Western Digital Ultrastar Serv60+8 Quick guide

Recommended Rack
Configurations
Ultrastar®Serv60+8
Regulatory Model: H4060-S
February 2019
Rev. 1.0
1ET1640
Long Live Data ™| www.hgst.com

Contents
Revision History..............................................................................................3
Points of Contact.............................................................................................4
Copyright........................................................................................................5
Chapter 1 Overview....................................................................................6
1.1 Ultrastar Serv60+8 Rack Requirements............................................6
1.2 Rack Safety........................................................................................7
1.3 CMA Standard Recommended Racks...............................................8
1.4 CMA Lite Recommended Racks........................................................9
1.5 Vertical Rack Rail Settings...............................................................11
1.6 Recommended PDUs and Available Installation Space...................12
Chapter 2 CMA Standard Rack Specifications......................................14
2.1 CRENLO/EMCOR............................................................................14
2.2 AFCO/Legrand.................................................................................14
2.3 TRIPP LITE......................................................................................15
2.4 APC/Schneider.................................................................................16
Chapter 3 CMA Lite Rack Specifications...............................................18
3.1 CRENLO/EMCOR............................................................................18
3.2 AFCO/Legrand.................................................................................18
3.3 TRIPP LITE......................................................................................19
3.4 APC/Schneider.................................................................................20
Chapter 4 Installation...............................................................................22
4.1 PDU Mounting Bracket Installation (KIT-MBVPT-1B).......................22
4.2 PDU Mounting Bracket Installation (KIT-MB-40)..............................29
ii
Contents
Recommended Rack Configurations

Revision History
CommentRevisionDate
Initial ReleaseRevision 1.0January 2019
3
Revision History
Recommended Rack Configurations

Points of Contact
For further assistance with an HGST product, contact Platform Engineering technical support. Please be
prepared to provide the following information: Serial Number (S/N), product name, model number, and a brief
description of the issue.
Email:
[email protected]
Website:
https://portal.wdc.com/Support/s/
4
Points of Contact
Recommended Rack Configurations

Copyright
The following paragraph does not apply to the United Kingdom or any country where such provisions
are inconsistent with local law: HGST a Western Digital company PROVIDES THIS PUBLICATION "AS
IS" WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT
LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR
PURPOSE. Some states do not allow disclaimer or express or implied warranties in certain transactions,
therefore, this statement may not apply to you.
This publication could include technical inaccuracies or typographical errors. Changes are periodically made
to the information herein; these changes will be incorporated in new editions of the publication. HGST may
make improvements or changes in any products or programs described in this publication at any time.
It is possible that this publication may contain reference to, or information about, HGST products (machines
andprograms),programming,orservices that are not announced in yourcountry. Such referencesorinformation
must not be construed to mean that HGST intends to announce such HGST products, programming, or
services in your country.
Technical information about this product is available by contacting your local HGST representative or on the
Internet at: [email protected]
HGST may have patents or pending patent applications covering subject matter in this document. The furnishing
of this document does not give you any license to these patents.
Copyright ©2017-2019 Western Digital Corporation or its affiliates.
Western Digital
5601 Great Oaks Parkway
San Jose, CA 95119
Long Live Data™is a trademark of HGST, Inc. and its affiliates in the United States and/or other countries.
HGST trademarks are authorized for use in countries and jurisdictions in which HGST has the right to use,
market and advertise the brands.
Other product names are trademarks or registered trademarks of their respective owners.
One MB is equal to one million bytes, one GB is equal to one billion bytes, one TB equals 1,000GB (one trillion
bytes) and one PB equals 1,000TB when referring to storage capacity. Usable capacity will vary from the raw
capacity due to object storage methodologies and other factors.
References in this publication to HGST products, programs or services do not imply that HGST intends to
make these available in all countries in which HGST operates.
Product information is provided for information purposes only and does not constitute a warranty.
Information is true as of the date of publication and is subject to change. Actual results may vary. This publication
is for general guidance only. Photographs may show design models.
5
Copyright
Recommended Rack Configurations

