Weston 01-0101 User manual

MOTOR ATTACHMENT
01-0101
twospeed
*TOMATO PRESS & SAUCE MAKER AND THE TRADITIONAL PASTA MACHINE ARE SOLD
SEPARATELY. DUE TO CONSTANT FACTORY IMPROVEMENTS, THE PRODUCT PICTURED
MIGHT DIFFER SLIGHTLY FROM THE PRODUCT IN THIS BOX. 011615

TABLE OF CONTENTS / ÍNDICE / TABLE DES MATIÈRES
2
GENERAL SAFETY RULES
COMPONENT LIST
GROUNDING INSTRUCTIONS
SWITCH INSTRUCTIONS
INSTALLING THE MOTOR ONTO TOMATO PRESS
REMOVING A JAM
INSTALLING THE MOTOR ONTO PASTA MACHINE
ATTACHING THE MOTOR ONTO PASTA MACHINE
RAVIOLI ADAPTER
RECIPES
FOOD SAFETY
WARRANTY
REGLAS IMPORTANTES DE SEGURIDAD
LISTA DE COMPONENTES
INSTRUCCIONES PARA HACER TIERRA
INSTURCCIONES DEL INTERRUPTOR
CÓMO INSTALAR EL MOTO EN LA MÁQUINA PARA PREPARAR SALSAS Y COLADOR DE ALIMENTOS
CÓMO ELIMINAR UN ATASCO DEL COLADOR DE ALIMENTOS CON EL ACCESORIO DEL MOTOR
CÓMO INSTALAR EL MOTOR EN LA MÁQUINA DE HACER PASTA
CÓMO ACOPLAR EL MOTO SOBRE LOS ACCESORIOS DE LA MÁQUINA DE HACER PASTA
INSTURCCIONES DEL ADAPTADOR PARA RAVIOLI
RECTAS
SEGURIDAD DE LOS ALIMENTOS
INFORMACIÓN DE GARANTÍA WESTON
IMPORTANTES RÉGLES DE SÉCURITÉ
DESCRIPTION DE LA PIÈCE
INSTRUCTIONS DE MISE À LA TERRE
DIRECTIVES POUR COMMUTATEUR
INSTALLATION DE MOTEUR SUR LA PASSOIRE ALIMENTAIRE ET LE SAUCIER
DÉCOINCER UNE PASSOIRE ALIMENTAIRE AVEC L’ACCESSOIRE À MOTEUR
INSTALLATION DU MOTEUR LA MACHINE À PÂTES
FIXER LE MOTEUR AUX ACCESSOIRES DE MACHINE À PÂTES
DIRECTIVES POUR L’ADAPTATEUR POUR RAVIOLI
RECETTES
SÉCURITÉ ALIMENTAIRE
INFORMATION SUR LA GARANTIE
3
4
5
5
6
7
8
9
9
10
11
12
14
15
16
16
17
18
19
20
21
22
23
24
26
27
28
28
29
30
31
32
32
33
34
35

1. ALWAYS DISCONNECT motor from
power source before servicing, changing
accessories or cleaning the unit.
2. Plug the motor into a standard 120 Volt
wall outlet. Avoid using extension cords.
3. DO NOT USE this motor if the power
cord, plug or any other parts are damaged.
DO NOT ATTEMPT TO REPLACE THE
CORD. DO NOT allow the power cord to
hang into your work area. Check that all
parts are operating properly, and perform
the intended functions. Check for alignment
of moving parts or any other conditions that
may affect the operation.
4. NEVER use any accessories or parts from
other manufacturers. Doing so will void your
warranty. Use this motor for its intended use
only.
5. Thoroughly clean all parts that will come
in contact with food before using. DO NOT
SUBMERGE THE MOTOR BODY INTO
WATER OR LIQUID. BE SURE THE
MOTOR IS DISCONNECTED FROM THE
POWER SOURCE BEFORE CLEANING.
Wash all parts by hand and thoroughly dry.
Never rinse motor under faucet, only use a
moist cloth to clean the motor unit.
6. Reduce risk of unintentional starting.
Make sure the power switch is in the “OFF”
position before attaching to the power
source.
GENERAL SAFETY RULES
READ AND FULLY UNDERSTAND ALL INSTRUCTIONS AND WARNINGS
PRIOR TO USING THIS UNIT. YOUR SAFETY IS MOST IMPORTANT!
FAILURE TO COMPLY WITH PROCEDURES AND SAFE GUARDS MAY
RESULT IN SERIOUS INJURY OR PROPERTY DAMAGE. REMEMBER:
YOUR PERSONAL SAFETY IS YOUR RESPONSIBILITY!
SAVE THESE INSTRUCTIONS
7. Keep ngers clear of the moving parts
at all times. Wait until all moving parts
have stopped before you remove any part
of the appliance.
8. KEEP CHILDREN AWAY. NEVER
LEAVE THE MOTOR UNATTENDED.
Be safe, DISCONNECT from power
source before leaving the work area.
9. TIE BACK loose hair and clothing, and
roll up long sleeves before operating the
appliance. REMOVE ties, rings, watches,
bracelets or other jewelry before operating
the appliance.
10. Be sure the appliance is on a stable
work surface. Be sure all the appliance
feet are stable.
11. DO NOT use outdoors. DO NOT use
or store on, in, or near stove or oven.
12. DO NOT use the motor while under
the inuence of drugs or alcohol.
3
ENGLISH INSTRUCTIONS

