Westinghouse WFE911SB User manual

1
IMPORTANT SAFETY INSTRUCTIONS
USER MANUAL
900MM COOKING APPLIANCES
WFE911SB

2CONTENTS
Important safety instructions..................................................... 3
Description of your appliance:
WFE911SB.................................................................................... 5
Before operating your appliance for the first time.......... 6
Installing your oven accessories ................................................7
Installing your cooktop accessories........................................ 8
Using your gas cooktop................................................................ 9
Using your oven...............................................................................10
Cooking test ......................................................................................13
Cooking guide ..................................................................................14
Dealing with cooking problems ...............................................16
Cleaning your appliance ..............................................................17
Cleaning oven accessories..........................................................18
Troubleshooting............................................................................. 20
Installation of the appliance......................................................22
Wiring requirements.....................................................................26
Installing the gas cooker.............................................................27
LPG Conversion ..............................................................................28
Testing the operation of the gas cooker.............................29
Warranty..............................................................................................31
Please read the user manual carefully and store in a
handy place for later reference.
The symbols you will see in this booklet have
these meanings:
WARNING
WARNING
This symbol indicates information concerning your
personal safety.
WARNING
CAUTION
This symbol indicates information on how to avoid
damaging the appliance.
TIPS & INFORMATION
IMPORTANT
This symbol indicates tips and information about use
of the appliance.
ENVIRONMENTAL TIPS
ENVIRONMENT
This symbol indicates tips and information about
economical and ecological use of the appliance.
Congratulations and thank you for choosing our product.
We are sure you will find your new cooker a pleasure to
use and a great asset to your cooking. Before you use
the appliance, we recommend you read through the
whole user manual which provides a description of the
product and its functions.
To avoid the risks that are always present when you use
an appliance, it is important that the appliance is
installed correctly and that you read the safety
instructions carefully to avoid misuse and hazards. We
recommend that you keep this instruction booklet for
future reference and pass it on to any future owners.
This appliance complies with the requirements of
Australian Standard AS/NZS 60335.2.6. Gas appliances
also comply with the requirements of As/NZS 5263.1 and
AS 5263.0.
Conditions of use
This appliance is intended to be used in household
and similar applications such as:
• Staff kitchen areas in shops, offices and other
working environments
• Farm houses
• By clients in hotels, motels and other residential
type environments
• Bed and breakfast type environments
Please ensure you read the instruction manual fully
before you call for service, or a full service fee could
be applicable.
Record model and serial number here:
Model number:.......................................................................................
Serial number:........................................................................................
PNC:............................................................................................................
CONTENTSCONGRATULATIONS

3IMPORTANT SAFETY INSTRUCTIONS
Please read the user manual carefully and store in a
handy place for later reference. Pass the user manual on
to possible new owners of the appliance.
Read the following carefully to avoid damage or injury.
NOTE: You must read these warnings carefully
before installing or using the appliance. If you need
assistance, contact your Customer Care Department.
The manufacturer will not accept liability, should
these instructions or any other safety instructions
incorporated in this book be ignored.
WARNING
WARNING
General warnings
• This appliance must not be used as a space heater.
• In order to avoid fire, the appliance must be kept
clean and vents kept unobstructed.
• Do not spray aerosols in the vicinity of this appliance
whilst it is in operation.
• Do not use or store flammable materials near
this appliance.
• Do not line the bottom of the oven with foil
or cookware.
• Always use gloves when handling hot items inside
the oven.
• Always turn the grill off immediately after use as fat
left behind may catch fire.
• Do not hang any objects from the hob as it may
block the air vents.
• Do not modify this appliance.
• To maintain safe operation, it is recommended
that the product be inspected every 5 years by an
authorised service person.
• Do not install an aftermarket lid or cover over
this appliance.
• The cooking process must be supervised.
A short term cooking process must be
supervised continuously.
IMPORTANT SAFETY INSTRUCTIONS
Installation, cleaning and servicing
• An authorised person must install this appliance.
(Certificate of Compliance to be retained).
• Before using the appliance, ensure that all packing
materials are removed from the appliance.
• In order to avoid any potential hazard, the enclosed
installation instructions must be followed.
• Ensure that all specified vents, openings and
airspaces are not blocked.
• Only authorised personnel should carry out servicing.
(Certificate of Compliance to be retained).
• Always ensure the appliance is switched off before
cleaning or replacing parts.
• Do not use steam cleaners, as this may cause
moisture build up.
• Always clean the appliance immediately after any
food spillage.
• This appliance must be earthed.
• Due to the weight (approx 75kg) and size of cookers,
2 persons are required to manually manoeuvre them.
Remove loose items such as trivets, oven racks and
trays to minimise weight.
• Do not use the handle to lift the cooker, instead open
the oven door and lift the roof of the oven cavity.
• Take care when lifting to avoid any sharp edges not
intended for lifting.
• This cooker must not be installed with a cut-off timer.

