White Knight CL447 SERIES User manual

WHITE KNIGHT CL447
Air Vented Dryer - UK
SERVICE MANUAL
Wiring Diagram
Exploded Views
Parts List
March 2005
4213 094 63084
CL447WV (white)...............
CL447AV (almond).............
CL447SV (silver)................
CL447BV (blue)..................
CL447YV (yellow)...............
CL447OGV (olive green)....
CL447CV (champagne)......
0312 447 15002
0312 447 15201
0312 447 15300
0312 447 15501
0312 447 15601
0312 447 15801
0312 447 15901

369
394
196
403
353
211
352
554
386
385
248
370
449
391
235
450
376
362
367
201
366
365
364
363
359
203a 363a
367
203
199
White Knight CL447 Air Vented Dryer - Exploded View 1
366
365
364
363a
363
203a
359
199
Different door & plinth for
Silver variant

144
446
112
447
432 101 437402
427 399 400
413
230
390
395
227
125
142
408 228 393
White Knight CL447 Air Vented Dryer - Exploded View 2
270
141
444
266

White Knight CL447 Air Vented Dryer- Exploded View 3
440
441
442
248
454
455
471
437
445
446
447a
537a
447
229
445a
456
457
458
459
448

Mains
Cable
F/E
B
G
TB-L
TB-N
B/K
1.5
G
DS B/K
1.5
G
D
D
F/E
1.25
EC Timer
D
3
4/7
5/8
A/K
1.5
B
E
B
E
CAP
BE
M
A
D
EX-TH
A/K
1.5
A*
1.5
A*
1.5
IN-TH
HE-SW
A
0.75
C
0.75
G*
1.0
MAN
TOC HE2 HE1
G*
1.0
TB-4
B11
B12
M
B3
B4
C9
C10
B9
B10
B6
B5
B7
B8
B2
B1
C11
C12
Component Code
TB
DS
M
EX-TH
IN-TH
HE
HE-SW
MAN TOC
A/C-SW
-
-
-
-
-
-
-
-
-
Terminal Block
Door Switch
Motor
Exhaust Thermostat
Inlet Thermostat
Heater
Heat Switch
Manual Reset Heater Cut-out
Anti-crease Switch
Wire Colour Code
A
B
C
D
E
F
G
H
K
N/A
-
-
-
-
-
-
-
-
-
-
Black
Brown
Red
Orange
Yellow
Green
Blue
Violet
White
Pink
Timer Connections
ABC
1
2
3
4
5
6
7
8
9
10
11
12
A/K
B/K
D
D
G
B
E
White Knight CL447WV & Variants - Wiring Diagram

