Westinghouse W2613 - 26" LCD TV User manual

Digital Television Transition Notice:
This device contains a digital television tuner, so it should receive digital over
the air TV programming, with a suitable antenna, after the end of full-power
analog TV broadcasting in the United States on February 17, 2009. Some older
television receivers, if they rely on a TV antenna, will need a TV Converter to
receive over the air digital programming, but should continue to work as before
for other purposes(e.g., for watching low-power TV stations still broadcasting in
analog, watching pre-recorded movies, or playing video games).
For more information, call the FCC at 1-888-CALL-FCC (1-888-225-5322) or
see www.DTV.gov. For information on the TV Converter program, and on
government coupons that may be used toward the purchase of one, see
www.dtv2009.gov,or call the NTIA at 1-888-DTV-2009.
Aviso Relativo A La Transición A Televisión Digital:
Este equipo incorpora un sintonizador de televisión digital, lo que le permitirá
recibir una programación digital televisada por aire, con una antena adecuada,
cuando se terminará la transmisión de alta potencia de la televisión analógica
en los Estados Unidos el 17 de febrero de 2009. Ciertos receptores de
televisión antiguos, si dependen de una antena de TV, necesitarán un
conversor de TV para recibir por el aire una programación digital, pero seguirán
funcionando como antes para otros usos (por ejemplo para ver emisoras de TV
de baja potenciaque todavía transmiten en analógico, para ver películas
pregrabadas, o para utilizar sus videojuegos).
Para obtener más información, llame FCC 1-888-CALL-FCC (1-888-225-5322)o
refiérase a www.DTV.gov. Para toda información sobre el programa
deconversores de TV, y acerca de los cupones del gobierno que se puedenusar
para comprarlos, refiérase a www.dtv2009.gov, o llame al NTIA al1-888-DTV-
2009.
MA-FO-0315-0702

1
TABLE OF CONTENTS
FOR YOUR SAFETY ……………………………….…………………. ....3
PRCAUTIONS AND REMINDERS ………………………….………......4
IMPORTANT SAFETY INSTRUCTIONS …………………….……… ...6
PREPARATION ……………………………………………….……….. .... 8
PERIPHERAL CONNECTION GUIDE ………………………..…….. ..10
OPERATING INSTRUCTIONS …………………………………….… .. 11
TO USE THE FRONT PANEL CONTROL ............................ .. 11
TO USE THE REMOTE CONTROL ........................................ 12
TO USE THE MENUS …………………………………..…….. .. 13
SETUP MENU …………………………………………..……… .. 13
VIDEO MENU ………………………………………..…………....14
AUDIO MENU ………………………………………..………… ...15
FEATURE MENU ……………………………………………….... 16
TIPS ……………………………………………………………… ..20
PRODUCT SPECIFICATION ………………………………...………. .. 22
BEFORE CALLING SERVICE ……………………………………….. ..24
GLOSSARY ……………………………………………………………....25
APPENDIX ………………………………………………………….….. .. 26
English

2
SYMBOL SYMBOL DEFINITION
SA 1965
DANGEROUS VOLTAGE: The lightning flash with
arrowhead symbol, within an equilateral triangle, is
intended to alert the user to the presence of uninsulated
“dangerous voltage” within the product’s enclosure that
may be of sufficient magnitude to constitute a risk of
electrical shock to persons.
SA 1966
INSTRUCTIONS: The exclamation point within on
equilateral triangle to alert the User to the presence of
important operating and maintenance (servicing)
instruction In the literature accompanying the appliance.
Apparatus shall not be exposed to dripping or splashing and no objects filled
with liquids, Such as vases, Shall be placed on the apparatus.
Caution - Danger of explosion if battery is incorrectly replaced. Replace only
with the same or equivalent type.

3
FOR YOUR SAFETY
Before operating the TV please read this manual thoroughly. This manual should
be retained for future reference.
FCC Class B Radio Frequency Interference Statement
WARNING: (FOR FCC CERTIFIED MODELS)
NOTE: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy, and if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
1. Reorient or relocate the receiving antenna.
2. Increase the separation between the equipment and receiver.
3. Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
4. Consult the dealer or an experienced radio/TV technician for help.
NOTICE
1. The changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate the
equipment.
2. Shielded interface cables and AC power cord, if any, must be used in order to
comply with the emission limits.
3. The manufacturer is not responsible for any radio or TV interference caused
by unauthorized modification to this equipment. It is the responsibilities of the
user to correct such interference.
WARNING:
To prevent fire or shock hazard, do not expose the TV to rain or moisture.
Dangerously high voltages are present inside the TV. Do not open the cabinet.
Refer servicing to qualified personnel only.
SAFETY: Lamp Disposal
LAMP(S) INSIDE THIS PRODUCT CONTAIN MERCURY AND MUST BE RECYCLED
OR DISPOSED OF ACCORDING TO LOCAL, STATE OR FEDERAL LAWS. FOR MORE
INFORMATION, CONTACT THE ELECTRONIC INDUSTRIES ALLIANCE AT
WWW.EIAE.ORG.

