Wide IDP2800SQ User manual

Issued Date
Revision Status
Title Page No.
1 / 77
V5.3
2009-06-08
IDP2800SQ
(SL28P2K)
USER MANUAL
IDP2800SQ
2048 x 2048 TFT LCD MONITOR
28.05" SQUARE FORMAT
Air Traffic Control Application
Proprietary Data Notice:
This document as well as all reports, drawings, data, information, or other material, whether accompanying it are the property of
WIDE Corporation, are disclosed by WIDE only in confidence, and, except as WIDE may otherwise permit in writing, are to be
used, disclosed, or copied only to the extent necessary for the evaluation thereof by recipient, or higher-tier contractor or
subcontractor.
Information in this document is subject to change without prior notice.

Issued Date
Revision Status
Title Page No.
2 / 77
V5.3
2009-06-08
IDP2800SQ
(SL28P2K)
Table of Contents
SAFETY INSTRUCTIONS..................................................................................................................................................6
FCC INFORMATION ..........................................................................................................................................................8
C C C .............................................................................................................................................................................9
BRIEF DESCRIPTION......................................................................................................................................................11
1. TECHNICAL SPECIFICATIONS..........................................................................................................................12
1.1 ELECTRO-OPTICAL SPECIFICATIONS.............................................................................................................12
1.1.1 SCREEN SPECIFICATIONS................................................................................................................................12
1.1.1.1 PANEL TECHNOLOGIES.....................................................................................................................................12
1.1.1.2 SCREEN DIMENSIONS.......................................................................................................................................12
1.1.1.3 DISPLAY COLORS...............................................................................................................................................12
1.1.1.4 RESOLUTION.......................................................................................................................................................12
1.1.1.5 DISPLAY MODE ...................................................................................................................................................12
1.1.2 OPTICAL CHARACTERISTICS............................................................................................................................12
1.1.2.1 PROTECTIVE FILTER GLASS.............................................................................................................................12
1.1.2.2 LUMINANCE (BRIGHTNESS)..............................................................................................................................12
1.1.2.3 CONTRAST RATIO...............................................................................................................................................12
1.1.2.4 VIEWING ANGLE: AT THE CONTRAST RATIO > 10:1 .......................................................................................12
1.1.2.5 RESPONSE TIME @ 25C AMBIENT..................................................................................................................12
1.1.3 INPUT SIGNAL SPECIFICATIONS ......................................................................................................................12
1.1.3.1 ANALOG INPUT (CRT TYPE, SONY DDM COMPATIBLE).................................................................................13
1.1.3.2 DIGITAL INPUT.....................................................................................................................................................13
1.1.3.3 INPUT SELECTION..............................................................................................................................................14
1.1.4 CONTROLS OF THE DISPLAY............................................................................................................................14
1.1.4.1 REMOTE CONTROL VIA SERIAL PORTS (CRT TYPE, SONY DDM COMPATIBLE)........................................14
1.1.4.2 CONTROL VIA ETHERNET FOR SNMP (OPTION)............................................................................................14
1.1.4.3 CONTROL VIAOSD AND CONTROL MODULE..................................................................................................14
1.1.5 LED INDICATOR AND OSD (ON SCREEN DISPLAY)........................................................................................14
1.1.6 POWER SUPPLY SPECIFICATION.....................................................................................................................14
1.1.6.1 VOLTAGE RANGE................................................................................................................................................15
1.1.6.2 POWER CONSUMPTION ....................................................................................................................................15
1.1.6.3 POWER VARIATION PROTECTION....................................................................................................................15
1.1.7 CONNECTORS.....................................................................................................................................................15
1.1.7.1 POWER CONNECTORS......................................................................................................................................15
1.1.7.2 INPUT SIGNAL CONNECTORS...........................................................................................................................15
1.1.7.3 INTERFACE CONNECTORS FOR REMOTE CONTROL...................................................................................15
1.1.8 CONNECTION......................................................................................................................................................16
1.2 MECHANICAL SPECIFICATIONS.......................................................................................................................18
1.2.1 DIMENSION AND WEIGHT (CHASSIS TYPE)....................................................................................................18
1.2.2 DIMENSION AND WEIGHT (DESK TOP TYPE)..................................................................................................21
1.2.3 DIMENSION AND WEIGHT (VESA MOUNTING TYPE)......................................................................................24
1.2.4 ASSEMBLY / DISASSEMBLY...............................................................................................................................27
1.2.5 MODULAR DESIGN.............................................................................................................................................29
1.2.6 FINISHING............................................................................................................................................................29
1.2.7 SCREWS/BOLTS..................................................................................................................................................29
1.2.8 COMPONENTS....................................................................................................................................................29
1.2.9 COOLING..............................................................................................................................................................29
1.3 ENVIRONMENTAL SPECIFICATIONS................................................................................................................29
1.3.1 TEMPERATURE...................................................................................................................................................29
1.3.2 HUMIDITY.............................................................................................................................................................29
1.3.3 VIBRATION...........................................................................................................................................................29
1.3.4 ALTITUDE.............................................................................................................................................................29
1.3.5 EMC......................................................................................................................................................................29

