CONSUMER SERVICES TECHNICAL
EDUCATION GROUP PRESENTS
R-96
JOB AID
Part No. 8178279
2003
5000 & 6000 BTU
AIR CONDITIONERS
Models: ACM052MM,
ACM062MM, ACD052MM
Models: ACQ058MM &
ACQ062MM

- ii -
WHIRLPOOL CORPORATION assumes no responsibility for any repairs made
on our products by anyone other than Authorized ervice Technicians.
FORWARD
This Whirlpool Job Aid, “2003 - 5000 & 6000 BTU Air Conditioners” (Part No. 8178279), provides
the technician with information on the installation and service of the 2003 - 5000 & 6000 BTU Air
Conditioners. It is to be used as a training Job Aid and ervice Manual. For specific information
on the model being serviced, refer to the “Use and Care Guide” provided with the air conditioner.
The Wiring Diagrams and trip Circuits used in this Job Aid are typical and should be used for
training purposes only. Always use the Wiring Diagram supplied with the product when servicing
the unit.
GOALS AND OBJ CTIV S
The goal of this Job Aid is to provide detailed information that will enable the service technician to
properly diagnose malfunctions and repair the 2003 - 5000 & 6000 BTU Air Conditioners.
The objectives of this Job Aid are to:
• Understand and follow proper safety precautions.
• uccessfully troubleshoot and diagnose malfunctions.
• uccessfully perform necessary repairs.
• uccessfully return the air conditioner to its proper operational status.
Copyright © 2003, Whirlpool Corporation, Benton Harbor, MI 49022

- iii -
TABL OF CONT NTS
Page
G N RAL............................................................................................................................... 1-1
afety First......................................................................................................................... 1-1
Whirlpool Model & erial Number Designations ................................................................ 1-3
Model & erial Number Label Locations ........................................................................... 1-4
pecifications..................................................................................................................... 1-5
Whirlpool Air Conditioner Warranty—Model ACD052MM ................................................. 1-6
Whirlpool Air Conditioner Warranty—Models ACM052MM,
ACM062MM, ACQ058MM, ACQ062MM ....................................................................... 1-7
INSTALLATION INFORMATION ........................................................................................... 2-1
COMPON NT ACC SS ......................................................................................................... 3-1
Component Locations ........................................................................................................ 3-1
Removing The ide Curtains, Front Grille, Top Cover, & creen ..................................... 3-2
Removing The Fan peed & Temperature Controls—Models ACD052MM,
ACM052MM, & ACM062MM ......................................................................................... 3-4
Removing The Electronic Control Assembly & Thermistor—Models ACQ058MM
& ACQ062MM................................................................................................................ 3-5
Removing The Power Cord And Capacitor—Models ACM052MM,
ACM062MM, & ACD052MM .......................................................................................... 3-6
Removing The Power Cord And Capacitor—Models ACQ058MM
& ACQ062MM................................................................................................................ 3-8
Removing The Fan Motor ................................................................................................ 3-10
Removing The Evaporator ............................................................................................... 3-14
Removing The Condenser ............................................................................................... 3-17
Removing The Overload Protector & Compressor .......................................................... 3-18
COMPON NT T STING ........................................................................................................ 4-1
Temperature Control.......................................................................................................... 4-1
Thermistor.......................................................................................................................... 4-1
Fan peed Control............................................................................................................. 4-2
Capacitor ........................................................................................................................... 4-2
Fan Motor ......................................................................................................................... 4-3
Overload Protector............................................................................................................. 4-3
Compressor ....................................................................................................................... 4-4
DIAGNOSTICS & TROUBL SHOOTING .............................................................................. 5-1
Diagnostics—Models: ACQ058MM & ACQ062MM ........................................................... 5-1
Troubleshooting Chart ....................................................................................................... 5-2
WIRING DIAGRAMS & STRIP CIRCUITS ............................................................................. 6-1
Wiring Diagram 1—Model ACD052MM ............................................................................. 6-1
Wiring Diagram 2—Models ACM052MM & ACM062MM .................................................. 6-2
Wiring Diagram 3—Models ACQ058MM & ACQ062MM ................................................... 6-3
trip Circuits ...................................................................................................................... 6-4
T CH TIPS ............................................................................................................................. 7-1
Installing The Condensate Drain Adapter .......................................................................... 7-1

