Kogan KAMN32F16LC User manual

32" CURVED GAMING MONITOR
1920 x 1080, 165Hz
KAMN32F16LC

2
Safety & Warnings 3
Components 4
Overview 5
Stand Assembly 6
VESA Mount 8
Connectivity 9
Operation 11
Cleaning & Care 17
Specifications 17
Notes 19

3
Ensure to read all instructions and warnings in this user guide prior to first use. Retain this
user guide for future reference.
•Do not position the monitor on unstable surfaces. If the monitor falls, it may lead to
damage and injuries to people around its vicinity.
•Do not place the monitor near heat sources (for example, heaters, stoves, fireplaces).
•Do not use the monitor in areas lacking adequate ventilation.
•Do not open the back panel of the monitor as it contains a high-voltage current even
when unplugged.
•Do not place heavy objects on the monitor, its power cord, or any other connected
cable.
•The back of this monitor is designed with ventilation holes. Do not cover or block them
as this may cause overheating and damage.
•Do not insert or spray anything into the vents of this monitor.
•Unplug the monitor if it will not be used for an extended period.
•Ensure the monitor is unplugged before cleaning.
•Do not use cleaning alcohol, ammonia-based liquids, or other harsh cleaners when
cleaning the monitor.
The terms HDMI and HDMI High-Definition Multimedia Interface,
and the HDMI Logo are trademarks or registered trademarks of
HDMI Licensing Administrator, Inc. in the United States, and other
countries.
SAFETY & WARNINGS

4
A Monitor (x1) B Stand stem (x1) C Stand base (x1)
D Headset hook (x1) E Cable guide (x1) F Stand plate (x1)
G Screw (x4) H VESA connector (x1) I DisplayPort cable (x1)
J Power cable (x1) K User guide (x1)
COMPONENTS

5
Ports
7 Power port
8 3.5mm headphone jack
9 HDMI 1 port
10 HDMI 2 port
11 DisplayPort port
1 Menu/enter button
2 Down button
3 Up button
4 Exit button
5 Power button
6 LED indicator
OVERVIEW

6
1. Open the packaging and remove the stand stem (B) and stand base (C). Using a
screwdriver (not supplied), secure the stand stem (B) to the stand base (C) with one
screw. Ensure all components are present before disposing of any packaging.
2.Slide and attach the cable guide (E) onto the bottom of the stand stem (B). Clip the
headset hook (D) onto the top of the stand stem (B).
3.Press the release button to remove the stand plate (F) from the packaging.
STAND ASSEMBLY
Stand stem
Screw
Stand base
Headset hook
Cable guide
Release button
Foam
Stand plate

7
4.Using a screwdriver, secure the stand plate (F) onto the stand stem (B) with two
screws.
5.Take out the monitor (A) and lay it on a flat surface.
6.Pull the release button on the stand plate (F) upwards and clamp the monitor (A)
onto the stand stem (B) and stand plate (F).
Note:
If this assembly needs to be removed, use a screwdriver to loosen the screws and
separate the components.
Release button

8
Release button
1. Open the packaging, and with the foam attached, take out the monitor (A) and place
it gently on a flat surface. Remove the foam covering the back of the monitor. If the
monitor is attached to the stand stem (B) or stand base (C), detach it.
2.Take out the stand stem (B) and stand base (C) from the packaging. Press the release
button to remove the stand plate (D).
3.Using a screwdriver, loosen the four screws on the back of the monitor.
4.Mount the monitor with the steps provided with the VESA mount. Ensure to use the
loosened screws from the previous steps to secure the monitor to the mount.
VESA MOUNT
Notes:
•The mounting hole distance for this monitor is 75 x 75mm.
•VESA mount and mounting accessories are not included.
Release button
Foam
Stand plate
Mount
(not supplied)

9
Power cable
Connect one end of the power cable into the power port on the monitor. Connect the other
end into a power socket.
Earphones
Plug in earphones (not supplied) into the 3.5mm headphone jack on the monitor.
Note: If audio devices are plugged into the monitor and computer, there will be no sound.
HDMI
To allow the monitor to receive HDMI signals from the computer, plug one end of an HDMI
cable (not supplied) into the monitor. Plug the other end of the cable into the HDMI output
port on your computer.
CONNECTIVITY
Power cable
Earphones (not supplied)
HDMI cable (not supplied)

10
DisplayPort
To allow the monitor to receive DisplayPort signals from your computer, plug in one end of
the provided DisplayPort cable into the DisplayPort port on the monitor. Plug the other end
of the cable into the DisplayPort output on the computer.
DisplayPort cable