4IMPORTANT SAFETY INSTRUCTIONS
WARNING
WARNING
Oven
• During use the appliance becomes hot. Care should
be taken to avoid touching the hot surfaces inside
the oven.
• Switch the appliance off at the isolating switch before
removing the oven light glass for globe replacement.
• To avoid an accident, ensure that oven shelves and
fittings are always inserted into the appliance in
accordance with the instructions.
• Do not use the door as a shelf.
• Do not push down on the open oven door.
• Do not cover the grill insert with foil, as fat left there
may catch fire.
• Always keep the grill dish clean as any fat there may
catch fire.
Gas cooktops
• Do not allow pots to boil dry, as damage to both
pan and cooktop may result.
• Do not operate the cooktop for an extended period
of time without a pot or pan on the burner.
• Do not allow large cookware to overhang the
cooktop onto the adjacent benchtop. This will
cause scorching to the benchtop surface.
• Do not allow cooking pots or pans to intrude into
the area which is close to the controls.
• Ensure burner bodies and trivets are
properly located.
• Unattended cooking with oil or fat on a hob can
be dangerous and result in fire.
• In order to avoid a fire do not store items on the
cooking surface.
WARNING
WARNING
Child safety
• This appliance is not intended for use by persons
(including children) with reduced physical, sensory
or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a
person responsible for their safety.
• Children should be supervised to ensure that they do
not play with the appliance.
• During use this appliance becomes hot. Care should
be taken to avoid touching hot surfaces, e.g. oven
door, heating elements etc.
• Accessible parts will also become hot when in use.
To avoid burns and scalds children should be
kept away.
• Always turn pan handles to the side or rear to
prevent accidental knocking and to keep out of reach
of children.
IMPORTANT SAFETY INSTRUCTIONS

5
Oven
function
control
knob
Thermostat
control
knob
Timer Hob control
knobs
Control Panel
Wok burner
High heat
(rapid) burner
Gas Hob
Cooktop
Contol panel
Oven door handle
Oven door
Storage drawer
Low heat (auxillary) burner
medium (semi-rapid)
burners
Adjustable feet
Gas hob, multi-function electric oven with electronic timer

6BEFORE OPERATION
BEFORE OPERATING YOUR APPLIANCE FOR THE FIRST TIME
Preparing your appliance for the first time
• Please remove all internal boxes and bags from the
oven before operation.
• Please wipe out the oven interior prior to operation
with warm soapy water and polish dry with a soft clean
cloth. Do not close the oven door until the oven is
completely dry.
• New appliances can have an odour during first
operation. It is recommended to ‘run in’ your oven
before you cook for the first time. Run the oven at 180°C
for 2 hours and ensure that the room is well ventilated.
• DO NOT line the oven with foil, it will damage the
enamel.
Use of Digital Timer
Time adjustment
The time must be set before you start using the oven.
Following the power connection, the symbol ´A` and
three ´0`s will flash on the screen.
NOTE: The oven functions cannot be operated until the
the time has been set.
In the event of power failure the time will be reset and
need to be reprogrammed
1. Press ´+` and ´-`keys
simultaneously. Symbol will
appear, and the dot in the middle
of the screen will start to flash.
2. Adjust the time while the dot
is flashing, using the ´+` and
´-`keys.
3. After a few seconds the dot
will stop flashing and light
continuously. The time of day
will be displayed and your clock
is now set.

7INSTALLING OVEN ACCESSORIES
INSTALLING YOUR OVEN ACCESSORIES
Shelves and trays
The shelves are designed so that they have maximum
travel but cannot be accidentally pulled right out.
• Locate the rear edge of the shelf/tray in between 2
guide rails of the side rack – see diagram. Ensure the
same rail positions on both sides of the oven are
being engaged.
• With the front edge raised, begin to slide the shelf
into the oven.
• Once the indents have passed the front edge of the
side rack, the shelf can be pushed completely in.
• When fully inserted the shelf/tray should not interfere
with the closed door.
Installing burners
• The burner crown must be fitted correctly into the
burner cup or damage will occur during operation.
• To do this, ensure that the 2 ribs on either side of the
spark plug hole are positioned into the 2 slots on the
burner cup.
• The burner cap and burner crown must be clean and
located correctly for the burner to light.
NOTE: When the burner is correctly fitted it will sit level
on the hob.
Burner cap
Burner cup
Burner crown
Flame safeguard
sensor
Ignition
spark plug
Injector
Prior to installing accessories, remove all packaging and
remove plastic film from external panels.
Side racks
The side racks that come with your oven are fitted in the
following manner:
• Align and insert the hooked ends to the two holes in
the cavity at the top.
• Locate the bottom holes and push in the bottom
ends firmly
WIRE GRID
Wire grid is used to grill or to
place different cookwares on it.
WARNING- Fit the grid correctly
into any corresponding rack in the
oven cavity and push it to the end.
DEEP TRAY
Deep tray is used to cook stews.
To locate the tray correctly in the
cavity, put it to any rack and push
it up to the end.
Deep Tray, Wire Grid and Handle Set
The grill pan set is used when grilling steaks, etc.
WARNING
WARNING
The grill pan has a detachable handle. Make sure when
using the grill pan handle that it is centralised and secure
as shown in the figure. Use the grill pan handle by two
hands. Do not leave the handle in position when grilling.