- iv -
— NOT S —

1-1
Electrical Shock Hazard
Plug into a grounded 3-prong outlet.
Do not remove ground prong.
Do not use an adapter.
Do not use an extension cord.
Failure to ollow these instructions can
result in death, ire, or electrical shock.
Electrical Shock Hazard
Disconnect power be ore servicing.
Replace all parts and panels be ore
operating.
Failure to do so can result in death or
electrical shock.
GENERAL
SAFETY FIRST
Your sa ety and the sa ety o others is very important.
We have provided many important safety messages in this Job Aid and on the appliance. Always
read and obey all safety messages.
This is the safety alert symbol.
This symbol alerts you to hazards that can kill or hurt you and others.
All safety messages will follow the safety alert symbol and either the word
“DA GER” or “WAR I G.” These words mean:
All safety messages will tell you what the potential hazard is, tell you how to reduce the chance
of injury, and tell you what can happen if the instructions are not followed.
You can be killed or seriously injured i you don’t
immediately ollow instructions.
You can be killed or seriously injured i you don’t
ollow instructions.

1-2
Electrical Shock Hazard
Connect green ground wire to ground
screw.
Failure to do so can result in death or
electrical shock.
Excessive Weight Hazard
Use two or more people to move and
install air conditioner.
Failure to do so can result in back or other
injury.
IMPORTANT
Electrostatic Discharge (ESD)
Sensitive Electronics
ESD problems are present everywhere.
ESD may damage or weaken the elec-
tronic control assembly. The new control
assembly may appear to work well a ter
repair is inished, but ailure may occur at
a later date due to ESD stress.
• Use an antistatic wrist strap. Connect the
wrist strap to the green ground connec-
tion point, or to an unpainted metal sur-
face in the appliance.
- OR -
• Touch your finger repeatedly to a green
ground connection point, or to an un-
painted metal surface in the appliance.
• Before removing the part from its pack-
age, touch the antistatic bag to a green
ground connection point, or to an un-
painted metal surface in the appliance.
• Avoid touching electronic parts, or termi-
nal contacts. Handle the electronic con-
trol assembly by the edges only.
• When repackaging the failed electronic
control assembly in an antistatic bag,
observe the previous instructions.

1-3
WHIRLPOOL MODEL & SERIAL NUMBER DESIGNATIONS
MODEL NUMBER
SERIAL NUMBER
MODEL NUMBER A C Q 05 8 M M 0
PRODUCT GROUP
A = AIR CO DITIO ER
PRODUCT IDENTIFICATION
C = WARRA TY
D = DEHUMIDIFIER
O = ROOM A/C CABI ETS
MODEL TYPE
D = VALUE
E = HEAT & COOL
M = VALUE SERIES
Q = DESIG ER WITH ELECTRO IC CO TROLS
S = SLIDI G WI DOW
U = THROUGH-THE-WALL
NOMINAL CAPACITY
05 - 5,000 BTU/HR
07 - 7,000 BTU/HR
08 - 8,000 BTU/HR
10 - 10,000 BTU/HR
12 - 12,000 BTU/HR
15 - 15,000 BTU/HR
18 - 18,000 BTU/HR
21 - 21,000 BTU/HR
24 - 24,000 BTU/HR
ELECTRICAL CODE
2 = 115 VOLT STA DARD EER
4 = 230 VOLT STA DARD EER
8 = 115 VOLT E ERGY STAR EER
9 = 230 VOLT E ERGY STAR EER
FEATURE CODE
M = “M” MODEL
YEAR OF INTRODUCTION
L = 2002, M = 2003
ENGINEERING CHANGE
0, 1, 2, ETC.
SERIAL NUMBER QM M 01 01527
MANUFACTURING RESPONSIBILITY
YEAR OF PRODUCTION
M = 2002, P = 2003
WEEK OF PRODUCTION
1ST WEEK
PRODUCT SEQUENCE NUMBER

1-4
MODEL & SERIAL NUMBER LABEL LOCATIONS
The Technician Model/Serial umber label location is shown below.
Model & Serial
Number Location
The Consumer Model/Serial umber label location is shown below.
Model & Serial
Number Location