4
Place unit on even surfaces. Don't place the TV in confined spaces
or in a box when using it.
Unplug immediately if is malfunction
like no picture, no video/audio,smoke
and bad odor from TV.
Unplug immediately if other foreign
materials are put inside TV box or if
the TV fell down.
Don't throw any object inside the TV
box like metals or other flammable
materials.
Prohibit/Avoid opening TV cabinet
PRECAUTIONS AND REMINDERS

5
Remember to unplug the AC cord
from the AC outlet before cleaning. Do
not use liquid cleaners or aerosol
cleaners to clean the display.
Avoid direct sunlight, dusty, high
humidity and smoky areas.
Make sure to unplug the unit when not
in use for a long period of time (days).
Call service personnel to clean the
internal part of the TV once a year.
Do not cover or block any vents and
openings. Inadequate ventilation may
shorten the life of the display unit and
cause overheating.
Do not place the display near water,
such as bathtub, washbasin, kitchen
sink laundry tub, swimming pool or in
a damp basement.
Notice for Remote Controller
Avoid Dropping Avoid Liquids Avoid Aerosol Cleaners
123
4
56
789
0
12
3
45
6
789
0
1
23
456
789
0

6
Read before operating equipment
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with a dry cloth.
7. Do not block any of the ventilation openings. Install in accordance with the
manufacturers instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves,
or other apparatus (including amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding type plug. A
polarized plug has two blades with one wider than the other. A grounding
type plug has two blades and third grounding prong. The wide blade or third
prong is provided for your safety. When the provided plug does not fit into
your outlet, consult an electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at plugs,
convenience receptacles, and the point where they exit from the apparatus.
11. Only use attachments/accessories specified by the manufacturer.
12. Use only with a cart, stand, tripod, bracket, or table specified by the
manufacturer, or sold with the apparatus. When a cart is used, use caution
when moving the cart/apparatus combination to avoid injury from tip-over.
13. The TV should be operated only from the type of power source indicated on
the label. If you are not sure of the type of power supplied to your home,
consult your dealer or local power company.
14. Unplug this apparatus during lightning storms or when unused for long
periods of time.
15. Refer all servicing to qualified service personnel. Servicing is required when
the apparatus has been damaged in any way, such as power-supply cord or
plug is damaged, liquid has been spilled or objects have fallen into apparatus,
the apparatus has been exposed to rain or moisture, does not operate
normally, or has been dropped.
16. This product may contain lead or mercury. Disposal of these materials may
be regulated due to environmental considerations. For disposal or recycling
information, please contact your local authorities or the Electronic Industries
Alliance: www.eiae.org
17. Damage Requiring Service – The appliance should be serviced by qualified
service personnel when:
A. The power supply cord or the plug has been damaged; or
B. Objects have fallen, or liquid has been spilled into the appliance; or
C. The appliance has been exposed to rain; or
IMPORTANT SAFETY INSTRUCTIONS

