Weslo CADENCE LX 15 User manual

W LD
Model No. WLTL31571
Serial No.
Serial
Number
Decal
QUESTIONS?
As a manufacturer, we are com-
mitted to providing complete
customer satisfaction. If you
have questions, or find that there
are missing or damaged parts,
we will guarantee complete sat-
isfaction through direct assis-
tance from our factory.
TO AVOID UNNECESSARY DE-
LAYS, PLEASE CALL DIRECT TO
OUR TOLL-FREE CUSTOMER
HOT LINE. The trained techni-
cians on our Customer Hot Line
will provide immediate assis-
tance, free of charge to you.
CUSTOMER HOT LINE:
1-800-999-3756
Mon.-Fri., 6 a.m.-6 p.m. MST
SEP08 1991
USER'S MANUAL

TABLE OF CONTENTS
IMPORTANT PRECAUTIONS ................................................................. 3
BEFORE YOU BEGIN ........................................................................ 5
ASSEMBLY ............................................................................... 6
OPERATION AND ADJUSTMENT ............................................................. 7
HOW TO FOLD AND MOVE THE TREADMILL .................................................. 10
MAINTENANCE AND TROUBLE-SHOOTING ................................................... 12
CONDITIONING GUIDELINES ........................ :....................................... 14
ORDERING REPLACEMENT PARTS .................................................. Back Cover
LIMITED WARRANTY ............................................................... Back Cover
Note: An EXPLODED DRAWING and aPART LIST are attached to the center of this manual. Save the
EXPLODED DRAWING and PART LIST for future reference.
2

IMPORTANT PRECAUTIONS
21
:.. ........ : :,.

The decal shown below has been placed on your treadmill, if the decal is missing, or if it is not legible,
please call our Customer Service Department, toll-free, to order a free replacement decal (see ORDERING
REPLACEMENT PARTS on the back cover of this manual). Apply the decal in the location shown.

BEFORE YOU BEGIN
Thank you for selecting the WESJ,.O CADENCE ° LX 15
treadmill. The CADENCE LX 15 treadmill combines
advanced technology with innovative design to let you
enjoy an excellent form of cardiovascular exercise in
the convenience and privacy of your home. And when
you're not exercising, the unique CADENCE LX 15 can
be folded up, requiring less than half the floor space of
other treadmills.
For your benefit, read this manual carefully before
using the treadmill. If you have additional questions,
please call our Customer Service Department toll-free
at 1-800-999-3756, Monday through Friday, 6 a.m.
until 6 p.m. Mountain Time (excluding holidays). To
help us assist you, please note the product model
number and serial number before calling. The model
number of the treadmill is WLTL31571. The serial
number can be found on a decal attached to the tread-
mill (see the front cover of this manual for the location).
Before reading further, please review the drawing
below and familiarize yourself with the parts that are
labeled.
Foo'
Water Bott!e Holder -Towel Rack
(Water Bottle i_'
Accesso
Han0ra, j\:, RIG.TSIDE
Storage Latch _ _
Walking i i lill Upright
!
L circuit
Breaker
Rear Roller \
Adjustment Bolt BACK Incline Leg
Power
Cord
Cushioned Walking Platform
for maximum exercise comfort
5

ASSEMBLY
Assembly requires two people. Set the treadmill in a cleared area and remove all packing materials. Do not
dispose of the packing materials until assembly is completed. Assemblyrequires the included allen wrench=_
and your own phillips screwdriver _===_ .
lw- With the help of a second person, carefully lay the
treadmill on its right side as shown (refer to the drawing
on page 5 to identify the right side).
Insert one of the Extension Legs (41) intothe treadmill as
shown. Make sure that the Base Pad (36) ison the indi-
cated side of the Extension Leg. Attach the Extension
Leg with an Extension Leg Screw (34).
Attach the other Extension Leg (41) as described above.
With the help of asecond person, carefully raise the
treadmill to the upright position so the Extension Legs
(41) are resting flat on the floor. /
...._"34
=Refer to HOW TO LOWER THE TREADMILL FOR USE
on page 11. Follow the instructions instep 2 to lower the
treadmill.
Attach the Storage Latch (12) to the left Upright (14) with
two Latch Screws (13). Be careful not to overtighten the
Latch Screws.
.Remove the backing from the Adhesive Clip (74). Press
the Adhesive Clip onto the base of the Uprights (14) in
the indicated location. Press the Allen Wrench (73) into
the Adhesive Clip.
I
73
74
64. Make sure that all parts are tightened before you use the treadmill. To protect the floor or carpet, place
a mat under the treadmill.

