SERVICE Whirlpool Europe
Customer Services
Model AWM 028/WS-P,I,E
Version 8570 028 01000 Page
Technical data 2 - 4
Spare part list 5 - 6
Exploded view 7 - 8
Wiring diagram 9
Circuit diagram 10
Program diagram 11 - 14
Text/Legend 15 - 16
Family 2a
Service Manual
Washing machine
Frontloader
AWM 028/WS-P,I,E
AWM 028/WS-P,I,E
This documentation is only intended for qualified technicians who are aware of the respec-
tive safety regulations.
Date: 10.03.1997 Subject to modification
Document-No.: 4812 712 11935

SERVICE
10.03.1997 / Page 2 Whirlpool Europe
Doc. No: 4812 712 11935 Customer Service
Technical data
Dimensions
Height 81,5-84cm
Width 59,5 cm
Depth 57,3 cm
Weight
without packing 75 kg
Main connection
Voltage 230 V
Frequency 50 Hz
Power consumption 2,3 kW
Fuse rating 10 A
Drum
Volume 48 l
Wash spin 54 rpm
Ramp spin 110 rpm
Speed spinning 800 rpm
600 rpm
400 rpm
Capacity of dry laundry
cotton/coloured laundry 5 kg
cotton rapid 3 kg
Easy care 2,5 kg
Easy care rapid 1,5 kg
Delicate 1,5 kg
Wool 1 kg
Pressostat for washing-machine (with cold water
connection)
Level1
Switching point 60 ± 5 mmWc
Reset 30 ±5 mmWc
Overflow
Switching point 280±20mmWc
Water column drum
Level1
Switching point 40-51 mm
Overflow
Switching point 260-300 mm
Nominal current
Contacte 11 - 12 4 (4) A
11 - 14 16 (4) A
11 - 16 1 (1) A
Contactsystem 11-12-14 jump contacts
11 - 16 slow action
contacts
Door lock
Lock time 3 - 6“ ( 20˚C )
Unlock time 60 - 90“
Nominal voltage 230 V
Nominal current
contact 4-5 1 mA
contact 11-14 16 (4) A

SERVICE Whirlpool Europe 10.03.1997 / Page 3
Customer Service Doc. No: 4812 712 11935
Technical data
Heating element
Kind of heating Tubular heating element with
NTC - Sensor
Nominal voltage 230 V
Nominal power 2050 W
Heat conductor
resistance 22-28 Ω
Resistance NTC 0 ˚C 35,9 kΩ
30 ˚C 9,8 kΩ
40 ˚C 6,6 kΩ
50 ˚C 4,6 kΩ
60 ˚C 3,2 kΩ
70 ˚C 2,3 kΩ
95 ˚C 1,1 kΩ
Aquastop
Water temperaturemax. 60 ˚C
Rated flow > 1 bar 8 l/min.
Pressure range 0,5-10 bar
Nominal voltage 220-240 V
Frequency 50 Hz
Starting voltage:
< 6 bar 160 V
6-10 bar 170 V
Nominal current 35 mA
Nominal power 6 VA
Nominal resistor (20˚C) 3,4-4,4 kΩ
Floater
Nominal voltage 230 V
Nominal current 3 (1) A
Drain pump (synchronus)
Nominal voltage 230 V
Nominal current 0,3 A
Nominal consumption 34 W
Frequency 50 Hz
Resistor (coil) 155 Ω ± 7%
Motor protection no
capacity (1,25m height) 15 l/min.
Program timer
Typ Hybridtimer with integreated
electronic
Fab. EC 4477
Nominal voltage 230 V
Frequency 50 Hz
Total positions 60
Program positions
Cotton/coloured laundry
Pre wash pos. 01 - 02
Main wash pos. 03 - 12
Rinse pos. 13 - 19
Spin pos. 20 - 22
Stop pos. 23
Easy care
Pre wash pos. 24 - 26
Main wash pos. 27 - 34
Rinse pos. 35 - 39
Spin pos. 40 - 41
Stop pos. 42
Delicate
Pre wash pos. 43 - 44
Main wash pos. 45 - 51
Rinse pos. 52 - 56
Spin pos. 57 - 59
Stop pos. 60
Wool
Pre wash pos. -
Main wash pos. 47 - 51
Rinse pos. 52 - 56
Spin pos. 57 - 59
Stop pos. 60
Silk
Pre wash pos. -
Main wash pos. 49 - 51
Rinse pos. 52 - 56
Spin pos. 57 - 59
Stop pos. 60