8INSTALLING YOUR COOKTOP ACCESSORIES
INSTALLING YOUR COOKTOP ACCESSORIES
Installing trivets
• The rubber feet on the trivets locate into the
contours of the hob
• Take care when placing the trivets as dropping them
may damage the hob or trivet
• The wok trivet sits on top of the trivet above the
wok burner

9USING YOUR GAS COOKTOP
Using your gas hotplates
NOTE: Gas controls turn anticlockwise from ‘Off’ and
have limited movement.
Lighting the burners
Electronic ignition
These hobs are fitted with mains powered electronic
ignition. When the appliance has been connected
and the power is on, depressing any knob will release
sparks to all burners. To light a burner, depress the
corresponding knob and while continuing to depress
knob turn anti-clockwise to ‘HI’ position. The knob may
be released once the flame is established, and turned
further anti-clockwise to r,educe the flame height
as desired.
The burners are equipped with a flame failure device
providing security in case of an accidentally extinguished
flame. If such a case occurs, the device will block the
burners gas lines and will avoid any accumulation of
unburned gas. Wait 90 seconds before re-igniting an
extinguished gas burner
WARNING
WARNING
• Keep hands clear of burners when lighting.
• If burner does not light within 5 seconds, turn knob
to ‘Off’ position, allow gas to disperse, then try
lighting again.
• Burners MUST be operated between ‘HIGH’ and
‘LOW’ settings only.
ENVIRONMENTAL TIPS
ENVIRONMENT
To conserve gas, place the pan centrally over the burner
and adjust the flame so that it does not go past the edge
of the cookware.
Your hob has burners of different diameters. The most
economic way of using gas is to choose the correct
size gas burners for your cooking pan size and to bring
the flame to minimum position once the boiling point
is reached. It is recommended to always cover your
cooking pan. In order to obtain maximum performance
from the main burners, use pots with the following flat
bottom diameters. Using smaller pots than the minimum
dimensions stated below will cause energy loss.
Intense heat wok Burner: 22-26cm
Medium heat (Semi-rapid) Burner: 14-22cm
Low heat (auxiliary) Burner: 12-18cm
Make sure that the tips of the flames do not spread out of
USING YOUR GAS COOKTOP
the outer circumference of the pan, as this may also harm
the plastic accessories around the pan (handles etc.).
NOTE: In the absence of electrical power, carry out
the ignition directly to the burner with a hand held
ignition source.
2
1 34
1. High heat burner (11.2 MJ/h)
Used for fast heating with large size cookware items.
2. Medium heat burner (6.60 MJ/h)
Used for normal cooking and simmering with mid
size cookware items.
3. Low heat burner (3.90 MJ/h)
Used for simmering with small cookware items.
4. Intense heat wok burner (13.0 MJ/h)
Used for very fast heating with woks and other large
size cookware items. Use wok trivet provided when
cooking with a wok.
OFF position MAX. position MIN. position. MODULATE

10 USING YOUR OVEN
USING YOUR OVEN
Oven Function Control Knob:
To select the desired cooking function, turn the knob to
the related symbol. the details of the oven functions are
explained in the next section.
Oven Thermostat Control Knob:
After the cooking function has been set, the desired
temperature can be adjusted by oven thermostat
knob and the oven will start to operate (timer must be
adjusted, if available).The thermostat signal light will be
on or off according to the thermostat operation.
Oven Functions
Light
Only the oven light will be turned on and it remains on in
all the cooking functions.
Bake
The oven’s thermostat and warning lights will be turned on,
the lower and upper heating elements will start operating.
The static cooking function emits heat, ensuring even
cooking of the lower and upper food. This is ideal for
making pastries, cakes, baked pasta, lasagne and pizza.
Prehating the oven for 10 minutes is recommended and it
is best to cook on only one shelf at a time in this function.
Defrost Function
The oven’s warning lights will be turned on, the fan starts
operating.
To use the defrost function, take your frozen food and
place it in the oven on a shelf placed in the third slot
from the bottom. It is recommended that you can place
an oven tray under the defrosting food, to catch the
water accumulated due to melting ice. This function will
not cook or bake your food, it will only help to defrost it
Grill Function
The oven’s thermostat and warning lights will be turned
on, the grill heating element will start operating.
The function is used for grilling and toasting foods, use
the upper shelves of oven. Lightly brush the wire grid
with oil to stop foods sticking and place foods in the
center of the grid. Always place a tray beneath to catch
any drips of oil or fat. It is recommended to pre-heat the
oven about 10 minutes.
WARNING
WARNING
When grilling, the oven door must be closed and the
oven temperature should be adjusted to 190°C.
Maxi Grill
The oven’s thermostat and warning lights will be turned
on, the grill and upper heating elements will start
operating.
The function is used for faster grilling and for covering a
larger surface area, such as grilling meats, use the upper
shelves of oven. Lightly brush the wire grid with oil to
stop foods sticking and place foods in the center of the
grid. Always place a tray beneath to catch any drips of
oil or fat. It is recommended to pre-heat the oven about
10 minutes.
WARNING
WARNING
When grilling, the oven door must be closed and the
oven temperature should be adjusted to 190°C.
Fan Bake
The oven’s thermostat and warning lights will be turned
on, the ring heating element and fan will start operating.
The turbo function evenly disperse the heat in the
oven. All foods on all racks will be cooked evenly. It is
recommended to pre-heat the oven about 10 minutes.
Fan Assist
The oven’s thermostat and warning lights will be turned
on, the upper and lower heating elements and fan will
start operating.
This function is very good for obtaining results in
baking pastry. Cooking is carried out by the lower and
upper heating element within the oven and by the fan
providing air circulation, which will give a slight grill
effect to the food. It is recommended to pre-heat the
oven about 10 minutes.
Pizza Function
The oven’s thermostat and warning lights will be turned
on, the ring and lower heating elements and fan will start
operating.
Fan and lower heating function is ideal for baking food,
such as pizza, equally in a short time. While the fan
evenly disperses the heat of the oven, the lower heating
element ensures the baking of food dough.

