Whitmor 6026-2415 User manual

6026-2415 Natural Wood Drying Rack ©2012 Whitmor, Inc.
A5 ea
Long hanging bar
B1 ea
Medium hanging bar
G16 ea
Locking collar
(Inserted into parts E & F)
H6 ea
Collar ring
I6 ea
Screw
C2 ea
Short hanging bar
D3 ea
Center hanging bar
E1 ea
Left side frame
F1 ea
Right side frame
This product is intended
for drying laundry.
Tools Needed:
Phillips Screwdriver,
and Coin or Standard
Screwdriver
STEP 1 Begin with the right side
frame (F) and place it on a hard,
flat surface like the floor. Make
sure all locking collars (G) are
inserted correctly as it came from
the box. Place 3 collar rings (H)
over exposed locking collars on
right side frame. Snap five long
hanging bars (A), one medium
hanging bar (B) and two short
hanging bars (C) into locking
collars (G) in right side frame.
Place the three center hanging
bars (D) into center axis of side
frame. Secure center hanging
bars with three screws (I) using a
Phillips screwdriver (not
included).
I I I
I
A
A
D D D
H
F
A
A
C
C
B
A
H
H
H
H
H
STEP 2 Next, place 3 remaining
collar rings (H) over exposed
locking collars on left side frame
(E). Place left side frame (E) onto
each hanging bar snapping in place
just like the right side was done.
Secure center hanging bars with
three screws (I) using a Phillips
screwdriver.
DDD
E
II
Page 1
NOTE: Make
sure the tabs on
end of hanging
bars (A, B, & C)
line up with
notch in locking
collar (G).

F
G
6026-2415 Natural Wood Drying Rack ©2012 Whitmor, Inc.
NOTE: Top
section of side
frame (E & F)
axis is not
centered. Short
end of side frame
is up.
Parts Breakdown: Left and right side frames
should already be assembled from the box, but
this parts breakdown should help if any
questions still remain.
STEP 3 Your final Whitmor Natural Wood
Drying Rack should look like this. Enjoy
its use.
Page 2
Part Reference
A
B
C
D
E
F
G
H
I
F6773
F6774
F6775
F6776
F6777
F6778
F6779
F6780
F6781
A
A
A
A
A
B
C
C
D
D
D
EG
I
I
I
I
I
I
H
G
G
Printed in China
8680 Swinnea Road • Suite 103 • Southaven, MS • 38671
NEED HELP? For help with assembly, or if you are missing a part,
please call Whitmor’s Customer Service Department, 1-888-944-8667
between 8 a.m. and 4:30 p.m. (Central Standard Time) Monday
through Friday. Or email: [email protected]. Visit us
online at www.whitmor.com
