Enterprise Hard Drives
Interface
Width/Height
Rotational Speed
Capacities
Model Numbers
As demand for storage continues to expand, the need for more efficient power
solutions becomes paramount. WD RE2-GP enterprise SATA hard drives make
it possible for large-scale data centers to increase storage capacity without
exceeding available power, and in many cases actually reducing power
consumption. WD RE2-GP drives help combat the four major challenges large
data installations face—total drive slots, maximum capacity, power allotment, and
financial constraints—while lowering the total cost of ownership.
Product Benefits
Reduced power consumption —The combination of WD’s IntelliSeek™, IntelliPark™, and
IntelliPower™technologies brings optimized performance at industry-leading low power
consumption; power is reduced as much as 40 percent.
Helps enable eco-friendly servers — Each WD RE2-GP drive consumes an average of
4-5 watts less than competitor drives making it possible for energy-conscious customers
to build servers with higher capacities, ensured reliability, and promote energy
conservation.
Lower total cost of ownership — Large data-hungry financial institutions and web
service providers can save up to $10 per drive per year in electricity costs (U.S). A large
data center with 10,000 drives could realize up to $100,000 in savings per year.
Product Features
IntelliPower —A fine-tuned balance of spin speed, transfer rate, and caching algorithms
designed to deliver both significant power savings and solid performance. Additionally,
GreenPower drives consume less current during start up allowing more drives to spin up
simultaneously resulting in faster system readiness.
IntelliSeek —Calculates optimum seek speeds to lower unnecessary power
consumption, noise, and vibration.
IntelliPark —Delivers lower power consumption by automatically unloading recording
heads during idle to reduce aerodynamic drag and disengages read/write electronics.
Active Power Management – WD GreenPower drives monitor work load and
automatically invoke idle mode whenever possible to further reduce unnecessary power
consumption. Drive recovery time from idle mode is less than one second, providing
seamless power management between the drive and the host controller.
StableTrac™—Secures the motor shaft at both ends to reduce system-induced vibration
and stabilize platters for accurate tracking, during read and write operations (750 GB and
1 TB models only).
RAID-specific time-limited error recovery (TLER) — Pioneered by WD, this feature
prevents drive fallout caused by the extended hard drive error-recovery processes common
to desktop drives.
Rotary Acceleration Feed Forward (RAFF™) optimizes operation and performance
when the drives are used in vibration-prone multi-drive systems such as rackmounted
servers.
1.2 million hours MTBF — The highest available reliability rating on a high-capacity drive.
SATA
IntelliPower
WD5000ABPS
WD7500AYPS
WD1000FYPS
Note: Not all products
may be available in all
regions of the world.
500 GB to 1 TB
3.5-inch/1-inch
WD RE2-GP
Power-Saving Hard Drives
Reduced Power Consumption
Environmentally Responsible
Lower Cost of Ownership

Enterprise Hard Drives
WD RE2-GP
Power Saving Hard Drives
Physical Specifications
500 GB (2-disk) 750 GB (3-disk) 1 TB (4-disk)
Model numbers WD5000ABPS WD7500AYPS WD1000FYPS
Formatted capacity
1500,107 MB 750,156 MB 1,000,204 MB
User sectors per drive 976,773,168 1,465,149,168 1,953,525,168
Interface SATA 3 Gb/s SATA 3 Gb/s SATA 3 Gb/s
Form factor 3.5-inch 3.5-inch 3.5-inch
Bytes per sector (STD) 512 512 512
Actuator latch/auto park Yes Yes Yes
SATA latching connector Yes Yes Yes
RoHS compliant2 Yes Yes Yes
For service and literature:
support.wdc.com
www.westerndigital.com
Western Digital, WD, and the WD logo are
registered trademarks; and IntelliSeek,
IntelliPower, IntelliPark, StableTrac, RAFF,
GreenPower, and FIT Lab are trademarks of
Western Digital Technologies, Inc. Other
marks may be mentioned herein that belong to
other companies. Product specifications
subject to change without notice.
© 2007 Western Digital Technologies, Inc.
All rights reserved.
Western Digital
20511 Lake Forest Drive
Lake Forest, California U.S.A. 92630
2879-701236-A01 Nov 2007
800.ASK.4WDC North America
949.672.7199 Spanish
+800.6008.6008 Asia Pacific
+31.20.4467651 EMEA
Power Requirements (3- and 4-disk)
Environmental Specifications7
Shock
Vibration
Acoustics (average)8
Limited Warranty9
Performance mode 12V (±10%) 5V (±5%) Power
Read/Write 340 mA 675 mA 7.4W
Idle 254 mA 195 mA 4W
Standby 6 mA 180 mA 0.97W
Sleep 6 mA 180 mA 0.97W
Operating (2 ms) 30G (read/write), 65G (read)
Non-operating (2 ms)
2-disk models 300G
3- and 4-disk models 250G
Half sine wave measured in 2 ms duration, measured without isolation.
Operating
- Random 0.004 g2/Hz (10 to 300 Hz)
- Linear 20-300 Hz, 0.75G (0 to peak)
Non-operating
- Random 0.05 g2/Hz (10 to 300 Hz)
- Linear 20-500 Hz, 4.0G (0 to peak)
Idle mode 24 dBA
Perfomance seek mode 29 dBA
Quiet seek mode 25 dBA
5 years
Performance Specifications
Data Transfer Rate
Read seek time 58.9 ms (average)
Physical Dimensions
Power Requirements (2-disk)
Buffer to host 3 Gb/s 3
Buffer to disk 84 MB/s sustained 4
Rotational speed IntelliPower
Buffer 16 MB
Drive ready time (2-disk) 11.0 sec (average)
Drive ready time
(3- and 4-disk)
17.0 sec (average)
Load/unload cycles6600,000 minimum
LBA support Yes
Error rate
(non-recoverable) <1 in 1015 bits read
Height 1.028 in (26.1 mm) max
Length 5.787 in (147.0 mm) max
Width 4.0 in (101.6 mm) ± .01 in.
Weight (2-disk) 1.39 lb (0.63 kg) ± 10%
Weight (3-disk) 1.52 lb (0.69 kg) ± 10%
Weight (4-disk) 1.61 lb (0.73 kg) ± 10%
Performance mode 12V (±10%) 5V (±5%) Power
Read/Write 220 mA 700 mA 6W
Idle 180 mA 220 mA 3.3W
Standby 6 mA 180 mA 0.97W
Sleep 6 mA 180 mA 0.97W
1One gigabyte (GB) = one billion bytes. One terabyte (TB) = one trillion bytes. Total accessible capacity varies depending on operating environment.
2WD hard drive products manufactured and sold worldwide after June 1, 2006, meet or exceed Restriction of Hazardous Substances (RoHS)
compliance requirements as mandated by the European Union for electrical and electronic products. The RoHS Directive 2002/95/EC of the
European Parliament, which is effective in the EU beginning July 1, 2006, aims to protect human health and the environment by restricting the use of
certain hazardous substances in new equipment, and consists of restrictions on lead, mercury, cadmium, and other substances.
3Effective maximum SATA 3 Gb/s transfer rate.
4Maximum drive capacity model.
5Read Seek Time=Move Time + Read Settle Time (excluding command overhead & latency).
6 Controlled unload at ambient condition.
7 No non-recoverable errors during operating tests or after non-operating tests.
8 Sound power level.
9The term of the limited warranty may vary by region. Visit support.wdc.com/warranty for details.
