Wide IF2105M User manual

USER’S MANUAL
IF2105M(PN21IQS)
TFT–LCD Monitor

1
Table of Contents
Safety Instructions ............................................................................................................2
Your New LCD Monitor ....................................................................................................5
Feature and Benefits.............................................................................................. 5
Unpacking Your Monitor.........................................................................................5
Regulatory Information ....................................................................................................6
Setting up Your LCD Monitor .........................................................................................8
Connecting Your LCD Monitor ...............................................................................8
Stand User Controls ...............................................................................................9
Adjusting Your LCD Monitor .......................................................................................... 9
Main User Controls................................................................................................................... 9
User Controls .........................................................................................................9
OSD Lock / Unlock .................................................................................................9
On Screen Display(OSD) Controls ....................................................................... 10
Direct Access buttons ...................................................................................10
Brightness ..................................................................................................... 10
Warm-up Time .............................................................................................. 10
Utility(Service control only) .................................................................................11
Accessing the menu system ......................................................................... 11
Utility Function Controls ............................................................................... 12
Appendix .............................................................................................................................14
Specifications(Monitor main) .................................................................................................14
Electrical Specifications ............................................................................... 14
Mechanical Specification and Regulatory ....................................................15
Power Management ............................................................................................16
Pin Assignments ..................................................................................................17
Troubleshooting ...................................................................................................18

2
Safety Instructions
Explanation of Graphical Symbols
The exclamation point within an equilateral triangle is intended to alert the user to the presence
of the important operating and maintenance (servicing) instructions in the literature accompaning
the appliance.
The lighting flash with arrowhead symbol, within an equilateral triangle, is intended to alert the
be user to the presence of un-insulated "dangerous voltage" within the product's enclosure that
of may sufficient magnitude to constitute a risk of electric shock to persons.
Stand-by Switch. Press to turn the monitor on or off (Stand-by mode).
Direct Current.
Warning : When the unit is used together with other equipment in the patient area, the equipment shall be
connected according to Standard UL60601-1 and IEC60601-1.
Classification :
• Protection against electric shock: Class l including AC/DC Adapter.
• Applied Parts: No Applied Parts.
• Protection against harmful ingress of water: ordinary IPXO.
• Degree of safety in the presence of flammable anesthetics mixture with air or with oxygen or with
nitrous oxide:
Not suitable for use in the presence of a flammable anesthetics mixture with air or with oxygen or with
nitrous oxide.
• Mode of operation: Continuous.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
AVERTISSEMENT RISQUE DE CHOC ELECTRIQUE NE PAS OUVRIR
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
LCD MONITOR
54IJ
E217340
WITH RESPECT TO ELECTRIC SHOCK,
FIRE AND MECHANICAL HAZARDS ONLY
IN ACCORDANCE WITH UL60601-1 AND
CAN/CSA C22.2 NO. 601.1,
MEDICAL EQUIPMENT CERTIFIED FOR CANADA
Grounding Reliability Can Only Be Achieved When The Equipment ls Connected
To An Equivalent Receptacle Marked “Hospital Only” or “Hospital Grade”.

3
Safety Instructions
Precautions
On Safety
1. Before connecting the AC power cord to the DC adapter outlet, make sure the voltage
designation of the DC adapter corresponds to the local electrical supply.
2. Never insert anything metallic into the cabinet openings of the Liquid Crystal
Display(LCD) monitor ; doing so may create the danger of electric shock.
3. To reduce the risk of electric shock, do not remove cover. No user-serviceable parts
inside. Only a qualified technician should open the case of the LCD monitor.
4. Never use your LCD monitor if the power cord has been damaged. Do not allow anything
to rest on the power cord, and keep the cord away from areas where people can trip
over it.
5. Be sure to hold the plug, not the cord, when disconnecting the LCD monitor from an
electric socket.
6. Unplug your LCD monitor when it is going to be left unused for an extended period of
time.
7. Unplug your LCD monitor from the AC outlet before any service.
8. If your LCD monitor does not operate normally - in particular, if there are any unusual
sounds or smells coming from it - unplug it immediately am authorized dealer or service
center.
WARNING Do not touch signal input, signal output or other connectors, and the
patient simultaneously.
WARNING External equipment intended for connection to signal input, signal output
or other connectors, shall comply with relevant IEC Standard (e.g.,IEC60950
for IT equipment and IEC60601-1 series for medical electrical equipment).
In addition, all such combination-system-shall comply with the standard
IEC60601-1 and/or IEC60601-1-1 harmonized national standard or the
combination.
If, in doubt, contact qualified technician or your local representative.

