Whitmor 6905-9042 User manual

4-Drawer Garment Rack
Assembly
Time:
Less than
45 minutes.
This product's
intended use is for
garment storage.
Tools Needed:
No extra tools required.
Page 1
A2 ea
Base
B2 ea
Bottom vertical tube
C2 ea
Upper vertical tube
E2 ea
Horizontal base tube
F2 ea
Horizontal middle tube
D1 ea
Top hanging tube
G2 ea
Side frame bracket
H2 ea
Base hex screw
I4 ea
Long hex screw
K4 ea
Short hex screw
L2 ea
Hex screw
M4 ea
Drawer
O1 ea
Drawer frame
N4 ea
Drawer bottom
P2 ea
Wheel
Q2 ea
Wheel with lock
R1 ea
Hex wrench
STEP 1. Attach a bottom vertical tube (B) to a base (A)
using a base hex screw (H). Tighten with hex wrench
(R). Repeat for the other side.
STEP 2. Attach a side frame bracket (G) to the bottom
vertical tube (B) using a medium hex screw (J). Tighten
with hex wrench (R). Repeat for the other side.
STEP 3. Insert two horizontal base tubes (E) and two
horizontal middle tubes (F) into the drawer frame (O)
sleeves at the top and bottom corners. Attach each end
of the horizontal middle tubes (F) to the side frame
brackets (G) using four short hex screws (K). Tighten
with hex wrench (R). Attach each end of the horizontal
base tubes (E) to the bases (A) using four long hex
screws (I). Tighten with hex wrench (R).
STEP 4. Insert an upper vertical tube (C) into a
bottom vertical tube (B). Attach with a hex screw (L).
Tighten with hex wrench (R). See note. Repeat for
the other side.
STEP 5. Install the top hanging tube (D) by sliding
over the top vertical tubes (C) until the locking tabs
lock into place.
STEP 5. Install the wheels (P) and wheels with locks
(Q) to the bases (A).
J2 ea
Medium hex
screw
A
E
H
E
F
G
G
O
F
A
B
C
D
B
C
I
J
K
L
J
I
K
L
I
K
HP
K
P
Q
Q
I
NOTE: The
locking tab should
be at the top of
the upper vertical
tube (C).

Page 2
STEP 6. Open the four drawers (M) and insert the
drawer bottoms (N).
STEP 7. Insert the assembled drawers into the drawer
fame. Assembly is complete.
4-Drawer Garment Rack
M
N
M
N
M
N
M
N