SERVICE
10.03.1997 / Page 4 Whirlpool Europe
Doc. No: 4812 712 11935 Customer Service
Technical data
Motor
Typ MCA 45/64 - 148/t.f. WHEO
i = 1 : 15,9
Resistance contacts
6 - 7 68,70 Ω ± 7%
Collector directly 2,35 Ω ± 7%
2 - 3 1,69 Ω ± 7%
Radio interference supression
Condensateur Fribourg Typ FA 26
Nominal voltage 230 V
Nominal capacity 0,47µFX2+2x0,022nFY
Nominal inductances 2 x 470 µH
Nominal resistance 680 kΩ
Temperature selector switch
Positions 7
Nominal voltage 5 V
Value of resistors
1-2-3 internal shunt
4- 6 internal shunt
5-6 Pos. 1 < 10 Ω ± 5%
Pos. 2 0,68 kΩ± 5%
Pos. 3 1,10 kΩ± 5%
Pos. 4 1,80 kΩ± 5%
Pos. 5 2,70 kΩ± 5%
Pos. 6 3,60 kΩ± 5%
Pos. 7 4,70 kΩ± 5%
Switch rotary spin speed
Positions 7
Nominal voltage 5 V
Value of resistors
1-2-3 internal shunt
4- 6 internal shunt
5-6 Pos. 1 < 10 Ω ± 5%
Pos. 2 0,68 kΩ± 5%
Pos. 3 1,10 kΩ± 5%
Pos. 4 1,80 kΩ± 5%
Pos. 5 2,70 kΩ± 5%
Pos. 6 3,60 kΩ± 5%
Pos. 7 4,70 kΩ± 5%
Push botton switch
Rinse hold SRS
Main switch SM
Quick SR
Eco SEC