4
Safety Instructions
This TFT LCD Monitor is as accessory intended for use with Medical Equipment to display
alpha, numerical and graphical data.
On Installation
1. Openings in the LCD monitor cabinet are provided for ventilation. To prevent overheating, these
openings should not be blocked or covered. Also avoid using the LCD monitor on a bed, sofa rug, or
other soft surface. Doing so may block the ventilation openings in the bottom of the cabinet. If you
put the LCD monitor in a bookcase or some other enclosed space, be sure to provide adequate
ventilation.
2. Put your LCD monitor in a location with low humidity and a minimum of dust.
3. Do not expose the LCD monitor to rain or use it near water (in kitchens, near swimming pools, etc.).
If the LCD monitor accidentally gets wet, unplug it and contact an authorized dealer immediately.
You can clean the LCD monitor with a damp cloth if necessary, but be sure to unplug the
LCD monitor first.
4. Place your LCD monitor on a solid surface and treat it carefully.
5. Locate your LCD monitor near an easily accessible AC outlet.
6. High temperature can cause problems. Don't use your LCD monitor in direct sunlight and keep it
away from heaters, stoves, fireplaces, and other sources of heat.
On Cleaning
The screen is made of thin glass with a plastic front surface and can be damaged if dropped, hit or
scratched. Do not clean the front panel with keton-type materials (e.g., acetone), ethyl alcohol, toluene,
ethyl acid, methyl, or chloride - these may damage the panel.
Panel : Clean with a soft woolen or cotton towel. Use a watery solution or a mild commercial glass
cleaning solution.
Cabinet : Clean with a soft cloth dampened with mild detergent and water. Repeat this with water
only and wipe dry with a dry cloth.
On Repacking
Do not throw away the carton and packing materials. They make an ideal container which to transfer
the unit. If you have any questions about this unit, contact your authorized dealer.
On Disposal
This unit contains which can pollute the environment if disposed carelessly. Please contact our
nearest representative office or your local environmental office in case of disposal of this unit.
Contact
WIDE Corporation
806-3, Yangcheong-Ri, Ochang-Myun, Cheongwon-Gun, Chungbuk-DO, 363-883, KOREA
(TEL : +82 - 43 - 219 - 2800 FAX : +82 - 43 - 219 - 2900)

5
Your New LCD Monitor
Feature and Benefits
•Dual design - Digital Interface
- Clear, sharp and crisp image
•Flexibility - Portrait/Landscape Display
- Auto pivot and Auto Height-adjustable Stand (Optional)
•Superior Spec - High Luminance/High Contrast ratio
- Wide viewing angle
- Large Display Area(21.3")
Unpacking Your Monitor
When you unpack the LCD Monitor, make sure that you have items below.
Manual Monitor Warranty Card
(not available in all locations)
Power Cord DC Adapter
USB-Driver
USB-Cable
DVI Signal Cable

6
Regulatory Information
FCC Information
User Instructions
The Federal Communications Commission Radio Frequency Interference Statement includes
the following warning:
NOTE This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television receptions,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
•Consult the dealer or an experienced radio/TV technician for help.
User Information
Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
If necessary, consult your dealer or an experienced radio/television technician for additional
suggestions. You may find the booklet called How to Identify and Resolve Radio/TV
Interference Problems helpful. This booklet was prepared by the Federal Communications
Commission. It is available from the U.S. Government Printing Office, Washington, DC
20402, Stock Number 004-000-00345-4.
Warning User must use shielded signal interface cables to maintain FCC compliance for
the product.

7
Regulatory Information
Declaration of conformity for products Marked with FCC Logo
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) this device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired
operation.
The party responsible for product compliance:
Provided with this monitor is a detachable power supply cord with IEC320 style
terminations. It may be suitable for connection to any UL Listed personal computer with
similar configuration. Before making the connection, make sure the voltage rating of the
computer convenience outlet is the same as the monitor and that the ampere rating of the
computer convenience outlet is equal to or exceeds the monitor voltage rating.
For 120 Volt applications, use only UL Listed detachable power cord with NEMA
configuration 5-15P type (parallel blades) plug cap. For 240 Volt applications use only UL
Listed Detachable power supply cord with NEMA configuration 6-15P type (tandem blades)
plug cap.
For connection to a supply not in USA, make sure the power cord is the correct type that is
required in your area.
IC Compliance Notice
This Class B digital apparatus meets all requirements of the Canadian Interference-Causing
Equipment Regulations of ICES-003.

