Whispbar Basic Carrier User manual

K631W
Fitting Kit
EN Fitting Instructions for Basic Carrier
PL Instrukcja systemu montażu
x 1 x 4 x 4 x 4
x 4 x 1 x 4
Revision No: 3B 1

Fitting Kit K631W
MAX kgs (lbs)
W/P WHD
Land Rover
Freelander 2, 5dr SUV 07-12 EU 75 kgs (165 lbs) 75 kgs (165 lbs)
Freelander 2, 5dr SUV 07-15 CN 75 kgs (165 lbs) 75 kgs (165 lbs)
Freelander 2, 5dr SUV 12-14 EU 75 kgs (165 lbs) 75 kgs (165 lbs)
Freelander 2, 5dr SUV Jul 07-Feb 11 NZ 75 kgs (165 lbs) 75 kgs (165 lbs)
Freelander 2, 5dr SUV Jul 07-Feb 11 AU 75 kgs (165 lbs) 75 kgs (165 lbs)
Freelander 2, 5dr SUV Jul 07-Feb 11 ZA 75 kgs (165 lbs) 75 kgs (165 lbs)
Freelander 2, 5dr SUV Mar 11-Mar 15 AU 75 kgs (165 lbs) 75 kgs (165 lbs)
Freelander 2, 5dr SUV Mar 11-Mar 15 NZ 75 kgs (165 lbs) 75 kgs (165 lbs)
Freelander 2, 5dr SUV Mar 11-Mar 15 ZA 75 kgs (165 lbs) 75 kgs (165 lbs)
LR2, 5dr SUV 07-+ US 75 kgs (165 lbs) 75 kgs (165 lbs)
2

Fitting Kit K631W
X
A B C 1 2 3
Freelander 2, 5dr SUV 07-12 (EU) -250mm 500mm - 925mm 905mm -
-9 -13/16ths" 19 11/16ths" - 36 7/16ths" 35 5/8ths" -
Freelander 2, 5dr SUV 07-15 (CN) -250mm 500mm - 925mm 905mm -
-9 -13/16ths" 19 11/16ths" - 36 7/16ths" 35 5/8ths" -
Freelander 2, 5dr SUV 12-14 (EU) -250mm 500mm - 925mm 905mm -
-9 -13/16ths" 19 11/16ths" - 36 7/16ths" 35 5/8ths" -
Freelander 2, 5dr SUV Jul 07-Feb 11 (NZ) -250mm 500mm - 925mm 905mm -
-9 -13/16ths" 19 11/16ths" - 36 7/16ths" 35 5/8ths" -
Freelander 2, 5dr SUV Jul 07-Feb 11 (AU) -250mm 500mm - 925mm 905mm -
-9 -13/16ths" 19 11/16ths" - 36 7/16ths" 35 5/8ths" -
Freelander 2, 5dr SUV Jul 07-Feb 11 (ZA) -250mm 500mm - 925mm 905mm -
-9 -13/16ths" 19 11/16ths" - 36 7/16ths" 35 5/8ths" -
Freelander 2, 5dr SUV Mar 11-Mar 15 (AU) -250mm 500mm - 925mm 905mm -
-9 -13/16ths" 19 11/16ths" - 36 7/16ths" 35 5/8ths" -
Freelander 2, 5dr SUV Mar 11-Mar 15 (NZ) -250mm 500mm - 925mm 905mm -
-9 -13/16ths" 19 11/16ths" - 36 7/16ths" 35 5/8ths" -
Freelander 2, 5dr SUV Mar 11-Mar 15 (ZA) -250mm 500mm - 925mm 905mm -
-9 -13/16ths" 19 11/16ths" - 36 7/16ths" 35 5/8ths" -
LR2, 5dr SUV 07-+ (US) -250mm 500mm - 925mm 905mm -
-9 -13/16ths" 19 11/16ths" - 36 7/16ths" 35 5/8ths" -
3

Fitting Kit EN
K631W
First Time Installation
●Remove parts from inside the package and
check. Contact your dealer if any parts are
missing or damaged.
●These instructions show type A crossbar
fitted. They also apply to type B, C and D.
●This kit fits type A, B, C and D.
●Use keys to remove covers.
4

Fitting Kit EN
K631W
●Use hex screwdriver to reverse adjusting
screw 10 turns.
●Press adjusting screw and pull crossbar
legs out. Refer to the crossbar instructions
for crossbar adjustment method.
●Ensure each end of the crossbar is
adjusted equally.
●Attaches to factory-fitted mounting points
●Please check the front of this manual for
information relating specifically to your
vehicle.
●Adjust crossbar in or out to suit vehicle.
Refer to the crossbar instructions for
crossbar adjustment.
5

Fitting Kit EN
K631W
●Remove plastic clamp block by gripping bar
leg with fingers and push firmly with
thumbs until clamp block drops out behind
leg.
●Select plastic internal block (from fitting kit)
and insert into foot.
●Repeat for all legs.
Fitment
●Locate ditch mouldings on roof.
●Carefully remove centre section of ditch
mould with flat-head screwdriver.
6

Fitting Kit EN
K631W
●Pull ditch moulding back towards you.
●Remove centre section.
●Remove as shown.
●Locate vehicle's fixed points.
7

Fitting Kit EN
K631W
●Remove plastic bungs as shown.
●Rotate as shown.
●Mark reference point with a pen onto
removed section of ditch mould.
●Mark reference point with a pen onto
removed section of ditch mould.
8

Fitting Kit EN
K631W
●Mark as shown.
●Use drill bit supplied, to drill holes in
marked positions.
●Re-install ditch mould in roof channel.
●Align holes.
9

