Westinghouse LTV-20V4 Assembly instructions

Westinghouse Digital Electronics
Power Button
Keypad
CONGRATULATIONS on pur-
chasing a Westinghouse LCD
TV! This Quick Connect Guide
will help you get started in 3
easy steps. On the back you
will find information to maxi-
mize your LCD TV experience.
For complete installation,
usage instructions, and safety
precautions please refer to
the User’s Manual.
20”
QUICK
CONNECT
GUIDE
CONNECT THE
POWER
Use the enclosed AC
power cable to connect
to a power outlet.
CONNECT THE
TUNER
Connect either cable or
TV antenna wire to the
cable ready NTSC tuner
input labeled "ANT" on the
connection panel.
Note: This step can be skipped if
you do not use these options.
Refer to the table on the back for
connection to satellite set top
box or digital cable.
CONNECT A DVD
PLAYER
Connect a DVD player
to the component YPbPr
input (Red, Green, blue)
and the corresponding
component audio inputs.
Press the Power button
to turn on the LCD TV.
1
1
2
2
3
3
GO!
GO!
LTV-20v4 LCD TV
www.westinghousedigital.com
Video 1 (S-Video 1)/
Video 2 (S-Video 2)/YPbPr/ANT Inputs

MAXIMIZE
YOUR LCD TV
EXPERIENCE
You can attach your LCD TV to
a variety of electronic devices
including a digital cable or
satellite set top box, a game
console or a VCR. The chart
shows our recommendations
for the best quality picture for
these commonly used devices.
If you have trouble connecting
these or other devices, please
refer to the User’s Manual.
TYPICAL SETUP
• Progressive scan DVD players with YPbPr
• Game console action using Video Input
• VCR viewing and editing with S-Video
*Only if receiver outputs 480p
DID YOU KNOW THAT
YOUR LCD TV ALSO HAS:
• Integrated 3 W Stereo Speakers
• Progressive Scan
• Inverse 3:2 Pull Down
CHECK OUT
www.westinghousedigital.com for our:
• Versatile Décor Wall Mounting options
© 2005 Westinghouse Digital Electronics, LLC. All rights
reserved. Specifications subject to change without notice.
¼, Westinghouse and You can be sure... if it's Westinghouse are
trademarks of Westinghouse Electric Corporation and are
used under license.
MA-PS-0113-0501 Customer Service: 866.287.5555 • www.westinghousedigital.com
Use the source button on the remote control or keypad to navigate
between the TV, Video 1 (S-Video 1), Video 2 (S-Video 2) or YPbPr
inputs.
Digital Cable/
Satellite Receiver Good Better Better Best*
DVD Player Good Better Best
Game Console Good Better Best
VCR Good Better Best
YPbPr
Video S-VideoANT
VIDEO INPUTS
Note: The audio input is shared between Video and S-Video.
S Video Input 1
YPbPr Video Input
Video Input 1
Menu SourceChannel Volume
YPbPr Audio Input
Right Audio Input 1Left Audio Input 1
Video Input 2
Left Audio Input 2
S Video Input 2
Right Audio Input 2
ANT