8
Setting up Your LCD Monitor
Connecting Your LCD Monitor
1. Power & Signal Input
1) Main Power Input : DC Power Input Jack from the AC to DC Adapter.
2) Digital Video Input : Digital Video Input connector (DVI) from the PC.
3) USB Connector - Up Stream.
4) USB Connector - Down Stream.
2. Connecting Cable
1) Connect the power cord to the DC adapter and connect the adapter plug to the DC12V
power connector on the back of the monitor.
2) Connect the Digital video signal cable from PC to .
3) Turn the monitor on, and then turn the computer on.
4) Recommended resolution of IF2105M(PN21IQS) is QSXGA, 2560 x 2048.
Option
If you want to use a USB port, Connect the USB cable from pc to .
1
2
143
2
3

9
Adjusting Your LCD Monitor
Main User Controls
Your LCD monitor allows you to easily adjust the characteristics of the image being
displayed. All of these adjustments are made using the control buttons on the monitor.
While you use these buttons to controls, an OSD shows you their change.
User Controls
Name/Symbol Description
RESET •Exit from menus.
•Enter the utility (Service control only).
•Moves the highlight icon Down to the function that wants.
•Moves the highlight icon Up to the function that wants.
•Adjust the overall light intensity of their images.
+ : Increase the light intensity of image.
- : Decrease the light intensity of image.
•Turns ON / OFF the monitor.
•Indicates the status of the monitor.
- Green : Normal Operation.
- Red : Power Saving Mode or Disconnected Signal.
Power/Indicator
Brightness
OSD Lock / Unlock
This function allows you to secure the current settings so that cannot be inadvertently
changed.
You can unlock the OSD controls at any time by using the same procedure.
- Access the utility menu (Push and hold Reset button for at least 10 seconds).
- Access OSD Lock menu.
- Press the Reset button once and select Unlock or Lock menu.
+ –

10
Adjusting Your LCD Monitor
On Screen Display (OSD) Controls
Direct Access buttons
You can quickly and easily adjust the brightness by using the Direct Access buttons located.
Before adjusting the user controls, enter the utility and unlock the OSD lock.
Brightness
1.Press the “ + ” button to increase the
brightness.
2.Press the " – " button to decrease the
brightness.
Warm-up Time
All LCD monitors need time to become thermally stable whenever you turn on the monitor
after letting the monitor be turned off for a couple of hours. Therefore, to achieve more
accurate adjustments for parameters, allow the LCD monitor to warm (be on) for at least 20
minutes before making any screen adjustments.

11
Adjusting Your LCD Monitor
Utility (Service control only)
If you have a problem setting up utility functions of your LCD monitor, contact customer
service.
On Screen Display
Accessing the menu system
1. With the menu off, press the RESET button for at least 10 seconds to display the utility
Main menu.
2. Use the "– , + " buttons to move the function, and press the RESET button once to
activate the selected function.
3. Use the "– , + " buttons to select the sub-menu, and press the Reset button once to
activate the selected sub-menu.
4. To exit the OSD, wait for 5 seconds or more without making any adjustments or select
the Exit from the utility main menu, and then press the RESET button.

OSD Lock
Factory Reset
SBC
8bit / 10bit
Language
Information
Exit
Utility

12
Adjusting Your LCD Monitor
Utility function Controls
OSD Lock
Lock the controls of the Brightness.
- Lock : Lock the Adjustment of the Brightness.
- Unlock : Unlock the Adjustment of the Brightness.
Factory Reset
Resets the Brightness Settings.
- Reset : Replace the factory default values.
- User : Does not make the adjustment.
SBC
Performs SBC (Stable Brightness Control).
- Adjust the overall light intensity stable to the target
luminance value.



Adjusting Your LCD Monitor
Utility function Controls
8bit / 10 bit
Selects the LUT and gradation of gray scale.
- 8bit : Set the 256 gradation.
- 10bit : Set the 1021 gradation.
- LUT1 : Factory preset DICOM (at 500 cd/m ).
- LUT2 : Factory preset Reverse LUT.
- LUT3 : User calibration purpose LUT.
Language
Selects the language of OSD.
Information
Shows the information of the current settings.
- Power on time.
- Number of Power on/off.
- Information of Dynamic Brightness.
- Setting of current gradation.
- Information of SBC.
- OSD Language.
- Temperature of the Inside.
2
13