1-5
SPECIFICATIONS
Model Number ACD052MM ACQ058MM ACQ062MM ACM052MM & ACM062MM
Ratings
BTU - Cool 5000 5000 6000 5000 (052)/6000 (062)
Energy Efficiency Rating # 9.7 10.7 9.7 9.7
Air Features
Air Flow on Turbo (CFM) 180 190 180 180
Air Flow on Medium (CFM) N / A 170 160 160
Air Flow on Low (CFM) 140 150 140 140
Features
Cooling Speed Selections 2 3 3 3
Timer (On/Off) No Yes Yes No
Power Saver No Yes Yes No
Remote No Yes Yes No
Electrical
Volts 115 115 115 115
Frequency (Hz) 60 60 6 0 60
Amps (Cooling) 4.8 4.7 5.7 5.7
Fuse Size (Amps) 15 15 15 15
Power Cord Length (ft) - Cabinet to Wall 6 ft. 6 ft. 6 ft. 6 ft.
Power Cord Length (m) - Cabinet to Wall 1.8 m. 1.8 m. 1.8 m. 1.8 m.
Exterior
Fan Control Rotary Electronic Electronic Rotary
Thermostat Control Rotary Electronic Electronic Rotary
Miscellaneous
Weight (lbs./kg) 52.5/24 54/24.5 54/24.5 54/24.5
Filter Washable, L/R Access Washable, L/R Access Washable, L/R Access Washable, L/R Access
Window Opening (Inches) 25 - 38 W x 16 H (min) 25 - 38 W x 16 H (min) 25 - 38 W x 16 H (min) 25 - 38 W x 16 H (min)
Warranty
Full 1 Year 1 Year 1 Year 1 Year
Full Sealed System 1 Year 5 Years 5 Years 5 Years

1-6
WHIRLPOOL AIR CONDITIONER WARRANTY
Model ACD052MM
LENGTH OF WARRANTY
FULL ONE-YEAR
WARRANTY FROM
DATE OF PURCHASE
MANUFACTURER WILL PAY FOR
Replacement parts and repair labor to correct
defects in materials or workmanship. Service must
be provided by an authorized service company.
A. Repairs when room air conditioner is used for other than household use.
B. Any shipping or handling costs to deliver your room air conditioner to a designated
service center.
C. Damage to your air conditioner caused by accident, misuse, fire, flood, acts of God,
or use of products not mentioned in the Use and Care Guide.
D. Repairs to parts or systems resulting from unauthorized modifications made to the
appliance.
E. Replacement parts or repair labor costs for units operated outside the United States.
MANUFACTURER SHALL NOT BE LIABLE FOR INCIDENTAL OR CONSEQUENTIAL
DAMAGES. Some states do not allow the exclusion or limitation of incidental or
consequential damages, so this exclusion or limitation may not apply to you. This warranty
gives you specific legal rights, and you may also have other rights which vary from state to
state.
Outside the United States a different warranty may apply. For details, please con-
tact your authorized dealer.
If you need service, first see the “Troubleshooting” section of the Use and Care Guide.
After checking “Troubleshooting,” additional help can be found by checking the
“Assistance or Service” section, or by calling the manufacturer’s Customer Interaction
Center, 1-800-253-1301 (toll-free), from anywhere in the U.S.A.
Room air conditioner, along with proof of purchase, should be delivered to your nearest
designated service company.
WE WILL NOT PAY FOR

1-7
LENGTH OF WARRANTY
FULL ONE-YEAR
WARRANTY FROM
DATE OF PURCHASE
FULL FIVE-YEAR
WARRANTY FROM
DATE OF PURCHASE
MANUFACTURER WILL PAY FOR
Replacement parts and repair labor to correct
defects in materials or workmanship. Service must
be provided by an authorized service company.
Replacement parts and repair labor to correct
defects in materials or workmanship in the sealed
refrigeration system. These parts are:
1. Compressor 4. Drier-Strainer
2. Evaporator 5. Connecting Tubing
3. Condenser
Service must be provided by an authorized service
company.
A. Service calls to:
1. Correct the installation of your air conditioner.
2. Instruct you how to use your air conditioner.
3. Replace house fuses or correct house wiring.
4. Clean or replace the air filter.
B. Pickup and delivery. Your air conditioner is designed to be repaired in the home.
C. Damage to your air conditioner caused by accident, misuse, fire, flood, acts of God,
or use of products not mentioned in the Use and Care Guide.
D. The removal and reinstallation of your air conditioner if it is installed in an overhead
or other inaccessible location or is not installed in accordance with published instal-
lation instructions.
E. Repairs to parts or systems resulting from unauthorized modifications made to the
appliance.
WHIRLPOOL CORPORATION SHALL NOT BE LIABLE FOR INCIDENTAL OR
CONSEQUENTIAL DAMAGES. Some states do not allow the exclusion or limitation of
incidental or consequential damages, so this exclusion or limitation may not apply to you.
This warranty gives you specific legal rights, and you may also have other rights which vary
from state to state.
Outside the United States a different warranty may apply. For details, please
contact your authorized dealer.
If you need service, first see the “Troubleshooting”section of the Use and Care Guide.
After checking “Troubleshooting,”additional help can be found by checking the
“Assistance or Service”section, or by calling the Whirlpool Customer Interaction Center,
1-800-253-1301 (toll-free), from anywhere in the U.S.A.
WE WILL NOT PAY FOR
WHIRLPOOL AIR CONDITIONER WARRANTY
Models ACM052MM, ACM062MM, ACQ058MM, ACQ062MM