11USING YOUR OVEN
Fan Grill
The oven’s thermostat and warning lights will be turned
on, the grill heating element and fan will start operating.
The function is ideal for thicker foods when grilling, use
the upper shelves of oven. Lightly brush the wire grid
with oil to stop foods sticking and place foods in the
center of the grid. Always place a tray beneath to catch
any drips of oil or fat.
WARNING
WARNING
When grilling, the oven door must be closed and the
oven temperature should be adjusted to 190°C.
Once the food is cooked, turn the temperature selector
off in an anticlockwise direction. Do not force it right
round in a clockwise direction as this will result in
damage to the thermostat. Turn the multifunction
selector off.
Audible warning time adjustment
The audible warning time can be set to any time
between 0:00 and 23:59 hours. Audible warning time is
for warning purposes only. The oven will not be activated
with this function.
1. Press MODE. The symbol will begin to
flash and three ´0`s will appear.
2. Select the desired time period in minutes
using the -and +keys while is flashing.
3. The symbol lights continuously, the time
is saved and the warning is set.
Note: The timer will countdown but the countdown time
will not be shown on the display.
When the timer reaches zero an audible warning will
sound and the symbol will flash. Press any key to stop
the audible warning. The symbol will disappear.
Semi-automatic time adjustment (cooking period)
This function helps you to cook for a fixed period of
time. A time range between 0and 10 hours can be set.
Prepare the food for cooking and put it in the oven.
1. Select the desired cooking function and the
temperature by turning the control knobs.
2. Press MODE until you see ´dur/` on
the screen. The symbol ´A` will flash.
3. Select the desired cooking time period
using the ´-` and ´+` keys.
4. The current time reappears on
the screen, ´A`, and light
continuously.
When the timer reaches zero, the oven will switch off
and an audible warning will sound. The symbol ´A`,
will flash. Turn both control knobs to position ´0` and
press any key on the timer to stop the audible warning.
The symbol will disappear and the timer will switch back
to manual function.
USING YOUR OVEN

Semi-automatic time adjustment (finishing time)
This function automatically starts the oven so that
cooking finishes at a set time. You can set an end time
up to 10 hours after the current time. Prepare the food
for cooking and put it in the oven.
1. Select the desired cooking function and the
temperature by turning the control knobs.
2. Press MODE until you see ´end/ ` on
the screen. ´A` and the days time will
flash.
3. The current time reappears on the
screen, ´A` and light continuously.
4. The current time reappears on
the screen, ´A`, and light
continuously.
When the timer reaches zero, the oven will switch off
and an audible warning will sound. The symbol ´A` and
will flash. Turn both control knobs to position ´0` and
press any key on the timer to stop the audible warning.
The symbol will disappear again and the timer will switch
back to manual function.
Full-automatic programming
This function is used to cook after a certain period of
time and within a certain duration. A time up to 10 hours
after the actual time can be set. Prepare the food for
cooking and put it in the oven.
1. Select the desired cooking function and the
temperature by turning the control knobs.
2. Press MODE until you see ´dur/`on
the screen. The symbol ´A` will flash.
3. Select the desired cooking time period
using the ´-` and ´+` keys.
4. The current time reappears on
the screen, ´A`, and light
continuously.
5. Press MODE until you see ´end/ `
on the screen. ´A`, and the time will
flash.
6. Select the desired finishing time using
the ´-` and ´+` keys.
7. Add the cooking period to the actual
time. You can set a time up to 23 hours
and 59 minutes after this.
8. The current time reappears on
the screen, ´A`, and light
continuously.
The oven will calculate the time and automatically start
the oven so that cooking finishes at the set finishing
time. When the timer reaches zero, the oven will switch
off and an audible warning will sound. The symbol ´A`,
will flash. Turn both control knobs to position ´0` and
press any key to stop the audible warning. The symbol
will disappear and the timer switch back to manual
function.
On completion of cooking
• The heat source will turn off, the timer will beep and
the end time and/or cook time ‘indicators’ will flash.
• Even though the heating element turns off the oven
will still retain substantial heat. This will continue to
cook the food until it is removed or the oven cools
down. If you do not plan on being present when the
oven turns off, you should take this extra heating
time into account.
• Turn the function and temperature controls to the
off position.
• Press any button to stop the timer beeping.
Cooling/Venting fan
Your appliance is fitted with a cooling fan.
This prevents your appliance from overheating and
reduces the condensation inside the oven. It will operate
whenever you are using your oven or grill and will expel
warm air from the appliance. In some
appliances the cooling fan may continue to operate after
the appliance is turned off. It will switch off by itself once
the oven is cool
Condensation
Excess condensation may fog the oven door. This may
happen when you are cooking large quantities of food
from a cold start. You can minimise condensation by:
• Keeping the amount of water used whilst cooking
to a minimum.
• Making sure that the oven door is firmly closed.
• Baking custard in a baking dish that is slightly
smaller than the water container.
• Cooking casseroles with the lid on.
NOTE: If you are using water in cooking, this will turn to
steam and may condense outside your appliance. This is
not a problem or fault with your oven.
USING YOUR OVEN
12 USING YOUR OVEN