OPERATION AND ADJUSTMENT
THE PERFORMANT LUBE TM WALKING BELT
Your treadmill features awalking belt coated with
PERFORMANT LUBE TM, a high-performance lubricant.
Important: Never apply silicone spray or other sub-
stances to the walking belt or the walking platform.
They will deteriorate the walking belt and cause ex-
cessive wear.
HOW TO PLUG IN THE POWER CORD
electric shock. This product is equipped with acord
having an equipment-grounding conductor and a
groundingplug. Plug the power cord into a surge
protector, and plug the surge protector into an ap-
propriate outlet that is properly installed and
grounded in accordance with all local codes and
ordinances.
This product is for use on a nominal 120-volt circuit,
and has a grounding plug that looks like the plug illus-
trated in drawing 1 below. A temporary adapter that
looks like the adapter illustrated in drawing 2 may be
used toconnect the surge protector to a 2-pole recep-
tacle as shown in drawing 2 if a properly grounded out-
let is not available.
The temporary adapter should be used only until a
properly grounded outlet (drawing 1) can be installed
by a qualified electrician.
Your treadmill, like any other type of sophisticated
electronic equipment, can be seriously damaged by
sudden voltage changes in your home's power.
Voltage surges, spikes, and noise interference can re-
suit from weather conditions or from other appliances
being turned on or off.
To decrease the pos-
sibility of your tread- 1
mill being damaged,
always use a surge
protector (not in-
cluded) with your
treadmill.
Surge protectors are
sold at most hardware
stores and department
stores. Use only a UL-
listed surge protector,
rated at 15 amps, with a
14-gauge cord of five
feet or less in length.
This product must be
grounded. If it should
malfunction or break
down, grounding pro-
vides a path of least re-
sistance for electric cur-
rent to reduce the risk of
The green-colored rigid ear, lug, or the like extending
from the adapter must be connected to a permanent
ground such as a properly grounded outlet box cover.
Whenever the adapter is used it must be held in place
by a metal screw. Some 2-pole receptacle outlet box
covers are not grounded. Contact a qualified elec-
trician to determine if the outlet box cover is
grounded before using an adapter.
Grounded Outlet Box
I .l . GroundingPin
L_" __._unding Plug
_Grounded Outlet
/Grounded Outlet Box
,__,Adapter
0. I( /_ ,,Grounding Pin
(_ , Grounding Plug
Metal Screw
Treadmill Power
Surge Protector
7

DIAGRAM OF THE CONSOLE
/_ Monitor Displays
/=,44 |PM HEART RATE TRAINING ZONES
eTsJmr--]r--ff--l r--]l_HSI
1311_C:3r"]r-l_
r---nr-nr-n_ r-nii;i_:!:;_
, r--II---_r-'3 r--I r-'l r--l_L_:i_i
CUSTOMERSERVICE
ItO0 999 3756
Speed Control
RESET
rING ZONE5
OPERATION _ 0 INilItT KIY O AISII'SPIID O S][TIPEED
Clip INote:If there' is a thin sheet ¢
clear plastic on the face of th_
console, remove it.
BATTERY INSTALLATION
The console requires three "AA" batteries (not
included); alkaline batteries are recommended. To
install batteries, first open the battery cover as shown
in the drawing at the right.
Press three batteries into the battery compartment,
with the negative ends of the batteries (marked "-")
touching the springs. Close the battery cover.
Battery Cover
8

