Whispbar K311W User manual

K311W
Fitting Kit
EN Fitting Instructions for Basic Carrier
x 2 x 2 x 4
Revision No: 6F 1

Fitting Kit K311W
MAX kgs (lbs)
W/P WHD
Mazda
2, 5dr Hatch 07-+ ZA 50 kgs (110 lbs) 50 kgs (110 lbs)
2, 5dr Hatch 07-+ CN 50 kgs (110 lbs) 50 kgs (110 lbs)
2, 5dr Hatch 07-14 EU 50 kgs (110 lbs) 50 kgs (110 lbs)
2, 5dr Hatch 10-+ US 50 kgs (110 lbs) 50 kgs (110 lbs)
2, 5dr Hatch Sep 07-14 AU 50 kgs (110 lbs) 50 kgs (110 lbs)
2, 5dr Hatch Sep 07-14 NZ 50 kgs (110 lbs) 50 kgs (110 lbs)
Demio, 5dr Hatch Sep 07-14 NZ 50 kgs (110 lbs) 50 kgs (110 lbs)
2

Fitting Kit K311W
X
A B C 1 2 3
2, 5dr Hatch 07-+ (ZA) -150mm 500mm - 760mm 693mm -
-5 -7/8ths" 19 11/16ths" - 29 15/16ths" 27 5/16ths" -
2, 5dr Hatch 07-+ (CN) -150mm 500mm - 760mm 693mm -
-5 -7/8ths" 19 11/16ths" - 29 15/16ths" 27 5/16ths" -
2, 5dr Hatch 07-14 (EU) -150mm 500mm - 760mm 693mm -
-5 -7/8ths" 19 11/16ths" - 29 15/16ths" 27 5/16ths" -
2, 5dr Hatch 10-+ (US) -150mm 500mm - 760mm 693mm -
-5 -7/8ths" 19 11/16ths" - 29 15/16ths" 27 5/16ths" -
2, 5dr Hatch Sep 07-14 (AU) -150mm 500mm - 760mm 693mm -
-5 -7/8ths" 19 11/16ths" - 29 15/16ths" 27 5/16ths" -
2, 5dr Hatch Sep 07-14 (NZ) -150mm 500mm - 760mm 693mm -
-5 -7/8ths" 19 11/16ths" - 29 15/16ths" 27 5/16ths" -
Demio, 5dr Hatch Sep 07-14 (NZ) -150mm 500mm - 760mm 693mm -
-5 -7/8ths" 19 11/16ths" - 29 15/16ths" 27 5/16ths" -
3

Fitting Kit EN
K311W
First Time Installation
●Remove parts from inside the package and
check. Contact your dealer if any parts are
missing or damaged.
●This kit fits type A, B, C and D.
●These instructions show type A crossbar
fitted. They also apply to type B, C and D.
NOTE: Clamp images in these instructions may
not be representative of the clamps in this kit
4

Fitting Kit EN
K311W
●Use keys to remove covers.
●Use hex screwdriver to reverse adjusting
screw 10 turns.
●Press adjusting screw and pull crossbar
legs out. Refer to the crossbar instructions
for crossbar adjustment method.
●Ensure each end of the crossbar is
adjusted equally.
5

Fitting Kit EN
K311W
●Remove locking screw.
●Apply protective strip as shown.
Trim if required.
●Letters refer to the part numbers stamped
on clamps.
●Clamp Part Number:
A = 457A
B = 458A
6

Fitting Kit EN
K311W
●Attach clamp to each leg. NOTE; clamps
may have labels showing their positions on
the vehicle (For example; "Front Right").
●Refit locking screw so that it goes through
the hole in the clamp. Do not begin to
tighten the locking screw.
●Fit rubber pads (supplied with fitting kit) to
foot. Pad may vary in shape to that shown.
7

Fitting Kit EN
K311W
●Make sure the pad fits into the holes
underneath the foot.
Fitment
●Place crossbar on vehicle. Minimum
recommended spacing between the bars is
700mm (27 1/2") (unless otherwise stated).
●Please check the front of this manual for
information relating specifically to your
vehicle.
●Adjust the legs on the crossbar so that they
are positioned equally from the ends of the
crossbar, and the clamps engage firmly on
the body work of the vehicle.
8

Fitting Kit EN
K311W
●Tighten adjusting screw to 5 Nm (3.7 ft lb)
hand tight.
●Tighten locking screw on both legs evenly.
●Check crossbar is securely attached to the
vehicle.
9

Fitting Kit EN
K311W
●Use keys to fit and lock covers
CAUTION: Recheck all fasteners immediately after
a load is applied to the crossbars.
Regularly check screws are tight.