Issued Date
Revision Status
Title Page No.
3 / 77
V5.3
2009-06-08
IDP2800SQ
(SL28P2K)
1.3.6 SAFETY................................................................................................................................................................30
1.4 OHTER SPECIFICATIONS ..................................................................................................................................30
1.4.1 RELIABILITY.........................................................................................................................................................30
1.4.1.1 MTBF (MEAN TIME BETWEEN FAILURES) .......................................................................................................30
1.4.2 MAINTAINABILITY................................................................................................................................................30
1.4.2.1 MTTR (MEAN TIME BETWEEN REPAIR)............................................................................................................30
1.4.2.2 USE OF MAINTENANCE EQUIPMENT...............................................................................................................30
1.4.2.3 BACKLIGHT REPLACEMENT..............................................................................................................................30
1.4.3 OPERATIONAL REDUNDANCY..........................................................................................................................32
1.4.3.1 BACKLIGHTS REDUNDANCY.............................................................................................................................32
1.4.3.2 DUAL POWER SUPPLY (OPTIONAL) .................................................................................................................32
1.4.4 USE OF TOXIC MATERIALS.............................................................................................................................32
1.4.5 PACKING ..............................................................................................................................................................32
2. COMMUNICATION...............................................................................................................................................33
2.1 WHAT IS SNMP & MIB.........................................................................................................................................33
2.1.1 SNMP(SIMPLE NETWORK MANAGEMENT PROTOCOL) ................................................................................33
2.1.2 MIB (MANAGEMENT INFORMATION BASE)......................................................................................................33
2.2 WHAT’S PROVIDED. ...........................................................................................................................................33
2.3 IP SETTING..........................................................................................................................................................34
2.3.1 IPADDRESS
.........................................................................................................................................................34
2.3.2 SUBMASK.............................................................................................................................................................35
2.3.3 GATEWAY.............................................................................................................................................................35
2.3.4 TRAP IPADDRESS..............................................................................................................................................36
2.3.5 MAC ADDRESS....................................................................................................................................................36
3. CONTROL ACCESS ............................................................................................................................................37
3.1 CONTROL MODULE............................................................................................................................................37
3.2 DIRECT CONTROL ACCESS..............................................................................................................................37
3.2.1 DIM. BRIGHTNESS CONTROL ...........................................................................................................................38
3.2.2 SOURCE SELECTION.........................................................................................................................................38
3.2.3 AUTO ADJUSTMENT...........................................................................................................................................38
3.3 OSD(ON SCREEN DISPLAY) NAVIGATION.......................................................................................................39
3.3.1 BASIC OPERATION.............................................................................................................................................39
3.3.2 ADJUSTMENT......................................................................................................................................................39
3.3.2.1 BRIGHTNESS.......................................................................................................................................................39
3.3.2.2 CONTRAST ..........................................................................................................................................................40
3.3.2.3 DIM BRIGHTNESS...............................................................................................................................................41
3.3.2.4 SHARPNESS........................................................................................................................................................42
3.3.2.5 RETURN...............................................................................................................................................................
43
3.3.3 INPUT SOURCE................................................................................................................................................43
3.3.3.1 ANALOG 1............................................................................................................................................................44
3.3.3.2 DVI 1.....................................................................................................................................................................45
3.3.3.3 DVI 2.....................................................................................................................................................................45
3.3.4 ADVANCED SETTING..........................................................................................................................................45
3.3.4.1 ANALOG ADJUSTMENT......................................................................................................................................46
3.3.4.1.1 Phase....................................................................................................................................................46
3.3.4.1.2 Frequency.............................................................................................................................................47
3.3.4.1.3 H-Position.............................................................................................................................................48
3.3.4.1.4 V-Position..............................................................................................................................................49
3.3.4.1.5 Return...................................................................................................................................................49
3.3.4.2 SET-UP.................................................................................................................................................................49
3.3.4.2.1 Source Priority.......................................................................................................................................49
3.3.4.2.1.1 Manual............................................................................................................................................50
3.3.4.2.1.2 Analog1, DVI 1, DVI 2....................................................................................................................50

