Westermo MCW-211 SERIES User manual

www.westermo.com
MCW-211 Series
Industrial Ethernet Media Converter

26645-2204

3
6645-2204
General information
Legal information
The contents of this document are provided “as is”. Except as required by applicable law,
no warranties of any kind, either express or implied, including, but not limited to, the
implied warranties of merchantability and fitness for a particular purpose, are made in
relation to the accuracy and reliability or contents of this document. Westermo reserves
the right to revise this document or withdraw it at any time without prior notice.
Under no circumstances shall Westermo be responsible for any loss of data or income or
any special, incidental, and consequential or indirect damages howsoever caused.
More information about Westermo can be found at www.westermo.com
About This Guide
This guide is intended for installation engineers and users of the Westermo products.
It includes information on safety and regulations, a product description, installation
instructions and technical specifications.

46645-2204
Safety and Regulations
Warning signs are provided to prevent personal injuries and/or damages to the product.
The following levels are used:
Level of warning Description Consequence
personal injury
Consequence
material damage
WARNING
Indicates a potentially
hazardous situation
Possible death or
major injury
Major damage to the
product
CAUTION
Indicates a potentially
hazardous situation
Minor or moderate
injury
Moderate damage to
the product
NOTICE
Provides information
in order to avoid
misuse of the
product, confusion or
misunderstanding
No personal injury Minor damage to the
product
NOTE
Used for highlighting
general, but important
information
No personal injury Minor damage to the
product
4
6645-2204

5
6645-2204
Safety Information
Before installation:
Read this manual completely and gather all information on the product. Make sure that
you understand it fully. Check that your application does not exceed the safe operating
specifications for this product.
WARNING - SAFETY DURING INSTALLATION
The product must be installed and operated by qualified service
personnel and installed into an apparatus cabinet or similar, where
access is restricted to service personnel only.
During installation, ensure a protective earthing conductor is
first connected to the protective earthing terminal (only valid for
metallic housings). Westermo recommends a crosssectional area
of at least 4 mm2.
If the product does not have a protective earthing terminal,
then the DIN-rail must be connected to protective earth. Upon
removal of the product, ensure that the protective earthing
conductor, or the connection to earth via the DIN-rail, is
disconnected last.
WARNING - HAZARDOUS VOLTAGE
Do not open an energized product. Hazardous voltage may occur
when connected to a power supply.
WARNING - PROTECTIVE FUSE
The power supply wiring must be sufficiently fused. It must be
possible to disconnect manually from the power supply. Ensure
compliance to national installation regulations.
Replacing the internal fuse must only be performed by Westermo
qualified personell.

66645-2204
WARNING - REDUCE THE RISK OF FIRE
To reduce the risk of fire, use only telecommunication line cords
with a cable diameter of AWG 26 or larger. Regarding power
cable dimensions, see Interface Specifications.
CAUTION - CORROSIVE GASES
If the product is placed in a corrosive environment, it is important
that all unused connector sockets are protected with a suitable
plug, in order to avoid corrosion attacks on the gold plated
connector pins.
CAUTION - CLASS 1 LASER PRODUCT
Do not look directly info a fibre optical port or any connected
fibre, although the product is designed to meed the Class 1 Laser
regulations and complies with 21 CFR 1040.10 and 1040.11.
CAUTION - ELECTROSTATIC DISCHARGE (ESD)
Prevent electrostatic discharge damages to internal electronic
parts by discharging your body to a grounding point (e.g. use a
wrist strap).
CAUTION - FIBRE OPTIC HANDLING
Fibre optic equipment need special treatment. It is very sensitive
to dust and dirt. If the fibre is disconnected from the product, the
protective plugs on the transmitter/receiver must be connected.
The protective plugs must be kept on during transportation. The
fibre optics cables must be handled the same way.