White Knight CL447 and Coloured Variants - Parts List
Item Description Code Expl.View
101 Motor & 8µf Capacitor Assembly 4213 092 25611 2
112 8µf Capacitor 4213 092 08091 2
125 Drive Belt 4213 092 18601 2
141 Mains Cable & Plug 4213 076 35123 2
142 Terminal Block 4213 078 44613 2
144 Earth Tab Assembly 4213 092 41181 2
196 Cabinet Assembly (white) 4213 092 17761 1
196 Cabinet Assembly (almond) 4213 092 08211 1
196 Cabinet Assembly (silver) 4213 092 36261 1
196 Cabinet Assembly (blue) 4213 092 28161 1
196 Cabinet Assembly (yellow) 4213 092 28171 1
196 Cabinet Assembly (olive green) 4213 092 28181 1
196 Cabinet Assembly (champagne) 4213 092 34181 1
199 Ignis Plinth (white) 4213 077 52715 1
199 Ignis Plinth (almond) 4213 077 69101 1
199 Stack Plinth (silver) 4213 092 36271 1
199 Ignis Plinth (blue) 4213 077 68181 1
199 Ignis Plinth (yellow) 4213 077 68191 1
199 Ignis Plinth (olive green) 4213 077 68171 1
199 Ignis Plinth (champagne) 4213 077 80501 1
201 Door Seal 4213 077 08344 1
203 Ignis Full Door Assembly (white) 4213 092 28061 1
203 Ignis Full Door Assembly (almond) 4213 092 28101 1
203 Continental Full Door Assembly (silver) 4213 092 36281 1
203 Ignis Full Door Assembly (blue) 4213 092 28071 1
203 Ignis Full Door Assembly (yellow) 4213 092 28081 1
203 Ignis Full Door Assembly (olive green) 4213 092 28091 1
203 Ignis Full Door Assembly (champagne) 4213 092 36551 1
203a Ignis Door Frame Assembly (white) 4213 092 17771 1
203a Ignis Door Frame Assembly (almond) 4213 092 26471 1
203a Continental Door Frame Assembly (silver) 4213 092 36091 1
203a Ignis Door Frame Assembly (blue) 4213 092 26321 1
203a Ignis Door Frame Assembly (yellow) 4213 092 28201 1
203a Ignis Door Frame Assembly (olive green) 4213 092 28211 1
203a Ignis Door Frame Assembly (champagne) 4213 092 34201 1
211 Timer (all dryers except silver) 4213 078 55131 1
211 Timer (silver only) 4213 078 54781
227 Heating Element 4213 092 05521 2
228 Heat TOC 4213 078 50161 2
229 Thermostat 4213 078 48373 3
230 Thermostat (inlet) 4213 078 56261 2
235 Rocker Switch 4213 078 51061 1
248 Microswitch/Bracket Assembly 4213 092 05251 1
266 Drum Assembly (all dryers except almond) 4213 092 05531 2
266 Drum Assembly (almond dryers only) 4213 092 08361 2
PLEASE NOTE bold text indicates choice of parts depending on model colour. 4213 094 63084

White Knight CL447 and Coloured Variants - Parts List
270 Drum Shaft/Bearing Kit 4213 092 05591 2
352 Timer Knob Assembly (white) 4213 092 30631 1
352 Timer Knob Assembly (almond) 4213 092 30741 1
352 Timer Knob Assembly (silver) 4213 092 36251 1
352 Timer Knob Assembly (blue) 4213 092 30641 1
352 Timer Knob Assembly (yellow) 4213 092 30651 1
352 Timer Knob Assembly (olive green) 4213 092 30661 1
352 Timer Knob Assembly (champagne) 4213 092 34211 1
353 Control Panel Assembly (white) 4213 092 25631 1
353 Control Panel Assembly (almond) 4213 092 26481 1
353 Control Panel Assembly (silver) 4213 092 36311 1
353 Control Panel Assembly (blue) 4213 092 26731 1
353 Control Panel Assembly (yellow) 4213 092 26741 1
353 Control Panel Assembly (olive green) 4213 092 26751 1
353 Control Panel Assembly (champagne) 4213 092 34221 1
356 Screw 6 x 11 2513 200 06297 3
359 Ignis Door Hinge Assembly (all dryers except silver) 4213 092 26071 1
359 Continental Door Hinge Assembly (silver dryers only) 4213 092 25361 1
362 Window 4213 077 44093 1
362 Window (modified for silver dryers only) 4213 075 15501 1
363 Ignis Door Frame (white) 4213 077 52694 1
363 Ignis Door Frame (almond) 4213 077 69081 1
363 Continental Door Frame (silver) 4213 077 82721 1
363 Ignis Door Frame (blue) 4213 077 68131 1
363 Ignis Door Frame (yellow) 4213 077 68151 1
363 Ignis Door Frame (olive green) 4213 077 68111 1
363 Ignis Door Frame (champagne) 4213 077 80491 1
363a Ignis Door Handle Inner (white) 4213 077 52982 1
363a Ignis Door Handle Inner (almond) 4213 077 69091 1
363a Continental Door Handle (silver) 4213 077 82861 1
363a Ignis Door Handle Inner (blue) 4213 077 68141 1
363a Ignis Door Handle Inner (yellow) 4213 077 68161 1
363a Ignis Door Handle Inner (olive green) 4213 077 68121 1
363a Ignis Door Handle Inner (champagne) 4213 077 80511 1
364 Latch Pivot 4213 075 13013 1
365 Latch Spring 4213 075 70833 1
366 Door Latch 4213 077 53413 1
367 Switch Strike 4213 077 83571 1
369 Loom Clip 4213 075 70941 1
370 Latch Guide 4213 077 40992 1
376 Front Panel Assembly (white) 4213 092 18271 1
376 Front Panel Assembly (almond) 4213 092 08221 1
376 Front Panel Assembly (silver) 4213 092 36301 1
376 Front Panel Assembly (blue) 4213 092 28471 1
376 Front Panel Assembly (yellow) 4213 092 28481 1
376 Front Panel Assembly (olive green) 4213 092 28491 1
376 Front Panel Assembly (champagne) 4213 092 34231 1
PLEASE NOTE bold text indicates choice of parts depending on model colour. 4213 094 63084

