Wfly MG216 User manual

Antenna
base
Mode
CRSF
S.BUS
PPM
Link
Color Status Function
Yellow
Yellow
Green
Blue
Purple
Red
Always on
Always on
Flashes
Flashes Linking
No transmitter data received
Warn Battery power<6.8v
Connected receiver
Connected receiver
Connected receiver
Receiver not nonnected
Mode Color Status Function
Yellow
Always on
Always on
Flashes
Flashes Linking
Warn
No transmitter data received
Link mode
Green
Red
Finish
Transmission mode
Voltage<3.7v
Ⅱ. Indicator status
1. RF module
2.Receiver
Ⅰ. Names of each parts
1. RF Module 2. RG202 Mini Receiver:
3. RG202 Pro receiver
MG216 RF Module Quick Guide
Status indication
light
【SET】button
USB port
5V
W_BUS
W_CRSF
Indicator
light
SET buttonNegative
Voltage
detection
5V
W_BUS
W_CRSF
Negative
Voltage
detection
Indicator
light
SET
button
3. LED state
Mode
Function
Blue light always on
Green light always on
Blue light flashes
Green light flashes
Indicator status
RF Module
Receiver
RF module upgrade
Receiver upgrade
Switch function
Confirm
Operation
Short press
Long press
Ⅲ. Link
1. RF module
(1) Method 1 【SET key linking】
When the RF module does not receive data from the receiver (indicator status: yellow,
blue, or purple light is always on), long press the 【SET】button to enter the linking
status, and the indicator status: the yellow light flashes.
IPEX
generation
Antenna
base
IPEX
generation

(2) Method 2 【Menu linking】
Open TX system
【MODEL SETUP】-【External RF】-【Mode】When the protocol is set to CRSF, the function setting
will bedisplayed.Long press the transmitter 【SYS】key to enter the 【TOOLS】-
【Crossfire configure】-【WFLY TX】function interface.
In the WFLY TX interface, press the 【Bind】key to check the code.
2. Receiver
(1) Linking mode within 0.13 seconds after power-on
Note: The RF module status needs to be in the linking mode.
(2) Long press the 【SET】key to enter the link state, the indicator light state: the yellow
light flashes.
Note: After the code is successfully link, if you need to enter the link again, the receiver
needs to be powered on again. Long press【SET】key to exit the linking mode.
Ⅳ. Telemetry interface
When the module is connected to the receiver normally, long press the 【MDL】key to
jump to the 【TELEMETRY】telemetry interface.
Shenzhen WFLY Technology Development Co., Ltd
C3 Buliding,Xiangli Industry Park,Heping Haoye Road,Fuyong
Town,Baoan District,Shenzhen,Guangdong Province,China
Scan the code to
download the details
CROSSFIRE SETUP
WFLY TX
WFLY RX
WFLY TX
Set Failsafe
Bind
Bind.Parameter
Re-Flag
Re-Num
TX .Power
Transfer_Mode
L_Freq
H_Freq
Firmware:
Enable
1
5mW
P2P
1
100
V1.0.1
WFLY ET16/S
Function path: 【Linkage setting】-[Bind】
①The built-in module is set to 【Disabled】
②Set the external module to【W.CRSF】
③Click 【Start】to check the code.
Ⅴ. Technical parameters
Product model: MG216
Suppor：ET16 ET16S Open TX
（Includes JR slo）
Frequency band：2.4GHz
working frequency：2.400-2.483 GHz
Modulated emission：LoRa
Adjustable position：Power adustable
Transmit power：20dBm
Flying range：>3km（No interference,
open area）
High refresh rate：200/135Hz
Delay：5ms（CRSF）
Set interface：Support LUA script
（OpenTX）
Wireless protocol：Third Generation
Signal input：CRSF、S.BUS、PPM
Transmission channel：16
Antenna type：External single antenna
Antenna interface：Internal thread inner hole
Antenna gain：3dbi
Power supply range：3.5~13V
Power consumption：0.36W
Weight：45.0g (including antenna)
Online upgrade：Suppor
Product dimensions：65mm*53mm22mm
Installation slot size：60.mm*45mm19.5mm
TOOLS
01 Crossfire configure
02 FrSky GaSuite
03 FrSky SBEC
04 FrSky SxR
05 Graupner HoTT
06 Spectrum(INT)