ENGLISH INSTRUCTIONS
4
COMPONENT LIST
DIAGRAM NUMBER PART DESCRIPTION PART NUMBER
1 MOUNTING BRACKET FOR THE
TOMATO PRESS & SAUCE MAKER N/A
2 BRACKET MOUNTING BOLT N/A
3 MOTOR MOUNTING BRACKET N/A
4 ELONGATED WASHER N/A
5 MOVABLE ARM N/A
6 ALLEN WRENCH N/A
7 RAVIOLI ATTACHMENT ADAPTER 01-0210
Motor
1
3
4
5
6
7
Selector Switch
Pulse Button
Power Cord
2
If any components of this unit are broken, the unit does not operate properly or you
need a replacement instruction manual, visit us on the web at
WestonProducts.com
Or call Weston Brands LLC Toll Free at 1-800-814-4895
Monday thru Friday 8:00am-5:00pm ET. Outside the U.S. call 001-440-638-3131

SWITCH INSTRUCTIONS
• The Motor has a Selector Switch that has two
speed settings. The rst speed is the slow speed,
marked “I”, the second speed is the fast speed
is marked “II”. The off position is marked “O”.
FIGURE 1
• The Motor also has a Pulse Button. Pressing this
button will engage the Motor in its slow speed until
you release the button. This feature is designed
for use with a ravioli attachment. It allows rapid
starting and stopping of the Motor when lling
ravioli. FIGURE 1
Selector
Switch
Pulse
Button
FIGURE 1
WARNING! Before cleaning, assembling or disassembling the
Motor Attachment, make sure the Motor is in the OFF Position (O)
and the PLUG IS REMOVED FROM THE OUTLET/POWER SOURCE!
5
ENGLISH INSTRUCTIONS
GROUNDING
This appliance must be grounded while in use
to protect the operator from electrical shock.
The appliance is equipped with a 3-conductor
cord and a 3-prong grounding type plug to t
the proper grounding-type receptacle. The
appliance has a plug that looks like Figure
A. An adapter, Figure B, should be used
for connecting Figure A plugs to two-prong
receptacles. The grounding tab which extends
from the adapter must be connected to a
permanent ground such as a properly grounded
outlet box as shown in Figure C using a metal
screw.
EXTENSION CORDS
Use only 3-wire extension cords which have
3-prong grounding-type plugs and a 3-pole
cord connector that accepts the plug from the
appliance. Use only extension cords having
an electrical rating not less than the rating of
the appliance. Do not use damaged extension
cords. Examine extension cord before using and
replace if damaged. Do not abuse extension
cord and do not yank on any cord to disconnect.
Keep cord away from heat and sharp edges.
FIGURE A
FIGURE B
FIGURE C
Circuit
Grounding
Conductor
Grounding
Prong
Metal
Grounding
Screw
Cover of
Grounded
Outlet Box
Grounding
Means
AA2220
GROUNDING INSTRUCTIONS