1-8
— NOTES —

2-1
INSTALLATION INFORMATION
Excessive Weight Hazard
Use t o or more people to move and
install air conditioner.
Failure to do so can result in back or
other injury.
IMPORTANT: Observe all governing codes
and ordinances.
Check the location where the air conditioner
will be installed. Proper installation is your
responsibility. Make sure you have everything
necessary for correct installation.
The location should provide:
• A grounded electrical outlet within ft. (122
cm) of the window. Do not use an extension
cord.
• Free movement of air to rooms to be cooled.
• A large enough opening for the air condi-
tioner. Installation parts are supplied for
double-hung windows (some models) up to
38 in. (96.5 cm) wide.
• Adequate wall support for the weight of the
air conditioner. The air conditioner weighs
between 56 lbs. (25 kg) and 80 Ibs. (36 kg).
Do not install the air conditioner in an area
where the front panel will be exposed to heat
sources that will raise the panel surface tem-
perature above 120°F (50°C).
Air Conditioner Size A B
5000 to 6000 BTUs 25″ to 38″ 16″
(63.5 cm to ( 0.6 cm)
96.5 cm)
Handle the air conditioner with care. Watch out
for the sharp metal fins on the rear coils.
Be sure the air conditioner does not fall out of
the opening during installation or removal.
The air conditioner should be placed no more
than ft. (122 cm) from a grounded outlet.
1. Center the air conditioner in the window.
Check that the lower rail of the air condi-
tioner is behind and against the back side
of the window seal, then lower the window
sash (A) to hold the cabinet in place. Do
not block the louvers in the front panel, or
block the openings on the outside of the air
conditioner.

2-2
3. Pull the left curtain (D) out and fit it into the
window channel (E).
. Install the right curtain in the same manner
as the left curtain. NOTE: If the air condi-
tioner does not have side curtains, fill
spaces with a suitable material.
7. Mount the window-lock bracket (H) on top
of lower window and against upper win-
dow sash (I). Use a 3/32″ drill bit to drill a
starter hole through the hole in the bracket.
2. Make sure that the back of the air condi-
tioner cabinet is tilted down so that water
will run to the outside. The tilt should be
about 1/2 bubble (B) on a spirit level. If the
cabinet is not properly positioned, reposi-
tion or shim it to provide the proper tilt.
5. Secure the left curtain with one of the
round-head screws (F) to the window chan-
nel. If desired, use alternate hole (G) at the
top of the curtain to secure it to the window
channel (see the illustration at the top of
the next column).
6. Fasten the right curtain to the window
channel in the same manner as the left
curtain.
8. Insert foam seal (K) behind the top of the
lower window sash (J), and against the
glass of the upper window.
9. Plug the power cord into an appropriate
AC outlet.

3-1
COMPONENT LOCATIONS
This section instructs you on how to service each component inside the air conditioner. The
components and their locations are shown below.
COMPONENT ACCESS
Evaporator
Temperature Control
Fan Speed Control
Power Cord
Compressor
Capacitor
Overload Protector
Condenser
Temperature
Sensor Tube
Models ACQ058MM
& ACQ062MM Use An
Electronic Control Assembly
Instead O Manual Controls
Models ACQ058MM &
ACQ062MM Use A
Thermistor In Place O A
Temperature Sensor Tube
Fan Motor