14
Appendix
Specifications (Monitor main)
Electrical Specifications
Panel Specification
Screen size 21.3 inch (540.9mm)
Viewable image size 21.3 inch (540.9mm)
Display resolution 2560 x 2048 pixels
Brightness 800 cd/m (maximum)
Contrast ratio 600:1
Viewing angle 85˚/ 85˚/ 85˚/ 85˚ (up/down/right/left)
Compatibility(Video Card)
Single Portrait 2048 x 2560
Landscape 2560 x 2048
Dual Portrait 4096 x 2560
2048 x 5120
Landscape 5120 x 2048
2560 x 4096
Input Specification
Input Signal Digital 10 bit (Specific DVI)
Sync. type Separate
- Hsync : 105 KHz
- Vsync : 48.4 Hz
- Dot CLK : 143.18 MHz
Power Specification
Power supply Ault Inc., Model : MW116-KA-1249-F02
Input : 100-240Vac, 1.0A, 50/60Hz
Output : 12Vdc, 6.67A
Power consumption Typical : 65 W
DPMS : 6 W
Power management EPA Energy Star / NUTEK
2

15
Appendix
Mechanical Specification and Regulatory
Mechanical Specification
Dimension Portrait (with stand) : 397 x 544.2 x 200 (mm)
Landscape (with stand) : 478 x 503.4 x 200 (mm)
(w/o stand) : 397 x 478 x 92 (mm)
Weights (Unpacked) : 10.3kg
(Packed) : 13.8kg
Environmental Consideration
Operating Temperature : 5°C to 40°C / 41°F to 104°F
Humidity : 10% to 80%
Storage Temperature : –20°C to 60°C / –40°F to 140°F
Humidity : 5% to 95%
Regulatory
Approvals UL60601-1 / EN60601-1 / IEC60601-1
FCC Class B
CE
VCCI
CCC
Features
User controls Power, Brightness
Mechanical Swivel / Tilt
Portrait /Landscape display
Utility OSD Lock
Factory Reset
SBC(Stable Brightness Control)
8 bit /10 bit
Language
Information

16
Appendix
Power Management
This system saves energy by switching your monitor into a low-power mode when it has not
been used for a certain period of time. Power Management system operates with a VESA
DPMS compliant video card installed in your computer. You use a software utility installed
on your computer to set up this feature.
Power Management Modes
State DPMS Standby DPMS Suspend DPMS Off
Horizontal Sync Active Inactive Active Inactive
Vertical Sync Active Active Inactive Inactive
Video Active Blanked Blanked Blanked
Power Indicator
Power
Consumption
This monitor is EPA ENERGY STAR compliant and NUTEK compliant when used with a
computer equipped with VESA DPMS functionality.
For energy conservation, turn your monitor OFF when you are not using it or when leaving it
unattended for long periods.
NOTE This monitor automatically returns to normal operation when horizontal and
vertical sync return. This occurs when you move the computer's mouse or press
a key on the keyboard.
Normal
Operation
65W Less than 6W Less than 6W Less than 6W
Green Red Red Flashing Red Flashing
(0.5 sec. interval) (1 sec. interval)
®

17
Appendix
Pin Assignments
DVI-D Connector
Pin Signal Assignment Pin Signal Assignment
1 T.M.D.S Data 2– 13 No Connection
2 T.M.D.S Data 2+ 14 5V Power
3 T.M.D.S Data 2 Shield 15 Ground (for 5V)
4 No Connection 16 Hot Plug Detect
5 No Connection 17 T.M.D.S Data 0–
6 DDC Clock 18 T.M.D.S Data 0+
7 DDC Data 19 T.M.D.S Data 0 Shield
8 No Connection 20 No Connection
9 T.M.D.S Data 1– 21 No Connection
10 T.M.D.S Data 1+ 22 T.M.D.S Clock Shield
11 T.M.D.S Data 1 Shield 23 T.M.D.S Clock +
12 No Connection 24 T.M.D.S Clock –

18
Appendix
Troubleshooting
No picture
• Make sure that the power cord is completely connected. (See page 8.)
• Make sure that the LCD Monitor and computer power switch are on.
• Check the signal cable connector for bent or pushed-in pins.
The display image is too light or too dark.
• Adjust the Brightness. (See page 10.)
Screen is blank and power indicator light is steady red or blinks every 0.5 or 1
seconds.
• Make sure that the signal cable is completely connected to the display card or
computer.
• Make sure that the display sources or computer are turned on. (See page 8.)
• The monitor is in the power management system.
• Press any key on the keyboard or move the computer's mouse.

19
Memo