SERVICE Whirlpool Europe 10.03.1997 / Page 5
Customer Service Doc. No: 4812 712 11935
Spare part list
Model AWM 028/WS-P,I,E
Service No. 857002801000
Version 857002801000
Pos. No. 12NC Code Description
001 0 4812 440 19419 Cabinet
003 0 4812 464 48097 Traverse Rear top degre
004 0 4812 440 19423 Drip tray assy
011 0 4812 500 18068 Foot variable
011 1 4812 500 18074 Foot leveling kit 85mm
011 1 4812 500 18075 Foot leveling kit 82mm
021 0 4812 440 19424 Panel,front
021 1 4812 462 79654 Stopper
024 0 4812 440 18997 Panel, rear
025 0 4812 440 19425 Holder Control device
033 0 4812 310 18231 Panel,insulatin
040 0 4812 417 18794 Hinge
041 0 4812 417 18034 Hinge
041 1 4812 417 18035 Insert shim 0.2mm
041 1 4812 417 28002 Insert shim 1mm
041 3 4812 417 18033 Cover,hinge
053 0 4812 459 38014 Plinth
054 0 4812 440 19433 Spacer f. pedestal
061 0 4812 466 88458 Counter weight upper
061 1 4812 466 88462 Counter weight Lower
065 0 4812 310 18341 Insulation B.in front
065 2 4812 310 18342 Insulation B.in left
065 3 4812 310 18343 Insulation B.in right
065 4 4812 310 18335 Insulation Middle Pane
065 5 4812 310 18336 Insulation Lower
080 0 4812 529 18036 Shock absorber 600-1200
084 0 4812 466 58001 Silent block
086 0 4812 401 18409 Holder Shock Absorber
086 1 4812 401 18413 Holder Shock absorber
086 2 4812 401 18412 Stopper
110 0 4812 498 18142 Handle,door
110 1 4812 417 18796 Lever grip door
130 0 4812 417 28051 Lock door
130 1 4812 417 28045 Pin Door Lock
131 0 4812 417 28053 Plate Doorlock Upper
131 1 4812 417 28052 Plate Doorlock Lower
134 0 4812 417 48001 Magnet + Buffer
134 1 4812 417 28001 Insert
141 0 4812 450 68219 Door glass
143 0 4812 440 19418 Glassdoor frame
144 0 4812 417 18795 Frame,door glas
144 1 4812 401 18417 Stopper
190 0 4812 466 68527 Door bellow
190 1 4812 492 18017 Strap
190 2 4812 492 98011 Strap
200 1 4812 418 18188 Tub Front Part 48L,1200
200 2 4812 418 18192 Tub rear part
200 3 4812 520 18068 Hub inner cpl. 800/1000,48L
200 4 4812 290 88054 Clamp for tub WH
220 0 4812 418 18196 Drum 800-1000
223 0 4819 515 28244 Drum lifter
271 0 4812 358 18056 V-ribbed belt WH 1250 J5
272 0 4812 528 58027 Pulley DIAM.298
292 0 4812 530 58101 Gasket Tub
301 0 4812 452 19346 Control panel
Pos. No. 12NC Code Description
301 3 4812 452 19348 Control panel
301 4 4812 452 19355 Frame Switch 5-FOLD
303 0 4812 498 18143 Handle, drawer
303 1 4812 498 18144 Handle,cover
322 0 4812 452 19347 Insert panel AWM 028-P/E
324 0 4812 440 18992 Lid Rearcover
331 0 4812 413 48246 Knob,timer 2A-
331 1 4812 413 18202 Adapter f. Knob
331 2 4812 413 18201 Adapter f. Knob
332 0 4812 410 28555 Push button
335 0 4812 413 48245 Knob thermostat
337 0 4812 412 58001 Knob speed spin 800
351 1 4812 134 48191 Lamp Door
354 1 4812 134 48196 Pilot lamp
401 0 4812 361 58117 Motor WA-DELTA 800U-MCA45
401 1 4812 362 48004 Brush,carbon motor CESET
421 0 4812 121 18142 Interf.filter 1,00 mF
430 0 4812 360 18369 Pump,draining BI
451 0 4812 259 28662 Heating element
490 0 4819 321 18136 Cable,mains 2m
490 1 4812 321 28367 Strain relief
504 0 4812 282 18458 Timer MASK 3 2A
511 0 4812 413 48223 Selector Temp./Spin
581 0 4812 271 28366 Pressostat
620 1 4812 276 18238 Switch Options
621 0 4812 276 18252 Switch On / Off
623 0 4812 271 38358 Switch MICRO
623 1 4812 271 38359 Support Switch Aquastop
630 0 4812 280 58023 Door lock
701 0 4812 530 28808 Hose, inlet VWS 1,5m
701 0 4812 530 28839 Hose, inlet VWS 3m
701 1 4822 480 50159 Sieve inlet
702 0 4812 530 28828 Hose
707 0 4812 526 48031 Nozzle Distribution
707 1 4812 526 48028 Nozzle
708 1 4812 530 48143 Bend
711 0 4812 418 88025 Dispenser BK,WH-3CH
712 0 4812 418 78922 Drawer Detergent
713 0 4812 418 88019 Flap Detergent Container
717 0 4812 321 28377 Bowden cable
717 1 4812 321 38013 Lever , Nozzle
717 2 4812 321 38012 Holder,adjust.
717 3 4812 278 88007 Slide
717 5 4812 282 18459 Cam BK,WH,BI,PL 2A,3CH
718 0 4812 526 48027 Siphon 3 - Chamber
718 1 4812 418 88018 Accessory
750 0 4812 530 48153 Chamber,expand. BUILT-IN
753 1 4812 418 68143 Chamber,air
754 0 4812 530 28826 Drainhose
754 1 4812 530 28832 Lock eco
754 2 4812 530 28829 Flange eco
756 0 4812 360 58101 Floater
760 0 4812 480 58078 Filters, set Pump
760 1 4812 418 68138 Gasket Sieve / Rough
781 0 4812 530 28831 Hose,draining