7
D. The appliance does not appear to operate normally or exhibits a marked
change in performance; or
E. The appliance has been dropped, or the enclosure damaged.
18. Tilt/Stability – All televisions must comply with recommended international
global safety standards for tilt and stability properties of its cabinets design.
yDo not compromise these design standards by applying excessive pull
force to the front, or top, of the cabinet, which could ultimately overturn
the product.
yAlso, do not endanger yourself, or children, by placing electronic
equipment/toys on the top of the cabinet. Such items could
unsuspectingly fall from the top of the set and cause product damage
and/or personal injury.
19. Wall or Ceiling Mounting – The appliance should be mounted to a wall or
ceiling only as recommended by the manufacturer.
20. Power Lines – An outdoor antenna should be located away from power lines.
21. Outdoor Antenna Grounding – If an outside antenna is connected to the
receiver, be sure the antenna system is grounded so as to provide some
protection against voltage surges and built up static charges.
Section 810 of the National Electric Code, ANSI/NFPA No. 70-1984, provides
information with respect to proper grounding of the mats and supporting
structure grounding of the lead-in wire to an antenna-discharge unit, size of
grounding connectors, location of antenna-discharge unit, connection to
grounding electrodes and requirements for the grounding electrode. See
Figure below.
EXAMPLE OF ANTENNA GROUNDING AS PER NATIONAL ELECTRICAL
CODE
Note to the CATV system installer: This reminder is provided to call the
CATV system installer’s attention to Article 820-40 of the NEC that provides
guidelines for proper grounding and, in particular, specifies that the cable
ground shall be connected to the grounding system of the building, as close
to the point of cable entry as practical.
Please, make sure to connect the power plug to the wall outlet socket after
connecting the TV to the adapter!
22. Objects and Liquid Entry – Care should be taken so that objects do not fall
and liquids are not spilled into the enclosure through openings.

8
Please, make sure to connect the power plug to the wall outlet socket after
connecting the TV to the power cord!
1. Install the base stand; place the TV on a solid surface.
Ensure that the TV is placed in a position to allow free flow of air. Do not cover
the ventilation openings on the back cover.
To prevent any unsafe situations, no naked flame sources, such as lighted
candles, should be placed on or in the vicinity.
Avoid heat, direct sunlight and exposure to rain or water. The equipment shall
not be exposed to dripping or splashing.
2. Connect the antenna cable or CATV cable to the aerial socket ANT IN 75Ωat
the back of the TV set.
PREPARATION

9
3. Remote control:
Remove the cover of the battery compartment. Insert the 2 batteries supplied
(Type AAA 1.5V).
4. Power:
Insert the power cord in the wall socket having an AC power supply. You can
see LED states at the front panel. If the LED color is Blue, means the TV set is
power on. If the LED color is Red,which means this TV set is in standby state.
5. Turn the TV on:
Push the POWER key on the Remote control or the Front panel control knobs.
Wait a minute, the TV will power on and can see the display on the screen
Power Key

10
HDMI S-Video Composite Pr Pb Y PC Line in 15-pin D-Sub
Once your equipment is connected, use the following procedure to view the input
signal:
Press the Source button or direct input buttons on the remote controller to select
the relevant source to view. (ex: Press Video button to select “Composite” if you
have connected a video recorder to Composite socket.)
Note: For W2613, only HDMI 1 is available.
PERIPHERAL CONNECTION GUIDE

11
TO USE THE FRONT PANEL CONTROL
1. VOL +
VOL +: Press to increase the sound volume level.
2. VOL -
VOL - : Press to decrease the sound volume level.
3. CH ▲
CH +: Press to select the next higher Program number.
4. CH ▼
CH - : Press to select the next lower Program number.
5. MENU
Menu key: Press to open or exit the OSD menu.
6. INPUT
Source key: Press to select the input source.
7. POWER
Power key: Press to turn on / off (standby) the TV set.
(Please re-turn on TV after the Power-ON status LED had
changed to the Red color and finished flashing.)
OPERATION INSTRUCTIONS

12
TO USE THE REMOTE CONTROL
Power
Video
123
456
789
0
PREV CH
Comp PC/HDMI TV
Sleep
Fav Source
Mute
Menu Exit
ENTER
V-Chip
Video Adj Audio Adj
C.C.
Info
VOLCH
EPG
Freeze ZoomMTS/SAP
Power:
Press to power ON/OFF (standby)
TV.
Note:
1. TV is never completely power off
unless physically unplugged.
2. Press Power Key to turn on TV
after the power status LED had
changed to red color and stopped
flashing.
Video:
Press repeatedly to choose S-
Video/Composite source mode
Comp:
Press repeatedly to choose
Component source mode
PC/HDMI:
Press repeatedly to choose VGA or
HDMI source mode.
TV:
Press to choose TV source mode.
0~9/- number:
Press to enter TV channel number
to select channel (press ‘-‘ to
indicate of choosing the sub-
channel).
Sleep:
Press to set sleep timer (off/5 min/
10 min/15 min/30 min/45 min/60
min/90 min/120 min/180 min/240
min) for TV to switch to standby
mode automatically.
Freeze:
Press to freeze the displayed picture
CH+/CH-:
Press + or – to browse through the
TV channels.
Menu:
Press to open or exit menu.
Direction keys and ENTER:
Press to adjust the various function
items on the menu.
PREV CH:
Press to display the previous TV
channel.
MTS/SAP:
Press to activate the NTSC TV
sounds, such as: Stereo, SAP or
Mono tone, and languages of DTV.
Zoom:
Press to choose the display aspect
as: Standard, Fill and Overscan
mode.
Source:
Press repeatedly to choose the
various input sources.
EPG:
This function is not support.
Mute:
Press to set TVsound mute ON/OFF
Info:
Press to show the information about
the input source, TV channel,
display resolution.
VOL- / VOL+:
Press + or - to adjust the volume.
Exit:
Press to exit menu or OSD.
V-Chip:
Press to lock / unlock Parental
Control temporarily. (After setting
the restricted table of MPAA or TV
Rating.)
Video Adj:
Press to choose the Brightness or
Contrast adjustment.
Audio Adj:
Press to switch the ATSC multi-
channel TV sounds.
C. C.:
Press repeatedly to change the
closed caption type as CC ON/CC
OFF/CC ON WHEN MUTE.

