Wilbur Curtis 1970 Series User manual

Curtis Genesis
Coffee machine English
User Manual
01.03.03
Series 1970 33 4433 2930 04.2021

2User Manual Curtis Genesis
Safety instructions
WARNING, to reduce the risk of fire or electric shock,
do not remove cover (or back),
no user-serviceable parts inside,
repair should be done by authorized service personnel only.
(33 1453 5000)
WARNING
Risk of fire or electric shock.
Do not open.
The lightning flash with arrowhead symbol, within an
equilateral triangle, is intended to alert the user to the
presence of uninsulated “dangerous voltage” within the
product’s enclosure that may be of sufficient magnitude
to constitute arisk of fire or electric shock to persons.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in this
User Manual.
Do not use the machine if it is not working properly or if it
is damaged.
Never alter built-in safety devices.
Ensure that there is always areceptacle under the outlet
when dispensing hot beverages to avoid scalding.
Do not touch hot machine components.
Never reach into the coffee grinder.

3
User Manual Curtis Genesis
Before cleaning the operating panel, switch off the coffee
machine or use the CleanLock function in order to prevent
abeverage from being dispensing accidentally.
Never reach under the spouts while system cleaning.
Do not reach into the bean hopper or the brewing unit
opening when the Coffee Machine is switched on to avoid
bruising or crushing when handling moving parts.

4User Manual Curtis Genesis
Congratulations on the purchase of your
Curtiscoffee machine.
The Curtis Genesis coffee machine is a fully automatic
single-cup machine for fi lter coffee and hot water.
Follow the User Manual
> Read the User Manual carefully prior to use.
> Please refer to the User Manual, paying
special attention to the safety instructions
and Safety chapter.
> Follow the warning instructions on the coffee
machine.
> Ensure that the staff and all users have access
to the User Manual.
Hazard to life due
to electrical shock
• The voltage inside the coffee machine is
ahazard to life.
> Never open the housing.
> Never loosen the screws, and do not remove
any housing parts.
Conditions for use and installation
• In the event of failure to comply with
maintenance information and the specifi-
cations in the Technical Data chapter, no
liability is accepted for any resultant damage.
> Follow the User Manual.
> Maintenance and repairs may only be carried
out by the CurtisService, using original spare
parts.
CAUTION
Follow the User Manual signs
andsymbols
page 22
Follow the Safety chapter
wstarting on page 5
WARNING
Follow the Safety chapter
wstarting on page 5
IMPORTANT
Technical data
wstarting on page 82
Maintenance
wstarting on page 71
Introduction and General information

5
User Manual Curtis Genesis
Safety
1 Safety
Misuse
• Failure to follow the safety
instructions can result in death or
serious injury.
> Follow all the safety instructions.
1.1 General safety instructions
Hazards to the operator
At Curtis, safety is one of the most
essential product features. The
effectiveness of safety devices can only
be ensured if the following points are
observed:
> Read the User Manual carefully
prior to use.
> Do not touch hot machine
components.
> Do not use the coffee machine if
it is not working properly or if it is
damaged.
> Use the coffee machine only when
it is completely assembled.
WARNING
CAUTION

6User Manual Curtis Genesis
Safety
> Built-in safety devices must never
be altered.
> This device can be used by children
of age 8years or older while under
continuous supervision, as well as
by persons with reduced physical,
sensory, or mental capabilities or
lack of experience or knowledge,
once they have been instructed in
the safe use of the machine and the
risks associated with it.
> Children must not play with the
device.
> Cleaning and user maintenance
must not be performed by children.
A coffee machine poses apotential for
hazard when correctly used, despite the
use of safety devices. Please observe the
following instructions when using the
coffee machine to prevent injury and
health hazards:
CAUTION

7
User Manual Curtis Genesis
Safety
Hazard to life due
to electrical shock
• The voltage inside the coffee
machine is ahazard to life.
> Never open the housing.
> Never loosen the screws, and do not
remove any housing parts.
> Avoid damage to the power cord.
Donot kink or crush it.
> Never use adamaged power cord.
Adamaged power cord must be
replaced by the manufacturer or
aservice representative in order to
prevent ahazard.
> Never immerse the mains plug in
water or other liquids. Never pour
water or other liquids over the mains
plug. Always keeps the mains plug dry.
> Do not unplug the equipment’s plug
on the rear of the coffee machine
until the power cord has been
unplugged from the mains.
> The coffee machine must be
disconnected from the power supply
prior to maintenance and repair work.
Pull out the plug to do so. The person
performing the maintenance or repair
must always be able to check, with
aclear line of sight, that the power
supply has been disconnected.
WARNING