Issued Date
Revision Status
Title Page No.
4 / 77
V5.3
2009-06-08
IDP2800SQ
(SL28P2K)
3.3.4.2.2 Auto-Tune..............................................................................................................................................50
3.3.4.2.3 Auto-Auto...............................................................................................................................................50
3.3.4.2.4 Basic Menu Lock...................................................................................................................................51
3.3.4.2.5 User Password......................................................................................................................................51
3.3.4.2.6 Return....................................................................................................................................................51
3.3.4.3 SCALE MODE ......................................................................................................................................................51
3.3.4.4 INFORMATION.....................................................................................................................................................52
3.3.5 ADMIN. SETTINGS ..............................................................................................................................................52
3.3.5.1 ADVANCED SETTINGS .......................................................................................................................................52
3.3.5.2 DISPLAY INFO......................................................................................................................................................53
3.3.5.2.1. Serial No...............................................................................................................................................53
3.3.5.2.2. S/W ver. ................................................................................................................................................53
3.3.5.2.3. Temp. Status.........................................................................................................................................53
3.3.5.2.4. BL Status...............................................................................................................................................54
3.3.5.2.5. Input......................................................................................................................................................54
3.3.5.2.6. Comm. ..................................................................................................................................................54
3.3.5.2.7. Display Status.......................................................................................................................................54
3.3.5.2.8. Power....................................................................................................................................................54
3.3.5.3 BACK-LIGHT MENU.............................................................................................................................................54
3.3.5.3.1 SBC (Self-Brightness Control)...............................................................................................................54
3.3.5.3.1.1 SBC................................................................................................................................................54
3.3.5.3.1.2 SBC value ......................................................................................................................................
55
3.3.5.3.1.3 Return.............................................................................................................................................55
3.3.5.3.2 Life time.................................................................................................................................................55
3.3.5.3.3 DPMS ....................................................................................................................................................55
3.3.5.4 FAN CONTROL MENU.........................................................................................................................................56
3.3.5.4.1. Control ..................................................................................................................................................56
3.3.5.4.2. Life time ................................................................................................................................................56
3.3.5.5 TEMPERATURE MENU .......................................................................................................................................57
3.3.5.6 TEST PATTERN....................................................................................................................................................57
3.3.5.7 SET-UP.................................................................................................................................................................58
3.3.5.7.1 Factory Reset........................................................................................................................................58
3.3.5.7.2 Communication......................................................................................................................................59
3.3.5.7.2.1 ID....................................................................................................................................................59
3.3.5.7.2.2 Comm. Mode..................................................................................................................................59
3.3.5.7.2.3 Baud Rate ......................................................................................................................................59
3.3.5.7.3 RGB Adjust............................................................................................................................................60
3.3.5.7.3.1 Gamma...........................................................................................................................................60
3.3.5.7.3.2 Auto Color (Available only in analog mode)...................................................................................60
3.3.5.7.3.3 RGB Black Level(Available only in analog mode)..........................................................................61
3.3.5.7.3.4 RGB Gain(Available only in analog mode).....................................................................................62
3.3.5.7.4 OSD Setup ............................................................................................................................................63
3.3.5.7.4.1 Brightness Display..........................................................................................................................63
3.3.5.7.4.2 OSD Timeout..................................................................................................................................63
3.3.5.7.4.3 LED Display....................................................................................................................................64
3.3.5.7.4.4 Power warning display ...................................................................................................................64
3.3.5.7.4.5 Return.............................................................................................................................................64
3.3.5.7.5 Admin. Password...................................................................................................................................64
3.3.5.7.6 Quick Searching Mode..........................................................................................................................65
3.3.5.7.7 TCP/IP...................................................................................................................................................65
3.3.5.7.7.1 IP Address......................................................................................................................................65
3.3.5.7.7.2 Submask ........................................................................................................................................65
3.3.5.7.7.3 Gateway.........................................................................................................................................66
3.3.5.7.7.4 Trap IP Address .............................................................................................................................66
3.3.5.7.7.5 Mac Address ..................................................................................................................................66

Issued Date
Revision Status
Title Page No.
5 / 77
V5.3
2009-06-08
IDP2800SQ
(SL28P2K)
3.3.5.7.7.6 Return.............................................................................................................................................66
3.3.6 EXIT......................................................................................................................................................................66
APPENDIX A: TROUBLE-SHOOTINGS .........................................................................................................................67
APPENDIX B: DDM PROTOCOL ON IDP2800SQ .........................................................................................................68
APPENDIX C: BACKLIGHT REPLACEMENT................................................................................................................73
APPENDIX D: FAN REPLACEMENT..............................................................................................................................76

