INSTALLATION INSTRUCTION MANUAL
LED WALL PACK LIGHT, 100-277VAC
MODELS:
LWPX-30-80W-MCTP
Model number parameter list:
CAUTION: This product use an input 100-277VAC driver of wide range voltage.
1. Introduction
This LED Wall-Packs light uses the latest in solid state lighting technology for long life,
low maintenance, and high efficiency.
An internal power-factor-corrected switch-mode supply allows it to be used from
any nominal 100V-277V, 60Hz AC supply without any variation in light output.
Suitable for use in the following locations:
• Ambient Temp: -4~+104°F
• Wet Locations
Note: Save these instructions for future reference.
2. Installation
Item Model Input Voltage Watt Input Current
ALWPX-30-80W-MCTP 100-277VAC 30W/40W/60W/80W 1.1A MAX
Warning:
To avoid the risk of fire, explosion, or electric shock, this product should be installed,
inspected, and maintained by a qualified electrician only, in accordance with all applicable
electrical codes.
Warning:
To avoid electric shock:
•Be certain electrical power is OFF before and during installation and maintenance.
•Luminaire must be connected to a wiring system with an equipment-grounding conductor.
WESTGATE MFG., INC | 2462 E 28th Street, Vernon, CA 90058 USA |1-323-826-9490|[email protected]

For supply connections use wire rated for at least 176°F
Installation:
Wall Mount Installation
FIG.1
FIG.2
Warning:
To avoid explosion:
•Make sure the supply voltage is the same as the rated luminaire voltage.
•Do not install where marked operating temperatures exceed the ignition temperature of
the hazardous atmosphere.
•Do not operate in ambient temperatures above those indicated on the luminaire
nameplate.
•Keep lens tightly closed when in operation.
FIG.2
WESTGATE MFG., INC | 2462 E 28th Street, Vernon, CA 90058 USA |1-323-826-9490|[email protected]

FLG.3
FLG.4
Step 1
Open the back box by using philips screw driver (FIG.2),Refer to size of the diagram to bore the
holes on the wall(FIG.1).
Step 2
screw the three green/yellow grounding cords to the position which indicated "GR"(FLG.3)
Step 3
Tighten enclosure screws to seal fixture. (FIG.4)
WESTGATE MFG., INC | 2462 E 28th Street, Vernon, CA 90058 USA |1-323-826-9490|[email protected]
WESTGATE MFG., INC | 2462 E 28th Street, Vernon, CA 90058 USA |1-323-826-9490|[email protected]

Wattage tunable (Optional)
Diagrams and Methods of Watt Selectable Function:
CCT tunable (Optional)
Diagrams and Methods of CCT Selectable Function:
MAINTENANCE
The emergency driver will perform required routine test, and indicates via its light. Maintenance
personnel should periodically check the indicator light. If the indicator light is flashing quickly, pls
contact manufactuer.
"Written records of testing shall be kept by the owner for inspection by the authority having
jurisdiction."
After installation, please
check whether the lighting fixture is firmly fixed.
check whether wires are connected correctly.
At last, turn on the power, and check if the lighting fixture works well. If not, please turn off the power
and contact with local dealer.
CCT Tunable selector inside
(3000/4000/5000/5700K)
According to the watt selectable label shown in the diagram,please toggle the DIP
switch 1,2,3 to select the corresponding watt.
Wattage tunable selector
(30/40/60/80W)
Please screw the knob cap to select the corresponding CCT.
Wattage tunable
CCT tunable
