ROOM AIR
CONDITIONER
Use & Care Guide
For questions about features, operation/performance, parts
or service, call: 1-877-465-3566.
or visit our website at... www.whirlpool.com
In Canada, for assistance, installation or service,
call: 1-800-360-2742
ACONDICIONADOR
DE AIRE PARA
HABITACIÓN
Manual de uso y cuidado
Si tiene preguntas respecto a las características, funcionamiento,
rendimiento, partes o servicio técnico,
llame al: 1-877-465-3566
o visite nuestro sito de internet en... www.whirlpool.com
CLIMATISEUR
DE PIÈCE
Guide d’utilisation et d’entretien
Au Canada, pour assistance, installation ou service,
composez le : 1-800-360-2742
ou visitez notre site web à... www.whirlpool.com
Table of Contents/Índice/Table des matières ...... 2
1305470
®

2
TABLE OF CONTENTS
AIR CONDITIONER SAFETY .........................................................3
INSTALLATION REQUIREMENTS................................................3
Tools and Parts ............................................................................3
Location Requirements................................................................4
Electrical Requirements ...............................................................4
INSTALLATION INSTRUCTIONS..................................................5
Unpack the Air Conditioner..........................................................5
Prepare Air Conditioner for Installation........................................6
Prepare Window for Installation...................................................7
Position the Air Conditioner .........................................................7
Complete Installation ...................................................................9
AIR CONDITIONER USE................................................................9
Starting Your Air Conditioner.....................................................10
Using the Remote Control .........................................................12
Changing Air Direction ...............................................................14
Exhaust Air Vent .........................................................................14
Normal Sounds...........................................................................14
AIR CONDITIONER CARE ...........................................................14
Cleaning the Air Filter .................................................................14
Cleaning the Front Panel............................................................14
Repairing Paint Damage ............................................................15
Annual Maintenance...................................................................15
TROUBLESHOOTING ..................................................................15
ASSISTANCE OR SERVICE.........................................................16
In the U.S.A. ...............................................................................16
In Canada ...................................................................................16
Notes ..........................................................................................17
ÍNDICE
SEGURIDAD DEL ACONDICIONADOR DE AIRE......................18
REQUISITOS DE INSTALACIÓN.................................................18
Herramientas y piezas................................................................18
Requisitos de ubicación.............................................................19
Requisitos eléctricos..................................................................20
INSTRUCCIONES DE INSTALACIÓN.........................................21
Desempaque el acondicionador de aire....................................21
Prepare el acondicionador de aire para la instalación ..............21
Prepare la ventana para la instalación.......................................22
Cómo colocar el acondicionador de aire...................................23
Complete la instalación..............................................................24
USO DE SU ACONDICIONADOR DE AIRE................................25
Cómo poner en marcha su acondicionador de aire..................25
Cómo usar el control remoto .....................................................27
Cómo cambiar la dirección del aire ...........................................29
Ducto de escape de aire ............................................................30
Sonidos normales.......................................................................30
CÓMO CUIDAR SU ACONDICIONADOR DE AIRE...................30
Limpieza del filtro de aire ...........................................................30
Limpieza del panel delantero .....................................................30
Reparación de la pintura dañada...............................................30
Mantenimiento anual..................................................................30
SOLUCIÓN DE PROBLEMAS......................................................31
AYUDA O SERVICIO TÉCNICO...................................................32
En los EE.UU..................................................................................32
TABLE DES MATIÈRES
SÉCURITÉ DU CLIMATISEUR ....................................................33
SPÉCIFICATIONS D’INSTALLATION .........................................33
Outils et pièces...........................................................................33
Exigences d’emplacement.........................................................34
Spécifications électriques..........................................................35
INSTRUCTIONS D'INSTALLATION ............................................36
Déballage du climatiseur............................................................36
Préparer le climatiseur pour l’installation...................................36
Préparer la fenêtre pour l’installation.........................................37
Positionnement du climatiseur...................................................38
Pour compléter l’installation ......................................................39
UTILISATION DU CLIMATISEUR................................................40
Mise en marche du climatiseur..................................................40
Utilisation de la télécommande..................................................42
Changement de direction de l'air...............................................44
Ventilation...................................................................................44
Sons normaux ............................................................................44
ENTRETIEN DU CLIMATISEUR ..................................................45
Nettoyage du filtre à air..............................................................45
Nettoyage du panneau avant.....................................................45
Remise en état de la peinture ....................................................45
Entretien annuel..........................................................................45
DÉPANNAGE.................................................................................45
ASSISTANCE OU SERVICE.........................................................47
Aux États-Unis............................................................................47
Au Canada..................................................................................47