Issued Date
Revision Status
Title Page No.
6 / 77
V5.3
2009-06-08
IDP2800SQ
(SL28P2K)
SAFETY INSTRUCTIONS
Precautions
ON SAFETY
1. Before connecting the AC power cord to monitor, make sure the voltage designation of the monitor
corresponds to the local electrical supply..
2. Never insert anything metallic into the cabinet openings of the monitor; doing so may create the
danger of electric shock..
3. To avoid electric shock, never touch the inside of the monitor. Only a qualified technician should open
the case of the monitor.
4. Never use your monitor if the power cord has been damaged. Do not allow anything to rest on the
power cord, and keep the cord away from areas where people can trip over it.
5. Be sure to hold the plug, not the cord, when disconnecting the monitor from an electric socket.
6. Unplug your monitor when it is going to be left unused for an extended period of time.
7. Unplug your monitor fromAC outlet before any service.
8. If your monitor does not operate normally - in particular, if there are any unusual sounds or smell
coming from it – unplug it immediately an authorized dealer or service center.
ON INSTALLATION
1. Openings and fans in the monitor cabinet are provided for ventilation. To prevent overheating, these
openings and fans should not be blocked or covered. Also avoid using the monitor on a bed, sofa rug,
or other soft surface, doing so may block the ventilation openings and fans in the monitor cabinet. If
you put the monitor in the enclosed space, be sure to provide adequate ventilation.
2. Put your monitor in a location with low humidity and minimum of dust.
3. Do not expose the monitor to rain or use it near water. If the monitor, accidentally, get wet, unplug it
and contact an authorized dealer immediately. You can clean the monitor with damp cloth if necessary,
but be sure to unplug the monitor first.
4. Place your monitor on a solid surface and treat it carefully.
5. Locate your monitor near an easily accessibleAC outlet.
6. High temperature can cause problems. Do not use your monitor in direct sunlight and keep it away
from heater, stoves and other sources of heat.
CAUTION: DOUBLE POLE / NEUTRAL FUSING.
DISCONNECT POWER BEFORE CHANGING FUSE.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

Issued Date
Revision Status
Title Page No.
7 / 77
V5.3
2009-06-08
IDP2800SQ
(SL28P2K)
ON CLEANING
The screen is made of thin glass with a plastic surface and can be damaged if dropped, hit and scratched.
Do not clean the front panel with keton-type materials(e.g., acetone), ethyl alcohol, toluene, ethyl acid,
methyl or chloride – these may damage the panel.
ON REPACKING
Do not throw away the carton and packing materials. They make an ideal container which to transfer the
unit. If you have any questions about this unit, contact your authorized dealer.
ON DISPOSAL
This unit contains which can pollute the environment if disposed carelessly. Please contact our nearest
representative office or your local environmental office in case of disposal of this unit.
ON VESA MOUNTING
Make sure to unplug before installing this product. Otherwise, it may cause a fire or could give
an electric shock.
Do not install this product by yourself. Contact the qualified service technician. Otherwise, it may
cause injuries.
Do not install this product on the place where it cannot be supported. Otherwise, it may cause
the product to fall and could cause injuries.
Contact the qualified service technician for moving or replacing this product after installing.
Installing the product needs specified technique, so it may cause safety problem to move or
install it by yourself.
Do not hang on or impact on this product. Otherwise, it may cause the product to fall and could
cause injuries.
Do not install this product by alone. Get some help from others. Otherwise, it may cause the
product to fall and could cause injuries.
Do not place a heat source or a humidifier under the installed product. Otherwise, it may cause a
fire or could give an electric shock.
Do not install this product near a high voltage electric line, any power source or the place where
impact or vibration can affect.
Do not install this product barehanded. Otherwise, it may cause injuries.
The screw is not provided to user as default. Use the screw, which can stand the weight of this
product. And, we recommend the machine screw BH(+)M4 x 14mm to 18mm as type.

Issued Date
Revision Status
Title Page No.
8 / 77
V5.3
2009-06-08
IDP2800SQ
(SL28P2K)
FCC INFORMATION
USER INSTRUCTIONS
The Federal Communications Commission Radio Frequency Interference Statement includes the
following warning:
NOTE This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio frequency energy and, if
not installed and used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in a residential area is likely
to cause harmful interference in which case the user will be required to correct the interference
at his own expense.
USER INFROMATION
Changes or modifications not expressly approved by the party responsible for compliance could void the
user’s authority to operate the equipment.
If necessary, consult your dealer or an experienced radio/television technician for additional suggestions.
You may find the booklet called How to identify and Resolve Radio/TV Interference Problems helpful. This
booklet was prepared by the Federal Communications Commission. It is available from the U.S.
Government Printing Office, Washington, DC 20402, Stock Number 004-000-00345-4.
WARNING User must shielded signal interface cables to maintain FCC compliance for the product.
DECLARATION OF CONFORMITY FOR PRODUCTS MARKED WITH FCC LOGO
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
This party responsible for product compliance:
Provided with this monitor is a detachable power supply cord with IEC320 style terminations. It may be
suitable for connection to any UL Listed personal computer with termination. Before making the
connection, make sure the voltage rating of the computer convenience outlet is the same as the monitor
and that the ampere rating of computer convenience outlet is equal to or exceeds the monitor voltage
rating.
For 120 Volt applications, use only UL Listed detachable power cord with NEMA configuration 5-15P type
(parallel blades) plug cap. For 240 Volt applications use only UL Listed detachable power supply cord
with NEMA configuration 6-15P type (tandem blades) plug cap.

