COOKTOP PARTS
1
For Models: RCS3004RS02
(Stainless)
09−07 Litho in U.S.A. (amd) Part No. W10163661 Rev. A
30" ELECTRIC
BUILT−IN
COOKTOP

COOKTOP PARTS
2
For Models: RCS3004RS02
(Stainless)
W10163661
Illus. Part
No. No. DESCRIPTION
1 Literature Parts
8286310 Installation
Instructions
8286613 Use & Care Guide
Safer Cooking Tips
3191638 English
9759133 French
2 8286401 Bracket, Switch
Mounting
3 3192454 Bracket, Mounting
4
W10140171 Cooktop
5 8286373 Burner Box
6 3400093 Screw
7 Switch, Infinite
3191472 Use W/8" Element
(Silver Shaft)
3191471 Use W/6" Element
(Blue Shaft)
8 4456181 Light, Indicator
9 4455917 Bracket, Mounting
10 3400093 Screw
11 Pan, Surface
3195208 6" Pan (2)
3195209 8" Pan (2)
12 Unit, Surface
8053265 6" (2)
8053267 8" (2)
13 3195917 Clip, Element
14
8286043BL Knob, Control (4)
15 3183956 Seal, Switch
16 3191506 Bushing, Conduit
17 3196537 Screw
18 3400855 Screw
19 3400015 Screw
20 3177991 Screw
WIRING HARNESS PARTS
8286368 Harness, Main
4455805 Grommet
8286375 Conduit Assembly
3196160 Screw