3
AIR CONDITIONER SAFETY
INSTALLATION REQUIREMENTS
Tools and Parts
Gather the required tools and parts before starting installation.
Read and follow the instructions provided with any tools listed
here.
Tools needed
Parts supplied
Check that all parts are included in parts package.
You can be killed or seriously injured if you don't immediately
You can be killed or seriously injured if you don't follow
All safety messages will tell you what the potential hazard is, tell you how to reduce the chance of injury, and tell you what can
happen if the instructions are not followed.
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety
messages.
This is the safety alert symbol.
This symbol alerts you to potential hazards that can kill or hurt you and others.
All safety messages will follow the safety alert symbol and either the word “DANGER” or “WARNING.”
These words mean:
follow instructions.
instructions.
DANGER
WARNING
IMPORTANT SAFETY INSTRUCTIONS
WARNING: To reduce the risk of fire, electrical shock or injury when using your air conditioner, follow these basic precautions:
SAVE THESE INSTRUCTIONS
Unplug air conditioner before servicing.
Use two or more people to move and install air conditioner.
Plug into a grounded 3 prong outlet.
Do not remove ground prong.
Do not use an adapter.
Do not use an extension cord.
■Phillips screwdriver
■Scissors
■Level
■Tape measure
■Cordless drill and ¹⁄₈" bit
■Pencil
A. Adhesive seal
B. Foam seal
C. L brackets (2)
D. Side brackets (2)
E.
³⁄₈ " screws (8)
F.
³⁄₄ " screws (12)
G. Side curtains (2)
A
B
C
DEF
G

4
Location Requirements
IMPORTANT: Observe all governing codes and ordinances.
Check the location where the air conditioner will be installed.
Make sure you have everything necessary for correct installation.
The location should provide:
■Heat/Cool Models—Grounded electrical outlet within 4 ft
(122 cm) of where the power cord exits the air conditioner.
■Cool Only Models—Grounded electrical outlet within 6 ft
(182.9 cm) of where the power cord exits the air conditioner.
NOTE: Do not use an extension cord.
■Free movement of air in room to be cooled.
■A large enough opening for the air conditioner. Installation
parts are supplied for double-hung windows.
■Adequate wall support for weight of air conditioner. Air
conditioner weighs 88 lbs to 100 lbs (40 kg to 45 kg).
NOTE: Cabinet louvers must not be obstructed. Air must be able
to pass freely through the cabinet louvers.
Window Installation
Window opening measurements:
■22³⁄₄" min. to 32⁵⁄₈" max. (57.8 cm to 82.9 cm) opening width.
■15" min. (38.1 cm) opening height.
Electrical Requirements
The electrical ratings for your air conditioner are listed on the
model and serial number label. The model and serial number
label is located on the right-hand side of the air conditioner
cabinet.
Specific electrical requirements are listed in the chart below.
Follow the requirements for the type of plug on the power supply
cord.
Recommended Grounding Method
This air conditioner must be grounded. This air conditioner is
equipped with a power supply cord having a grounded 3 prong
plug. To minimize possible shock hazard, the cord must be
plugged into a mating, grounded 3 prong outlet, grounded in
accordance with all local codes and ordinances. If a mating outlet
is not available, it is the customer's responsibility to have a
properly grounded 3 prong outlet installed by a qualified electrical
installer.
A. Cabinet louvers
A
A. 22 ³⁄₄ " min. (57.8 cm)
B. 15" min. (38.1 cm)
A
B
Electrical Shock Hazard
Plug into a grounded 3 prong outlet.
Do not remove ground prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions can result in death,
fire, or electrical shock.
WARNING
Power supply cord Wiring requirements
■115-volt (103.5 min. - 126.5 max.)
■0-12 amps
■15-amp time-delay fuse or
circuit breaker
■Use on single outlet circuit only.

5
It is the customer's responsibility:
■To contact a qualified electrical installer.
■To assure that the electrical installation is adequate and in
conformance with National Electrical Code, ANSI/NFPA 70 -
latest edition, and all local codes and ordinances.
Copies of the standards listed may be obtained from:
National Fire Protection Association
One Batterymarch Park
Quincy, MA 02269
Power Supply Cord
NOTE: Your air conditioner’s device may differ from the one
shown.
This room air conditioner is equipped with a power supply cord
required by UL. This power supply cord contains state-of-the-art
electronics that sense leakage current. If the cord is crushed, the
electronics detect leakage current and power will be
disconnected in a fraction of a second.
To test your power supply cord:
1. Plug power supply cord into a grounded 3 prong outlet.
2. Press RESET (on some devices, a green light will turn on).
3. Press TEST (listen for click; Reset button will trip, and on
some devices, a green light will turn off).
4. Press and release RESET (listen for click; Reset button will
latch, and on some devices, a green light will turn on). The
power supply cord is ready for operation.
NOTES:
■The Reset button must be pushed in for proper operation.
■The power supply cord must be replaced if it fails to trip when
the test button is pressed or fails to reset.
■Do not use the power supply cord as an off/on switch. The
power supply cord is designed as a protective device.
■A damaged power supply cord must be replaced with a new
power supply cord obtained from the product manufacturer
and must not be repaired.
■The power supply cord contains no user serviceable parts.
Opening the tamper-resistant case voids all warranty and
performance claims.
INSTALLATION INSTRUCTIONS
Unpack the Air Conditioner
Remove packaging materials
■Remove and dispose of/recycle packaging materials.
Remove tape and glue residue from surfaces before turning
on the air conditioner. Rub a small amount of liquid dish soap
over the adhesive with your fingers. Wipe with warm water
and dry.
■Do not use sharp instruments, rubbing alcohol, flammable
fluids, or abrasive cleaners to remove tape or glue. These
products can damage the surface of your air conditioner.
■Handle the air conditioner gently.
A. Test button
B. Reset button
TEST
RESET
A
B
Electrical Shock Hazard
Plug into a grounded 3 prong outlet.
Do not remove ground prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions can result in death,
fire, or electrical shock.
WARNING
WARNING
Excessive Weight Hazard
Use two or more people to move and install
air conditioner.
Failure to do so can result in back or other injury.

