Whirlpool AKZ 162 - USING THE ELECTRONIC PROGRAMMER Guide

GUIDE TO USING THE ELECTRONIC PROGRAMMER
GB
5019 610 56189
Electronic Display
programmer Operating the oven using the electronic programmer
Temperature
increase
indicators
Heat
Maintenance
Extra
browning
Cooking time ClockEnd of
cooking time
Fast starting the oven
When the oven is connected to the power supply for the first time, or reconnected after a power
failure, the display indicates “ ”.
To switch on the oven:
1. Turn knob 1 to “0”.
2. press the 2<< button. The display shows “--:--”.
Selecting and changing the clock time:
1. Press the button 2three times.
2. Turn the knob 2within 15 seconds to set the time of day. The time of day flashes on the display.
3. Press the button 2or wait 15 seconds to get automatic confirmation of the setting.
To modify the time of the day:
Press the button 2twice blinks on the display. Repeat the steps described above.
Select cooking function:
1. Turn knob 1to the chosen function: the preset temperature or grill level will flash on the
display.
2. If this value is right, press the button 2to confirm or wait 10 seconds to have the setting
accepted automatically.
To change the pre-set temperature or grill level:
1. Turn knob 3: the temperature (or grill level when knob 1is on the selection )
blinks on the display.
2. Press button 2to confirm or else wait about 10 seconds to have the setting accepted
automatically.
The oven begins operation about 5 seconds after confirmation: the temperature increase
indicators on the display turn on sequentially, indicating the temperature increase on the
graduated scale °C .
Notes:
The set values can be changed even during cooking.
At the end of cooking:
Switch off the oven by turning knob 1back to“0”. The time of day appears again on the display.
Important notes:
To cancel any selection made, turn knob 1to “0”.
Keeping button 2down for 5 seconds deactivates the audio signal associated with the manipulation of knobs and buttons.
Press button 2again for 5 seconds to reactivate. For safety reasons, the oven switches off automatically (except for the
“ ” and functions) after 4.5 hours of continuous operation.
S
electing the cooking time:
S
elect the cooking time (available with any function) to turn the oven on for a specified period of
t
ime. At the end of the specified time the oven will switch off automatically. The maximum
p
rogrammed cooking time is 3 hours and 59 minutes.
1. Set the function and temperature or grill level (see chapter: “Fast starting the oven” and
“Selecting the cooking function”).
2
. Repeatedly press the button 2, the indicator blinks on the display and “-0:00” appears.
3. Turn knob 3clockwise: the selected time blinks on the display. The appearance of the dash ”-
”indicates that the chosen time decreases until “0” is reached.
4
. The oven automatically starts cooking 20 seconds after the setting and the time remaining until
the end of cooking appears on the display.
Note: To view or change the previously set temperature, turn the knob 3by one click. To return
to the display of the remaining time, wait 20 seconds or press the button 2.
T
o use the special functions Extra browning and Heat Maintenance , consult the chapter
“
Special functions”.
T
o change the pre-set temperature or grill level:
T
urn the knob 3and confirm by pressing the button 2or wait about 10 seconds for automatic
a
cceptance of the setting.
A
ppearance of on the display:
W
hen the pre-set time (end of cooking) runs out, appears on the display and an acoustic
s
ignal sounds for 15 minutes in intervals. The oven switches off automatically and the oven's interior
l
amp stay on for 25 min.
1. Press button 2to stop the acoustic signal.
2
. Turn knob 1back to “0”. The lamp turns off.
T
he time of day appears again on the display.
1ON/OFF - Function Selector Knob
2Button to select and confirm
programmes
3Knob to change preprogrammed values
(temperature, time, levels)
 !

Setting end of cooking time
Special functions: (Extra browning and Heat Maintenance )
These functions are only available with the selection of cooking time or end of cooking time.
It is possible to select the two special functions simultaneously or separately.
Extra browning
This function is used for browning food (e.g. roast) during cooking. It is possible to choose between levels 1-2-3, where the
number 1represents minimum browning and the number 3maximum browning.
This function can be selected only together with the functions .
Selecting the special Extra Browning function:
Selecting the special Heat Maintenance function:
Minute minder
By using this function it is possible to preset the end of cooking time. The maximum programmed
cooking time is 23 hours and 59 minutes.
1. Set the function and temperature or grill level. See chapter: “Fast starting the oven”, paragraph:
“Select cooking function”.
2. Example: it is 10 a.m.: press button 2, the indicator blinks on the display and “- 0:00”
appears.
3. Set the cooking time (e.g. 45 minutes) by turning the knob 3: the set time appears on the
display.
4. Press the button 2to confirm setting selection (e.g. 45 minutes): the indicator blinks and
the display indicates the time of day plus the cooking time (e.g.: time 10:00 + 45 minutes = ore
10:45).
5. Select the time when you want cooking to end by turning the knob 3
(e.g.: 12:30).
6. Repeatedly press the button 2until the time of day (10:00) appears, or wait about 20 seconds
for the setting to be automatically accepted.
The oven will turn on automatically at the end of cooking time minus cooking time
(e.g. 11:45): on the display turn on.
To verify the chosen temperature or grill level, turn knob 3by one click.
To verify or change both the cooking time (e.g. 45 min.) and the end of cooking time (e.g. 12:39),
press the <<button 2.
1
.
S
e
t
th
e coo
ki
ng
ti
me or en
d
o
f
coo
ki
ng
ti
me.
S
ee
“F
as
t
s
t
ar
ti
ng
th
e oven
”
an
d
“S
e
l
ec
ti
ng
th
e
cooking function”.
2. Repeatedly press button 2until the symbol blinks on the display and “0” appears.
3. Turn the knob 3to select the food's level of browning: 1, 2 or 3.
4. Press button 2twice or wait 20 seconds to get automatic confirmation of the setting.
Heat Maintenance
This function is used to maintain an oven temperature of 60°C at the end of cooking with automatic oven
operation.
The “Heat Maintenance” function can be selected only together with the functions .
1. Set the cooking time or end of cooking time. See chapter: “Fast starting the oven” and “Selecting
the cooking function”
2. Repeatedly press button 2, the symbol blinks on the display and “-- C” appears on the
display.
3. Turn the knob 3to “60C”.
4. Press button 2or wait 20 seconds to get automatic confirmation of the setting.
The minute minder can only be used when the oven is not in use, and allows a maximum setting of 3 hours
and 59 minutes.
To set the minute minder:
1. Leave knob 1on “0”. The display shows the time of the day.
2. Press button 2, the symbol blinks on the display.
3. Turn knob 3clockwise. The set time blinks on the display. The appearance of the dash “-”
indicates that the chosen time decreases until “0” is reached.
4. Press button 2or wait about 20 seconds to get automatic confirmation of the setting.
Once the set time has elapsed:
An acoustic signal is heard and appears on the display.
Press the <<button 2: The acoustic signal stops. The time of day appears again on the display.
