Whirlpool EveryDrop EDRD101G1W User manual

USE & CARE GUIDE
WATER
DISPENSER

TABLE OF CONTENTS
WARNING
DANGER
23
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and on your
appliance. Always read and obey all safety messages.
This is the safety alert symbol.
This symbol alerts you to potential hazards that can kill or hurt
you and others.
All safety messages will follow the safety alert symbol and either
the word “DANGER” or “WARNING.”
These words mean:
You can be killed or seriously injured if
you don’t immediately follow instructions.
You can be killed or seriously injured if
you don’t follow instructions.
All safety messages will tell you what the potential hazard is, tell you how to
reduce the chance of injury, and tell you what can happen if the instructions
are not followed.
NOTE: In accordance with guidelines from the American Heart Association,
as with many products containing magnets, it is recommended that those with
implantable pacemakers/debrillators should use care and keep their device
12 inches away from the dispenser.
INTRODUCTION 4–7
Get to know your new Water Dispenser
INSTALLATION 8–18
Prepare for installation
Overview
Step-by-step instructions
USE 19–21
Get freshly filtered water on demand
Important information about your filter
Learn about the EveryDrop™ filter subscription service
Winterize your Water Dispenser
CARE 22–25
Replace your filter every six months
Troubleshoot potential problems
WARRANTY 26-27
PERFORMANCE DATA SHEET 28
Watch our step-by-step installation video online at
bit.ly/edwdispenserhowto.

GET TO KNOW YOUR EVERYDROPTM WATER DISPENSER
INTRODUCTION
45
FILTER ACCESS DOOR
FILTER
LOCK/UNLOCK
KNOB* WATER LINE
SPOUT ON/OFF
BUTTON
WATER SPOUT
DRIP TRAY
TUBING HOLDERS
REPLACEMENT FILTER
WELCOME TO A NEW WAY TO WATER
Refilling bulky pitchers, rethinking shelf space, and being concerned about
contaminants are all behind you. Now you’re ready to enjoy a steady stream
of clean water at the push of a button. Let’s get started.
*Locking the knob turns on the flow of water from your water supply to the filter.
Unlocking the knob turns the flow o.

67
IMPORTANT
• Plumbing must be installed in accordance with the International
Plumbing Code and any local codes and ordinances.
• Copper and PEX tubing connections from the household water line to
the refrigerator are acceptable and will help avoid o-taste or o-odor
water and ice. Check for leaks.
• If PEX tubing is used instead of copper, we recommend the following part
numbers: W10505928RP (7 ft. [2.14 m]) and W10267701RP (25 ft. [7.62 m] PEX).
• Install tubing only in areas where temperature will remain above freezing.
WATER SUPPLY REQUIREMENTS
A cold water supply with water pressure between 30 and 120 psi
(207 and 827 kPa) is required to operate the Water Dispenser and ice maker.
The maximum operating water temperature is 100° F (38° C).
If the water pressure is less than what is required, the flow of water from
the Water Dispenser could decrease or ice cubes could be hollow
or irregularly shaped.
If you have questions about your water pressure, call a licensed, qualified plumber.
TOOLS THAT MAY BE NEEDED BASED ON
INSTALLATION REQUIREMENTS
Gather the required tools and parts before starting installation.
The required tools may vary, depending on your specific installation
requirements.
• Flat-blade screwdriver
• Pliers
• 2 adjustable wrenches
• Bucket
• Towel
NOTE: Do not use a piercing-type or 3/16"(4.76 mm) saddle valve, which
reduces water flow and can clog more easily.
INTRODUCTION

89
PREPARING FOR INSTALLATION
1. Clean refrigerator surface using a mild dish detergent solution. Dry
thoroughly to avoid water spots.
• Wash refrigerator exterior with a clean, soft cloth or sponge and
a mild detergent in warm water. Rinse surface with clean, warm
water. (NOTE: If your refrigerator is stainless steel, always wipe
in the direction of the grain to avoid cross-grain scratching.)
2. You will need two adjustable wrenches and one pair of pliers
for tightening.
3. You will need a towel and a bucket for excess water.
INSTALLATION
INSTALLATION OVERVIEW
There are two tubes attached to your Water Dispenser. The house line
connects to your house’s cold water supply. If you have an ice maker, the
dispenser’s refrigerator line connects to your refrigerator. You will need to
remove the cap from the end of the tube to connect it to your refrigerator.
REFRIGERATOR CONNECTION HOUSE CONNECTION
WATER DISPENSER
MAGNETIC TUBE HOLDER