6
Prepare Air Conditioner for Installation
Install Side Curtains
NOTE: Attach curtains to the air conditioner before placing the air
conditioner in window.
1. Locate provided bag of screws.
2. Insert top and then bottom of right-hand curtain housing in
top and bottom curtain channels on air conditioner.
Back View
Bottom View
3. Extend right-hand curtain outward so you may insert a ³⁄₈"
screw through the top hole in the curtain. Using a ³⁄₈" screw,
screw curtain to the top hole in the air conditioner cabinet.
NOTE: This screw is required to correctly attach curtain (top
to bottom) to the air conditioner cabinet.
Front View
4. While the right-hand curtain is still extended, insert ³⁄₈" screws
through the other three holes in the curtain. Screw curtain to
all four holes in the air conditioner cabinet.
5. Slide the curtain housing into the channels as far as it will go.
6. Repeat above steps for the left-hand curtain.
A. Curtain housing
B. Curtain top channel on air conditioner
A. Curtain housing
B. Curtain bottom channel on air conditioner
AB
A
B

7
Prepare Window for Installation
Attach Adhesive Seal
1. Cut the adhesive seal to the width of the lower window sash.
2. Remove the backing from the seal and attach the seal to the
bottom of the lower window sash.
Install L Brackets
1. Measure the width of the window opening and mark the
center line on the outside windowsill.
2. Use ¹⁄₈" drill bit to drill a starter hole for each of the two L
brackets located 7¹⁄₂" from the center line.
3. Using ³⁄₄" screws, install the L brackets on the outside
windowsill. The short side of the brackets should face toward
the outside.
Position the Air Conditioner
NOTES:
■Handle air conditioner gently.
■Be sure your air conditioner does not fall out of the opening
during installation or removal.
■The place where the power cord exits the air conditioner
should be no more than 6 ft (182.9 cm) from a grounded
outlet.
■Do not block the louvers in the front panel.
■Do not block the louvers on the outside of the air conditioner.
1. Center air conditioner in window. Be sure the bottom
channels on the air conditioner drop into the notches of the L
brackets. Lower the window sash behind the top channel to
hold cabinet in place.
NOTE: Your model may differ from the one shown.
A. Width of window opening
B. Center line
B
A
A. Outside windowsill
B.
³⁄₄ " screw
C. Inside windowsill
D. Center line
E. 7 ¹⁄₂ "
F. Short side of L bracket
A
BC
D
B
E
E
F
WARNING
Excessive Weight Hazard
Use two or more people to move and install
air conditioner.
Failure to do so can result in back or other injury.
A. Side curtain against window channel
B. Window sash behind top channel
C. Bottom channel in bracket notches
B
C
A

8
2. Remove the screw on the right-hand side of the air
conditioner cabinet near the bottom.
3. Attach the side bracket to the air conditioner cabinet.
4. Use ¹⁄₈" drill bit to drill a starter hole through the holes in the
side bracket and windowsill.
5. Using two ³⁄₄" screws, attach the side bracket to the
windowsill.
6. Repeat for side bracket installation on the left-hand side of
the air conditioner.
Attach Side Curtains to Window
1. Pull the left-hand curtain out until it fits into the window
channel.
2. Use ¹⁄₈" drill bit to drill a starter hole through the hole in the
side curtain and window sash.
3. Insert one of the ³⁄₄" screws through the left-hand curtain and
into the window sash.
4. Repeat for the right-hand curtain.
Window Sash View
5. Drill a starter hole through the notch in the side curtain and
the windowsill.
6. Insert one of the ³⁄₄" screws through curtain notch and into
the windowsill.
7. Repeat for the right-hand curtain.
Windowsill View
A. Window sash
B. Hole in side curtain
C.
³⁄₄ " screw
A.
³⁄₄ " screw
B. Notch in side curtain
C. Windowsill
A
B
C
A
B
C

9
Complete Installation
1. Insert foam seal behind the top of the lower window sash and
against the glass of the upper window.
2. Use a ¹⁄₈" drill bit to drill a starter hole through the hole in the
top channel.
3. Attach top channel to window sash with one ³⁄₄" screw to
secure window in place.
4. Plug into a grounded 3 prong outlet.
5. Press RESET on the power supply cord. See “Electrical
Requirements.”
AIR CONDITIONER USE
Operating your air conditioner properly helps you to obtain the
best possible results.
This section explains proper air conditioner operation.
IMPORTANT:
■If you turn off the air conditioner, wait at least 3 minutes
before turning it back on. This prevents the air conditioner
from blowing a fuse or tripping a circuit breaker.
■Do not try to operate your air conditioner in the Cool mode
when outside temperature is below 65°F (18°C). The inside
evaporator coil will freeze up, and the air conditioner will not
operate properly.
NOTE: In the event of a power failure, your air conditioner will
operate at the previous settings when the power is restored.
A. Top of lower window sash
B. Foam seal
A
B
Electrical Shock Hazard
Plug into a grounded 3 prong outlet.
Do not remove ground prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions can result in death,
fire, or electrical shock.
WARNING