Chapter
1
1 Overview
This section provides an overview of rack requirements and recommendations.
1.1 Ultrastar Serv60+8 Rack Requirements
The Ultrastar Serv60+8 is designed to be installed into a rack that meets the EIA-310 standard at a minimum
1200 mm (47.24in.) of usable rack space, frame to frame. The vertical rack rails must be set between 32 in.
- 36 in. to support the enclosure. It requires 4U of rack space, and it should be installed into the rack at the
lowest possible U height to keep the load on the rack balanced.
Table 1: Required Rack Specifications
RequirementParameter
1200 mm (47.24in.) of usable rack space, frame to
frame
Rack Depth
450mm with (17.72in.) with 465mm (18.31in.) ±
1.5mm nominal hole spacing. See EIA-310 Rack
Standard
Rack Width
4URack Units (U)
32 in. - 36 in.Vertical Rack Rail Spacing
1360.7 kg. / 3000 lbs.Static Load Rating
1020.5 kg. / 2250 lbs.Dynamic Load Rating
Warning: When extended out of the rack on the rail system, the Ultrastar Serv60+8 will
be ~950 mm / 37.4in. extended outward. This may be a potential tipping hazard depending on the
configuration of the rack. Ensure that leveling feet, anti-tilt, and any other safety features recommended
by the specific rack manufacturers have been deployed before servicing.
The following section provides specific information necessary to install, service, and remove the Ultrastar
Serv60+8. The installation of the Ultrastar Serv60+8 requires two people and a space of 1371mm / 54in. in
front of the installation space. The servicing of the enclosure requires one person and a minimum of 1219.2mm
/ 48in. of space in front of the installation space. The removal of the enclosure requires two people, 1371mm
/ 54in. of space in front of the installation space, and 24in. on either side of the enclosure for two people to
remove the enclosure.
Warning: The handles on the front of the chassis are not intended to be used to support the weight of
the Ultrastar Serv60+8. Lifting the unit by the chassis handles or trying to support the unit on the handles
can cause them to fail. This can cause serious damage to the unit or serious bodily harm to those
6
1 Overview
Recommended Rack Configurations 1.1 Ultrastar Serv60+8 Rack Requirements

handling the unit. Always team lift the chassis by gripping the underside of the unit, and never try to lift
a chassis that is filled with drives.
Figure 1: Installation, Servicing, and Removal
Attention: Do not install or remove the enclosure while it is populated with drives. The fully populated
enclosure exceeds the amount of weight that a team of two should lift.
1.2 Rack Safety
If the chassis is being installed into a rack that will be shipped fully assembled, you must install eight (four
per side) of the included M5 x 10mm T15 Torx screws into the two brackets at the front of the chassis in the
7
1 Overview
Recommended Rack Configurations 1.2 Rack Safety

following locations. These screws should be tightened to 3.38-3.61 Nm / 30-32 in-lbf using a Long T15 Torx
Screwdriver.
Figure 2: Shipping Bracket Screw Locations
ScrewLocation
1.3 CMA Standard Recommended Racks
The following is a list of racks that are recommended for the Ultrastar Serv60+8 using CMA Standard.
Table 2: Recommended Racks
NotesDimensionsRack
Units
Part NumberVendor
N/AH: 2060mm x W: 600mm x D: 1200mm/
H: 81.1in. x W: 23.6in. x D: 47.2in.
42AS-160099-03EMCOR/CRENLO
N/AH: 2057mm x W: 600mm x D: 1270mm/
H: 80.98in. x W: 23.6in. x D: 50in.
42DC-42U2448-G
N/AH: 2989.2mm x W: 609.6mm x D:
1317.6mm/
H: 98in. x W: 24in. x D: 51.9in.
52WEDIT602AFCO/Legrand
8
1 Overview
Recommended Rack Configurations 1.3 CMA Standard Recommended Racks