7
6645-2204
Care recommendations
Follow the care recommendations below to maintain full operation of product and to
fulfil the warranty obligations:
• Do not drop, knock or shake the product. Rough handling above the specification may
cause damage to internal circuit boards.
• Use a dry or slightly water-damp cloth to clean the product. Do not use harsh
chemicals, cleaning solvents or strong detergents.
• Do not paint the product. Paint can clog the product and prevent proper operation.
If the product is used in a manner not according to specification, the protection provided
by the equipment may be impaired.
If the product is not working properly, contact the place of purchase, nearest Westermo
distributor office or Westermo technical support.
Cleaning of the optical connectors
In the event of contamination, the optical connectors should be cleaned by the use of
forced nitrogen and some kind of cleaning stick.
Recommended cleaning fluids:
• Methyl-, ethyl-, isopropyl- or isobutyl-alcohol
• Hexane
• Naphtha
Maintenance
No maintenance is required, as long as the product is used as intended within the
specified conditions.
Product disposal
This symbol means that the product shall not be treated
as unsorted municipal waste when disposing of it. It needs
to be handed over to an applicable collection point for
recycling electrical and electronic equipment.
By ensuring the product is disposed of correctly, you will
help to reduce hazardous substances and prevent potential
negative consequences to both environment and human
health, which could be caused by inappropriate disposal.

86645-2204
Agency approvals and standards compliance
Type Approval / Compliance
EMC EN 61000-6-2, Immproducty industrial environments
EN 61000-6-4, Emission industrial environments
Marine DNV GL rules for classification – Ships and offshore products¹
Note ¹ Applicable only for 3645-0030, 3645-0040 , 3645-0050
Article number, model and description
Article Model Description
3645-0001 MCW-211-MM-SC2 10/100Base-T/TX: 1 port 100Base-FX: 1 port
3645-0010 MCW-211-MM-ST2 10/100Base-T/TX: 1 port 100Base-FX: 1 port
3645-0020 MCW-211-SM-SC15 10/100Base-T/TX: 1 port 100Base-FX: 1 port
3645-0030 MCW-211-SM-LC15 10/100Base-T/TX: 1 port 100Base-FX: 1 port
3645-0040 MCW-211-SM-LC40 10/100Base-T/TX: 1 port 100Base-FX: 1 port
3645-0050 MCW-211-MM-LC2 10/100Base-T/TX: 1 port 100Base-FX: 1 port
Corrosive
environment:
This product has been successfully tested in a corrosion test according to
IEC 60068-2-60, method 4. This means that the product meets the requirements
to be placed in an environment classified as ISA-S71.04 class G3.
Simplified EU declaration of conformity
Hereby, Westermo declares that the equipment is in compliance with applicable EU
directives. The full EU declaration of conformity and other detailed information are
available at the respective product page at www.westermo.com/support/product-support.
CAUTION - CORROSIVE GASES
If the product is placed in a corrosive environment, it is important
that all unused connector sockets are protected with a suitable
plug, in order to avoid corrosion attacks on the gold plated
connector pins.

9
6645-2204
Type tests and environmental conditions
Electromagnetic Compatibility
Phenomena Test Description Level
ESD EN 61000-4-2 Enclosure contact ± 4 kV
Enclosure air ± 8 kV
RF field AM modulated IEC 61000-4-3 Enclosure 10 V/m 80% AM (1 kHz), 30 – 2700 MHz
Fast transient EN 61000-4-4 Signal ports ± 1 kV
Power ports ± 2 kV
Surge EN 61000-4-5 Signal ports balanced ± 2 kV line to earth, ± 1 kV line to line
Power ports ± 2 kV line to earth, ± 2 kV line to line
RF conducted EN 61000-4-6 Signal ports 10 V 80% AM (1 kHz), 0.15 – 80 MHz
Power ports 10 V 80% AM (1 kHz), 0.15 – 80 MHz
Voltage dips
and interruption
EN 61000-4-29 DC power ports 10 ms, interruption
10 ms, 30% reduction
10 ms, 60% reduction
+20% above & –20% below rated voltage
Radiated emission CISPR 16-2-3
ANSI C63.4
(FCC part 15)
Enclosure Class A
Conducted emission CISPR 16-2-1 DC power ports Class A
Dielectric strength UL 60950-1 Signal port to other
isolated ports
1.5 kVrms 50 Hz 1 min
Power port to other
isolated ports
2 kVrms 50 Hz 1 min
Environmental
Temperature EN 60068-2-1
EN 60068-2-2
Operating –25 to +70ºC
Maximum surface
temperature
135°C (temperature class T4)
Storage & Transport –40 to +70ºC
Humidity EN 60068-2-30 Operating 5 to 95% relative humidity
Storage & Transport 5 to 95% relative humidity
Altitude Operating 2 000 m / 70 kPa
Service life Operating 10 year
Vibration IEC 60068-2-6 Operating 7.5 mm, 5 – 8 Hz
2 g, 8 – 500 Hz
Shock IEC 60068-2-27 Operating 15 g, 11 ms
Packaging
Enclosure, MCW-211 UL 94 PC / ABS Flammability class V-1
Enclosure, MCW-211 Ex Cabelec 6141
Dimension W x H x D 35 x 121 x 119 mm
Weight 0.25 kg
Degree of protection IEC 529 Enclosure IP 21
Cooling Convection
Mounting Horizontal on 35 mm DIN-rail