10
Starting Your Air Conditioner
Cool Only Models Heat/Cool Models
NOTE: When the air conditioner is set to Fan mode and the room
temperature is below 32ºF (0ºC), the display will show LO. If the
room temperature is above 99ºF (37ºC), the display will show HI.
1. Remove the clear protective film from the front panel badge.
2. Press the power button to turn on the air conditioner.
NOTE: When the air conditioner is turned on for the first time
after it is plugged in, the display will show the current room
temperature and will run in the 6th Sense™System control.
When the air conditioner is turned on at all other times, the
display will show the previous settings for 5 seconds, and
then show the current room temperature.
3. Select mode. See “Mode.”
4. Select fan speed. See “Fan Speed.”
5. Set temperature. See “Temperature.”
Mode
1. Press MODE until you see the indicator light glow for the
desired setting.
2. Choose Cool, Dry, Fan or Heat (Heat/Cool models only).
■Cool—Cools the room. Press FAN SPEED to select High,
Med, Low or Auto. Press the plus or minus TEMP button
to adjust the temperature.
■Dry—Dries the room. The air conditioner automatically
selects the temperature. Fan runs on Low speed only.
NOTE: Dry mode should not be used to cool the room.
■Fan—Only the fan runs. Press FAN SPEED to select High,
Med or Low. The display shows the current room
temperature.
■Heat (Heat/Cool models only)—Heats the room. Press
FAN SPEED to select High, Med, Low or Auto. Press the
plus or minus TEMP buttons to adjust the temperature.
NOTE: After 5 seconds, the display will show the current room
temperature.
Fan Speed
NOTE: The Fan Speed button will operate only when the Cool,
Fan or Heat mode (on some models) is selected.
1. Press FAN SPEED until you see the indicator light glow for
the desired setting.
2. Choose High, Med, Low or Auto.
■High—for maximum cooling
■Med—for normal cooling
■Low—for sleeping comfort

11
■Auto—automatically controls the fan speed depending on
the current room temperature and temperature control
setting
NOTE: Auto fan speed cannot be selected in Fan mode.
NOTE: After 5 seconds, the display will show the current room
temperature.
Filter Monitor
1. When the Filter Monitor indicator light is lit, remove, clean and
replace the air filter. See “Cleaning the Air Filter.”
2. Press FILTER MONITOR after cleaning and replacing the air
filter. This resets the filter monitor.
NOTE: After 360 hours of fan operating time, the filter indicator
light will turn on. It will remain on for 180 hours or until you press
FILTER MONITOR. After 180 hours, it will turn off automatically.
Temperature
■Press the plus TEMP button to raise the temperature. Each
time you press or hold the plus TEMP button, the
temperature will go up 2ºF (1ºC) until it reaches 90°F (32°C).
NOTE: After 5 seconds, the display will show the current
room temperature.
■Press the minus TEMP button to lower the temperature. Each
time you press or hold the minus TEMP button, the
temperature will go down 2ºF (1ºC) until it reaches 64°F
(18°C).
NOTE: After 5 seconds, the display will show the current room
temperature.
Timer Delay
To set the Timer for a 30-minute to 24-hour delay until the
air conditioner turns off (the air conditioner must be On):
1. Press TIMER. Timer indicator light will flash. Display will show
remaining hours before the air conditioner will turn off.
2. Press the plus or minus TEMP button to change the delay
time from 30 minutes to 24 hours.
3. After 5 seconds, Timer indicator light will remain on. Display
will show the current room temperature.
To set the Timer to turn on the air conditioner, keeping
previous settings:
1. Turn off air conditioner.
2. Press TIMER. Timer indicator light will flash. Display will show
remaining hours before the air conditioner will turn on.
3. Press the plus or minus TEMP button to change the delay
time from 30 minutes to 24 hours.
4. After 5 seconds, Timer indicator light will remain on. Display
will show current room temperature.
To set the Timer to turn on the air conditioner, changing
previous settings:
1. Turn on air conditioner.
2. Adjust the mode to Cool, Dry, Fan or Heat (Heat/Cool models
only).
3. For Cool or Heat (Heat/Cool models only) mode:
■Adjust fan speed to High, Med, Low or Auto.
■Adjust temperature between 64ºF and 90ºF (18ºC and
32ºC).
4. For Fan mode, adjust fan speed to High or Low.
NOTE: In Fan mode, temperature cannot be set.
5. For Dry mode, adjust temperature up or down by 4ºF (2ºC).
6. Turn off air conditioner.
7. Press TIMER. Timer indicator light on the air conditioner
control panel will flash.
8. Press up or down arrow button to change the delay time from
30 minutes to 24 hours.
9. After 5 seconds, Timer indicator light on the air conditioner
control panel will remain on.
To clear Timer delay program:
NOTE: Air conditioner can be either on or off.
1. Press TIMER once after it has been programmed. Display will
show remaining time.
2. While the display is showing the remaining time, press TIMER
again. Timer indicator light will turn off.
To see or change the remaining time (in hours):
1. Press TIMER once after it has been programmed. Display will
show remaining time.
2. While the display is showing the remaining time, you can
press the plus or minus TEMP button to increase or decrease
the time.
3. After 5 seconds, the display will show the current room
temperature.

