INSTALL THE ICE MAKER
Please replace current Page 9 in the Installation Guide with this insert.
Top/Bottom Freezer Models
IMPORTANT:
■Depending on your model, you will have one of three styles of
connection. Read and follow the instructions specific to your
model.
■You will be working inside the freezer compartment.
Access Water Fill Tube and Wiring Harness
Style 1 - Open-Top Fill Tube with Wiring Cover
1. Remove the screw from the ice maker wiring cover.
2. Squeeze the top and bottom to release the snaps along the
top edge of the cover. Remove and discard the cover.
3. Pull the 4-wire ice maker harness out from behind the back of
the freezer as far as possible, and hang it over the edge of the
cutout.
NOTE: Do not remove any other wiring.
Style 2 - Flat Wiring Cover
1. Remove the screw from the ice maker wiring cover.
2. Unhook the tab on the right-hand side of the cover and
remove the wiring cover.
3. Look at the back of the wiring cover and locate the grooved
lines. Using pliers, bend the areas inside the grooved lines
back and forth until they break away from the cover.
4. Pull the 4-wire ice maker harness out from behind the back of
the freezer as far as possible, and hang it over the edge of the
cutout.
NOTE: Do not remove any other wiring.
Style 3 - Evaporator Cover Only
1. Remove the four plastic plugs to access the screws. Remove
the four screws. Set aside.
2. Remove the evaporator cover by disengaging it from the side
snaps.
NOTE: The evaporator cover has a plastic foam backing.
3. Punch through both the plastic foam backing and plastic
evaporator cover where indicated by the indentations on the
back of the cover.
4. Remove and discard the circular and rectangular cutouts to
create holes for the fill tube and wire harness to pass through.
W10519544A
A. Mounting hole
B. Open top fill tube
C. Snaps
D. Cover
E. Snap
F. Hex screw
A
B
D
E
F
C
A. Mounting hole
B. Hex screw
C. Tab
D. Wiring cover
E. Break off and discard.
B
C
D
E
A

5. Pull the 4-wire ice maker harness out from behind the back of
the freezer as far as possible, and hang it over the edge of the
cutout.
NOTE: Do not remove any other wiring.
Install the Fill Tube
14 to 18 Cubic Foot Top Freezer and Bottom Freezer and
11 Cubic Foot (Style 3 - Evaporator Cover) Models
1. Locate the fill tube and the round foam gasket from the ice
maker kit. Slide the gasket over the end of the fill tube.
NOTE: The gasket may already be installed on the fill tube.
2. With the spout facing downward, insert the other end of the fill
tube into the hole in the back of the freezer.
3. Using two ¹⁄₂" hex head sheet metal screws, fasten the fill tube
to the freezer.
11 Cubic Foot Top Freezer (Style 1 and Style 2) Models
1. Insert the bracket fill tube into the holes in the back of the
freezer compartment.
2. Insert the fill tube into the hole in the bracket fill tube. Twist the
fill tube until the spout is locked into place between the ribs of
the bracket fill tube.
3. Using two ¹⁄₂" hex head sheet metal screws, fasten the
bracket fill tube to the back of the freezer.
Replace the Cover
Style 1 - Open Top Ice Maker Fill Tube with Wiring Cover
■Do not replace the cover.
Style 2 - Flat Wiring Cover
■Thread the wiring harness through the slot and place the
cover over the fill tube.
■Hook the tab in the side of the cover into the slot in the back
of the freezer. Using the hex screw removed earlier, fasten the
cover to the freezer.
Style 3 - Evaporator Cover Only
■Thread the wiring harness through the cutout and place the
evaporator cover over the fill tube.
■Using the screws and plastic plugs removed earlier, fasten the
cover to the freezer.
A. Plastic plugs and screws
B. Fill tube
C. Wire harness
A. Hex head sheet metal screws
B. Spout
C. Foam gasket
D. Fill tube
A
B
C
B C DA
A. Hex head sheet metal screws
B. Spout
C. Fill tube
D. Ribs
E. Bracket fill tube
B C EDA
W10519544A ®/™ ©2013 Whirlpool. All rights reserved. 2/13