10 6645-2204
Interface specifications
Power
Rated voltage 12 to 48 VDC
Operating voltage 10 to 60 VDC
Rated current 200 mA @ 12 VDC
100 mA @ 24 VDC
50 mA @ 48 VDC
Rated frequency DC
Inrush current I2t 0.03 A²s @ 12 VDC
Startup current* 0.75 A peak
Polarity Reverse polarity protected
Redundant power input Ye s
Isolation to Ethernet TX
Ethernet FX
Connection Detachable screw terminal
Connector size 0.2 – 2.5 mm² (AWG 24 – 12)
Shielded cable Not required
* Direction relative this product
Ethernet TX
Electrical specification IEEE std 802.3. 2000 Edition
Data rate 10 Mbit/s or 100 Mbit/s, manual or auto
Duplex Full or half, manual or auto
Transmission range 100 m
Isolation to Power
Connection RJ-45
Ethernet FX
Optical specification IEEE std 802.3. 2000 Edition
Data rate 100 Mbit/s
Duplex Full or half
Connection SC, ST or LC

11
6645-2204
Location of interface ports and LEDs
LED Indicators
Ethernet TX – RJ-45
Position Direction* Description
1 In/Out TD+
2 In/Out TD–
3 In/Out RD
4 – –
5 – –
6 In/Out RD–
7 – –
8 – –
* Direction relative this product
Ethernet FX – SC, ST or LC
Position Direction* Description Product
marking
Rx In Receive port Rx
Tx Out Transmit
port
Tx
* Direction relative this product
Power
Position Direction* Description Product
marking
1– Common COM
2 In + Voltage A +VA
3 In + Voltage B +VB
* Direction relative this product
DIP switches are accessible under the lid

12 6645-2204
Fibre optic power budget
Model MCW-211-MM
xx2
MCW-211-SM
SC15
MCW-211-SM
LC15
MCW-211-SM
LC40
Transmitted
wavelength
1310 nm 1310 nm 1310 nm 1310 nm
Min. output
power,
transmitter
–19 dBm –15 dBm –15 dBm –5 dBm
Max. output
power,
transmitter
–12 dBm –8 dBm –8 dBm 0 dBm
Input sensitivity,
receiver
–31 dBm –34 dBm –31 dBm –34 dBm
Min. power
budget
12 dBm 19 dBm 16 dBm 29 dBm
Max. power
budget
19 dBm 26 dBm 23 dBm 34 dBm
Recommended
fibre cable and
core / cladding
diameter
Multimode
50/125, 62.5/125
Singlemode
9/125, 10/125
Singlemode
9/125, 10/125
Singlemode
9/125, 10/125
Fibre type Normal attenuation
@ 1310 nm multimode
Normal attenuation
@ 1310 nm singlemode
50/125 3.0 dBm/km –
62,5/125 3.5 dBm/km –
9/125 – 0.5 dBm/km
10/125 – 0.5 dBm/km
Attenuation in connectors / splices
Type Normal attenuation
Connector 0.2 – 0.4 dBm
Fusion splice 0.1 dBm
Mechanical splice 0.2 dBm