Issued Date
Revision Status
Title Page No.
9 / 77
V5.3
2009-06-08
IDP2800SQ
(SL28P2K)
C C C
声明: 此为A级产品, 在生活环境中,被产品可能会造成无线电干扰,
在这种情况下, 可能需要用户对其干扰采取切实可行的措施。
安全说明
注意事项
安全
1. 将交流电源线插入直流适配器插座前,应确保直流适配器的标示电压与当地供电电压相符。
2. 切勿在液晶显示器 (LCD) 的机箱开口处插入任何金属物体;
否则可能导致电击。
3. 为防止触电 , 请勿拆卸盖板。 机器内部没有用户可以维修的部件。 只有有资格的技师才能打开
LCD 显示器的外壳。
4. 如果电源线已破损,切勿使用 LCD 显示器。 切勿在电源线上挂放任何物体,并应防止电线绊人。
5. 在从电源插座上拔下 LCD 显示器时,应握住插头而不是电线。
6. 如果长时间不使用 LCD 显示器,应拔下其电源插头。
7. 进行任何维修前,应将 LCD 显示器的插头从交流电源插座上拔下。
8. 如果 LCD 显示器不能正常工作 – 特别是在其中有异常声音或气味时 – 应立即拔下电源线并联系
授权经销商或维修中心。
警告
不要同时触摸信号输入、信号输出或其它连接器和患者。
警告
要将外部设备连接信号输入、信号输出或其它连接器,该外部设备应符合相关 IEC 标准(例如,用于 IT 设
备的 IEC60950 和用于医疗电气设备的 IEC60601)。
另外,所有这样的组合系统应符合用于医疗电气系统安全要求的 IEC 60601-1-1 标准。 在信号输入、信号
输出或其它连接器上连接外部设备以构成系统的任何人都有责任使系统符合 IEC 60601-1-1 的要求。
如有疑问,请联系有资格的技师或当地代理商。
安全说明
此“TFT LCD 显示器”是“医疗设备”使用的附件,用于显示字母、数字和图形数据。
安装
1. LCD 显示器机箱中的开口用于通风。 为避免过热,不得阻塞或覆盖这些开口。 还应避免在床上、沙发
垫上或其它柔软表面上使用此 LCD 显示器。 否则可能阻塞位于机箱底部的通风口。 如果将 LCD 显
示器放在书柜或某些封闭空间,应确保通风良好。
2. 应将 LCD 显示器放在湿度低和灰尘少的地方。
3. 切勿让 LCD 显示器淋雨或在有水的环境中(例如厨房、游泳池附近等)使用。 如果 LCD 显示器意
外弄湿,应立即拔下电源插头并联系授权经销商。 如有必要,可以使用湿布清洁 LCD 显示器,但应确
保先拔下 LCD 显示器电源插头。
4. 应将 LCD 显示器放在坚固的表面上并小心使用。
5. 应将 LCD 显示器放在可方便使用交流电源插座的地方。
6. 高温会导致故障。切勿在阳光直射处使用
LCD
显示器并应使其远离加热器、火炉、壁炉和其它热源。

Issued Date
Revision Status
Title Page No.
10 / 77
V5.3
2009-06-08
IDP2800SQ
(SL28P2K)
清洁
屏幕由前表面带有塑料的薄玻璃制成,如果跌落、受到撞击或刮擦,可能会损坏。 不要使用酮类物质(例
如丙酮)、普通酒精、甲苯、乙基酸、甲基或氯化物清洁前面板 – 这些物质会损坏面板。
面板: 使用柔软的毛纺或棉质毛巾进行清洁。 使用水性溶液或中性玻璃清洁液进行清洁。
机箱: 使用由中性清洁剂和水湿润的软布进行清洁。 只使用水清洁并用干布擦干。
重新装箱
不要扔掉纸箱和包装材料。 在转运装置时它们是理想的容器。 如有有关此装置的问题,请联系授权经销
商。
处置
此装置包含的物质如果处置不当,可能会污染环境。 处置此装置时,请联系距您最近的代理商办事处或当
地环境保护机构。
联系方式
WIDE Corporation
456, Gomae-dong, Giheung-gu, Yongin-si, Gyeonggi-do, 446-901 Republic of Korea
(电话: +82 - 31 - 218 - 1600 传真: +82 - 31 - 218 - 1699)