Get to know your new oven with this ‘Simple Test Cake’
Although we strive for a perfect performing oven, it’s
possible that there will be some variation in colour
when baking. Therefore, we suggest this simple, easy
and delicious to make Simple Test Cake, it can help you
understand your new oven. All ovens do sometimes have
hot or cold spots, therefore it is important to judge with
your eye as you may require to rotate during baking.
‘Simple Test Cake’
125g butter, softened to room temperature
1 cup caster sugar
1 teaspoon pure vanilla essence
4 large eggs
2 cups self-raising flour
pinch of salt
4 tablespoons (80ml) full-cream milk
NOTE: If desired substitute butter for either margarine
or olive oil spread. Recipe is based on the Australian
standard metric 250ml cup and 20ml tablespoon sets.
Method:
1. Butter base and sides of two 20cm straight-sided
round or square cake pans. Then line the base with
grease proof or baking paper.
2. Preheat oven to moderate ‘180°C’ (170°C fan
forced) and ensure oven shelf is in the centre
position of oven.
3. Cream softened butter and sugar until light in colour.
4. Add vanilla essence.
5. Then eggs one at a time, beating well after each
addition.
6. Sift flour and salt into the mixture and beat until
well combined.
7. Add milk and beat or stir to combine.
8. Spoon mixture equally between prepared cake pans.
9. Bake in preheated oven, middle shelf for about 25
to 35 minutes or until when tested with a fine cake
skewer it comes out clean, or the edges of the
cakes have come away slightly from the sides of
the cake pans.
10. Remove from oven to wire cake rack and rest for 5
minutes before removing from cake pans.
Cool completely.
To Serve: sandwich together with your favourite jam or
conserve, and dust top with pure icing sugar.
• For best baking results preheat oven for 30 minutes.
• Select the correct shelf location for food being
cooked.
• Make sure dishes will fit into the oven before you
switch it on.
• Keep edges of baking dishes at least 40mm from
the side of the oven. This allows free circulation of
heat and ensures even cooking.
• Do not open the oven door more than necessary.
• Do not place foods with a lot of liquid into the oven
with other foods. This will cause food to steam and
not brown.
• After the oven is turned off it retains the heat
for some time. Use this heat to finish custards or to
dry bread.
• Do not use a lot of cooking oil when roasting. This
will prevent splattering oil on the sides of the oven
and the oven door. Polyunsaturated fats can leave
residue which is very difficult to remove.
• When cooking things which require a high heat from
below (e.g. tarts), place the cooking dish on a scone
tray in the desired shelf position.
• For sponges and cakes use aluminium, bright
finished or non-stick utensils.
• Remove unnecessary trays or dishes when roasting
or baking.
Oven shelf location
Your oven has five positions for shelves. These are
number from 1 (the lowest shelf position to 5 (the
highest shelf position) See diagram.
1. Rack
2. Rack
3. Rack
4. Rack
5. Rack
Shelf
positions
To give maximum space above and below the shelves,
load them in this way:
• When cooking with 1 shelf, use position 3 or 4.
• When cooking with 2 shelves, use position 1 and 4.
Use the oven efficiently, by cooking many trays of food
at the same time. For example:
• Cook 2 trays of scones, small cakes or sausage rolls.
13COOKING TEST
COOKING TEST

Choosing the best oven settings
The following table is intended as a guide and
experience may show some variation in cooking
times necessary to meet individual requirements. We
recommend that you preheat your oven for 30 minutes.
Modes without oven fan
FOOD TEMPERATURE C OVEN SHELF POSITION* TIME IN MINUTES
Scones Plain or fruit 220 3 or 4 10 – 15
Biscuits Rolled 170 313 – 18
Spooned 190 313 – 18
Shortbread biscuits 160 330 – 35
Meringues Hard – individual 110 390
Soft – individual 180 315 – 20
Pavlova – 6 egg 110 375
Cakes Cup cakes 190 3 or 4 15 – 20
Sponge – 4 egg 180 3 or 4 20 – 30
Shallow butter cake 180 325 – 30
Pastry – short
crust
Cornish pasties 200 340 – 45
Custard tart 200/180 3Pastry 8/200
Whole tart 10/200
& 20/180
Pastry – choux Cream puffs 210 325 – 30
Yeast goods Bread 210 325 – 30
Modes with oven fan
FOOD TEMPERATURE C OVEN SHELF POSITION* TIME IN MINUTES
SINGLE SHELF MULTI SHELF
Scones Plain or fruit 210 3 or 4 2 & 5 10 – 15
Biscuits Rolled 150 3 or 4 2 & 5 13 – 18
Spooned 180 3 or 4 2 & 5 13 – 18
Shortbread 150 3 or 4 2 & 5 13 – 18
Meringues Hard – individual 100 3 or 4 2 & 5 90
Soft – individual 165 3 or 4 2 & 5 15 – 20
Pavlova – 6 egg 100 3 or 4 2 & 5 75
Cakes Cup cakes 180 3 or 4 2 & 5 15 – 20
Sponge – 4 egg 170 3 or 4 2 & 5 20 – 30
Shallow butter cake 170 3 or 4 2 & 5 25 – 30
Rich fruit cake 170 3 or 4 2 & 5 60
Pastry –
short crust
Cornish pasties 180 3 or 4 2 & 5 40 – 45
Custard tart 190/170 3 or 4 2 & 5 20 – 30
Whole tart Pastry 8/190
Whole tart 10/190
& 20/170
Pastry –
choux
Cream puffs 200 3 or 4 2 & 5 25 – 30
Yeast goods Bread 200 42 & 5 25 – 30
* Counting from the bottom shelf up.
COOKING GUIDE
14 COOKING GUIDE

