Western WB-160D Operating instructions

WB-160D
Walk-Behind Drop Spreader
85201
Owner's Manual and Installation Instructions
Original Instructions
Western Products, PO Box 245038, Milwaukee, WI 53224-9538 • www.westernplows.com
November 1, 2017
Lit. No. 43575, Rev. 01
CAUTION
Read this document before operating or
servicing the spreader.
This document supersedes all editions with an earlier date.
This document is for WESTERN®WB-160D walk-behind drop spreaders with
serial numbers 0000 and higher.

Lit. No. 43575/43585/43595, Rev. 01 November 1, 2017

Lit. No. 43575/43585/43595, Rev. 01 3 November 1, 2017
TABLE OF CONTENTS
PREFACE..................................................................................................................................................................5
Owner's Information............................................................................................................................................5
SAFETY INFORMATION.......................................................................................................................................... 6
LOADING ..................................................................................................................................................................8
ASSEMBLY...............................................................................................................................................................9
OPERATION ........................................................................................................................................................... 10

Lit. No. 43575/43585/43595, Rev. 01 November 1, 2017

Lit. No. 43575, Rev. 01 5 November 1, 2017
PREFACE
This manual has been prepared to acquaint you with
the safety information, operation, and maintenance
of your new walk-behind spreader. Please read this
manual carefully and follow all recommendations. This
will help ensure profitable and trouble-free operation
of your spreader. Keep this manual accessible. It is a
handy reference in case minor service is required.
When service is necessary, bring your walk-behind
spreader to your distributor. They know your spreader
best and are interested in your complete satisfaction.
Register your spreader online at www.westernplows.com
OWNER'S INFORMATION
Owner's Name: _______________________________________________________________________
Date Purchased: ______________________________________________________________________
Outlet Name: ______________________________________________ Phone: ___________________
Outlet Address: _______________________________________________________________________
Spreader Type (Model):________________________________ Weight: ____________________ lb/kg
Spreader Serial Number:________________________________________________________________

Lit. No. 43575/43585/43595, Rev. 01 6 November 1, 2017
SAFETY
SAFETY DEFINITIONS
NOTE: Indicates a situation or action that can lead
to damage to your spreader and vehicle or other
property. Other useful information can also be
described.
CAUTION
Indicates a potentially hazardous situation
that, if not avoided, may result in minor or
moderate injury. It may also be used to alert
against unsafe practices.
WARNING
Indicates a potentially hazardous situation
that, if not avoided, could result in death or
serious personal injury.
LABELS
Please become familiar with the labels on the
spreader.
NOTE: If labels are missing or cannot be read, see
your sales outlet.
Open/Close Label
Serial Number Label
Code Definition
MM 2-Digit Month
YY 2-Digit Year
LL 2-Digit Location Code
#### 4-Digit Sequential Number
PPPPP 5-Digit Assembly PN

Lit. No. 43575/43585/43595, Rev. 01 7 November 1, 2017
SAFETY
SAFETY PRECAUTIONS
Improper installation and operation could cause
personal injury and/or equipment and property
damage. Read and understand labels and this
Owner's Manual before installing, operating, or making
adjustments.
NOTE: Lubricate grease fittings after each use.
Use a good quality multipurpose grease.
WARNING
• Always make sure personnel are clear of
areas of danger when using equipment.
• Before working with the spreader, secure all
loose-fitting clothing and unrestrained hair.
• Do not climb into or ride on spreader.
• Never attempt to lift a unit with material in it.
• Always inspect unit for defects and
replace any broken, missing, or worn parts
immediately.
• Always check areas to be spread to be sure
no hazardous conditions or substances are
in the area.
CAUTION
• Do not operate a spreader in need of
maintenance.
•Before operating the spreader, reassemble
any parts or hardware removed for cleaning
or adjusting.
•Before operating the spreader, remove
materials such ascleaning rags, brushes,
and hand tools from the spreader.
•Never use wet materials or materials with
foreign debris with this spreader. This unit is
designed tohandle dry, clean,free-flowing
material.
CAUTION
DO NOT leave unused material in
hopper. Material can freeze or solidify,
causing unit to not work properly.
Empty and clean after each use.
PERSONAL SAFETY
• Wear only snug-fitting clothing while working on
your spreader.
• Do not wear jewelry or a necktie, and secure long
hair.
• Wear safety goggles to protect your eyes from dirt
and dust.
NOISE
Airborne noise emission during use is below 70 dB(A)
for the spreader operator.
VIBRATION
Operating spreader vibration does not exceed 2.5 m/s2
to the hand-arm or 0.5 m/s2to the whole body.