13
6645-2204
LED indicators
LED indicators are available on the front panel and on the RJ-45 TX connector.
LED Status Description
PWR ON Internal power, initialising OK
Slow flash Initialisation progressing
Fast flash Initialisation error
LINK TX OFF No Ethernet link TX
ON Good Ethernet link TX
Flash Ethernet data is transmitted or
received on TX interface
LINK FX OFF No Ethernet link FX
ON Good Ethernet link FX
Flash Ethernet data is transmitted or
received on FX interface
FX DPX OFF Half dupex FX interface
ON Full duplex FX interface
LFF OFF Link fault forward is not active
ON Link fault forward is active and
has shutdown an interface
LED Status Description TX
SPD DPX
SPD OFF 10 Mbit/s TX interface
ON 100 Mbit/s TX interface
DPX OFF Half duplex TX interface
ON Full duplex TX interface

14 6645-2204
Installation
Mounting / Removal
Mounting
This product should be mounted on 35 mm
DIN-rail which is horizontally mounted on a
wall or cabinet backplate. Snap on mounting,
see figure
Cooling
This product uses convection cooling. To avoid obstructing the
airflow around the product, use the following spacing rules.
Recommended spacing 25 mm (1.0 inch) above/below and 10 mm
(0.4 inches) left/right the product.
10 mm *
(0.4 inches)
25 mm
25 mm
* Spacing (left/right) recommended for full operating
temperature range
CLICK!
CAUTION - ELECTROSTATIC DISCHARGE (ESD)
Prevent electrostatic discharge damages to internal electronic
parts by discharging your body to a grounding point (e.g. use a
wrist strap).
WARNING - HAZARDOUS VOLTAGE
Do not open an energized product. Hazardous voltage may occur
when connected to a power supply.
Removal Press down the black support at the back of the product,
see figure.
CLICK!

15
6645-2204
Configuration
DIP switches are accessible under the lid on top of the product. DIP switches are used
to configure the product.
DIP-switch settings
NOTE! DIP-switch alterations are only effective after a power on.
Observe this when the DIP-switches will be configured
… Speed and duplex setting only valid when auto-negotiation is disabled.
… If auto-negotiation and auto MDI/MDI-X disabled the TX ports supports MDI-X
configuration.
CAUTION - ELECTROSTATIC DISCHARGE (ESD)
Prevent electrostatic discharge damages to internal electronic
parts by discharging your body to a grounding point (e.g. use a
wrist strap).
WARNING - HAZARDOUS VOLTAGE
Do not open an energized product. Hazardous voltage may occur
when connected to a power supply.

16 6645-2204
TX Port settings
ON
1 2 3 4 5 6 7 8
ON
1 2 3 4 5 6 7 8
ON
1 2 3 4 5 6 7 8
ON
1 2 3 4 5 6 7 8
ON
1 2 3 4 5 6 7 8
ON
1 2 3 4 5 6 7 8
Auto-negotiation and
auto MDI / MDI-X
enabled TX port
S1
10 Mbit/s speed
selected TX port
S1
100 Mbit/s speed
selected TX port
S1
Half duplex
selected TX port
S1
Full duplex
selected TX port
S1
Flow control setting
ON
1 2 3 4 5 6 7 8
Flow control
disabled
S1
ON
1 2 3 4 5 6 7 8
Flow control
enabled
S1
Link fault forward settings
ON
1 2 3 4 5 6 7 8
TX →FX Link
fault forward disabled
S1
ON
1 2 3 4 5 6 7 8
TX →FX Link
fault forward enabled
S1
ON
1 2 3 4 5 6 7 8
FX →TX Link
fault forward disabled
S1
ON
1 2 3 4 5 6 7 8
FX →TX Link
fault forward enabled
S1
FX Port settings
ON
1 2 3 4 5 6 7 8
Half duplex
selected FX port
S1
Factory settings
ON
1 2 3 4 5 6 7 8
S1
ON
1 2 3 4 5 6 7 8
Full duplex
selected FX port
S1
S1
Auto-negotiation and
auto MDI / MDI-X
disabled TX port
S1

REV. F 6645-2204 2021-01 Westermo Network Technologies AB, Sweden
Westermo • SE-635 35 Stora Sundby, Sweden
Tel [phone] Fax [phone]
E-mail: [e-mail]
www.westermo.com