Fitting Kit EN
K631W
●Select grubscrews and screw into the
vehicle's fixed points.
●Do not over tighten.
●Repeat for all four positions.
●Place crossbars on pads ensuring the pads
fit into the holes underneath the foot and
the grubscrew passes through the hole in
the foot.
●Repeat for all four positions.
●Tighten adjusting screw to 5 Nm (3.7 ft lb)
hand tight.
10

Fitting Kit EN
K631W
●Tighten the plastic knob. The side with the
nut showing should be facing up.
●Ensure the plastic knob is in the position
shown when fully tightened.
●Repeat for all legs.
●Check crossbar is securely attached to the
vehicle.
●Use keys to fit and lock covers
11

Fitting Kit EN
K631W
Removal of crossbars
●Remove the products from the vehicle
when not in use. Make sure all loose parts
are stored safely.
●Using the Hex Key and the capscrews,
secure the ditch mould to the vehicle.
CAUTION: Recheck all fasteners immediately after
a load is applied to the crossbars.
Regularly check screws are tight.
12

Fitting Kit EN
K631W
Maintenance
●Clean the car roof and surfaces of the
product that will be in contact with the car
roof.
●Follow the fitting instructions for fitting the
product to your vehicle. Make sure all steps
are carried out in order.
●Set crossbars a minimum distance of
700mm (27 1/2") apart where no other
distance is specified in the fitting
instructions. This is especially important
when carrying long loads.
●Check unit is securely attached whenever
you refit it to the vehicle. If the unit feels
loose, refer to the fitting instructions and
readjust.
●Some glass/panoramic roofs and radio
antennae may not be able to be used when
the product is fitted.
●Do not modify this product.
●Refer to the maximum permitted load
capacity specified in the fitting instructions.
Do not exceed the vehicle manufacturers
roof load rating if it is lower than the
maximum load capacity specified in the
fitting instructions.
●Loads should not overhang the sides of the
product and be evenly distributed with the
lowest possible centre of gravity.
●Long loads should be secured with non-
elastic straps to the front and rear of the
vehicle.
●Objects with pointed ends (e.g. ski poles)
should be carried with the pointed ends to
the rear of the vehicle.
●Remove all loose or removable objects
from the load prior to loading.
●Make sure all loads are securely fastened
with non-elastic straps. Check regularly
during longer journeys.
●A loaded roof rack system can alter the
performance of your vehicle. Be especially
aware of the effects of side winds,
changing of direction, and braking
performance. Avoid rapid acceleration and
deceleration. Drive carefully.
●Note that the total height of the vehicle
increases when upright loads are carried.
●Products should be locked during transport
if they have locks fitted.
13

Fitting Kit EN
K631W
●Check and replace worn out or defective
parts.
●Keep the product clean and maintained.
●Never drive into a car wash with the roof
rack system fitted.
●Lubricate locks and adjusting screws at
regular intervals.
●Remove the products from the vehicle
when not in use. Make sure all loose parts
are stored safely.
●Yakima Europe Coöperatief U.A.
Archimedesbaan 25
3439 ME Nieuwegein
The Netherlands
[phone]
www.whispbar.eu
www.whispbar.co.uk
●Yakima Products, Inc.
4101 Kruse Way,
Lake Oswego, OR 97035
USA
www.whispbar.com
www.whispbar.ca
14

Fitting Kit PL
K631W
Pierwszy montaż
●Sprawdź zawartość opakowania i upewnij
się, czy zawiera wszystkie części
znajdujące się na liście. Jeśli nie,
skontaktuj się z odpowiednim sklepem.
●Instrukcja opisuje sposób montażu belek
typu A. Może być również stosowana do
belek typu B, C i D.
●Kit pasuje do belek typu A, B, C oraz D.
●Odkręć osłony za pomocą klucza.
15

Fitting Kit PL
K631W
●Zdejmij osłony za pomocą klucza.
●Przyciśnij i usuń blokadę. Zamontuj stopy.
●Sprawdź czy oba końce belek mają taką
samą długość.
●Montaż w punkty fabryczne
●Czytać na z przodu instrukcji znajdziesz
specyfikacje dla twojego samochodu.
●Wypośrodkuj równe odległości belek (patrz:
instrukcja montażu belek)
16

Fitting Kit PL
K631W
●Zdjąć blok zacisku z tworzywa sztucznego
chwytając stopę poprzeczki palcami i
mocno docisnąć kciukami aż blok
zaciskowy wysunie się za stopę.
●Usuń wewnętrzną blokadę i umieść ją w
stopie.
●Powtórz czynność dla reszty stóp.
Montaż
●Wsuń łapki w kanał montażowy na dachu.
●Ostrożnie usunąć część środkową
kształtkę rowkową za pomocą płaskiego
wkrętaka.
17

Fitting Kit PL
K631W
●Przesuń uszczelkę do siebie.
●Usuń część środkową.
●Zdjąć jak pokazano.
●Zlokalizuj punkty fabryczne samochodu.
18

Fitting Kit PL
K631W
●usuń zaślepki punktów montażowych jak
na rysunku.
●Obracają się, jak pokazano.
●Zaznaczyć punkt odniesienia za pomocą
długopisu.
●Zaznaczyć punkt odniesienia za pomocą
długopisu.
19

Fitting Kit PL
K631W
●Zaznaczyć jak pokazano.
●Użyj dołączonego wiertła do wiercenia
otworów w zaznaczonych pozycjach.
●Ponownie zainstalować kształtkę rowkową
w kanale na dachu.
●Dopasować otwory.