NotesDimensionsRack
Units
Part NumberVendor
N/AH: 2311.4mm x W: 609.6mm x D:
1317.6mm/
H: 91in. x W: 24in. x D: 51.9in.
48WEDIT603
N/AH: 2178.1mm x W: 609.6mm x D:
1317.6mm/
H: 85.75in. x W: 24in. x D: 51.8in.
45WEDIT604
N/AH:2044.7mm x W: 609.6mm x D:
1317.6mm/
H: 80.5in. x W: 24in. x D: 51.8in.
42WEDIT605
N/AH: 2444.8mm x W: 609.6mm x D:
1317.6mm/
H: 96.25in. x W: 24in. x D: 51.8in.
51WEDIT606
The rear door must
be removed when
H: 1991mm x W: 600mm x D: 1222mm
H: 78.4in. x W: 23.6in. x D: 48.18in.
42AR3300WAPC/Schneider
using the standard
CMA with this rack.
N/AH: 2444.8mm x W: 609.6mm x D:
1200mm or 1403.2mm w/ Rack Extender/
H: in. x W: in. x D: in. w/ Rack Extender
42Rack:SR42UBDP
Extender:
SREXTENDER
TRIPP LITE w/
Rack Extender
1.4 CMA Lite Recommended Racks
The following is a list of racks that are recommended for the Ultrastar Serv60+8 using CMA Lite.
Table 3: Recommended Racks
NotesDimensionsRack
Units
Part NumberVendor
N/AH: 2060mm x W: 600mm x D: 1200mm/
H: 81.1in. x W: 23.6in. x D: 47.2in.
42AS-160099-03EMCOR/CRENLO
N/AH: 2057mm x W: 600mm x D: 1270mm/
H: 80.98in. x W: 23.6in. x D: 50in.
42DC-42U2448-G
The enclosure
cannot be installed
H: 2989.2mm x W: 609.6mm x D:
1317.6mm/
H: 98in. x W: 24in. x D: 51.9in.
52WEDIT602AFCO/Legrand
into the U spaces
that are in line with
the front door
stiffeners or the
door latch in the
CMA Lite
conguration.
9
1 Overview
Recommended Rack Configurations 1.4 CMA Lite Recommended Racks

NotesDimensionsRack
Units
Part NumberVendor
The enclosure
cannot be installed
H: 2311.4mm x W: 609.6mm x D:
1317.6mm/
H: 91in. x W: 24in. x D: 51.9in.
48WEDIT603
into the U spaces
that are in line with
the front door
stiffeners or the
door latch in the
CMA Lite
conguration.
The enclosure
cannot be installed
H: 2178.1mm x W: 609.6mm x D:
1317.6mm/
H: 85.75in. x W: 24in. x D: 51.8in.
45WEDIT604
into the U spaces
that are in line with
the front door
stiffeners or the
door latch in the
CMA Lite
conguration.
The enclosure
cannot be installed
H:2044.7mm x W: 609.6mm x D:
1317.6mm/
H: 80.5in. x W: 24in. x D: 51.8in.
42WEDIT605
into the U spaces
that are in line with
the front door
stiffeners or the
door latch in the
CMA Lite
conguration.
The enclosure
cannot be installed
H: 2444.8mm x W: 609.6mm x D:
1317.6mm/
H: 96.25in. x W: 24in. x D: 51.8in.
51WEDIT606
into the U spaces
that are in line with
the front door
stiffeners or the
door latch in the
CMA Lite
conguration.
N/AH: 1991mm x W: 600mm x D: 1222mm
H: 78.4in. x W: 23.6in. x D: 48.18in.
42AR3300WAPC
N/AH: 2444.8mm x W: 609.6mm x D:
1200mm or 1403.2mm w/ Rack Extender/
H: in. x W: in. x D: in. w/ Rack Extender
42Rack:SR42UBDP
Extender:
SREXTENDER
Tripplite w/ Rack
Extender
10
1 Overview
Recommended Rack Configurations 1.4 CMA Lite Recommended Racks

1.5 Vertical Rack Rail Settings
The vertical rack rails should be adjusted to the specified measurements in all of the recommended rack
configurations to ensure the enclosure and cable management fit properly. After the front and rear vertical
rack rails have been adjusted the enclosure rails can be extended or retracted to best fit these adjustments.
Refer to the specific rack manufacturer documentation for instructions on how to adjust the vertical rack rails
on the chosen rack.
Both front vertical rack rails should be adjusted to a depth of 41mm / 1.61in. from the front of the rack frame
as shown in the image below.
Figure 3: Front Vertical Rack Rails
Both rear vertical rack rails should be adjusted to a depth of 812mm - 914.4mm / 32in. -36 in. from the front
vertical rack rails as shown in the image below.
Figure 4: Rear Vertical Rack Rails
11
1 Overview
Recommended Rack Configurations 1.5 Vertical Rack Rail Settings