1. Making sure that the Tomato
Press & Sauce Maker is securely
mounted to the work surface, remove
the two screws from the neck of the
body. FIGURE 2
2. Attach Mounting Bracket
using the two screws that were
removed in #1. FIGURE 3
3. Insert the Bracket Mounting
Bolt through the hole in the Motor
Mounting Bracket. Attach the
Elongated Washer to the back of the
Bolt loosely.
4. Slide the Elongated Washer on
the Motor Mounting Bracket into the
large hole of the Mounting Bracket
by inserting the long end of the
Elongated Washer rst followed by
the shorter end. FIGURE 4
5. Position the Motor Mounting
Bracket horizontally.
6. Using the supplied Allen Wrench,
tighten the Bracket Mounting Bolt
rmly, securing the Motor Mounting
Bracket to the Mounting Bracket.
7. With the Power Switch of the
Motor facing up, line up the Motor
Shaft with the drive hole on the and
rotate the Motor into place. Allow
the left side of the Motor to come to
rest on the Motor Mounting Bracket.
FIGURE 5
8. After Motor is positioned on the
Motor Mounting Bracket, rotate the
Movable Arm counter-clockwise so it
is positioned on the Motor. FIGURE 5
9. Once Motor is attached and you
haveveried the Power Switch is in
the off position (O), plug the unit into
the power source.
INSTALLING THE MOTOR ONTO
THE TOMATO PRESS & SAUCE MAKER
FIGURE 2
FIGURE 3
FIGURE 4
FIGURE 5
Neck
Remove
these
screws
Mounting
Bracket
Neck
Enlongated
Washer
Bracket
Mounting
Bolt
Motor
Mounting
Bracket
Mounting
Bracket
Movable
Arm
Motor
Mounting
Bracket
Motor
ENGLISH INSTRUCTIONS
6

NOTE: This Motor DOES NOT have a reverse speed. If the Tomato Strainer
should become jammed:
1. Switch the Motor off immediately
2. Unplug the Motor from the power source
3. Pivot the Movable Arm away from the Motor
4. Remove the Motor from the Tomato Press & Sauce Maker.
5. Either insert the manual handle and rotate counter clockwise to free
the jam, or remove the splash guard/discharge chute and the stainless
screen to free the jam. If you remove the screen and squirt guard to remove
the jam, reassemble the Tomato Press & Sauce Maker before reattaching the
Motor and connecting to the power source.
REMOVING A JAM FROM THE FOOD STRAINER WITH THE
MOTOR ATTACHMENT
Follow all operating and assembly instructions for the as before, except now
instead of turning the handle, simply turn the Motor ON by selecting either slow
speed (Setting I) or high speed (Setting II).
7
ENGLISH INSTRUCTIONS
WARNING! Before cleaning, assembling or disassembling the
Motor Attachment, make sure the Motor is in the OFF Position (O)
and the PLUG IS REMOVED FROM THE OUTLET/POWER SOURCE!

The 2-Speed Electric Motor eliminates
the need for the c-clamp when setting up
your pasta machine.
1. Position the pasta machine on your
work surface with the drive holes of the
rollers facing you. FIGURE 6
2. Locate the Motor Mounting Bracket
and lay it on the work surface in front of
the drive holes.
3. Insert the Bracket Mounting Bolt
through the hole in the Motor Mounting
Bracket and position it into the hole that
is used by the c-clamp. FIGURE 6
4. After aligning the Bracket Mounting
Bolt with the c-clamp hole, attach the
Elongated Washer to the back of the
Bolt. Using the included Allen Wrench,
securely tighten the Motor Mounting
Bracket to the pasta machine. FIGURE 6
5. Rotate the Movable Arm clockwise to
the far right. This will allow easy access
for Motor placement.
6. Hold the Motor with the Power Switch
facing up and the Motor Shaft pointing
toward the pasta machine.
7. Line up the Motor Shaft with the drive
hole on the pasta machine and rotate
the Motor into place, allowing the left
part of the Motor to come to rest on the
Motor Mounting Bracket. FIGURE 7
8. After Motor is positioned on the Motor
Mounting Bracket, rotate the Movable
Arm counter-clockwise so it is positioned
on the Motor. FIGURE 7
9. Once Motor is attached and you have
veried the Power Switch is in the off
position (O), plug the unit into the power
source.
INSTALLING THE MOTOR ONTO THE PASTA MACHINE
Motor
Mounting
Bracket
Enlongated
Washer
Bracket
Mounting
Bolt
C-Clamp
Hole
Movable
Arm
Drive
Hole
Drive
Hole
Pasta
Machine
Movable
Arm
Motor
Mounting
Bracket
Motor
FIGURE 7
FIGURE 6
ENGLISH INSTRUCTIONS
8
WARNING! Before cleaning, assembling or disassembling the
Motor Attachment, make sure the Motor is in the OFF Position (O)
and the PLUG IS REMOVED FROM THE OUTLET/POWER SOURCE!