12
Using the Remote Control
NOTE: Remote control may differ in appearance.
NOTE: One CR2025 battery (included) powers the remote
control. Replace battery after 6 months of use, or when the
remote control starts to lose power.
Power
Press POWER to turn on the air conditioner.
Mode
Press MODE to choose Cool, Dry or Fan.
6th Sense™ System Control
The air conditioner automatically selects Cool or Dry mode,
depending on room temperature and sets the temperature to
79ºF (26ºC).
■The temperature set point can be adjusted down to 75ºF
(24ºC) or up to 83ºF (28ºC). Press the up or down arrow
button once to change the temperature 2ºF (1ºC) or twice to
change it 4ºF (2ºC).
■If the current room temperature is lower than the temperature
set point, Dry mode is selected. Fan runs on Auto speed only.
■If the current room temperature is higher than the
temperature set point, Cool mode is selected. Fan speed may
be selected by the user.
1. Press 6th Sense™System control.
2. In Cool mode, press FAN to select High, Med, Low or Auto.
RapidCool™Control
Used for fast cooling. The air conditioner automatically sets the
fan speed to High and temperature to 64°F (18ºC).
NOTE: 6th Sense™System control button does not operate when
RapidCool control is selected.
1. Press RapidCool™control. The air conditioner automatically
sets the fan speed to High and temperature to 64°F (18ºC).
2. To turn RapidCool™control off, press the RapidCool control
button, Mode, Fan, Power or the up arrow button.
Fan Speed
Press FAN to choose High, Med, Low or Auto.
NOTE: Auto fan speed cannot be selected in Fan mode.

13
Sleep Control
NOTES:
■If the current room temperature is 80ºF (26ºC) or higher, the
set temperature will not change when Sleep control is
activated.
■If the current room temperature is below 80ºF (26ºC), the set
temperature will automatically increase 2ºF (1ºC) during the
first 2 hours after Sleep control is activated.
The set temperature will not increase during the last 6 hours
of Sleep control.
1. Press MODE to select Cool, Heat (Heat/Cool models only) or
Dry.
2. Press FAN to select High, Med or Low.
3. Press the up or down arrow button to set the temperature.
4. Press SLEEP. After 10 seconds, the lights on the control
panel display will dim. The mode indicator lights will remain
on.
NOTE: The mode, temperature and fan speed may be
adjusted during Sleep control. After 10 seconds, the lights on
the control panel display will dim again.
5. To turn off Sleep control, press SLEEP again. or wait 8 hours
for the air conditioner to turn off automatically.
NOTE: The air conditioner will return to previous settings after
Sleep control is turned off.
Temperature
■Press the up arrow button to raise the temperature. Each time
you press or hold the up arrow button, the temperature will go
up 2ºF (1ºC) until it reaches 90°F (32°C).
■Press the down arrow button to lower the temperature. Each
time you press or hold the down arrow button, the
temperature will go down 2ºF (1ºC) until it reaches 64°F
(18°C).
Timer
To set Timer for a 30-minute to 24-hour delay before air
conditioner is turned off (air conditioner must be On):
1. Press TIMER. Timer indicator light on the air conditioner
control panel will flash.
2. Press up or down arrow button to change the delay time from
30 minutes to 24 hours.
3. After 5 seconds, Timer indicator light on the air conditioner
control panel will remain on.
To set Timer to turn on air conditioner, keeping previous
settings:
1. Turn off the air conditioner.
2. Press TIMER. Timer indicator light on the air conditioner
control panel will flash.
3. Press up or down arrow button to change the delay time from
30 minutes to 24 hours.
4. After 5 seconds, Timer indicator light on the air conditioner
control panel will remain on.
To set Timer to turn on air conditioner, changing the
previous settings:
1. Turn on air conditioner.
2. Adjust the mode to 6th Sense™System control, Cool, Dry, Fan,
Heat (Heat/Cool models only) or RapidCool™control.
3. For Cool or Heat (Heat/Cool models only) mode:
■Adjust fan speed to High, Med, Low or Auto.
■Adjust temperature between 64ºF and 90ºF (18ºC and
32ºC).
4. For Fan mode, adjust fan speed to High, Med or Low.
NOTE: In Fan mode, temperature cannot be set.
5. For 6th Sense™System control, adjust fan speed to High,
Med, Low or Auto.
6. For Dry mode and 6th Sense™System control, adjust
temperature up or down by 4ºF (2ºC).
7. Turn off air conditioner.
8. Press TIMER. Timer indicator light on the air conditioner
control panel will flash.
9. Press up or down arrow button to change the delay time from
30 minutes to 24 hours.
10. After 5 seconds, Timer indicator light on the air conditioner
control panel will remain on.
To clear Timer delay program:
NOTE: Air conditioner can be either on or off.
1. Press TIMER once after it has been programmed. Display will
show remaining time.
2. While the display is showing the remaining time, press TIMER
again. Timer indicator light will turn off.
To see or change the remaining time (in hours):
1. Press TIMER once after it has been programmed. Display will
show remaining time.
2. While the display is showing the remaining time, press the
plus or minus TEMP button to increase or decrease the time.
3. After 5 seconds, the display will show the current room
temperature.