Issued Date
Revision Status
Title Page No.
11 / 77
V5.3
2009-06-08
IDP2800SQ
(SL28P2K)
BRIEF DESCRIPTION
GENERAL
This specification defines the requirements for the IDP2800SQ, 28.05” square formatted TFT LCD
monitor with 2048 X 2048 pixels visible resolution, which is designed and tailored for use in operator
display systems such as Air Traffic Control applications.
The IDP2800SQ has a 28.05” diagonal viewable display area and 2048 x 2048 pixels addressable
resolution. The .246mm pixel pitch (or 103 pixels per inch) LCD provides the most accurate and crisp
images on the screen for mission critical applications.
The IDP2800SQ provides 16.7 million true colors (8 bit) per pixel. Each pixel is divided into Red, Green
and Blue sub pixels which are arranged in vertical stripes and each sub-pixel is controlled in 256 grey
levels.
KEY FEATURES
Square formatted 28.05” TFT LCD Monitor
Full 2048 x 2048 resolution
Multi-mode display : VGA ~ SXGA and 2Kx2K
Dual Analog input and Dual DVI input (default)
RS-422, RS423 and RS-232 Communication
Auto Adjustment within 5 seconds on analog input
Real-time Phase Tracing on analog input
Self-Brightness Control
Source Priority
Backlight units to be able to replace
Versatile mechanical version : Chassis Type, Desktop Type, VESA Mount Type
Free Voltage AC power : 100 ~ 250Vac, 50/60Hz
Secondary(optional) : 12VDC output external adapter
INPUT DIAGRAM
Analog input connectable to any source compatible to 2Kx2K CRT based monitor and also
compatible to general CRT monitor
Digital input fully compatible to DVI-D Standard of VESA DDWG
An analog input and two DVI-D inputs are basically installed in IDP2800SQ

Issued Date
Revision Status
Title Page No.
12 / 77
V5.3
2009-06-08
IDP2800SQ
(SL28P2K)
1. TECHNICAL SPECIFICATIONS
1.1 ELECTRO-OPTICAL SPECIFICATIONS
1.1.1 Screen Specifications
1.1.1.1 Panel Technologies
AMLCD (Active Matrix Liquid Crystal Display) technology
Amorphous silicon TFT (Thin Film Transistor) technology
ASV (Advanced Super Viewing) technology
1.1.1.2 Screen Dimensions
Aspect ratio 1:1 SQUARE
Active screen size:
°503.8 (H) x 503.8 (V) mm (19.83” x 19.83”)
°712.4 mm (28.05”) diagonal
1.1.1.3 Display colors
16,777,216 true colors (8-bit), 256 grey scales
1.1.1.4 Resolution
2048 (H) x 2048 (V) pixels
Pixel arrangement: RGB (Red dot, Green dot, Blue dot) Vertical Stripe
Pixel pitch: 0.246 (W) x 0.246 (H) mm (0.082” x 0.082”)
Pixels Per Inch: 103 PPI
1.1.1.5 Display mode
Normally Black
1.1.2 Optical Characteristics
1.1.2.1 Protective Filter Glass
Clear, tempered glass
Anti Reflective Film and Anti-Static Treatment
1.1.2.2 Luminance (Brightness)
225 cd/m² (max. typical on LCD)
210 cd/m² (max. typical on Protective Filter Glass)
Dimming Ratio: 10 to 1
White uniformity: 1.25 max.
1.1.2.3 Contrast ratio
1000 : 1 (typical)
1.1.2.4 Viewing Angle: At the contrast ratio > 10:1
Horizontal: +/- 85(typical)
Vertical: +/- 85(typical)
1.1.2.5 Response time @ 25C ambient
Tr (White Black): 5 ms (typical)
Td (Black White): 20 ms (typical)
1.1.3 Input Signal Specifications
IDP2800SQ provides maximum three (3) input signal interfaces, an analog input and 2 x digital
input. One input is displayed at a time by automatic* and/or manual input selection. (* Factory
setting is automatic)