1.6 Recommended PDUs and Available Installation Space
The following is a list of available PDU space that is recommended for use in each rack.
Table 4: Available PDU Space
Space AvailablePDU OrientationModelRack
W: 56mm x D: 190mm/
W: 2.2in. x D: 7.5in.
Rear FacingAS-160099-03EMCOR/CRENLO
DC-42U2448-G
W: 67mm x D: 200mm/
W: 2.6in. x D: 7.9in.
Rear or Inward FacingWEDIT602AFCO/Legrand
WEDIT603
WEDIT604
WEDIT605
WEDIT606
W: 60mm x D: 113mm/
W: 2.4in. x D: 4.4in.
Rear FacingAR3300APC/Schneider
W: 60mm x D: 120mm/
W: 2.4in. x D: 4.7in.
Rear or Inward FacingRack:SR42UBDP
Extender: SREXTENDER
TRIPP LITE w/ Rack
Extender
12
1 Overview
Recommended Rack Configurations 1.6 Recommended PDUs and Available Installation Space

The following image displays the available zero space for mounting the PDU into the rack. This can be used
to size the PDU and related installation hardware outside of the hardware that is specified within this document.
Figure 5: PDU in the Zero Space
13
1 Overview
Recommended Rack Configurations 1.6 Recommended PDUs and Available Installation Space

Chapter
2
2 CMA Standard Rack Specifications
This section provides information related to the recommended rack models, compatible PDUs, and required
accessories and hardware using CMA Standard. Each rack recommendation comes with information specific
to what PDUs are approved and what hardware is required to mount them.
2.1 CRENLO/EMCOR
Table 5: Recommended CRENLO/EMCOR Rack Models
DimensionsRack UnitsModel Number
H: 2060mm x W: 600mm x D: 1200mm /
H: 81.1in. x W: 23.6in. x D: 47.2in.
42UAS-160099-03
H: 2057mm x W: 600mm x D: 1270mm /
H: 80.9in. x W: 23.6in. x D: 50in.
42UDC-42U2448-G
Table 6: Compatible PDUs
OrientationDepthWidthModel NumberPDU
Rear86.15mm / 3.39in.55.5mm / 2.18in.STV-4501Server Technology
Rear86.15mm / 3.39in.55.5mm / 2.18in.STV-4502
Rear86.15mm / 3.39in.55.5mm / 2.18in.STV-4503
Table 7: Required Accessories and Hardware
DescriptionQTYPart NumberSupplier
PDU Mounting Bracket1KIT-MBVPT-1BServer Technology
N/A4M6 x 16 Hex Cap ScrewsGeneric/Various
N/A8M6 Fender Washers
N/A4M6 Hex Nut with Nylon Lock
2.2 AFCO/Legrand
Table 8: Recommended AFCO/Legrand Rack Models
DimensionsRack UnitsModel Number
H: 2989.2mm x W: 609.6mm x D: 1317.6mm/
H: 98in. x W: 24in. x D: 51.9in.
52WEDIT602
H: 2311.4mm x W: 609.6mm x D: 1317.6mm /
H: 91in. x W: 24in. x D: 51.8in.
48WEDIT603
14
2 CMA Standard Rack Specifications
Recommended Rack Configurations 2.1 CRENLO/EMCOR

DimensionsRack UnitsModel Number
H: 2178.1mm x W: 609.6mm x D: 1317.6mm /
H: 85.75in. x W: 24in. x D: 51.8in.
45WEDIT604
H:2044.7mm x W: 609.6mm x D: 1317.6mm /
H: 80.5in. x W: 24in. x D: 51.8in.
42WEDIT605
H: 2444.8mm x W: 609.6mm x D: 1317.6mm /
H: 96.25in. x W: 24in. x D: 51.8in.
51WEDIT606
Table 9: Compatible PDUs
OrientationDepthWidthModel NumberPDU
Rear86.15mm / 3.39in.55.5mm / 2.18in.STV-4501Server Technology
Rear86.15mm / 3.39in.55.5mm / 2.18in.STV-4502
Rear86.15mm / 3.39in.55.5mm / 2.18in.STV-4503
Table 10: Required Accessories and Hardware
DescriptionQTYPart NumberSupplier
PDU Mounting Bracket1KIT-MB40Server Technology
2.3 TRIPP LITE
Table 11: Recommended TRIPP LITE Rack Models
DimensionsRack UnitsModel Number
H: 1111.25mm x W: 601.98mm x D: 1200mm /
H: 43.75in. x W: 23.7in. x D: 47.2in.
42USR42UBDP
Table 12: Recommended TRIPP LITE Rack Extender Models
DimensionsRack UnitsModel Number
Shipping Dimensions:
H: 236.22mm x W: 1206.5mm x D: 203.2mm /
42USREXTENDER
H: 9.3in. x W: 47.5in. x D: 8 in.
Assembled Dimensions:
H: 1866.9mm x W: 601.98mm x D: 200.66mm /
H: 73.5in. x W: 47.5in. x D: 7.9in.
Shipping Dimensions:
H: 236.22mm x W: 1206.5mm x D: 203.2mm /
48USREXTENDER
H: 9.3in. x W: 47.5in. x D: 8 in.
Assembled Dimensions:
15
2 CMA Standard Rack Specifications
Recommended Rack Configurations 2.3 TRIPP LITE