14
Changing Air Direction
Roll the wheel to direct the air right or left. Rotate the whole cartridge to direct air up, down or straight ahead.
Exhaust Air Vent
■Pull out the exhaust air vent control to Open the exhaust air
vent and draw stale or smoky air from the room.
■Push in the exhaust air vent control to close the exhaust air
vent for maximum continuous cooling.
NOTE: The exhaust air vent control will function only when the
Fan Speed control is operating.
Normal Sounds
When your air conditioner is operating normally, you may hear
sounds such as:
■Droplets of water hitting the condenser, causing a pinging or
clicking sound. The water droplets help cool the condenser.
■Air movement from the fan.
■Clicks from the thermostat cycle.
■Vibrations or noise due to poor wall or window construction.
■A high-pitched hum or pulsating noise caused by the modern
high-efficiency compressor cycling on and off.
AIR CONDITIONER CARE
Your new air conditioner is designed to give you many years of dependable service. This section tells you how to clean and care for your
air conditioner properly. Call your local authorized dealer for an annual checkup. Remember… the cost of this service call is your
responsibility.
Cleaning the Air Filter
The air filter is removable for easy cleaning. A clean filter helps
remove dust, lint, and other particles from the air and is important
for best cooling and operating efficiency. Check the filter every
2 weeks to see whether it needs cleaning.
NOTE: Do not operate the air conditioner without the filter in
place.
1. Turn off the air conditioner.
2. Remove the air filter by sliding the filter out from the left-hand
side of the front panel.
3. Use a vacuum cleaner to clean the air filter. If the air filter is
very dirty, wash it in warm water with a mild detergent. Do not
wash the air filter in the dishwasher or use any chemical
cleaners. Air dry the filter completely before replacing to
ensure maximum efficiency.
4. Replace the air filter by sliding the filter back into the left-
hand side of the air conditioner.
Cleaning the Front Panel
1. Turn off the air conditioner.
2. Clean the front panel with a soft, damp cloth.
3. Air dry the front panel completely.
A. Wheel
A
A. Cartridge
A
A. Exhaust air vent control
A

15
Repairing Paint Damage
Check once or twice a year for paint damage. This is very
important, especially in areas near oceans or where rust is a
problem. If needed, touch up with a good grade enamel paint.
Annual Maintenance
Your air conditioner needs annual maintenance to help ensure
steady, top performance throughout the year. Call your local
authorized dealer to schedule an annual checkup. The expense
of an annual inspection is your responsibility.
TROUBLESHOOTING
Before calling for service, try the suggestions below to see whether you can solve your problem without outside help.
Air conditioner will not operate
■The power supply cord is unplugged. Plug into grounded
3 prong outlet. See “Electrical Requirements.”
■The power supply cord has tripped (Reset button has
popped out). Press and release RESET (listen for click; Reset
button will latch and on some devices, a green light will turn
on) to resume operation.
■A household fuse has blown, or circuit breaker has
tripped. Replace the fuse or reset the circuit breaker. If the
problem continues, call an electrician. See “Electrical
Requirements.”
■The Power button has not been pressed. Press the Power
button.
■The local power has failed. Wait for power to be restored.
Air conditioner blows fuses or trips circuit breakers
■Too many appliances are being used on the same circuit.
Unplug or relocate appliances that share the same circuit.
■Time-delay fuse or circuit breaker of the wrong capacity
is being used. Replace with a time-delay fuse or circuit
breaker of the correct capacity. See “Electrical
Requirements.”
■An extension cord is being used. Do not use an extension
cord with this or any other appliance.
■You are trying to restart the air conditioner too soon after
turning off the air conditioner. Wait at least 3 minutes after
turning off the air conditioner before trying to restart the air
conditioner.
Air conditioner power supply cord trips (Reset button
pops out)
■Disturbances in your electrical current can trip (Reset
button will pop out) the power supply cord. Press and
release RESET (listen for click; Reset button will latch and on
some devices, a green light will turn on) to resume operation.
■Electrical overloading, overheating, cord pinching or
aging can trip (Reset button will pop out) the power
supply cord. After correcting the problem, press and release
RESET (listen for click; Reset button will latch and on some
devices, a green light will turn on) to resume operation.
NOTE: A damaged power supply cord must be replaced with a
new power supply cord obtained from the product manufacturer
and must not be repaired.
Air conditioner seems to run too much
■The current air conditioner replaced an older model. The
use of more efficient components may cause the air
conditioner to run longer than an older model, but the total
energy consumption will be less. Newer air conditioners do
not emit the “blast” of cold air you may be accustomed to
from older air conditioners, but this is not an indication of
lesser cooling capacity or efficiency. Refer to the efficiency
rating (EER) and capacity rating (in Btu/h) marked on the air
conditioner.
■The air conditioner is in a heavily occupied room, or heat-
producing appliances are in use in the room. Use exhaust
vent fans while cooking or bathing and try not to use heat-
producing appliances during the hottest part of the day. A
higher capacity air conditioner may be required, depending
on the size of the room being cooled.
Air conditioner cycles on and off too much or does not
cool/heat room in cooling/heating mode
■The air conditioner is not properly sized for your room.
Check the cooling capabilities of your room air conditioner.
Room air conditioners are not designed to cool multiple
rooms.
■The filter is dirty or obstructed by debris. Clean the filter.
■The inside evaporator and outside condenser coils are
dirty or obstructed by debris. See “Annual Maintenance.”
■There is excessive heat or moisture (open container
cooking, showers, etc.) in the room. Use a fan to exhaust
heat or moisture from the room. Try not to use heat-
producing appliances during the hottest part of the day.
■The louvers are blocked. Install the air conditioner in a
location where the louvers are free from curtains, blinds,
furniture, etc.
Electrical Shock Hazard
Plug into a grounded 3 prong outlet.
Do not remove ground prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions can result in death,
fire, or electrical shock.
WARNING

