Wetif DT 392 User manual

WebDT Mobile Tablet Barcode Scanner Operation Guide
MobilesTablet
Barcode Scanner
Buon Management
The default scanner trigger buon is at right side. To
assign Scanner Trigger buon, follow the procedures
below.
1. Start Buon Manager by clicking on in the
system tray.
2. Select an available unused buon marked with the
icon .
3. Click on to go to the second screen of Buon Manager.
4. Click on the icon to assign the Scanner Trigger to the unused buon.
5. Click OK to apply conguraon sengs and close the window.
Installaon
The Barcode Scanner is preinstalled as an opon for DT 392.
DT 392 OPERATION GUIDE
Scanner 1/2
Barcode Scanner
Trigger Buon
Scanner Conguraon
To Add/Remove Symbologies, follow the procedures below.
1. Click Start | All Programs | DT Research | Buon
Manager | ScannerCong.
2. Select COM3 and click Connect buon.
3. Add Symbology with buon and Remove
Symbology with buon.
4. Select the Beep aer scanning barcode checkbox to
enable beep sound aer scanning bar code or deselect
it to disable the beep sound.
5. Click OK to apply the conguraon sengs and close
the window.
Note: Adding only the symbologies you need for tesng will give the best results. Adding too many
symbologies all at the same me will inuence performance.

WebDT Mobile Tablet Barcode Scanner Operation Guide
To Connect Barcode Scanner Module
To connect the Barcode Scanner, you can use the DT Keyboard Wedge to connect. Tap on
the icon in the task bar, a menu displayed as shown in the picture below. Select Connect
Scanner.
To Test Barcode Scanner Module
Click 1. Start | All Programs | Accessories | NotePad to run
the Notepad
Scan one of the several supported barcode Symbologies.
2.
The output will appear in the Notepad screen.
Verify the captured data.
3.
The Default Port Parameters for Barcode Scanner Module
Port COM3
Baud Rate 57600
Data Bits 8
Parity None
Stop Bits 1
Flow Control None
Note: Please refer to Hyper Terminal Sengs to conrm or change the port parameters.
SPECIFICATIONS
Scanning
Performance
Scan rate 2D mode: 56 images/s auto adapve
Linear (1D)emulaon mode: 200 scans/s auto adapve
Scan angle 38.9° (Horizontal), 25.4°(Vercal)
Opcal resoluon 752 (H) x 480 (V) pixels, 256 gray levels
Print contrast down to 25%
Versions Standard range and high density
Note: Specicaons are subject to change without noce.
signage dtri com
Linear Imager Compliance and Precauon
This product complies with the following standards for laser and LED safety.
IEC 60825-1 / EN 60825-1 - Class 1 LED Product
Scanner 2/2
Scanner connected
WETIF Industrie EDV Telefon DE [phone]
Senserstraße 3 Telefon AT [phone]
D - 82140 Olching [email protected] www.wetif.com

WebDT Mobile Tablet Barcode Scanner Operation Guide
MobilesTablet
CMOS Camera
Installaon
The CMOS Camera is preinstalled as an opon for DT 392.
To Test CMOS Camera Module
To test the CMOS Camera, launch Microso® Paint from Start | All Programs | Accessories.
Select File | From Scanner or Camera to iniate the Capture Pictures from Video window.
Click Seng to decide
properes of captured
pictures.
Click on Capture buon or
pre-assigned trigger buon
to take a picture.
Select a captured picture
on right column, click
Get Picture to export
the picture to Paint or
click Delete to delete the
picture.
4
4
4
Buon Management
To assign Camera Trigger buon, follow the procedures below.
1. Start Buon Manager by clicking on in the system tray.
2. Select an available unused buon marked with the icon .
3. Click on to go to the second screen of Buon
Manager.
4. Click on the icon to assign the Camera Trigger to the
unused buon.
5. Click OK to apply conguraon sengs and close the window.
Camera 1/2
Note: The user interface may be slightly dierent according to
dierent operang systems.
Camera
DT 392 OPERATION GUIDE

WebDT Mobile Tablet Barcode Scanner Operation Guide
signage dtri com
SPECIFICATIONS
Sensor CMOS sensor
Resoluon 640 x 480 (default),
1280 x 1024, 1600 x 1200, 2048 x 1536
Auto Focus Yes
Automac Image Control Automac exposure control
Automac white balance control
Focusing Type Auto focus
Focus Distance Focal on 60cm
Note: Specicaons are subject to change without noce.
Camera 2/2
WETIF Industrie EDV Telefon DE [phone]
Senserstraße 3 Telefon AT [phone]
D - 82140 Olching [email protected] www.wetif.com