9
ENGLISH INSTRUCTIONS
1. Follow instructions 1 through 6 of the “INSTALLING THE MOTOR ONTO
THE PASTA MACHINE” instructions.
2. Line up the Motor Shaft with the drive hole on the pasta machine
attachment and rotate the Motor into place, allowing the left part of the Motor
to come to rest on the Motor Mounting Bracket.
3. After Motor is positioned on the Motor Mounting Bracket, rotate the Movable
Arm counter-clockwise so it is positioned on the Motor.
4. Once Motor is attached, and you have veried the Power Switch is in the off
position (O), plug the unit into the power source.
ATTACHING THE MOTOR ONTO THE PASTA MACHINE
ATTACHMENTS
RAVIOLI ADAPTER INSTRUCTIONS
The included Ravioli Adapter is to be used with
the ravioli attachment when using the Motor.
1. Follow instructions 1 through 5 of the
“INSTALLING THE MOTOR ONTO THE
PASTA MACHINE” instructions.
2. Install the Ravioli Adapter onto the Motor by
inserting the female end of the Ravioli Adapter
onto the male end of the Motor Shaft.
FIGURE 8
3. Line up the Motor and Adapter Shaft with the
drive hole of the ravioli attachment and rotate
the Motor into place, allowing the left part of the
Motor to come to rest on the Motor
Mounting Bracket. FIGURE 9
4. After Motor is positioned on the Motor
Mounting Bracket, rotate the Movable Arm
counter-clockwise so it is positioned on the
Motor.
5. Once Motor is attached and you have
veried the Power Switch is in the off position
(O), plug the unit into the power source.
NOTE: It is suggested when using the Motor
with the ravioli attachment, only use the
intermittent Ravioli Switch. This will allow you
to stop and start the Motor as you ll the ravioli.
Female End of
Ravioli Adapter
FIGURE 8
Male End of
Ravioli Adapter
FIGURE 9
Ravioli
Attachment
Ravioli
Adapter
Motor
Shaft
INSTALLING THE MOTOR ONTO THE PASTA MACHINE
WARNING! Before cleaning, assembling or disassembling the
Motor Attachment, make sure the Motor is in the OFF Position (O)
and the PLUG IS REMOVED FROM THE OUTLET/POWER SOURCE!

ENGLISH INSTRUCTIONS
10
INSTRUCTIONS
• Measure the semolina our into a bowl, or pour it in a mound onto a pastry board. Make a
well in the center of the our.
• Pour the beaten eggs or egg whites, oil and water into the well in the our.
• Mix together with a fork or your ngers until the dough can be gathered into a rough ball.
Moisten any remaining dry bits of dough with drops of water and press them into the ball.
• Knead the dough until all the ingredients are thoroughly blended, and the dough is the
same consistency throughout. If it sticks to your ngers, add some our a little at a time
just until it no longer sticks. If it seems too dry, add water a few drops at a time. The
dough will be stiff at this time; you will use the pasta machine to continue kneading it until it
is smooth, shiny and elastic.
SEMOLINA PASTA DOUGH
INGREDIENTS
1 ½ CUPS SEMOLINA FLOUR 2 EGGS OR 3 EGG WHITES,
BEATEN
2 TBSP WATER 2 TBSP OLIVE OIL
RECIPES
INSTRUCTIONS
• Measure the our into a bowl, or pour it in a mound onto a pastry board. Make a well in
the center of the our.
• Pour the egg, egg white, and oil into the well in the our.
• Mix together with a fork or your ngers until the dough can be gathered into a rough ball.
Moisten any remaining dry bits of dough with drops of water and press them into the ball.
• Knead the dough until all the ingredients are thoroughly blended, and the dough is the
same consistency throughout. If it sticks to your ngers, add some our a little at a time
just until it no longer sticks. If it seems too dry, add water a few drops at a time. The
dough will be stiff at this time; you will use the pasta machine to continue kneading it until it
is smooth, shiny and elastic.
WHITE FLOUR PASTA DOUGH
INGREDIENTS
1 ½ CUPS UNSIFTED ALL-PURPOSE
FLOUR 1 EGG
1 EGG WHITE 1 TBSP OLIVE OIL
A FEW DROPS OF WATER
