Westinghouse LTV-17v1 User manual

1
Table of Contents
IMPORTANT PRODUCT SAFETY INSTRUCTIONS ....................................................................2
ANTENNA INSTALLATION SAFETY .......................................................................................................4
CLEANING THE LCD DISPLAY .............................................................................................................4
SAFETY GUIDELINES ...........................................................................................................................5
FCC COMPLIANCE STATEMENT...........................................................................................................5
INSTALLATION.................................................................................................................................6
1. INSERT REMOTE CONTROL BATTERIES.........................................................................................6
2. ATTACH BASE STAND TO THE LCD TV .......................................................................................7
3. CONNECT ANTENNA, CABLE, VIDEO, S-VIDEO,AND/OR YPBPRCABLES .....................................8
4. CONNECT POWER CABLES ..............................................................................................................9
5. TURN POWER ON..........................................................................................................................9
6. PROGRAMMING TV CHANNELS....................................................................................................10
CONTROLS & CONNECTIONS.....................................................................................................11
FRONT VIEW OF THE PRODUCT ..........................................................................................................11
REMOTE CONTROL............................................................................................................................12
INPUT/ .........................................................................................................................................13
DISPLAY MODES ...............................................................................................................................13
AUTO ...............................................................................................................................................13
OSD FUNCTIONS.............................................................................................................................14
MAIN TV MENU ...............................................................................................................................14
Audio Adjustment Menu ..............................................................................................................15
OSD Language Menu...................................................................................................................15
TV Channel Scanning Menu ........................................................................................................16
OSD Menu...................................................................................................................................16
Antenna/CATV Input Menu.........................................................................................................17
V-Chip and Parental Control Menu ..............................................................................................18
MOVIE Rating Menu...................................................................................................................19
PIP function Menu .......................................................................................................................20
Main PC OSD Menu in Analog Mode..........................................................................................21
PC OSD Menus............................................................................................................................22
PC OSD Menu Language Selection Menus ..................................................................................23
APPENDIX ........................................................................................................................................25
SPECIFICATIONS ................................................................................................................................25
TROUBLESHOOTING...........................................................................................................................26
No power .....................................................................................................................................26
Power is ON but no screen image.................................................................................................26
Wrong or abnormal colors............................................................................................................26
Snow appears on screen ...............................................................................................................26
No sound......................................................................................................................................26
Remote control does not work......................................................................................................26
Remote control code not found in “universal” remote...................................................................26
How do I mount the LCD TV on a wall........................................................................................26
How do I find more help?.............................................................................................................26

2
IMPORTANT PRODUCT SAFETY
INSTRUCTIONS
Read carefully and follow all warnings and instructions in this User's Manual and those
marked on the product before you operate your television. Failure to follow warnings can
result in personal injury or damage to product. Keep this User’s Manual in a convenient
location for future reference.
Proper Positioning of Television
Always handle your LCD television with care. The product can be heavy and bulky, requiring
the assistance of a second person to move. Avoid touching the LCD screen. Skin oils are
difficult to remove.
Always position your LCD television on a stable and level surface. Unstable surfaces can
cause your LCD to topple and fall, resulting in possible damage or injury.
Avoid exposing the LCD display to direct sunlight or high temperatures, which can damage or
shorten its useful life. Do not place near heat sources such as radiators, heat registers, or
other appliances that generate heat.
Avoid exposing the LCD display to rain, water, moisture or high humidity. Do not place your
LCD near basins or sinks where it may come in contact with water.
Orient your LCD display away from direct sunlight to reduce glare.
Never place heavy or sharp objects on the LCD display, video cable, or power cord.
Overloading Outlets
Do not overload electrical power sources when installing television. Overloading wall outlets,
circuits, or extension cords can result in overheating, fire, or electric shock. Use only
grounded or polarized outlets.
Power Cord Protection
Minimize wear on power supply cords. Power supply cords should be routed away from foot
traffic and contact with other objects. Do not route power cord under rugs or carpeting. The
cord should never be severely bent, pinched, or twisted. Periodically inspect power cords for
wear or damage, particularly near plug and the point where it exits from the product. Unplug
cord and discontinue use if damage is discovered.
Ventilation
Slots and openings on the cabinet are provided for ventilation purposes.
To ensure reliable operation of the product and to protect it from overheating, these openings
must not be blocked or covered. Keep LCD a minimum of four (4) inches away from any wall
to assure sufficient airflow and ventilation. Increased temperatures may cause fire or device
failure.