White Knight CL447 and Coloured Variants - Parts List
385 Top Cover Bracket 4213 077 40923 1
386 Top Cover Assembly (white) 4213 092 21521 1
386 Top Cover Assembly (almond) 4213 092 28121 1
386 Top Cover Assembly (silver) 4213 092 36141 1
386 Top Cover Assembly (blue) 4213 092 28131 1
386 Top Cover Assembly (yellow) 4213 092 28141 1
386 Top Cover Assembly (olive green) 4213 092 28011 1
386 Top Cover Assembly (champagne) 4213 092 34241 1
390 Gasket 4213 074 50862 2
391 Push Button (white) 4213 077 59394 1
391 Push Button (almond) 4213 077 61011 1
391 Push Button (silver) 4213 077 82741 1
391 Push Button (blue) 4213 077 66881 1
391 Push Button (yellow) 4213 077 67011 1
391 Push Button (olive green) 4213 077 66021 1
391 Push Button (champagne) 4213 077 80531 1
393 Flex Support Clip 4213 077 40982 2
394 Foot 4213 077 39833 1
395 Heater Wires Clip 4213 075 70971 2
399 Heater Support 4213 080 06619 2
400 Heater Plate 4213 080 14551 2
402 Access Panel 4213 080 06555 2
403 Roller Assembly 4213 092 35651 1
413 Back Panel 4213 080 0654B 2
427 Motor Spring Clip 4213 078 45362 2
432 Motor Mount Bracket 4213 080 0675A 2
437 Vent Hose Assembly (short) 0312 002 01000 2 & 3
440 Banjo Assembly 4213 092 17811 3
441 Front Bearing (short) 4213 077 40952 3
442 Front Seal 4213 077 61701 3
444 Lifter 4213 077 41009 2
445 Front Bearing (long) 4213 077 40962 3
445a Bearings & Brush Seal Kit Assy 4213 092 21171 3
446 Fan 4213 077 40896 2 & 3
447 Access Cover Assembly 4213 092 18081 2 & 3
448 Spring Clip (Fan) 4213 075 71162 3
449 Button Switch Spring 4213 075 71151 1
450 Switch Bracket 4213 070 11631 1
454 Filter 4213 092 17821 3
456 Banjo Seal 4213 077 07991 3
457 J' Clip 2513 482 08002 3
458 Banjo Insert No 2 4213 077 53502 3
459 Banjo Insert No 1 4213 077 53492 3
471 U' Type Captive Nut 2513 483 12036 3
537 W' Button Plug 4213 078 26311 3
552 Timer Shaft Support 4213 077 59953 1
Loom Assembly 4213 076 56172
User Instruction Booklet 4213 094 5932A
Not shown on exploded views
PLEASE NOTE bold text indicates choice of parts depending on model colour. 4213 094 63084