SERVICE
10.03.1997 / Page 6 Whirlpool Europe
Doc. No: 4812 712 11935 Customer Service
Spare part list
Model AWM 028/WS-P,I,E
Service No. 857002801000
Version 857002801000
Pos. No. 12NC Code Description
781 1 4812 530 28818 Hose
783 0 4812 530 28827 Hose Pressostat
783 1 4812 530 28822 Hose
783 3 4812 530 18001 Connection Part
786 0 4812 530 28812 Hose Draining
786 1 4812 462 78179 Threaded cap
786 3 4812 530 28809 Hose Aqua-Stop
787 0 4812 530 28819 Hose with hole
794 5 4812 530 58098 Gasket Airtrap
901 0 4812 401 18415 Clamp,hose Tub
901 2 4812 401 18401 Strap
901 3 4812 401 18414 Clamp,hose
902 0 4812 290 88049 Bracket
902 1 4812 255 18204 Holder Hose outlet
903 0 4812 255 18205 Holder Pressostat
903 5 4812 290 88048 Cable clamp
903 9 4812 290 88046 Cable clamp
904 0 4812 529 58002 Rivet Aquastop
910 0 4812 502 18383 Screw M 8X 25
911 1 4812 502 48004 Screw 4x15H
911 7 4812 903 08014 Screw M5x12
912 0 4812 502 18382 Screw M8 X 35
912 1 4812 502 18007 Screw M 5x16-H
915 2 4812 505 18371 Nut M 12
923 0 4812 532 18024 Washer
931 0 4812 492 38363 Spring
932 3 4812 492 58025 Spring door
932 4 4812 492 58024 Spring Door Safety
932 5 4812 492 38359 Spring , Nozzle
941 0 4812 310 18365 Bearing, kit KD SET Agg1.
941 1 4819 520 18034 Bearing
941 5 4812 520 18069 Hub 800/1000,48L
953 0 4812 530 58097 Shaft sealing 800-1000
953 1 4812 530 58096 O-Ring Bearing
961 0 4812 321 48004 Cover
962 2 4812 360 78035 Foil Water protect.
990 0 4819 310 39227 Mounting kit Weight top
990 1 4819 310 39228 Mounting kit Weight bottom
993 0 4812 530 48017 Bow
993 2 4812 268 18015 Lever,security
993 3 4812 395 58004 Tool

SERVICE Whirlpool Europe 10.03.1997 / Page 7
Customer Service Doc. No: 4812 712 11935
Exploded view

SERVICE
10.03.1997 / Page 8 Whirlpool Europe
Doc. No: 4812 712 11935 Customer Service
Exploded view

SERVICE Whirlpool Europe 10.03.1997 / Page 9
Customer Service Doc. No: 4812 712 11935
Wiring diagram

SERVICE
10.03.1997 / Page 10 Whirlpool Europe
Doc. No: 4812 712 11935 Customer Service
Circuit diagram

SERVICE Whirlpool Europe 10.03.1997 / Page 11
Customer Service Doc. No: 4812 712 11935
Program diagram

SERVICE
10.03.1997 / Page 12 Whirlpool Europe
Doc. No: 4812 712 11935 Customer Service
Program diagram

SERVICE Whirlpool Europe 10.03.1997 / Page 13
Customer Service Doc. No: 4812 712 11935
Program diagram

SERVICE
10.03.1997 / Page 14 Whirlpool Europe
Doc. No: 4812 712 11935 Customer Service
Program diagram

SERVICE Whirlpool Europe 10.03.1997 / Page 15
Customer Service Doc. No: 4812 712 11935
Text/Legend

SERVICE
10.03.1997 / Page 16 Whirlpool Europe
Doc. No: 4812 712 11935 Customer Service

SERVICE Whirlpool Europe 10.03.1997 / Page 17
Customer Service Doc. No: 4812 712 11935
Text/Legend

SERVICE
10.03.1997 / Page 18 Whirlpool Europe
Doc. No: 4812 712 11935 Customer Service
