Pour out the dirty water and rinse the tank out thoroughly with warm water
(max. 38°C).
4. The exhaust air lter is located at the top of the dirty water tank. Press the
locking mechanism outward toward the lter and remove the lter mount.
5. Take the lter out of the holder and rinse it off with warm water.
6. Take the protective motor lter out of the main unit and rinse it off
withwarm water.
7. Pour the leftover cleaning solution out of the fresh water tank and clean
the tank thoroughly with warm water.
8. As required, wipe down the appliance with a moist cloth.
9. Let all parts of the appliance (even the brushes on the bottom of the
shampooer, dry completely before storing it.
Replace the belt / the roller brush
WARNING: Always unplug power cord from electrical outlet before
performing any service on extractor.
Due to the normal wear and tear, the belt may break and the roller brush will

10
stop working.
Please follow the instruction below on how to replace the belt and the roller
brush.
Caution!
Do not remove any other screws, besides the ones specied in the image
above. The cleaning head contains electrical connection. The cleaning
head is not a serviceable part. Please return the product to your nearest
Godfreys store if the cleaning head is faulty.
Undo the below three screws. The roller brush
and the belt can be removed for replacement.

Carpet Shampooer SE2000
11
TROUBLESHOOTING
Service problems that appear to be major can often be solved easily. You
can be your own troubleshooter by reviewing this guide. All other servicing
should be done by an authorised service agent or qualied technician.
SPARE PARTS
Problem Cause Remedy
Reduced spray
or no spray. 1. Water tank is empty 1. Rell tank with water
and solution
Not picking up
cleaning solution.
1. Collection tank not
tted properly.
2. Collection tank is full.
1. Check alignment of
the tanks.
2. Empty the tank.
Filter Set (pre motor and exhaust) 32200790
Solution Tank Assembly 33151763
Dirty Water Tank 33151764
Agitating Brush Roll 33787995
Belt 32100179

This warranty on your cleaner commences
from the original date of purchase and is not
transferable; please retain your original proof of
purchase for any warranty claims. This warranty
is valid only in the country where the cleaner
is purchased.
The cleaner must be operated in accordance
with these instructions and used only for domestic
household cleaning to remove DRY dirt and dust
from household carpets, ooring and fabrics.
This cleaner is not t to be used as an industrial
cleaner, and is not designed for the collection
of vitreous building material including particle
board, construction products and similar products
such as wood/bres, cement, llers, bre glass
etc or excessive or frequent sand. The infrequent
pick-up of these materials in these circumstances
may be harmful to your cleaner and may void the
manufacturer’s warranty.
Accessories and consumables including dust
bags and lters, unless defective in manufacture,
are not subject to this warranty. In order to prolong
the life of accessories and consumables, regular
care and maintenance is recommended.
When properly used and cared for, your
cleaner will render excellent service; refer to the
instruction manual for further details, as misuse
or failure to follow the instructions makes this
warranty void.
In the event of service or advise being
needed, please contact Electrical Home-
Aids Pty. Ltd. Level 1, Building 2, Brandon
Business Park, 530 Springvale Road, Glen
Waverley Victoria 3150, AUS: 1800 815 270,
NZ: [phone], Monday – Friday, 9am-5pm
EST. Email: [email protected].au
The decision to repair or replace the cleaner is
at the sole discretion of Electrical Home-Aids
Pty Ltd.
Electrical Home-Aids Pty Ltd is unable to accept
responsibility under this warranty for any repair
work not carried out by an authorised Electrical
Home-Aids Service Agent or from the use of non-
genuine parts. If any part is no longer available
or manufactured, Electrical Home-Aids Pty
Ltd will replace it with a genuine functional
replacement part. This warranty does not apply
to the cost of replacing any parts of the product
due to normal wear and tear, alterations,
improper installation, physical abuse, misuse or
accidental damage. Any transportation costs
involved in the repair of defective parts shall be
borne by the claimant.
If proof of purchase cannot be provided at the
time of a warranty claim or service, any work
carried out on the cleaner is chargeable. The
repair or replacement of the cleaner under this
warranty does not extend the original period
of warranty.
The benets conferred by this warranty are
in addition to all other rights and remedies
in respect of the product as outlined under
the Trade Practises Act and other State and
Territory laws.
“Our goods come with guarantees that cannot
be excluded in the Australian Consumer Law.
You are entitled to a replacement or refund for
a major failure and for compensation for any
other reasonably foreseeable loss or damage.
You are also entitled to have the goods repaired
or replaced if the goods fail to be of acceptable
quality and the failure does not amount to a
major failure.”
SAVE TIME, REGISTER WARRANTY ONLINE!
www.wertheim.net.au and www.wertheim.co.nz
V1 09/15
