WHITECROFT LIGHTING COM 9 User manual

Whitecroft Lighting Limited
Burlington Street, Ashton-under-Lyne, Lancashire OL7 0AX
Telephone [phone] Facsimile: [phone]
Registered No. 3848973 England Registered Office: As above
MARCH 2019 - Rev A
COM 9
PK/COM9-IL
SPECIFICATION
Finish RAL7035, Translucent cover
Weight 185g
Supply Powered by SR driver low voltage
Power consumption 200mW
15mA at 15V
Operating temp -30C v to +65C v
Connection 2 X 18AWG wires, unpolarized, 60cm length, 8mm strip length
Ingress protection IP65
Mounting Height 5m to 16m
GENERAL INFORMATION
1) A qualified electrician, in accordance with IEE wiring regulations should carry out
connection to mains wiring.
2) This unit must be EARTHED.
3) Ensure that the rated voltage and frequency requirements are compatible with the
available mains supply.
4) Cleaning of reflectors and lenses should be carried out using clean, soft and lint
free cloths and anti-static cleaning fluid
5) Do not carry out high voltage insulation test, i.e. 500/1000v this may damage
internal components.
Installation Instruction
TECHNICAL SUPPORT
Telephone: [phone]
Email: technical whitecroftlight.com
http://whitecroftlighting.com/
DIMENSIONS
O
115 43
123,2 20,6
O 20

Mounting
Overview
A compact luminaire based sensor and control module that utilises a passive infra-red detector (PIR) and photocell,
programmed using a smart phone or tablet 'App'.
Maximum mounting height 16 metres with 18m diameter detection zone
Wireless contol module integrally wired into the luminaire
Communicates wirelessly via Zigbee with luminaires up to 15m distance
Local luminaire zones can be created with common functions
Up to 40 sensors per group and up to 6 zones per group
Product comes programmed to factory setttings below but can also be commisioned via android based device.
Factory settings
Distance from
Window
Height to
Window
0
0.5
1
1.5
2
2.5
3
0 5 10 15 20
Minimum distance from window(m)
Sensor mounting height with respect to window
Commissioning
Commissioning is done via Philips Field Apps is available for free download on Google Play Store.
The app works with Android based devices. There are two sub-apps are available within Philips Field Apps:
1. EasyAir Industry IR – This app allows configuring EasyAir parameters plus enables grouping to a wireless switch, which
can be done with an Android phone and an IR dongle (COM9DG).
2. EasyAir NFC – This app allows configuring EasyAir parameters only when you can physically access the sensor with a
smartphone. The correct functioning of this app is strongly dependent on the strength and placement of NFC antenna within
the Android phone .
Note: Please refer the list of recommended phones on Philips website for details on NFC and IR support per Android phone.
You must first register for Philips Field Apps to receive a username and password, then download Philips Field Apps from the
Google Play Store.
Refer to http://www.lighting.philips.co.uk/oem-emea/products/connectedlighting for details such as app user manual,
recommended Android phones and supported switches
.
To achieve high heights up to 16m with minimal interference, it is mandatory to use the ‘IR Dongle’, even if the device has
inbuilt IR transmitter. Ensure that you stand and point from directly beneath the sensor to avoid interference with
neighbouring sensors.
Default Factor Settings
Occupanc based control Auto-on Enabled
Da light Based Control Auto-on Disabled
Da light dependent switching Default disabled
Da light dependent override Default disabled
LED Indicator Enabled
Occupanc Mode Auto-on/off
Group Occupanc Sharing Enabled
Group Light Behaviour Background level
Field Task Tuning 100%
Eco-On Level* 100%
Background Light Level 20%
Hold Time 15 minutes
Prolong Time 15 minutes
Grace Fading 10 seconds
Fade to Switch On 0.7 seconds
Fade to Switch Off 0.7 seconds
*% between task and background level (power on level)