DimensionsRack UnitsModel Number
H: 2133.6mm x W: 601.98mm x D: 200.66mm /
H: 84in. x W: 47.5in. x D: 7.9in.
Note: Installation instructions for the Tripp Lite SREXTENDER, may be acquired from the manufacturers
website.
Table 13: Compatible PDUs
OrientationDepthWidthModel NumberPDU
Rear86.15mm / 3.39in.55.5mm / 2.18in.STV-4501Server Technology
Rear86.15mm / 3.39in.55.5mm / 2.18in.STV-4502
Rear86.15mm / 3.39in.55.5mm / 2.18in.STV-4503
Table 14: Required Accessories and Hardware
DescriptionQTYPart NumberSupplier
PDU Mounting Bracket1KIT-MB40Server Technology
Rack Extension1SREXTENDERTripp Lite
2.4 APC/Schneider
Table 15: Recommended APC/Schneider Rack Models
DimensionsRack UnitsModel Number
H: 1991mm x W: 600mm x D: 1222mm
H: 78.4in. x W: 23.6in. x D: 48.18in.
42AR3300
Table 16: Compatible PDUs
OrientationDepthWidthModel NumberPDU
Rear86.15mm / 3.39in.55.5mm / 2.18in.STV-4501Server Technology
Rear86.15mm / 3.39in.55.5mm / 2.18in.STV-4502
Rear86.15mm / 3.39in.55.5mm / 2.18in.STV-4503
Table 17: Required Accessories and Hardware
DescriptionQTYPart NumberSupplier
PDU Mounting Bracket1KIT-MBVPT-1BServer Technology
N/A4M6 x 16 Hex Cap ScrewsGeneric/Various
N/A8M6 Fender Washers
16
2 CMA Standard Rack Specifications
Recommended Rack Configurations 2.4 APC/Schneider

DescriptionQTYPart NumberSupplier
N/A4M6 Hex Nut with Nylon Lock
17
2 CMA Standard Rack Specifications
Recommended Rack Configurations 2.4 APC/Schneider

Chapter
3
3 CMA Lite Rack Specifications
This section provides information related to the recommended rack models, compatible PDUs, and required
accessories and hardware using CMA Lite. Each rack recommendation comes with information specific to
what PDUs are approved and what hardware is required to mount them.
3.1 CRENLO/EMCOR
Table 18: Recommended CRENLO/EMCOR Rack Models
DimensionsRack UnitsModel Number
H: 2060mm x W: 600mm x D: 1200mm /
H: 81.1in. x W: 23.6in. x D: 47.2in.
42UAS-160099-03
H: 2057mm x W: 600mm x D: 1270mm /
H: 80.9in. x W: 23.6in. x D: 50in.
42UDC-42U2448-G
Table 19: Compatible PDUs
OrientationDepthWidthModel NumberPDU
Rear86.15mm / 3.39in.55.5mm / 2.18in.STV-4501Server Technology
Rear86.15mm / 3.39in.55.5mm / 2.18in.STV-4502
Rear86.15mm / 3.39in.55.5mm / 2.18in.STV-4503
Table 20: Required Accessories and Hardware
DescriptionQTYPart NumberSupplier
PDU Mounting Bracket1KIT-MBVPT-1BServer Technology
N/A4M6 x 16 Hex Cap ScrewsGeneric/Various
N/A8M6 Fender Washers
N/A4M6 Hex Nut with Nylon Lock
3.2 AFCO/Legrand
Table 21: Recommended AFCO/Legrand Rack Models
DimensionsRack UnitsModel Number
H: 2989.2mm x W: 609.6mm x D: 1317.6mm/
H: 98in. x W: 24in. x D: 51.9in.
52WEDIT602
H: 2311.4mm x W: 609.6mm x D: 1317.6mm /
H: 91in. x W: 24in. x D: 51.8in.
48WEDIT603
18
3 CMA Lite Rack Specifications
Recommended Rack Configurations 3.1 CRENLO/EMCOR