Issued Date
Revision Status
Title Page No.
13 / 77
V5.3
2009-06-08
IDP2800SQ
(SL28P2K)
Standard input resolution is 2K x 2K (2048 x 2048 pixels)
Other resolutions are supported as specified below. Three scaling method are provided for input
signals with resolutions less than the standard input resolution 2048 x 2048 pixels.
Refer “3.3.4.3” for scale mode.
Resolution Hsync
(KHz) Vsync
(Hz)
VGA 640 x 480 31.0 - 43.0 60.0 - 85.0
SVGA 800 x 600 35.0 - 53.7 56.0 - 85.0
XGA 1024 x 768 48.4 - 68.3 60.0 - 85.0
SXGA 1280 x 1024 64.0 60.0
2K x 2K 2048 x 2048 Refer to “1.1.3.2” for analog
Refer to “1.1.3.3” for digital
1.1.3.1 Analog Input (CRT type, Sony DDM compatible)
Analog RGB input signal shall be as follows:
°Video Signal Level: 0.714 Vp-p nominal
°Video Signal Polarity: Positive (Black to White). Polarity is detected automatically.
Both 0 V to +0.714 Vp-p and -0.714 V to 0 Vp-p is allowed.
°Video Input Impedance: 50 Ohm terminated (RGB Video Signal)
°Sync: TTL voltage levels, External Separate H & V Sync.
°Interlace: Non-interlaced
2K x 2K Timing Specification
Pixel Clock 357.181MHz
H frequency 126.84 kHz V frequency 60.0Hz
H line time 7.884µs V line time 2114H
H active time 5.734µs (2048 pixels) V active time 2048H
H sync width 0.8959µs V sync width 3H
H front porch 0.1176µs V front porch 3H
H back porch 1.137µs V back porch 60H
H blank 2.150µs (768 pixels) V blank 66H
1.1.3.2 Digital Input
Two digital input according to Dual Link DVI Specification of VESA DDWG
2K x 2K Timing Specification (Recommend)
Pixel Clock 255.92 MHz
H frequency 117.61 kHz V frequency 56.57Hz
H line 2176 Pixels V line 2079 Lines
H active 2048 Pixels V active 2048 Lines
H sync width 32 Pixels V sync width 3 Lines
H front porch 32 Pixels V front porch 5 Lines
H back porch 64 Pixels V back porch 23 Lines
H blank 128 Pixels V blank 31 Lines
2K x 2K Guaranteed Timing Specification
°Pixel Clock: max. 300MHz
°V frequency: 50 – 70Hz
°V front porch: min. 5 lines
°V back porch: min. 5 lines
°V sync width: min. 3 lines
°H front porch: min. 5 pixels
°H back porch: min. 5 pixels
°H sync width: min. 3 pixels

Issued Date
Revision Status
Title Page No.
14 / 77
V5.3
2009-06-08
IDP2800SQ
(SL28P2K)
1.1.3.3 Input Selection
In case multiple input source is connected, input to be displayed can be selected by:
Manual: Operator can select the input manually using OSD menu and/or control panel (if
available).
Automatic: IDP2800SQ will select a valid input signal per the priority defined by user. When the
selected input source becomes invalid, reselection will be made automatically.
1.1.4 Controls of the Display
1.1.4.1 Remote Control via serial ports (CRT type, Sony DDM compatible)
There are serial ports on the back side of the IDP2800SQ for remote control of the monitor by
customer application. Either Sony DDM protocol (RS-422) or WIDE serial communication
protocol (RS-232) can be used.
°RS-422 port: Sub D, 15p, Female (for Sony DDM protocol)
°RS-232 port: Sub D, 9p, Female (for WIDE protocol)
1.1.4.2 Control via Ethernet for SNMP (Option)
A Built-in Lan port is available for direct connection to ethernet which enables centralized status
monitoring and control of multiple display monitors connected to the network using SNMP
(Simple Network Monitoring Protocol).
Standard and Enterprise MIB (Management Information Base) available for SNMP Application
S/W
1.1.4.3 Control via OSD and Control module
Control module with two push buttons and one encoder switch is available: Power and Source
keys, and Menu/Control encoder switch. Settings are selected by the Menu/Control encoder
switch that guides you through the OSD menu.
Hot plug-in and plug-out without interference to the display supported.
Control module also has two LED indicators, refer to 1.1.5.
1.1.5 LED Indicator and OSD (On Screen Display)
Fault information in available by LED indicators
Power “ON”: Green indicator, Power “Off” : Red indicator
No sync/Fault: Red blinking
1.1.6 Power Supply Specification

Issued Date
Revision Status
Title Page No.
15 / 77
V5.3
2009-06-08
IDP2800SQ
(SL28P2K)
1.1.6.1 Voltage range
100 – 250Vac, 50/60Hz
1.1.6.2 Power consumption
Ptyp
(50% Light Output) Pmax
(100% Light output)
IDP2800SQ 110 W 150 W
1.1.6.3 Power variation protection
Unit will not be damaged when Voltage transients remain within value as defined in the
applicable voltage range
1.1.7 Connectors
1.1.7.1 Power connectors
Standard: IEC type connector
Secondary(option) : 6-Pin LAD1140-N(X)(Hanlim) Connector
1.1.7.2 Input signal connectors
Analog Input: 5 Coaxial BNC connectors for R, G, B, HS and VS
°High quality interconnection cable is recommended (less than 1 dB loss at 350 MHz)
Digital input: DVI-D connectors
1.1.7.3 Interface connectors for remote control
RS-422 port: Sub D, 15p, Female (for Sony DDM protocol)
RS-232 port: Sub D, 9p, Female (for WIDE protocol)
LAN port: RJ45, 8p, female (for SNMP protocol, option)