3-2
REMOVING THE SI E CURTAINS, FRONT GRILLE,
TOP COVER, & SCREEN
1. Unplug air conditioner or disconnect power.
2. Remove the air conditioner rom the win-
dow.
NOTE: Model ACD052MM is shown.
3. To remove the left and right side cur-
tains:
a) Remove the three screws rom each o
the side curtains.
b) Slide the curtains out o the top and
bottom guides and remove them.
Electrical Shock Hazard
isconnect power before servicing.
Replace all parts and panels before
operating.
Failure to do so can result in death or
electrical shock.
b) Pull the grille orward and remove it.
Grille Screws
(2 o 4)
Front Grille
4. To remove the front grille:
a) Remove the our screws (two on each
side) rom the grille.
Side Curtain
Screws

3-3
5. To remove the top cover, remove the
nine screws rom the cover, and the two
screws rom the top curtain guide, and
remove the cover and the guide.
6. To remove the screen:
a) Remove the two screws rom each side
o the screen.
b) Pull the ends o the screen rom the
slots in the side holders.
c) Li t the screen rom the unit.
Top Cover Screw
(1 o 9)
Screen Screw (1 o 4)
Screen
Top Curtain Guide
Screw (1 o 2)

3-4
REMOVING THE FAN SPEE & TEMPERATURE CONTROLS
MO ELS AC 052MM, ACM052MM, & ACM062MM
Electrical Shock Hazard
isconnect power before servicing.
Replace all parts and panels before
operating.
Failure to do so can result in death or
electrical shock.
1. Unplug air conditioner or disconnect power.
2. Remove the air conditioner rom the win-
dow.
3. Remove the side curtains and the ront
grille (see page 3-2 or the procedures).
4. Pull the knobs o the an speed control
and temperature control sha ts.
6. Depending on which control you are ser-
vicing, remove the two screws rom the an
speed control or the temperature control.
Fan Speed Control Screws Temp Control Screws
7. Disconnect the wire connectors rom the
control terminals and remove the control
rom the mounting plate.
8. I you are removing the temperature con-
trol, unclip the temperature sensor tube
rom the holder on the evaporator.
Black Red White
Power Cord Lead
White Yellow
Fan Speed Control Temperature Control
Fan Speed Control Temperature Control
Control Mounting Plate Screw (1 o 4)
Temperature Sensor Tube
5. Remove the our screws rom the control
mounting plate and position it so that you
can access the controls and wiring (see
the photo at the top o the next column). Model AC 052MM Shown Above

3-5
REMOVING THE ELECTRONIC CONTROL ASSEMBLY &
THERMISTOR—MO ELS ACQ058MM & ACQ062MM
Electrical Shock Hazard
isconnect power before servicing.
Replace all parts and panels before
operating.
Failure to do so can result in death or
electrical shock.
1. Unplug air conditioner or disconnect power.
2. Remove the air conditioner rom the win-
dow.
3. Remove the side curtains and the ront
grille (see page 3-2 or the procedures).
4. Remove the thermistor by unclipping it
rom the holder and disconnecting it rom
the control board (see step 7).
5. Remove the screw rom the electronic
control box assembly.
6. Li t the two locking arms, and pull the
assembly orward.
7. Disconnect the wires rom the electronic
control board terminals as ollows:
White rom L2
Gray rom L1
Yellow rom COMP
Black rom TURBO
Blue rom HIGH
Red rom LOW
To Thermistor connector rom P7
Locking Arms
L2 (WH) L1 (GY) COMP (YL) TURBO (BK)
P7 (Thermistor) HIGH (BU) LOW (RD)
Unclip Thermistor
Electronic Control Box Assembly Screw

3-6
REMOVING THE POWER COR AN CAPACITOR
MO ELS ACM052MM, ACM062MM, & AC 052MM
Electrical Shock Hazard
isconnect power before servicing.
Replace all parts and panels before
operating.
Failure to do so can result in death or
electrical shock.
5. Remove the our screws rom the control
mounting plate and position it so that you
can access the wiring.
6. Disconnect the smooth power cord lead con-
nector rom an speed control terminal 1.
7. Remove the three screws rom the control
housing and and remove the housing.
Screw 1 o 3)
Control Housing
Smooth Power Cord Lead At Terminal 1
Control Mounting Plate Screw (1 o 4)
1. Unplug air conditioner or disconnect power.
2. Remove the air conditioner rom the win-
dow.
3. Remove the side curtains and the ront
grille (see page 3-2 or the procedures).
Power Cord
4. Remove the power cord green ground
wire screws rom the control mounting
plate and the evaporator rame.
Ground Screws
Model AC 052