3
To assure proper ventilation, do not block the openings by placing the product on a bed, sofa,
rug or other similar surface. Do not place the product in a built-in installation, such as a
bookcase or an enclosed rack, unless proper ventilation is provided.
Other Notices and Precautions
Caution: Never remove the rear cover. There are no user serviceable parts inside. Your LCD
display contains high-voltage parts. You may be seriously injured if you touch them.
Do not attempt repairs yourself. Your warranty does not cover repairs or attempted repairs by
anyone not authorized by the manufacturer. Refer all servicing and repairs to qualified service
personnel.
If smoke, abnormal noise, or strange odor is present, immediately unplug the power cord.
Contact a qualified service technician
If your LCD display will not be used for extended periods of time, unplug the power cord and
remove the batteries from the remote control.

4
Antenna Installation Safety
Outdoor Antenna Grounding
If an outside antenna or cable system is connected to the product, be sure the antenna or cable
system is grounded so as to provide some protection against voltage surges and built-up static
charges. Article 810 of the National Electrical Code, ANS/NFPA 70, provides information with regard to
proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna
discharge unit, connection to grounding electrodes, and requirements for the grounding electrode.
Lightning
For added protection for this product during a lightning storm, or when it is left unattended and unused
for long periods of time, unplug it from the wall outlet and disconnect the antenna or cable system. This
will prevent damage to the product due to lightning and power-line surges. Do not disconnect the
antenna or the power cord during a heavy storm – lightning may strike while you are holding the cable
cord, causing serious injury. Turn off your LCD display and wait for the weather to improve.
Power Lines
An outside antenna system should not be located in the vicinity of overhead power lines or other
electric light or power circuits. When installing an outside antenna system, extreme care should be
taken to keep from touching such power lines or circuits as contact with them may be fatal.
Cleaning the LCD Display
•MAKE SURE THE LCD DISPLAY IS TURNED OFF
•NEVER SPRAY OR POUR LIQUID DIRECTLY ONTO THE SCREEN OR CASE
To clean the screen:
1. Wipe the screen with a clean, soft, lint-free cloth. This removes dust and other particles.
2. If still not clean, apply a small amount of non-ammonia, non-alcohol based glass cleaner onto a
clean, soft, lint-free cloth, and wipe the screen.
To clean the case:
1. Use a soft, dry cloth.
2. If still not clean, apply a small amount of non-ammonia, non-alcohol based, mild non-abrasive
detergent onto a clean, soft, lint-free cloth, then wipe the surface.
Disclaimer
Manufacturer does not recommend the use of any ammonia or alcohol-based cleaners on the LCD
display screen or case. Some chemical cleaners have been reported to damage the screen and/or
LCD display case. Manufacturer will not be liable for damage resulting from use of any ammonia or
alcohol-based cleaners.