WebDT Mobile Tablet Barcode Scanner Operation Guide
MobilesTablet
Magnec Stripe Reader
MSR 1/2
Installaon
The Magnec Stripe Reader (MSR) is preinstalled as an opon for DT 392
To Connect Magnec Stripe Reader Module
To connect the Magnec Stripe Reader, you can use the DT Keyboard Wedge. Tap on the
icon in the task bar, a menu is displayed as shown in the picture below. Choose Connect MSR.
To Congure MSR
For a magnec stripe card, the raw data in each data track may contain start and end sennel
characters. To remove those characters, you can select the Congure MSR command to parse
input raw data and lter out the start and end sennel characters on each track.
Click
1. Cong MSR in the DT Keyboard Wedge menu,
and the MSR Parse Format Seng window will be
displayed.
Choose
2. Enable in the Parse Data secon.
Choose data you want to parse at the start or end of each
track.
For Example:
Check Track 1
In Start Sennel Character, select %
•
In End Sennel Character, select ?•
Click 3. OK to complete the sengs
DT 392 OPERATION GUIDE
MSR connected
MSR

WebDT Mobile Tablet Barcode Scanner Operation Guide
signage dtri com
To Test Magnec Stripe Reader Module
Click 1. Start | All Programs | Accessories | NotePad to run
the Notepad.
Swipe a magnec stripe card across the module.
2.
The output will appear in the NotePad screen.
Verify the captured data.
3.
Default Port Parameters for Magnec Stripe Reader Module
Port COM2
Baud Rate 19200
Data Bits 8
Parity None
Stop Bits 1
Flow Control None
Note: Please refer to Hyper Terminal Sengs to conrm or change the port parameters.
SPECIFICATIONS
Reference Standards
ANSI/ISO Standards 7810, 7811-1/6, 7812 & 7813-
JIS X6301, X6302
-
AAMVA
-
Recording Method Two frequency coherent phase (F2F)
Decoding Method ISO Track1: IATA, Track2: ABA, Track3: THRIFT
Card Swiping Direcon Bi-direconal
Card Swiping Speed Card speed through the unit may vary from 3ips to 100ips
(7cm/s to 250cm/s)
Life Electronics 125,000 hours
Head 1,000,000 passes
Note: Specicaons are subject to change without noce.
MSR 2/2
WETIF Industrie EDV Telefon DE [phone]
Senserstraße 3 Telefon AT [phone]
D - 82140 Olching [email protected] www.wetif.com

WebDT Mobile Tablet Barcode Scanner Operation Guide
MobilesTablet
RFID Reader
Installaon
The RFID reader is preinstalled as an opon for DT 392.
To Connect RFID Reader Module
To connect the RFID, you can use the DT Keyboard Wedge to connect. Tap on the
icon in the task bar, a menu displayed as shown in the picture below. Select Connect RFID.
To Test RFID Reader Module
Click 1. Start | All Programs | Accessories | NotePad to run
the Notepad
Place the ISO card within a distance of the RFID tag(see
2.
reading range of specicaon). The output will appear in
the Notepad screen.
Verify the captured data.
3.
SPECIFICATIONS
Frequency 13.56MHz ±7 KHz
Module Mode FSK
Reading Range Within 30mm
HF RFID Reader ISO 15693,1443A(B), Felica UID
signage dtri com
RFID Reader
RFID
DT 392 OPERATION GUIDE
RFID connected

WebDT Mobile Tablet Barcode Scanner Operation Guide
HyperTerminal
HyperTerminal
HyperTerminal
You also can connect Barcode Scanner/MSR from HyperTerminal:
1. Run Start l All Programs l Accessories l Communicaons l HyperTerminal to run the
HyperTerminal.
2. Input a connecon name in “Connecon Descripon” window.
3. Choose the connecon port (please refer to the parameters table
of each module), then click OK.
4. Change the port Properes (please refer to the parameters table
of each module), then click Apply to complete the sengs.
5. If the sengs are all correct, HyperTerminal will be connected to
the module. Scan a barcode or swipe a card, the captured data
will display in the HyperTerminal windows.
6. Verify the captured data.
DT 392 OPERATION GUIDE