Lit. No. 43575/43585/43595, Rev. 01 8 November 1, 2017
LOADING YOUR SPREADER
Material Weights
Material Density
(lb/ft3)
Rock Salt 80–90
LOADING
SPREADING TIPS
• Use care when operating spreader near
pedestrians.
• Spread ice melting materials "with the storm" to
prevent unmanageable levels of ice from building.
• Adjust material flow by following the instructions in
the "Operation" section of this document.
WARNING
Never remove spreader from vehicle with
material in it as this could cause damage to
the frame assembly.
WARNING
Do not overload spreader. Use chart below
to calculate weight of material. Weights of
material are an average for dry materials. CAUTION
DO NOT leave unused material in
hopper. Material can freeze or solidify,
causing unit to not work properly.
Empty and clean after each use.
CAUTION
Read and adhere to manufacturer's
ice-control material package
labeling, including Material Safety
Data Sheet requirements.

Lit. No. 43575/43585/43595, Rev. 01 9 November 1, 2017
4. Install the control handle onto the end of the
control rod, as shown. Tighten the set screw.
5. Attach the clear protective cover to the hopper.
ASSEMBLY
ASSEMBLING YOUR SPREADER
1. Tires are not fully inflated when shipped. Inflate
tires with a manual pump.
2. Insert the bent end of the rod through the hole in
the cross piece of the main frame. Apply a washer
to the end and slide the rod end into the gate slide.
Lock in place with the hairpin cotter as shown.
The washer should be between the hole in the
gate slide and the cotter pin.
3. Insert the rod through the main frame while sliding
the upper handle assembly down onto the main
frame. Fasten with cap screws and locknuts.
WARNING
Use safety glasses and gloves when inflating
and installing the tires. Use manual pump
only to inflate. Refer to the tire sidewall for
manufacturer's recommended pressure. Do
not exceed the maximum inflation pressure.

Lit. No. 43575/43585/43595, Rev. 01 10 November 1, 2017
OPERATION
ADJUSTING MATERIAL FLOW
The rate of material flow on your drop spreader may
be adjusted for your specific material and usage.
1. Loosen the black knob and washer.
2. Adjust the cam wheel to the desired setting.
Higher numbers mean increased flow, lower
numbers result in reduced flow.
3. Tighten the black knob and washer to lock the
setting.

Copyright © 2017 Douglas Dynamics, LLC. All rights reserved. This material may not be reproduced or copied, in whole or in part, in any
printed, mechanical, electronic, film, or other distribution and storage media, without the written consent of Western Products. Authorization
to photocopy items for internal or personal use by Western Products outlets or spreader owner is granted.
Western Products reserves the right under its product improvement policy to change construction or design details and furnish equipment when
so altered without reference to illustrations or specifications used. Western Products offers a limited warranty for all spreaders and accessories.
See separately printed page for this important information. The following is a registered (®) trademark of Douglas Dynamics, LLC: WESTERN®.
Printed in U.S.A.
A DIVISION OF DOUGLAS DYNAMICS, LLC
Western Products
PO Box 245038
Milwaukee, WI 53224-9538
www.westernplows.com
Lit. No. 43575, Rev. 01 November 1, 2017
This product conforms to EU Machinery Directive 2006/42/EC.