5
Safety Guidelines
Warning: This device must be operated with the original power supply, part number: ADP-60CF A.
CAUTION: The socket-outlet should be installed near the equipment and should be easily accessible.
CAUTION: Use a power cable that is properly grounded. Always use the appropriate AC cord that is certified for
the individual country. Some examples are listed below:
USA.................UL Switzerland ..... SEV
Canada.............CSA Britain ............. BASE/BS
Germany..........VDE Japan ............... Electric Appliance Control Act
IMPORTANT NOTICE CONCERNING POWER CORD SELECTION
The power cord set for this unit has been enclosed and has been selected according to the country of destination
and must be used to prevent electric shock. Use the following guidelines if it is necessary to replace the original
cord set, or if the cord set is not enclosed.
The female receptacle of the cord set must meet IEC-60320 requirements and may look like (Figure A1 below):
Figure A1 Figure A2
For the United States and Canada
In the United States and Canada the male plug is a NEMA5-15 style (Figure A2), UL Listed, and CSA Labeled.
For units that are mounted on a desk or table, type SVT or SJT cord sets may be used. For units that sit on the
floor, only SJT type cord sets may be used. The cord set must be selected according to the current rating for your
unit. Please consult the table below for the selection criteria for power cords used in the United States and
Canada.
Cord Type Size of Conductors in Cord Maximum Current Rating of Unit
SJT 18 AWG
16 AWG
14 AWG
10 Amps
12 Amps
12 Amps
SVT 18 AWG
17 AWG
10 Amps
12 Amps
FCC Compliance Statement
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses, and can radiate radio frequency energy, and may cause harmful interference to radio
communications if not installed and used in accordance with the instructions. However, there
is no guarantee that interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
FCC Warning
To assure continued FCC compliance, the user must use a grounded power supply cord and the provided
shielded video interface cable with bonded ferrite cores. If a BNC cable is going to be used, use only a shielded
BNC (5) cable. Also, any unauthorized changes or modifications not expressly approved by the party responsible
for compliance could void the user's authority to operate this device.

6
Installation
Congratulations on your purchase of a Westinghouse 17” LCD TV display. Sleek and
practical, this lightweight and wall-mountable LCD TV delivers crisp and vibrant video, and
doubles as a superb SXGA computer monitor. Your new Westinghouse 17" LCD TV not only
acts as your television, but also your computer monitor—making it a practical solution for tight
spaces in the office, bedroom, or kitchen. Watch television, play video games, e-mail, or surf
the Internet.
Package Contents
Your LCD TV package includes:
•LCD TV Display
•LCD TV Base Stand Attachable
•Remote Control (2 AAA batteries are included)
•Cables
oDC Power Adapter Supply
oAC Power Adapter Cord
oVGA (HD15) Male – Male Cable
oDIN -> YPbPr and S-Video Adapter Cable
o3.5 mm Male – Male Stereo Audio Cable
•Literature
oQuick Install Instructions
oUser’s Manual
oWarranty Card
Important
Save the original box and all packing material for future shipping needs.
1. Insert Remote Control Batteries
•Remove the battery cover.
•Insert the batteries, paying careful attention to
match the corresponding (+) and (_) markings
on the battery compartment.
•Re-attach the battery cover.
CAUTION
•Only use the specified AAA batteries.
•Do not mix new and old batteries. This may result in
cracking or leakage, which may pose a fire risk or lead
to personal injury.
•Insert batteries according to (+) and (_) markings.
Inserting the batteries incorrectly may result in
cracking or leakage, which may pose a fire risk or lead
to personal injury.
•Dispose of the battery in accordance with local laws
and regulations.
•Keep the battery away from children and pets.
•When the remote control will not be used for an
extended period, remove the batteries.

7
2. Attach Base Stand to LCD TV
Attach the Base Stand to the LCD TV stand neck. Align the holes and tabs, press in and snap
into place.