Roasting Meat
1. Place the meat in the oven and set the temperature
between 180°C and 200°C. (It is recommended to
wrap your meats in an oven roasting bag or foil to
prevent fats and oils from splattering, making it easier
to clean your oven.)
2. Use the grill/oven dish and grill insert.
Place the meat on the insert.
3. Do not pierce the meat, as this will allow juices
to escape.
4. When the meat is cooked, take the roast out of
the oven, wrap in aluminium foil and leave to stand
for about 10 minutes. This will help retain the
juices when the meat is carved. The table shows
temperatures and cooking times for different kinds
of meat. These may vary depending on the thickness
or bone content of the meat.
MEAT RECOMMENDED
TEMPERATURE
MINUTES
PER KG
Beef 180°C – 200°C Rare 35 – 40
Medium 45 – 50
Well done 55 – 60
Lamb
180°C – 200°C Medium 40
Well done 60
Veal
180°C – 200°C Well done 60
Pork
180°C – 200°C Well done 60
Roasting poultry and fish
1. Place the poultry or fish in an oven set at a moderate
temperature of 180°C.
2. Place a layer of foil over the fish for about three
quarters of the cooking time.
The table shows temperatures and cooking times for
different kinds of fish and poultry. These may vary
depending on the thickness or bone content of the meat.
POULTRY
& FISH
RECOMMENDED
TEMPERATURE
MINUTES PER
KILOGRAM
Chicken 180°C – 200°C 45 – 50
Duck
180°C – 200°C 60 – 70
Turkey
180°C – 200°C 40 – 45
(<10kg)
35 – 40
(>10kg)
Fish
180°C – 200°C 20
Grilling Guide
WARNING
WARNING
Always clean the grill/oven dish after every use.
Excessive fat build up may cause a fire.
Grilling is conducted with the oven door closed
As a method of cooking, grilling can be used to:
• Enhance the flavours of vegetables, fish, poultry
and meat.
• Seal the surface of the food and retain the
natural juices.
This table shows how to grill different types of meat:
Beef Tenderloin, rump, sirloin. Brush with oil
or melted butter, especially if the meat is
very lean.
Lamb Loin chops, short loin chops, chump
chops, and forequarter chops. Remove
skin or cut at intervals to stop curling.
Brush with oil or melted butter.
Sausages Prick sausages to stop skin from bursting.
Poultry Divide into serving pieces. Brush with oil.
Fish Brush with oil or melted butter and
lemon juice.
Bacon Remove rind. Grill flat.
Guide to better grilling
Steak 15 – 20 minutes
Chops 20 – 30 minutes
Fish 8 – 10 minutes
Bacon 4 – 5 minutes
No definite times can be given for grilling because this
depends on your own tastes and the size of the food.
These times should only be used as a guide and remember
to turn the food over halfway through the cooking process.
For better grilling results, follow these easy instructions:
1. Preheat grill for at least 5 minutes.
2. Choose only prime cuts of meat or fish. If the cut is
less than 5mm thick it will dry out. If the cut is more
than 40mm thick, the outside may burn whilst the
inside remains raw.
3. Do not place aluminium foil under the food as this
prevents fats and oils from draining away, which could
result in a fire.
4. Baste the food during cooking with butter, olive oil
or marinade. Grilled food is better if marinated
before cooking.
5. Use tongs to turn food as a fork pierces the surface
and will let juices escape.
Fan Grill
The “Fan Grill” assists the grilling process by circulating
the heat evenly around the food. The recommended
temperature setting is 180°C for all fan grilling functions.
1. Place the grill dish on the bottom rack.
2. Place meat/poultry on an oven shelf above the
grill dish.
3. Wipe off any oil or fat which spatters while the oven
is still warm.
15COOKING GUIDE