DimensionsRack UnitsModel Number
H: 2178.1mm x W: 609.6mm x D: 1317.6mm /
H: 85.75in. x W: 24in. x D: 51.8in.
45WEDIT604
H:2044.7mm x W: 609.6mm x D: 1317.6mm /
H: 80.5in. x W: 24in. x D: 51.8in.
42WEDIT605
H: 2444.8mm x W: 609.6mm x D: 1317.6mm /
H: 96.25in. x W: 24in. x D: 51.8in.
51WEDIT606
Table 22: Compatible PDUs
OrientationDepthWidthModel NumberPDU
Rear86.15mm / 3.39in.55.5mm / 2.18in.STV-4501Server Technology
Rear86.15mm / 3.39in.55.5mm / 2.18in.STV-4502
Rear86.15mm / 3.39in.55.5mm / 2.18in.STV-4503
Table 23: Required Accessories and Hardware
DescriptionQTYPart NumberSupplier
PDU Mounting Bracket1KIT-MB40Server Technology
3.3 TRIPP LITE
Table 24: Recommended TRIPP LITE Rack Models
DimensionsRack UnitsModel Number
H: 1111.25mm x W: 601.98mm x D: 1200mm /
H: 43.75in. x W: 23.7in. x D: 47.2in.
42USR42UBDP
Table 25: Recommended TRIPP LITE Rack Extender Models
DimensionsRack UnitsModel Number
Shipping Dimensions:
H: 236.22mm x W: 1206.5mm x D: 203.2mm /
42USREXTENDER
H: 9.3in. x W: 47.5in. x D: 8 in.
Assembled Dimensions:
H: 1866.9mm x W: 601.98mm x D: 200.66mm /
H: 73.5in. x W: 47.5in. x D: 7.9in.
Shipping Dimensions:
H: 236.22mm x W: 1206.5mm x D: 203.2mm /
48USREXTENDER
H: 9.3in. x W: 47.5in. x D: 8 in.
Assembled Dimensions:
19
3 CMA Lite Rack Specifications
Recommended Rack Configurations 3.3 TRIPP LITE

DimensionsRack UnitsModel Number
H: 2133.6mm x W: 601.98mm x D: 200.66mm /
H: 84in. x W: 47.5in. x D: 7.9in.
Note: Installation instructions for the Tripp Lite SREXTENDER, may be acquired from the manufacturers
website.
Table 26: Compatible PDUs
OrientationDepthWidthModel NumberPDU
Rear86.15mm / 3.39in.55.5mm / 2.18in.STV-4501Server Technology
Rear86.15mm / 3.39in.55.5mm / 2.18in.STV-4502
Rear86.15mm / 3.39in.55.5mm / 2.18in.STV-4503
Table 27: Required Accessories and Hardware
DescriptionQTYPart NumberSupplier
PDU Mounting Bracket1KIT-MB40Server Technology
Rack Extension1SREXTENDERTripp Lite
3.4 APC/Schneider
Table 28: Recommended APC/Schneider Rack Models
DimensionsRack UnitsModel Number
H: 1991mm x W: 600mm x D: 1222mm
H: 78.4in. x W: 23.6in. x D: 48.18in.
42AR3300
Table 29: Compatible PDUs
OrientationDepthWidthModel NumberPDU
Rear86.15mm / 3.39in.55.5mm / 2.18in.STV-4501Server Technology
Rear86.15mm / 3.39in.55.5mm / 2.18in.STV-4502
Rear86.15mm / 3.39in.55.5mm / 2.18in.STV-4503
Table 30: Required Accessories and Hardware
DescriptionQTYPart NumberSupplier
PDU Mounting Bracket1KIT-MBVPT-1BServer Technology
N/A4M6 x 16 Hex Cap ScrewsGeneric/Various
N/A8M6 Fender Washers
20
3 CMA Lite Rack Specifications
Recommended Rack Configurations 3.4 APC/Schneider