Issued Date
Revision Status
Title Page No.
16 / 77
V5.3
2009-06-08
IDP2800SQ
(SL28P2K)
1.1.8 Connection
Power Input
Analog Input
Digital Input
DVI 1
DVI 2
Control Interface
●100-250Vac, 50/60Hz with double pole /
neutral fusing, 250V F3.15AL
●Disconnect power before changing fuse
● Secondary power adapter : 12Vdc, 15A,
180W with UL60950, cUL, CE , FCC approved.
1. TMDS Data 0-
2. TMDS Data 0+
3. TMDS Data 0/5 Shield
4. TMDS Data 5-
5. TMDS Data 5+
6. TMDS Clock Shield
7. TMDS Clock+
8. TMDS Clock-
●DVI 1 : Digital Input
●DVI 2 : Digital Input (DVI-I)
●Connection Type : 29p DVI-I Female (Digital only support)
9. TMDSData2-
10. TMDS Data 2+
11. TMDS Data 2/4 Shield
12. TMDS Data 4-
13. TMDS Data 4+
14. DDC Clock
15. DDC Data
16. No Connection
17. TMDS Data 1-
18. TMDS Data 1+
19. TMDS Data1/3 Shield
20. TMDS Data 3-
21. TMDS Data 3+
22. +5V power
23. Ground (Return for +5V)
24. Hot plug Detect
●R : Analog Red Signal Input (0.7 Vpp, 50 ohm)
●G : Analog Green Signal Input (0.7 Vpp, 50 ohm)
●B : Analog Blue Signal Input (0.7 Vpp, 50 ohm)
●H : Horizontal Sync Signal Input (TTL)
●V : Vertical Sync Signal Input (TTL)
●Connection Type : 5 x BNC

Issued Date
Revision Status
Title Page No.
17 / 77
V5.3
2009-06-08
IDP2800SQ
(SL28P2K)
Remote In
● Connection Type : 9p Dsub Female
● RS-232, RS-423 : for communication with remote
control system
1. No connection
2. RX_IN (for RS232, RS423)
3. TX_IN (for RS232, RS423)
4. TX0_B
5. RX0_B
6. No connection
7. Ground
8. TX0_A
9. RX0_B
Control
● Connection Type : 8p miniDIN
● for communication with control module
provided from WIDE
Download
● Connection Type : 9p Dsub Female
● for download the firmware
1. No connection 2. RX_DL
3. TX_DL 4. No connection
5. No connection 6. No connection
7. Ground 8. No connection
9. No connection
SNMP
● for SNMP Protocol
1. TD+ 2. TD-
3. RD+ 4. NC0
5. NC1 6. RD-
7.NC2 8. NC3
Remote Aux
● Connection Type : 15p Dsub Female
●RS-422 : for communication with remote control
system (compatible with SONY DDM)
1. Ground 2. TX1_A
3. RX1_A 4. DTR-
5. CTS- 6. Ground
7. No connection 8. +5V
9. TX1_B 10. RX1_B
11. DTR+ 12. CTS+
13. Ground 14. No connection
15. No connection

Issued Date
Revision Status
Title Page No.
18 / 77
V5.3
2009-06-08
IDP2800SQ
(SL28P2K)
1.2 MECHANICAL SPECIFICATIONS
1.2.1 Dimension and Weight (Chassis Type)
The dimension of the unit is as shown in the table below:
Monitor only Packing
Height (mm / inch) 610.0 / 24.01 382.0 / 15.03
Width (mm / inch) 610.7 / 24.04 826.0 / 32.52
Depth (mm / inch) 177.4 / 6.98 791.0 / 31.14
Weight (kg / lbs) 26.0 / 57.3 35.0 / 77.21
The following figures show a chassis version mechanical dimension. IDP2800SQ basically provides three input
connectors and all connectors are located the bottom side of monitor.
< IDP2800SQ Front View : unit mm >

Issued Date
Revision Status
Title Page No.
19 / 77
V5.3
2009-06-08
IDP2800SQ
(SL28P2K)
< IDP2800SQ Bottom View >
< IDP2800SQ Rear View >

Issued Date
Revision Status
Title Page No.
20 / 77
V5.3
2009-06-08
IDP2800SQ
(SL28P2K)
< IDP2800SQ Top View >
< IDP2800SQ Side View : unit mm>
Table of contents