8
3. Connect Antenna, Cable, Video, S-Video, and/or YPbPr Cables
Connect video and audio cables from compatible devices to the back panel of the LCD TV.
VGA Audio
In Out

9
4. Connect power cables
Connect the DC power adapter cord to the LCD TV and then connect the female AC power
cord to the adapter. Plug the AC power cord into a properly grounded AC outlet.
5. Turn Power On
Press the power button on the front of the LCD TV display or on the remote control. LED light
will turn blue if signal input is detected, orange if no signal.
DC Power Plug Input
Power Button

10
6. Programming TV Channels
1. Select TV as the input using the TV button on
the remote.
2. Push Menu button and bring up OSD Display
Menu.
3. Move using the _/_ arrow keys to select the TV
Tuner Menu.
4. Using the _/_ arrow keys or the MENU key,
step down into the menu and highlight the Auto
scan function. Push _ arrow key and Channel
Scan will commence.
5. Once completed, switch channels by using the
CH _/_ arrow keys on the remote. Using the
_/_ arrow keys will change the channel that is
displayed on the CH edit area.
6. To ADD/DEL channels step down into the CH
edit function to select channel to be added or
deleted.
7. Step down to the Status function and using the
_/_ arrow keys select Off or On depending on
whether you want to delete or add the channel.
8. Adjust VOL + or VOL - to preference.
9. Enjoy watching TV!

11
Controls & Connections
This section describes the front panel controls, and remote control in more detail.
Front View of the Product
Use the buttons on the front panel control to display and adjust the On Screen Display (OSD).
The OSD controls are explained at the bottom of the page and are defined in the “OSD
Functions” section.
Button Mode TV Source PC Source
Input
Menu
OSD
Menu
Contrast
Mode
Volume
Menu
Brightness
Menu
1Input /
Display input menu.
Hold for 2secs, and then press
again to set power savings level.
Hold for 2secs, and
then press again to
set power savings
level.
Scroll
down
2 Menu Display OSD menu
Scroll
down
Scroll down
3 - / Contrast CH- Display contrast
menu
Scroll up
Navigate
left
Decrease
contrast
Decrease
volume
Decrease
brightness
4 + / Brightness CH+ Display brightness
menu
Select
input
source
Navigate
right
Increase
contrast
Increase
volume
Increase
brightness
5Exit / Volume
Control Display volume menu Display volume
menu
Exit input
menu
Exit OSD
menu
Exit
contrast
menu
Exit volume
menu
Exit
brightness
menu
6 Auto Auto-adjust PC
image.
7Power ON or OFF ON or OFF
Control keys are shown
in detail below
Speaker
IR Receiver
7
1 2 3 4 5 6

12
Remote Control
The Remote Control should be used within 5 meters of the LCD TV.
1. POWER
Switch the power between on & off
2. SLEEP
Use to shut off TV after a period of time
3. MTS
Multi-language, stereo and mono selection
4. MUTE
Switch the sound between on & off
5. CHANNEL NUMBER KEY 0-9, 100
Direct channel selection by number
6. VOLUME _/_
Volume Up/Down adjustment; also
available on key controls and OSD menu
control
7. CHANNEL _/_
Channel Up/Down adjustment; also
available on key controls and OSD menu
8. _/_ Arrow Keys
Step Down into OSD Menus
9. MENU
Press to enter into OSD Menus
10._/_ Arrow Keys
Allows for adjustment of OSD functions and
Navigating the OSD Menus; also available
on key controls.
11.PIP
Available only in Analog Mode, used to
navigate through the PIP OSD menus.
Audio for PIP is also controlled from the
menus.
12.CC
Set Closed Caption and Text modes toggle
through OFF, CC1, CC2, CC3 etc.
13.V-Chip
Set Parental and Movie Rating
Block/UnBlock features. Navigation
through OSD menus. Pin Code is also set
here.
14.BACK
Exits from the current OSD menu back-up
one level.
15.AV1 - CVBS
Push to select composite video source
16.S-VIDEO
Push to select S-Video source
17.YPbPr
Push to select component video source
18.TV
Set source to TV tuner
19.Analog
Push to select PC VGA source
20.DISPLAY
Display the channel information
21.PREV. CH
Recall the previous channel

13
Input/
The input and PC display mode allows the user to select the source by depressing the input
button and cycling through each source, selecting menu on the remote will select the source.
Display Modes
Pressing the Input/ button on the control keys for more than 2 seconds will result in placing
the LCD TV into a unique display mode. There are 3 modes that the user can select.
Economy, Text and Picture. To toggle between these modes press the Turbo key again until
the mode you desire is selected. These modes automatically change the backlighting levels
between bright, brighter and brightest.
Auto
Pressing the AUTO button on the control keys while in analog PC mode will adjust
automatically the picture and synch the LCD TV monitor.