STEP BY STEP CONSOLE OPERATION
Before operating the console, make sure that the power
cord is properly plugged in. (See HOW TO PLUG IN
THE POWER CORD on page 7.)
TIME display--This
display shows the total
time that you have
walked or runon the
treadmill.
Step onto the foot rails of the treadmill. Next, find the
clip attached to the key (see the drawing on page 8).
Slide the clip onto the waistband of your clothing.
Follow the steps below to operate the console.
nInsert the key fully into the power switch.
Inserting the key will
not turn on the dis-
plays. The displays will
turn on when the
ON/RESET button is
pressed or when the
walking belt is started.
M
Note: If you just installed batteries, the displays will
already be on.
CAL/FAT CAL PuLse
display--This display
shows the approximate
numbers of both ca/o- •
ties and fat calories you ators
have burned (see FAT .
BURNING on page 14
for an explanation of fat calories). Every seven sec-
onds, the display will change from one number to
the other. Indicators in the display will show which
number is currently displayed.
SPEED display--This
display shows the speed
of the walking belt, in
miles per hour.
SPEED
"m_UI
u.3.
19Reset the speed control.
Turn the speed
control counter- ,,o,,,,.,,,, zo..
clockwise to the
RESET position.
Note: Each time
the walking belt is
stopped, the
speed control
must be turned to
the RESET position before the walking belt can
be restarted.
Start the walking belt.
After you have turned the speed control to the
RESET position, turn it slowly clockwise until the
walking belt begins to move at slow speed.
Carefully step onto the walking belt and begin exer-
cising. Change the speed of the walking belt as de-
sired by turning the speed control.
To stop the walking belt, step onto the foot rails and
turn the speed control to the RESET position.
Follow your progress with the monitor displays.
DISTANCE displaym
This display shows thp
total distance that you
have walked or run, in
miles.
DISTANCE
t"1 I
The displays can be
reset, if desired, by
pressing the ON/RESET
button. OI_RESET
Measure your pulse, if desired.
To use the pulse sensor, stand on the foot rails and
place your thumb
on the pulse sen-
sor as shown. Pulse
Sensor
The pulse sensor
is pressure-acti-
vated; fully press
down the pulse
sensor. Do not
press too hard,
or the circula-
tion In your thumb will be restricted, and your
pulse will not be detected. Next, slightly raise your
thumb until the heart-
shaped indicator in the
PULSE display flashes
steadily. Hold your
thumb at this level.
After 5 to 10 seconds,
your pulse will be
shown. Hold your
PULSE
F/ F/
ALj'FAT C,AI.
Indicator
thumb on the sensor for another 15 seconds for the
most accurate reading. If the displayed pulse ap-
pears to be too high or too low, or if your pulse is
not displayed, lift your thumb off the sensor and
allow the display to reset. Press down again on the
sensor as described above.
9

Make sure that your thumb is positioned as shown,
and that you are applying the proper amount of pres-
sure to the pulse sensor. Try the sensor several
times until you become familiarwith it. Remember to
stand still while measuring your pulse.
When you are finished exercising, stop the
walking belt and remove the key.
Step onto the foot rails,
stop the walking belt, and
remove the key from the
console. Store the key in
a secure place. After the
key is removed, the
displays will remain on
for about five minutes.
Note: Any time that the walking belt is stopped
and no console buttons are pressed for five
minutes, the displays will automatically turnoff.
HOW TO CHANGE THE INCLINE OF THE TREADMILL
The incline of the treadmill can be changed by raising or
lowering the back end. Before changing the incline,
remove the key and unplug the power cord.
Hold the rear roller endcap with both hands. When the
back end of the treadmill is in the lowest position, the in-
cline is about 10%. Raise the back end until it clicks into
positiorj. (Note: It may be necessary to shake the tread-
mill lightly so that it clicks into position.) The incline will
then be
about 5%.
Raise the
back end
again until
it clicks into
position.
The incline Hold the Rear
will then be Roller Endcap . Incline
about 3%. in these locations Leg
To lower
the back
end, first raise it past the highest position, and then
lower it. CAUTION: Before exercising, push on the
back of the treadmill to make sure tl_at the incline
legs are locked in position. Do not place objects
under the treadmill to change the incline; change
the incline only as described above.
4_
HOW TO FOLD AND MOVE THE TREADMILL
HOW TO FOLD THE TREADMILL FOR STORAGE
Before folding the treadmill, unplug the power cord. Caution:
You must be able to safely lift 45 pounds (20 kg) in order
to raise, lower, or move the treadmill.
.Hold the treadmill with your hands in the locations shown
at the right. To decrease the possibility of injury, bend
your legs and keep your back straight. As you raise
the treadmill, make sure to lift with your legs rather
than your back. Raise the treadmill about halfway to the
vertical position.
.Move your right hand to the position shown and hold the
treadmill firmly. Raise the treadmill until the storage latch
closes over the catch. Make sure that the storage latch
is fully engaged over the catch.
To protect the floor or carpet from damage, place a
mat under the treadmill. Keep the treadmill out of
direct sunlight. Do not leave the treadmill in the stor-
age position in temperatures above 85°Fahrenheit.
Engaged
10