13
TO USE THE MENUS
1. Press the Menu button to display the main menu
2. Use the cursor Up/Down to select a menu item.
3. Use the cursor Left/Right to enter a submenu.
4. Press the ENTER button to enable/disable the function.
5. Press the Menu or Exit button to exit the menu.
Press the Menu button to enter the main OSD (On Screen Display). Adjust the
items including Setup menu, Video menu, Audio menu and Feature menu.
However, some function items in the menus may only be enabled in the particular
source modes.
SETUP MENU
The Setup menu in TV mode shows as below. In others source modes, the Setup
menu only shows Menu Language and Aspect Ratio items.
1. Tuning Band: Select TV source signal from the Air (antenna) or Cable
(CATV).
2. DTV Signal: Show the intensity of the received DTV signal.
3. Auto Ch Search: Automatically scan all NTSC / ATSC TV channels
and then store in the channel table. In channel scan process, the OSD
can display the number of channels which had been found.
4. Add on Ch search:Add channels which are new found.
5. Manual Channel Set: Show the channel setup table. User can choose to
display the ATSC or NTSC TV channels and then edit the channel (Viewable
or Not Viewable by pressing Enter button). User won’t be able to view the

14
channel that has been set to Not Viewable when toggling through channels.
However, the channels are still accessible when user enters the channel
number.
6. Channel Labels: Show the NTSC / ATSC TV channel label menu for user
modifying channel labels specifically.
7. Menu Language: Select the menu display language. (English / Espanol /
Francais)
8. Aspect Ratio: Select the display aspect ratio. (Standard/Fill/Overscan)
9. Favorite Channel Mode: When favorite channel mode is on, user can edit
favorite channel table in favorite channel set option.
VIDEO MENU
The Video menu in most source modes shows as below. It provides several video
adjustment items for user fine tuning the video display. Only in VGA source
modes, the Video menu simply provides Contrast,Brightness, Back light and
Settings (Preset) items.
1. Contrast: Video contrast adjustment, the tuning range is 0 ~ 100.
2. Brightness: Video brightness adjustment, the tuning range is 0 ~ 100.
3. Sharpness: Video sharpness adjustment, the tuning range is -50 ~ 50.
4. Color: Video color chroma adjustment, the tuning range is 0 ~ 100.
5. Tint: Video tint adjustment, the tuning range is R50 ~ G50.
6. BackLight: Backlight strength adjustment, the tuning range is 0 ~ 10.
7. Settings: Restore the default video settings.

15
AUDIO MENU
The Audio menu in TV mode shows as below. It provides audio adjustment for
user to modify the audio setting. Audio language setting is only available with
ATSC TV source, the option is disable under other source modes.
1. Audio Language: Change the audio language setting on ATSC TV
programs The number of the supported audio languages depends on the
ATSC TV programs.
2. Bass: Bass tone adjustment, the tuning range is 0 ~ 63. (The default state is
enabled)
3. Treble: Treble tone adjustment, the tuning range is 0 ~ 63. (The default state
is enabled)
4. Balance: Audio balance adjustment, the tuning range is L31 ~ R31.)
5. Digital Audio Output: Digital audio output format selection, user can
choose RAW (default) or PCM format or off.
6. TV Speaker: Choose to turn on / off the TV internal speaker. The digital
audio output signals、earphone output signals will not be turn-off even
though the TV speaker is off. The default setting is On.
7. Settings: Restore the default audio settings.