8User Manual Curtis Genesis
Safety
Burn hazard/scalding hazard
• When dispensing beverages, hot
liquid comes out of the spouts.
The adjacent surfaces and spouts
become hot.
• Hot water may escape from the
outlets in the heating-up phase.
> When dispensing beverages do not
reach beneath the spouts.
> Do not reach beneath the spouts
during the heating-up phase.
> Do not touch the spouts
immediately after dispensing.
> Always place an appropriate cup
under the spout before dispensing
abeverage.
CAUTION

9
User Manual Curtis Genesis
Safety
Risk of injury
• Long hair could become caught in
the grinder head and drawn into
the coffee machine.
> Always protect hair with ahairnet.
Bruising or crushing hazard/
risk of injury
• The coffee machine contains
moving parts that can cause finger
or hand injury.
• Closing the operating panel can
cause acrushing hazard.
> Always switch off the coffee
machine and unplug the mains plug
before reaching into the coffee
grinder or the opening of the
brewing unit.
> Carefully and gently close the
operating panel.
CAUTION
CAUTION

10 User Manual Curtis Genesis
Safety
Health hazard
> Only use products that are suitable
for consumption and for use with
the coffee machine.
> The bean hopper and the manual
insert may only be filled with
materials for the use intended.
Health hazard
• The cleaning tablets are irritants.
> Follow the protective measures
on the packaging of the cleaning
agent.
> Only put in acleaning tablet when
an appropriate message is displayed.
CAUTION
CAUTION

11
User Manual Curtis Genesis
Safety
Health hazard/
irritation and scalding hazard
• During cleaning, hot cleaning
solution and hot water run out of
the combi spout.
• Hot liquids can irritate the skin, and
the heat poses ascalding hazard.
• The drip tray may contain hot
liquids.
> Never reach under the spouts while
cleaning.
> Ensure that no one ever drinks the
cleaning solution.
> Be careful when moving the drip
tray.
Slipping hazard
• Fluids can be discharged from the
coffee machine if used improperly
or if errors occur. These fluids can
cause aslipping hazard.
> Regularly check the coffee machine
for leaks, and make sure no water is
coming out.
CAUTION
CAUTION

12 User Manual Curtis Genesis
Safety
1.2 Intended use
Misuse
• If the machine is used other than as
intended, this could lead to arisk of
injury.
> The coffee machine must only be
used as intended.
• The Curtis Genesis is designed to dispense beverages made with
coffee into suitable containers.
• The coffee beans must be suitable for processing in afully
automated coffee machine. The products must not be processed
after their expiration date.
• This device is intended for industrial and commercial use and
should be operated by experts or trained users in stores, offices,
restaurants, hotels, or similar places. It can also be used in
adomestic environment.
WARNING

13
User Manual Curtis Genesis
Safety
Installation location
• The device can be used as aself-service device if it is supervised
by trained personnel.
The machine must be set up so as to allow good visual access.
•The device must be placed and levelled on ahorizontal, sturdy,
water-resistant, and heatproof base.
• The device must not be cleaned using awater jet. The device
must be installed where it is protected against water spray.
• The device must not be located on asurface that is sprayed or
cleaned with awater hose, steam jet, steam cleaner, or similar
devices.
Water supply
• 3/8inch hose connector with water mains tap, and dirt filter
with 0.003in (0.08mm) mesh size, on-site. At least 29psi
(0.2MPa) (2bar) supply pressure at 0.53gal/min (2l/min).
Maximum 87psi (0.6MPa) (6bar).
Maximum inlet temperature 95°F (35°C).
• The set of hoses provided with the new coffee machine
and/or the new water filter must be used. Do not use the old
set of hoses.
Ambient temperature
• Ambient temperature 41°F to amaximum of 95°F
(+5°Cto amaximum +35°C)

14 User Manual Curtis Genesis
Safety
Usage
• The use of the device is subject to this User Manual. Any other
use or use that goes beyond the aforementioned is considered
incorrect use. The manufacturer shall not be liable for any
damage resulting from this.
• Under no circumstances may the Curtis Genesis be used to
dispense and heat liquids other than coffee or hot water
(beverages, cleaning).
Hygiene
• The coffee machine must be set up by the operator such that
care and maintenance can be performed without hindrance.
• In office/floor kitchen areas or similar self-service set-ups,
only staff instructed in operation of the coffee machine should
supervise the coffee machine. Trained personnel should carry
out care procedures and be available for questions regarding
use.

15
User Manual Curtis Genesis
Safety
1.3 Conditions for use and installation
Risk of fire and accidents
> The conditions for use and
installation listed in the “Technical
Data” chapter must be met.
> Before inserting the device plug,
ensure that the information on
the rating plate matches the mains
voltage for the installation.
WARNING
Technical data
wpage 82
Any necessary on-site preparatory work for
electricity, water, and drainage connections
at the customer‘s premises is to be arranged
by the machine owner/operator.
The work must be carried out by authorized
installation technicians in compliance
with general, country-specific and local
regulations. The CurtisService engineers
must only connect the coffee machine
to existing prepared connection points.
CurtisService is neither authorized nor
responsible for carrying out any on-site
installation work prior to connection.
NOTE
The device is to be installed to
comply with applicable federal,
state or local plumbing codes.
This includes sufficient backflow
preventers.