14
OSD Functions
This section describes each on-screen display (OSD) command. There are different OSD
menus depending on whether you are in TV mode or Analog PC mode.
All the function settings for your LCD TV display are controlled either via the remote control or
using the control keys located on the bottom right of the front panel. To display the OSD main
menu, press the Menu button on the control keys or the MENU key on the remote control.
Use either the Menu key or the _/_ arrow keys to navigate within the menus. The _/_ arrow
keys are used to change the values of the functions that are selected in the OSD menu. The
BACK key on the remote control or Exit button on the control keys allows you to exit out of the
OSD menus and functions.
The OSD menu display will disappear automatically after 10 seconds, if no action is taken. To
adjust the time the OSD menu displays go to the following OSD Menu:
Main TV Menu
Function Name Explanation
Brightness Brightness adjustment
Contrast Contrast adjustment
Color Adjust the Color Levels
Hue Adjust the Video Hue level
Sharpness Adjust the Video Sharpness
Recall Reset to default settings
Enter OSD Menus by
pressing MENU key

15
Audio Adjustment Menu
Selecting this menu and using the _/_ arrow keys will change the values of the functions that
are selected in the OSD menu.
OSD Language Menu
Selecting this menu and using the _/_ arrow keys will change the language displayed and
used for the OSD menus. There are 9 OSD menu languages available.

16
TV Channel Scanning Menu
Selection of this menu provides for the scanning of the antenna input source in order to tune in
channels. Using the _/_ arrow keys will toggle between the yes and no selections. To
add/delete a channel move to the Status selection and toggle between off and on.
Function Name Explanation
Auto Scan Selecting yes will start to program the channels available from the antenna
input source.
Blue Screen Toggle between video blanking between channel changes default is No
Ch Edit Select the channel to Edit using _/_ arrow keys
Status Select Off to delete channel and On to add channel.
OSD Menu
Selecting this menu allows for the control of the OSD menus. Using the _/_ arrow keys will
change the values of the each function in the menu.

17
Function Name Explanation
Black Level Sets the backlight level of the LCD TV – Default value is 50
OSD Time-out Sets the time in seconds that the OSD menu is displayed. Default value is 10
seconds. Range from 0 – 60 seconds.
OSD Position Sets the position of the OSD menus on the display. Default is 1 which is
upper left corner.
Antenna/CATV Input Menu
Selecting this menu chooses the source when tuning the TV. The selections available are
between Air which will tune between channels 2-69 and a cable TV source which will tune
between channels 1-125. For different cable systems the choices are between STD, IRC or
HRC. Default setting for the LCD TV is set to STD.

18
V-Chip and Parental Control Menu
To access the PARENTAL CONTROL menu press the V-Chip button located on the remote
control. Enter the Pin Code (default is 0000).
To change the Pin Code select the following menu. Pin Code default is 0000.

19
MOVIE Rating Menu
Set the Movie Ratings to block selected Movie channels. U – Unblock, B – Block.
Function Name Explanation
MOVIE RATING G:
PG:
PG 13:
R:
NC 17:
X:
General audience
Parental Guidance suggested
Parents strongly cautioned
Restricted
No one 17 and under admitted
Adult audience only
TV RATING
Y:
Y7:
G:
PG:
14:
MA:
<<< AGE >>>
All Children
Directed to Older Children
General Audience
Parental Guidance Suggested
Parents Strongly Cautioned
Mature Audience Only