16
■The outside temperature is below 65°F (18°C). Do not try to
operate your air conditioner in the cooling mode when the
outside temperature is below 65°F (18°C).
■The temperature of the room you are trying to cool is
extremely hot. Allow extra time for the air conditioner to cool
off a very hot room.
■Windows or doors to the outside are open. Close all
windows and doors.
■The Exhaust control is set to Open. Push the Exhaust
control Closed for maximum cooling.
■The Temp control is not at a cool enough setting. Adjust
the Temp control to a cooler setting by pressing the minus
button to reduce the temperature. Set the Fan Speed control
to the highest setting.
■The air conditioner in the heating mode has insufficient
Btu/h for the heating requirements of the room. Do not
use the air conditioner as a primary source of heat.
Water drips from cabinet into your house
■The air conditioner is not properly leveled. The air
conditioner should slope slightly downward toward the
outside. Level the air conditioner to provide a downward
slope toward the outside to ensure proper drainage. See the
Installation Instructions.
NOTE: Do not drill a hole in the bottom of the metal base and
condensate pan.
ASSISTANCE OR SERVICE
Before calling for assistance or service, please check
“Troubleshooting.” It may save you the cost of a service call. If
you still need help, follow the instructions below.
When calling, please know the purchase date and the complete
model and serial number of your appliance. This information will
help us to better respond to your request.
If you need replacement parts
If you need to order replacement parts, we recommend that you
use only factory-specified replacement parts. Factory-specified
replacement parts will fit right and work right because they are
made with the same precision used to build every new appliance.
To locate factory-specified replacement parts in your area, call
your nearest designated service center.
Please record your model's information.
Whenever you call to request service on your appliance, you
need to know your complete model number and serial number.
You can find this information on the model and serial number
label. See “Electrical Requirements” for the location of the model
and serial number label.
Please record the model and serial number information below.
Also, record the purchase date of your appliance and the store's
name, address, and telephone number.
Model Number__________________________________________________
Serial Number __________________________________________________
Purchase Date__________________________________________________
Store Name ____________________________________________________
Store Address __________________________________________________
Store Phone ____________________________________________________
Keep this book and the sales slip together for future reference.
In the U.S.A.
Call Customer Service toll free: 1-877-465-3566 or visit our
website at www.whirlpool.com.
Our consultants provide assistance with:
■Features and specifications on our appliances.
■Installation information.
■Use and maintenance procedures.
■Repair parts sales.
■Referrals to repair parts distributors and service companies.
Designated service technicians are trained to fulfill the
product warranty and provide after-warranty service,
anywhere in the United States.
For further assistance
If you need further assistance, you can write with any questions
or concerns to:
Hisense USA Inc.
Customer Service
105 Satellite Blvd. NW, Suite A
Suwanee, GA 30024
Please include a daytime phone number in your correspondence.
In Canada
Call Customer Service toll free: 1-800-360-2742, or visit our
website at www.whirlpool.com.
Our consultants provide assistance with:
■Features and specifications on our appliances.
■Use and maintenance procedures.
■Repair parts sales.
■Referrals to repair parts distributors and service companies.
Designated service technicians are trained to fulfill the
product warranty and provide after-warranty service,
anywhere in Canada.
For further assistance
If you need further assistance, you can write with any questions
or concerns to:
Hisense USA Inc.
Customer Service
105 Satellite Blvd. NW, Suite A
Suwanee, GA 30024
U.S.A.
Please include a daytime phone number in your correspondence.

17
Notes

18
SEGURIDAD DEL ACONDICIONADOR DE AIRE
REQUISITOS DE INSTALACIÓN
Herramientas y piezas
Reúna las herramientas y piezas necesarias antes de comenzar
la instalación. Lea y siga las instrucciones provistas con
cualquiera de las herramientas enlistadas aquí.
Herramientas necesarias
Piezas suministradas
Verifique que estén todas las piezas en el paquete de piezas.
Si no sigue las instrucciones de inmediato, usted puede
morir o sufrir una lesión grave.
Si no sigue las instrucciones, usted puede morir o sufrir
una lesión grave.
Todos los mensajes de seguridad le dirán el peligro potencial, le dirán cómo reducir las posibilidades de sufrir una lesión y lo que
puede suceder si no se siguen las instrucciones.
Su seguridad y la seguridad de los demás es muy importante.
Hemos incluido muchos mensajes importantes de seguridad en este manual y en su electrodoméstico. Lea y obedezca siempre
todos los mensajes de seguridad.
ADVERTENCIA
PELIGRO
Este es el símbolo de advertencia de seguridad.
Este símbolo le llama la atención sobre peligros potenciales que pueden ocasionar la muerte o una lesión a
usted y a los demás.
Todos los mensajes de seguridad irán a continuación del símbolo de advertencia de seguridad y de la palabra
“PELIGRO” o “ADVERTENCIA”. Estas palabras significan:
INSTRUCCIONES IMPORTANTES DE SEGURIDAD
ADVERTENCIA:
Para reducir el riesgo de incendio, choque eléctrico o lesiones personales al usar su acondicionador de aire,
siga estas precauciones básicas:
CONSERVE ESTAS INSTRUCCIONES
Desconecte el acondicionador de aire antes de
darle servicio.
Use dos o más personas para mover e instalar el
acondicionador de aire.
Conecte a un contacto de pared de conexión a tierra de
3 terminales.
No quite el terminal de conexión a tierra.
No use un adaptador.
No use un cable eléctrico de extensión.
■Destornillador Phillips
■Tijeras
■Nivel
■Cinta para medir
■Taladro inalámbrico y una
broca de ¹⁄₈"
■Lápiz
A. Sello adhesivo
B. Sello espuma
C. Soportes en L (2)
D. Soportes laterales (2)
E. Tornillos de
³⁄₈ "(8)
F. Tornillos de
³⁄₄ " (12)
G. Cortinas laterales (2)
A
B
C
DEF
G