16 User Manual Curtis Genesis
Table of Contents
1 Safety 5
1.1 General safety instructions 5
1.2 Intended use 12
1.3 Conditions for use and installation 15
Table of Contents 16
2 Introduction 20
2.1 Parts of the coffee machine 20
“Ready to operate” display. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Glossary .........................................................................23
3 Operation 24
3.1 Operation safety instructions 24
3.2 Switch on the coffee machine 25
3.3 Coffee dispensing (order flow) 26
3.3.1 Blend selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
3.3.2 Size selection .....................................................................26
3.3.3 Filling volume adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
3.4 Hot water dispensing 26
3.5 Bean hopper lockable 27
3.6 Manual insert 27
3.7 Grounds container 28
3.8 Grounds disposal through the counter (optional) 28
3.9 Drip tray 29
3.10 Switch off the coffee machine 30
4 Software 32
4.1 Overview 32
Ready to operate ..................................................................32
Function bar “Ready to operate” display. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Main menu functions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Menu control pads .................................................................33
Messages on the display ............................................................33
4.2 Care 34
System cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
CleanLock ........................................................................34
Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
4.3 Beverages 35
General information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Cup volume, multiple brewing, anddispensingoption ....................................37
Change recipes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Select coffee grinder ...............................................................42
Text and picture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Change hot water recipes ...........................................................42
4.4 Operating options 43
Operating elements ................................................................43
Button layout .....................................................................44
PostSelection .....................................................................44
Nutritional information .............................................................44
Cancel beverage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Logo ............................................................................45
Table of Contents

17
User Manual Curtis Genesis
Table of Contents
4.5 Information 46
Last brewing cycle .................................................................46
Timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Service. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Care.............................................................................46
Water filter and descaling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Journal ..........................................................................46
4.6 Accounting 47
Counters .........................................................................47
Vending machines .................................................................47
External accounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
4.7 PIN rights 48
Cleaning PIN. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Settings PIN ......................................................................49
Accounting PIN. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Re-enter PIN. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
4.8 Timer 50
Timer overview and setting the timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Delete timer ......................................................................50
Daily timer overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Set timer switching times ...........................................................51
Timer state .......................................................................51
Button layout overview .............................................................51
Button layout .....................................................................51
Time/date .......................................................................52
Daylight saving time ...............................................................52
Time zone ........................................................................52
4.9 System 53
Progress display ...................................................................53
Display and illumination ............................................................53
Display brightness .................................................................53
Reduce brightness automatically .....................................................53
Touch calibration ..................................................................53
Display background ................................................................53
Water filter. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Temperature ......................................................................54
Grinding degree setting.............................................................55
Portioner .........................................................................55
Nutritional information .............................................................55
4.10 Language 55
4.11 USB 56
Load recipes ......................................................................56
Load beverage symbols .............................................................56
Save recipes ......................................................................56
Export counters ...................................................................56
HACCP export .....................................................................57
Data back-up .....................................................................57
Load data ........................................................................57
Load language ....................................................................57
Firmware update ..................................................................57

18 User Manual Curtis Genesis
Table of Contents
5 Care 58
5.1 Care safety instructions 58
5.2 Cleaning intervals overview 60
5.3 Cleaning programs 61
5.3.1 System cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
5.3.2 Brewer care. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
5.4 Manual cleaning 62
5.4.1 Clean the operating panel (CleanLock) .................................................62
5.4.2 Clean the grounds container (groundschute, optional) ...................................62
5.4.3 Clean the brewing unit .............................................................63
5.4.4 Clean the drip tray .................................................................66
5.4.5 Clean the housing .................................................................67
5.4.6 Clean the bean hopper. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
6 HACCP cleaning schedule 69
7 Maintenance and descaling 71
7.1 Maintenance 71
7.2 CurtisService 72
8 Messages and instructions 73
8.1 Messages for operation 73
8.2 Error messages and malfunctions 74
8.3 Errors without error message 76
9 Safety and warranty 77
9.1 Hazards to the coffee machine 77
9.2 Directives 79
9.3 Duties of the owner/operator 80
9.4 Warranty claims 81
Appendix: Technical data 82
Technical data for coffee machine 82
Appendix: Accessories and spare parts 86
Index 87

19
User Manual Curtis Genesis

20 User Manual Curtis Genesis
1
2
1
3
4
7
1312
10
11
6
5
9
8
Introduction | Parts of the coffee machine
2 Introduction
2.1 Parts of the coffee machine
“Ready to operate” display
Function bar
Header bar