16
PROBLEM CAUSES REMEDIES
Uneven cooking: • Incorrect shelf position.
• Oven tray too large.
• Trays not centralised.
• Air flow in oven uneven.
• Grill dish affecting thermostat.
– Select shelf that puts food in the centre of
the oven.
– Experiment with other trays or dishes.
– Centre trays.
– Rotate food during cooking.
– Remove grill dish from oven on bake modes.
Baked products too brown
on top:
• Oven not preheated.
• Baking tins too large for the recipe.
• Baking tins not evenly spaced.
• Products not evenly sized or spaced
on trays.
• Baking temperature too high.
– Preheat the oven.
– Use correct size tins.
– Stagger baking tins at least 3cm between
tins and the oven walls.
– Make into same size and shape, & spread
evenly over trays.
– Lower the temperature.
Baked products too brown
on bottom:
• Baking tins too large for the recipe.
• Baking tins are dark metal or glass.
• Food too low in the oven.
• Oven door opened too frequently
during baking.
• Baking temperature too high.
• Grill dish affecting thermostat.
– Use correct size tins.
– Change to shiny, light tins or lower the
temperature by 10°C.
– Cook one shelf higher.
– Don’t open the oven door until at least half
the cooking time has passed.
– Lower the temperature.
– Remove grill dish from oven on bake modes.
Cakes have a cracked,
thick crust:
• Baking temperature too high.
• Food too high in oven.
• Cake batter over mixed.
• Pan too deep.
• Baking pans dark.
– Lower the temperature.
– Cook one shelf lower.
– Mix just long enough to combine
ingredients.
– Check size of pan and use recommended
size.
– Change to shiny pans.
Baked products are pale,
flat and undercooked:
• Baking temperature too low.
• Food too low in oven.
• Baking time too short.
• Incorrect tin size.
– Raise the temperature.
– Cook one shelf higher.
– Increase cooking time.
– Use correct size tin.
Cakes fallen in the centre: • Baking temperature too low.
• Baking time too short.
• Proportions of ingredients incorrect
in the recipe.
• Opening door too early in baking.
– Raise the temperature.
– Increase cooking time.
– Check recipe.
– Do not open the door until the last quarter
of cooking time.
Roast meat and potatoes
not browning in fan oven:
• Poor hot air circulation.
• Grill dish affecting thermostat.
– Elevate food onto a rack to allow air
circulation.
– Remove grill dish from oven on bake
modes.
Juices running out of meat: – Do not pierce meat with fork, turn with
tongs.
Grilled meats overcooked
on outside and raw in the
centre:
– Grill at lower insert position.
Grilled chops and steaks
curling:
– Cut into fat every 2cm (1/2”).
DEALING WITH COOKING PROBLEMS
(SEE ALSO TROUBLESHOOTING)
COOKING PROBLEMS

WARNING
WARNING
• Always make sure that the oven is electrically
isolated before cleaning. This can be done by the
functional switch nearby.
• Do not line the bottom of the oven with foil
or cookware.
• Do not use steam cleaners.
Stainless steel
WARNING
WARNING
• The oven door trim, the control panel and the
storage compartment are decorated with stainless
steel and should only be cleaned with warm water
and a mild detergent. Do not use stainless steel
cleaners, abrasive cleaners or harsh solvents on
these parts.
NOTE: Make sure you follow the polish or brushing lines
in the stainless steel.
• All grades of stainless steel can stain, discolour or
become greasy. You must clean these regularly by
following the procedures below if you want your
appliance to look its best, perform well and have
a long life.
• Care must be taken when wiping exposed stainless
steel edges, they can be sharp!
• The stainless steel gas hob can be cleaned
with stainless steel cleaners if it becomes soiled
or discoloured.
• A suitable cleaner can be purchased from Electrolux
Customer Care Centres.
Glass
• Glass surfaces on doors and control panels are best
cleaned immediately after soiling.
• A damp cloth may help remove baked on
food deposits.
WARNING
WARNING
• The door glass on this appliance is made from a
tough, durable material that withstands heating
and cooling without breaking. However, it must be
remembered that it is GLASS, it may break. Treat it
accordingly! Should you have any questions about
the glass in your new appliance, please contact the
customer care centre by dialling 1300 363 640.
• Do not use harsh abrasive cleaners or sharp
metal scrapers to clean the oven door since they
can scratch the surface, which may result in the
shattering of glass.
Gas hotplate
• The trivets can be removed for cleaning by carefully
lifting them from the hob.
• Clean by washing with warm soapy water.
• The burner caps and crowns are also removable
for cleaning.
• If the caps, crowns and cups are heavily soiled, use
a non-abrasive cleaning compound.
• Flame port blockages should be removed by using a
matchstick or brush.
• Do not clean them with abrasive or caustic type
cleaners, or clean them in a dishwasher.
Oven
• Always keep your appliance clean. Ensure that fats
and oils do not accumulate around elements, burners
or fans.
TIPS & INFORMATION
IMPORTANT
• Always keep the oven dish, baking trays, grill dish
and grill dish inserts clean, as any fat deposits may
catch fire.
• Always wrap your meats in foil or an oven roasting
bag to minimise cleaning. Any polyunsaturated fats
can leave a varnish-like residue which is very difficult
to remove.
TIPS & INFORMATION
IMPORTANT
Grill
• Always keep the grill dish and grill dish insert clean,
as any fat deposits may catch fire.
CLEANING YOUR APPLIANCE
17CLEANING YOUR APPLIANCE