19
Requisitos de ubicación
IMPORTANTE: Observe todos los códigos y reglamentos
aplicables.
Verifique el lugar donde se instalará el acondicionador de aire.
Asegúrese de que tiene todo lo necesario para una instalación
correcta.
El lugar debe tener:
■Modelos con aire caliente/frío—Tomacorriente puesto a tierra
a 4 pies (122 cm) de la parte donde el cable eléctrico sale del
acondicionador de aire.
■Modelos con sólo aire frío—Tomacorriente puesto a tierra a
6 pies (182,9 cm) de la parte donde el cable eléctrico sale del
acondicionador de aire.
NOTA: No use un cable eléctrico de extensión.
■Libertad de movimiento del aire en la habitación que desea
enfriar.
■Una abertura con la amplitud suficiente para el
acondicionador de aire. Se incluyen piezas de instalación
para ventanas de guillotina.
■Soporte adecuado en la pared para el peso del
acondicionador de aire. El acondicionador de aire pesa de
88 lbs a 100 lbs (40 kg a 45 kg).
NOTA: No deben obstruirse las rejillas de la carcasa. El aire debe
circular libremente a través de las rejillas de la carcasa.
Instalación en la ventana
Medidas de la abertura de la ventana:
■Ancho de la abertura: 22³⁄₄" mín. a 32⁵⁄₈" máx. (57,8 cm a
82,9 cm)
■Altura de la abertura: 15" mín. (38,1 cm)
A. Rejillas de la carcasa
A
A. 22 ³⁄₄ " mín. (57,8 cm)
B. 15" mín. (38,1 cm)
A
B

20
Requisitos eléctricos
Las clasificaciones eléctricas para su acondicionador de aire
están enumeradas en la etiqueta de número del modelo y de
serie. La etiqueta de modelo y serie se encuentra en el lado
derecho de la carcasa del acondicionador de aire.
Los requisitos eléctricos específicos se indican en la tabla a
continuación. Siga los requisitos para el tipo de enchufe en el
cable de alimentación eléctrica.
Método recomendado para la puesta a tierra
Este acondicionador de aire debe ser puesto a tierra. Este
acondicionador de aire está equipado con un cable de suministro
de energía provisto de un enchufe con tres terminales. Para
reducir a un mínimo el peligro de posibles choques eléctricos, el
cable debe ser enchufado en un contacto apropiado de pared de
tres terminales conectado a tierra de acuerdo con todos los
códigos y reglamentos locales. Si no se dispone de un
tomacorriente apropiado, es responsabilidad del cliente hacer
instalar un contacto con tres terminales debidamente puesto a
tierra por un instalador eléctrico calificado.
Es responsabilidad del cliente:
■Llamar a un instalador eléctrico calificado.
■Asegurarse de que la instalación eléctrica sea adecuada y
esté hecha de acuerdo con el Código Nacional Eléctrico,
ANSI/NFPA 70, última edición, y todos los códigos y
reglamentos locales.
Pueden obtenerse copias de las normas señaladas en:
National Fire Protection Association
One Batterymarch Park
Quincy, MA 02269
Cable de suministro de energía
NOTA: El dispositivo de su unidad puede ser diferente del que se
ilustra.
Este acondicionador de aire para habitación está equipado con
un cable de suministro de energía según lo exige UL. Este cable
de suministro de energía incluye circuitos electrónicos de última
generación que detectan la fuga de corriente. Si se aplasta el
cable, el elemento electrónico detecta la fuga de corriente y la
energía se desconecta en una fracción de segundo.
Para poner a prueba el cable de suministro de energía:
1. Enchufe el cable de suministro de energía en un
tomacorriente de 3 terminales con conexión a tierra.
2. Presione RESET (Reposición) (en algunos aparatos se
encenderá una luz verde).
3. Presione TEST (Prueba) (escuche el chasquido, el botón de
reposición se atrapará y en algunos aparatos se apagará una
luz verde).
4. Presione y suelte RESET (escuche el chasquido, el botón de
reposición queda asegurado y en algunos aparatos se
encenderá una luz verde). El cable de suministro de energía
está listo para su funcionamiento.
El cable eléctrico Requisitos de cableado
■115 voltios (103,5 mín. - 126,5 máx.)
■0-12 amperios
■Fusible de retardo de 15 amperios o
disyuntor
■Úselo solamente en un circuito con
tomacorriente único.
ADVERTENCIA
Peligro de Choque Eléctrico
Conecte a un contacto de pared de conexión a tierra de
3 terminales.
No quite la terminal de conexión a tierra.
No use un adaptador.
No use un cable eléctrico de extensión.
No seguir estas instrucciones puede ocasionar
la muerte, incendio o choque eléctrico.
A. Botón de prueba
B. Botón de reposición
TEST
RESET
A
B
ADVERTENCIA
Peligro de Choque Eléctrico
Conecte a un contacto de pared de conexión a tierra de
3 terminales.
No quite la terminal de conexión a tierra.
No use un adaptador.
No use un cable eléctrico de extensión.
No seguir estas instrucciones puede ocasionar
la muerte, incendio o choque eléctrico.