16
FEATURE MENU
The Feature menu in TV mode shows as below. It provides certain optional
control functions such as time set, sleep timer, advanced video menu, Password
Set, parental control (V-chip) and Digtal closed caption setting. This menu gives
users the most flexibilities to satisfy their generally demands. According to the
various requirements in different source modes, certain features should be hidden
(disable) on the menu. The details footnotes will be described clearly below.
1. Time Set: Set current time. This sub-menu includesTime Set Mode ,Time
Zone and Time items. 【Time Set Mode】user can choose Auto or Manual,
【Time Zone】item provides user to set current time zone, such as: Pacific,
Alaska, Hawaii, Eastern, Central and Mountain.
【 Time 】 item provides user
to set the time clock.
2. Sleep Timer: Enable or disable the TV standby timer. User can set the TV
standby timer
as off / 5 min / 10 min / 15 min/ 30 min / 45 min / 60 min/ 90
min / 120 min / 180min/ 240min. Timer starts to count down after cursor
leaving the sub-menu. (At the moment, the item shows 『** min Left』and
the cursor highlights on the Feature icon.)

17
3. Advanced Video Menu: Provide the Noise Reduction、Color Temperature
and 3D Y/C. Dynamic Contrast options for enhancing video quality.
【 Noise Reduction 】 gi ves four NR effect degrees, such as: Low, Mid, High and
Off. The default setting is Mid.
【 Colour Temp 】 gives three color temperature modes as: Normal、Warm and
Cool.
【 3D Y/C 】 provides On / Off switches. The default setting is On.
【 Dynamic Contrast 】 user can choose 0n or Off.
【 Setting 】 restores the default advanced video option settings.
4. Password Set: Change the 4-numeral parental control password. Three
steps are required for changing the password: Enter Old Password -> Enter
New Password -> Confirm New Password. Note: This item is only available in
TV, Composite and S-Video source modes. The default password is 『0 0 0
0』.
5. Parental Control: provide the parental Control (V-chip) function setting.
Before entering the Parental Control sub-menu, user has to key in the
password first. Then enter the Parental Lock item, User can modify the
restricted table about MPAA or TV Rating respectively. While exiting the sub-
menu, the parental control function is working. The inhibitive channels or
source signals can be un-lock through pressing the V-CHIP key on the
remote control and then key in the correct password. Note: This feature is
only available in TV, Composite and S-Video source modes. (The default
password is: 0 0 0 0.)

18
6. Digital Captions: Select the close caption options ( Service 1-6, Text
1-4 and CC 1-4) in digital TV mode. When select service 1 to service
6 you canmodulate parameters in the Digital Close Caption.
7. Digital Close Caption: Provide numerous options for setting the digital close
caption style. In the sub-menu.
【Style】item can be set as Automatic or Custom mode. If Custom mode is
selected, user can modify the detail styles described below. The setting result
will be shown immediately on the bottom side of the sub-menu OSD. Note:
This feature is only available in Digital TV(ATSC) mode.
【Size】: Digital close caption font size, which can be set as Small、Normal
or Large.
【Font】: Digital close caption font style, which can be chosen as Default or
Font 1 ~ 7.
【Text Color】: Giving Red / Green / Blue/ Yellow / Magenta / Cyan / Black /
White Colors.

19
【Text Opacity】: Giving Transparent / Translucent / Solid / Flashing modes.
【Background Color】: Giving Red / Green / Blue / Yellow / Magenta / Cyan /
Black / White Colors.
【Background Opacity】: Giving Transparent / Translucent / Solid / Flashing
modes.
【Edge Effect 】: The text edge effects, which gives None / Raised /
Depressed / Uniform / Left Shadow / Right Shadow
modes.
【Edge Color】: The colors of text edge effects, which provides Red / Green
/ Blue / Yellow / Magenta / Cyan / Black / White Colors.
8. Component Set: This option only shows and is available in component mode,
which provides fine tuning component display, such as: 【H-
Position】、【V-Position】, 【Clock】and【Phase】(Auto Adjust function is
not supported under Component mode). All these items are giving the tuning
range from 0 to 100.【Setting】item provides the default component setting
values restoring.
9. VGA Set: This option only shows and is available in VGA mode, which
provides several items for the VGA display fine tuning, such as : 【H-
Position】、【V-Position】、【Clock】, 【Phase】, and【Auto Adjust】. All
these items giving the tuning range from 0 to 100.【Setting】item provides
the default VGA setting values restoring.