CLEANING YOUR OVEN ACCESSORIES
Removing the trays and shelves from your
appliance
• Slide the dish and grill tray towards you until they
reach the front stop.
• Tilt them up at the front to clear the side supports,
taking care not to spill the contents.
• Lift them clear.
• Wash the tray and shelves in hot soapy water.
• Reverse the above steps to put the grill tray and
shelves back again.
• Ensure that they are placed between the 2
support wires.
Removal of side rack
To remove the side rack;
Pull the side rack as shown in the figure. After releasing it
from clips (a), lift it up.
Removal of inner Glasses
Before cleaning the oven door glass, you must remove
the inner glass as shown:
Note: the door will lift when the glass panels are removed
so it is strongly recommended to have a person assist
with this to hold the door down while the glass panels
are removed.
1. Push the glass towards direction Band release from
the location bracket (x). Pull out the glass towards
direction A.
y
B
x
C
a
xA
B
To replace the inner glass;
2. Push the glass towards and under the location
bracket (y) towards todirection B.
y
B
x
C
a
xA
B
3. Place the glass under the locationbracket (x)
towards to direction C.
y
B
x
C
a
xA
B
WARNING
WARNING
If the oven door is a triple glass ovendoor, the third glass
layer can beremoved the same way as the second glass.
Removal of Oven Door
It is not necessary to remove the door to clean it
however the door can be removed for better access for
oven cavity cleaning if necessary. Due to size and weight
of the door it is recommended this is done with two
people present to assist with the handling of the door.
1. Open the oven door.
y
B
x
C
a
xA
B
2. Open the saddle bracket (a) (with the aid of a screw
driver) up to the end position.
y
B
x
C
a
xA
B
3. Close the door until it almost reaches thefully closed
position and remove the doorCleaning your oven
door by pulling it towards you.
y
B
x
C
a
xA
B
Put the door with the outer side down on a soft cloth on
a stable surface. This is to prevent scratches.
WARNING
CAUTION
Rough handling of the glass, especially around the edges
of the front panel, can cause the glass to break.
Replace the door by following these steps in reverse
order.
A
18 CLEANING OVEN ACCESSORIES

WARNING
WARNING
• DO NOT use the oven without the inner and middle
door glass fitted.
• NEVER spray any caustic cleaners on any surface
of the door or damage to the surface coatings
will result.
• DO NOT use metal utensils, scrapers, scourers, or
abrasive cleaners to clean the glass or any of the
door trims. These will damage or scratch the surface
coatings and degrade the finish and appearance.
• DO NOT place glass in dishwasher.
• Use only warm water and liquid detergent with a
soft cloth to clean the glass or trims.
• Before refitting the glass panes to the door ensure
they are dried with a soft cloth.
• The glass edges have been specially ground to
remove any sharp edges. However it is glass, and
should be handled carefully to avoid injury to your
person and damage to the glass.
WARNING
WARNING
Make sure the appliance power is switched off at the
isolating switch before you remove or replace parts, to
avoid the possibility of electric shock.
Changing the light globes
• There is one oven globe located in the top right hand
corner of the cavity.
• To remove, turn oven light glass anticlockwise.
• A special high temperature resistant globe should
be used. This can be purchased from the customer
care centre.
CLEANING YOUR OVEN ACCESSORIES
19CLEANING OVEN ACCESSORIES

Faults
If there is a problem with the oven and/or grill, please:
• Check the points listed below before calling for
service. It may be possible to avoid a call by fixing
the problem yourself – and so continue cooking.
PROBLEM POSSIBLE CAUSE WHAT TO DO
Oven or grill not working Power not turned on Switch on electricity
Household fuse blown Check fuses
Controls incorrectly set Reset controls
Circuit breaker tripped Check circuit breaker
Clock not set Set time of day on timer
Deactivate DEMO Mode. Refer to ‘Using
your oven’
Child Lock ‘ON’ (for WFE946 & WFE916) Deactivate Child Lock. Refer to ‘Using
your oven’
Oven not heating enough Foil or trays on bottom of oven Remove foil or trays
Light & fans on continuously Timer not in manual mode Set timer to manual mode
Oven not working Timer not in manual mode Set timer to manual mode
Household fuse blown Check fuses
Oven light not working Household fuse blown Check fuses
Circuit breaker tripped Check circuit breaker
Lamp blown or loose in socket Replace or tighten lamp
Cooker smoking when first
used
Protective oils being removed Turn grill on high for 30 mins and then
the oven on 220°C for 1 hour
Too much condensation
building up when baking
Too much water used when cooking Reduce amount of water
Leave oven door open after cooking
Condensation on back wall
adjacent to the rear of the
appliance
High moisture content air is being
exhausted from the rear vents
The appliance is rear vented so this is
normal when cooking high moisture
content foods
Smells when first using oven Protective oils being removed This is normal
Timer flashing Power failure or interruption Reset time of day
Burner will not light even
though the sparker is
working
Knob not held down long enough in ‘High’
position for flame safeguard (where fitted)
to engage
Repeat lighting procedure and hold
knob down for 5 seconds in ‘High‘
position
Gas supply valve turned off Turn on gas supply to appliance
Wrong knob turned off Ensure the knob you are turning
corresponds to the burner you wish to
light
Port blockage in ignition area Ensure the ports in the ignition area are
clean and dry
Ignition spark plugs wet or dirty Dry or clean ignition spark plugs
No spark is obtained when
control knob is activated
Electricity supply is disconnected or
switched off
Switch on electricity or check fuses
Ignition spark plugs wet or dirty Dry or clean ignition spark plugs
Flames uneven or tending
to lift
Flame ports blocked or wet Clean or dry flame ports
Burner incorrectly fitted Ensure this component is fitted
correctly
TROUBLESHOOTING
NOTE: Only authorised personnel should carry out servicing. If the household fuse continues to blow, call the Customer Care Centre. In the
event of a power failure the gas burners may be lit with a hand held igniter and used. Take care to avoid letting unburnt gas flow for more
than 5 seconds when attempting to light the burner.
NOTE: We may charge for service even in the guarantee
period if your problem is due to the causes listed below.
20 TROUBLESHOOTING