Excessive Weight Hazard
Use two or more people to
move and install refrigerator.
Failure to do so can result in
back or other injury.
Electrical Shock Hazard
Disconnect power
before servicing.
Replace all parts and panels
before operating.
Failure to follow these
instructions can result in
death or electrical shock.
OFF
10 11
INSTALLATION
MOVE AND UNPLUG REFRIGERATOR
1
Slide the refrigerator out so
you can access the water
connections behind it. Then,
unplug the refrigerator
power cord.
NOTE:
Your refrigerator is heavy. When moving
the refrigerator for cleaning or service,
be sure to cover the floor with cardboard
or hardboard to avoid floor damage.
Always pull the refrigerator straight out
when moving it. Do not wiggle or “walk”
the refrigerator when trying to move it,
as floor damage could occur.
3DISCONNECT WATER LINE
Disconnect the water line
that is running between your
refrigerator and the house at
the refrigerator end.
2SHUT OFF WATER
If your refrigerator does not
have an ice maker, skip ahead
to step 5.
If your refrigerator does
have an ice maker, find
the water shut-o valve
for your house’s water line
and turn o your water.
IMPORTANT: Turn the water
back on before plugging your
refrigerator back in.

12 13
INSTALLATION
EMPTY WATER LINE
4MOUNT DISPENSER 5MOUNT TUBING 6
Empty any excess water that
may be in the water line tube
into a bucket.
Route the dispenser’s tubing
through the prongs on the
back of the unit and place the
dispenser on the front or side
of your refrigerator with its
integrated magnets. If hanging
on the front, mount the
dispenser 2–3 inches from the
hinge side to allow the tubing
to move freely within the
Tubing Holders on the side.
Mount the two Tubing Holders
to the side of the refrigerator
and run the tubing through
the holder—do this prior to
making any water connections.
Mount the holders 2–3 inches from
the front and back of refrigerator.
BACK OF
WATER DISPENSER

OR
A
B
C
D
A
B
C
A
B
C
D
14 15
CONNECT TO REFRIGERATOR
If you don’t have an ice maker,
skip this step. Simply leave
the cap on the dispenser’s
refrigerator line and move on
to step 9.
If your refrigerator has an ice
maker, remove the cap from
the end of the dispenser’s
refrigerator line and connect
the line to your refrigerator.
Hand-tighten the nut, then use
a wrench to give it a half-turn.
Be careful not to overtighten the
nut, and avoid kinks in the line.
8
INSTALLATION
CONNECT TO WATER SUPPLY
Disconnect the old hose from
your house water line and
replace it with the dispenser’s
house water line. Use your
hand to tighten the nut,
then use a wrench to give
it a half-turn.
7
WATER LINE PARTS
A. Sleeve
B. Nut
C. Copper tubing
(to refrigerator)
D. Household supply
line (1/2"min.)
CONNECTION POINT
A. Compression
sleeve
B. Compression
nut
C. Copper tubing
HOSE
A. Copper tubing
B. P-clamp
C. Compression nut
D. Compression sleeve

ON
Excessive Weight Hazard
Use two or more people to
move and install refrigerator.
Failure to do so can result in
back or other injury.
Electrical Shock Hazard
Disconnect power
before servicing.
Replace all parts and panels
before operating.
Failure to follow these
instructions can result in
death or electrical shock.
16 17
TURN WATER ON
Turn your house’s water back
on. Make sure water isn’t
leaking anywhere. If it is,
check the connections and
tighten if necessary.
9
INSTALLATION
PLUG IN REFRIGERATOR
AND MOVE IT BACK
Plug the refrigerator power
cord back into the outlet
and slide the refrigerator
back into place.
10
NOTE:
Your refrigerator is heavy. When moving
the refrigerator for cleaning or service,
be sure to cover the floor with cardboard
or hardboard to avoid floor damage.
Always pull the refrigerator straight out
when moving it. Do not wiggle or “walk”
the refrigerator when trying to move it,
as floor damage could occur.

8
MINUTES
(4 Gallons)
18 19
FLUSH FILTER
Your EveryDrop™ Water
Dispenser is now ready to use.
Enjoy great-tasting filtered
water at the push of a button.
11
INSTALLATION
12 ENJOY
USE
HOW TO USE THE PRODUCT
The purpose of the EveryDropTM Water Dispenser is to deliver filtered tap
water when and where you want it. The built-in magnet allows you to attach
the dispenser anywhere on the magnetic surface of your refrigerator.
The EveryDropTM Water Dispenser includes a pull-out Drip Tray that is intended
to catch any drips. The Drip Tray is not intended to support a glass or container.
To use the Water Dispenser, place a glass or container under the Spout.
With your other hand, press the Spout On/O Button to dispense the water.
Continue pressing the button until your glass or container has the amount
of water you would like. Release the button to stop the water flow. Rated
service flow is 0.5 gpm (1.89 lpm).
NOTE: The Spout On/O Button is harder to push when water pressure is
applied. For the best experience, press along the raised line on the button face.
NOTE: The Filter Lock/Unlock Knob also controls the water valve. Locking the
knob turns on the flow of water from your water supply to the filter. Unlocking
the knob turns the flow o.
Hold a bucket under the Spout.
Press and hold the Spout
On/O Button for a total of
eight minutes, emptying your
bucket when necessary. This
will flush out your filter. Repeat
this process every time you
replace your water filter.
