How to install, operate and
maintain your Undersink
Drinking Water Filter System
Model WHED20
Do not return unit to store
Installation and Operation Manual
System tested and certified by NSF nternational
against NSF/ANS Standards 42 & 53.
See performance data sheet for details.
f you have any questions or concerns when
installing, operating or maintaining your
undersink drinking water filter system,
call our toll free number:
1-866-986-3223
Monday- Friday, 8 AM - 7 PM EST or visit
www.ecodynewatertreatment.com
When you call, please be prepared to provide
the model, date code and serial number of
your product, found on the rating decal,
located inside the cover.

2
Questions? Call toll free 1-866-986-3223 or visit www.ecodynewatertreatment.com
Table of Contents
Parts of the System / Materials and Tools Needed / Typical Undersink nstallation . . . . . . . . . . . . . . . . .3
nstallation Steps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-6
Filter Cartridge Life / Filter Cartridge Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Faucet Timer / Battery Change . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Troubleshooting the System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Exploded View / Repair Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10-11
Before You Start
qRead all steps and guides carefully before installing and using your undersink drinking water filter sys-
tem. Follow all steps exactly to correctly install. Reading this manual will also help you to get all the ben-
efits from the undersink drinking water filter system.
qDo not use with water that is microbiologically unsafe or of unknown quality without adequate disinfec-
tion before or after the system. This system is certified for cyst reduction and may be used on disinfected
waters that may contain filterable cysts.
qAll plumbing should be done in accordance with local codes and requirements. n Massachusetts,
plumbing code 248 CMR 3.00 and 10.00 shall be adhered to. Consult with your licensed plumber.
qThe undersink drinking water filter system works on water pressures of 30 psi (minimum) to 125 psi
(maximum). f your house water pressure is over the maximum, install a pressure reducing valve in the
water supply pipe to the filter system.
qDo not install the undersink drinking water filter system outside, or in extreme hot or cold tempera-
tures. Temperature of the water supply to the undersink drinking water filter system must be between
40°F and 100°F. Do not install on hot water.
Min. - Max. Supply Water Pressure 30 - 125 psi (207 - 862 kPa)
Min. - Max. Supply Water Temperature 40 - 100 °F (4 - 38 °C)
nlet - Outlet 3/8" quick connect fittings and tubing included
Specifications and Dimensions
9-3/8” 4-3/8”
12-3/4”
4-3/8”9-3/8”
12-3/4”

arts of the System
Materials and Tools Needed
Typical Undersink Installation
•filter system assembly
•water supply fitting
•filtered water faucet for sink or countertop mounting
•3/8" tube bends
•3/8" tubing to make all needed connections
NOTE: Gather the required tools before starting installation. Read and follow
the instructions provided with any tools listed here.
•slotted and Phillips screwdrivers
•pliers and adjustable jaw wrench
•tubing cutter
•electric drill and 1-1/4" drill bit if mounting hole is needed for the faucet
IM ORTANT: To avoid damaging the sink, consult a qualified plumber or
installer for drilling procedures in porcelain or stainless steel.
Locate the water filter housing on the cold water supply pipe, under the kitchen and/or bathroom sink, to
filter the cold drinking water. Refer to the following drawing.
shutoff valve
filtered water
faucet
post filter
pre filter
Blue
WATER
OUT
Yellow
WATER
IN
supply fitting
S NK
NOTE: f tubing needs to make a sharp
bend, use included tube benders to
prevent kinking.
NOTE: Be sure to allow a minimum space of 1-1/2" under the system
for removing the filter cartridges, in order to change the cartridges.
Fig. 1
4-1/4”
3
Questions? Call toll free 1-866-986-3223 or visit www.ecodynewatertreatment.com
HOT COLD

Installation Steps
Step 1 - Cold Water Supply Fitting
Check and comply with local plumbing codes as you plan, then install a cold feed (supply) water fitting.
The fitting must provide a leak-tight connection to the water filter 3/8" tubing. A typical connection using
the included water supply fitting is shown in Figure 2A. An optional connection using standard plumbing
fittings (not included) is shown in Figure 2B.
Cold Water Supply Fitting
1. Close the water shut off valve that is immediately before supply fitting and open faucets to drain water
from the sink cold water pipe.
2. Remove nut that connects the cold water faucet to cold water plumbing.
3. Thread water supply fitting onto pipe and reconnect nut to bottom of fitting.
Optional Pipe Fittings (compression type shown)
NOTE: Be sure to turn off the water supply and open a faucet to drain the pipe.
Complying with plumbing codes, install a fitting on the cold water pipe to adapt 3/8" OD tubing. A typical
connection is shown in Figure 2B. f threaded fittings are used, be sure to use pipe joint compound or
thread sealing tape on outside threads.
Fig. 2
cold water
faucet stud
thread sealing
tape on threads
cold water
pipe
cold water
pipe
A. Water supply connection
(using included water supply fitting)
B. Water supply typical connection
(using compression fitting)
- parts not provided -
cold water
shutoff
cold water
shutoff
water supply fitting
3/8" tubing to
water filter inlet
3/8" compression
fitting
insert
ferrule
3/8" tubing to
Water Filter inlet
4
Questions? Call toll free 1-866-986-3223 or visit www.ecodynewatertreatment.com

Installation Steps
Step 2 - Make Hole For Filtered Water Faucet
Step 3 - nstall Faucet
IM ORTANT: To avoid damaging the sink, consult a qualified plumber or installer for drilling procedures
in porcelain or stainless steel. Special drill bits are made for this.
1. Select one of the following places to install the faucet. Be sure there's room underneath so you can
make the needed connections.
•n an existing sink spray attachment hole.
•Drill a hole in the sink top.
•Drill a hole in the countertop next to the sink.
2. f drilling is needed make a 1-1/4" dia. (minimum) hole for the faucet.
1. Feed the 3/8" tubing that is attached to the faucet through the mounting hole. Slide the toggle bolts
through the mounting hole. Tighten the screws to secure the base flat on the mounting surface. Do not
overtighten.
2. Move the faucet down onto the base. Turn 1/4 clockwise to attach the faucet to the base.
3. nstall battery in base. See “Battery Change” section for instructions.
Fig. 3
faucet base
1/4 turn to connect
faucet to base
screw
toggle bolt
rubber washer
hole in sink
or countertop
faucet
5
