Williams Sound SoundPlus WIR RX15-2 Operator's manual

MAN 162B
WIR RX15-2 Receiver - 2.3 MHz or 2.8 MHz
Instructions For Use and Care
Safety Information
HEARING SAFETY:
CAUTION!
This product is designed to amplify sounds to a high volume level which could
potentially hearing damage if used improperly. To protect your hearing and the hearing
of others:
1. Make sure the volume is turned down before putting on the earphone or
headphone before adjusting the volume to a comfortable level.
2. Set the volume level at the minimum setting that you need to hear.
3. Do not allow children or other unauthorized persons to have access to this product.
BATTERY SAFETY & DISPOSAL
CAUTION!
Do not attempt to recharge disposable batteries, which may explode, release
dangerous chemicals, cause burns, or other serious harm to the user or product.
PACEMAKER SAFETY
CAUTION!
1. Before using this product with a pacemaker or other medical device, consult your
physician or the manufacturer of your pacemaker or other medical device.
2. If you have a pacemaker or other medical device, make sure that you are using this
product in accordance with safety guidelines established by your physician or the
pacemaker manufacturer.

MAN 162B
Operating Instructions
Battery Instructions
Two batteries (AAA Alkaline) must be placed into the battery compartment of the
headphone, and ensure that the positive and negative terminal on the batteries are
inserted correctly.
Operation Instructions
1. Slide the Power and channel switch of the headphone to the position A / B to
power on the headphone. The Power and channel indicator turns red when the
Power and channel switch slides to A and turns green when the Power and channel
switch slides to B. You can enjoy different varieties of audio with different channel
selections.
2. Adjust the volume of the headphone with the Volume control knob to desired level.
3. You can silence the audio to hear outside environment by holding the Monitor
button continuously and releasing the Monitor button to continue listening to audio
on selected channel.
4. Slide the Power switch of the headphone to position OFF to power off the
headphone when it is not in use.
5. Connect audio source and Audio input jack of the headphone with audio connect
line, the headphone is also used as regular wired stereo headphone without battery.
INFRARED
SENSOR
BATTERY
COVER
POWER/CHANNEL
SWITCH
POWER/
CHANNEL
INDICATOR
A127
AUDIO INPUT JACK
MONITOR/MUTE
BUTTON
VOLUME
KNOB
RIGHT EARPHONELEFT EARPHONE
MUTE

MAN 162B
Special Features
1. The WIR RX15-2 receiver headphone has an auto mute function: When the IR
transmitter turns off or the WIR RX15-2 does not receive the IR signal, the WIR
RX15-2 automatically turns off its power amplier and mutes.
2. The WIR RX15-2 receiver headphone has an auto power off function: After 3-5
minutes if the WIR RX15-2 does not receive the IR signal, the WIR RX15-2 will
automatically turn off its power and the power indicator will turn off. To reactivate
when the signal is present, the WIR RX15-2 power switch should be turned off and
then back on.
3. The WIR RX15-2 headphones are equipped with a moving coil type speaker and
are compatible with T-coil equipped hearing aids.
4. Audio input jack. Use optional cord to plug into audio source.
Specications
WIR RX15-2 Receiver
System Infrared light (850nm)
Reception 360 degrees
Carrier Frequency Channel A: 2.3MHz
Channel B: 2.8MHz
Modulation FM
Mode MONO
S/N > = 60dB
Distortion < 1.5% (1KHz sine wave)
Max Average SPL 118dB
Frequence Response 30-20,000Hz
Power (2) AAA Alkaline batteries
Power Indicator Red = 2.3MHz; Green = 2.8MHz
Battery Life Up to 80 hours
Current Draw Normal 12mA
Approvals CE, RoHS, WEEE

MAN 162B
Recycling Instructions
Help Williams Sound protect the environment! Please take the time to dispose of your
equipment properly.
Product Recycling:
Please do NOT dispose of your Williams Sound equipment in the household
trash. Please take the equipment to a electronics recycling center; OR, return
the product to the factory for proper disposal.
Battery Recycling:
Please do NOT dispose of used batteries in the household trash. Please take
the batteries to a retail or community collection point for recycling.
Approvals
This product meets approval standards established for:
RoHS WEEE

MAN 162B
Limited Warranty
Williams Sound products are engineered, designed and manufactured under carefully
controlled conditions to provide you with many years of reliable service. Williams
Sound warrants the Infrared Receiver against defects in materials and workmanship
for TWO (2) years. During the rst two years from the purchase date, we will promptly
repair or replace the Infrared Receiver.
Earphones, headphones, batteries, cables, carry cases, and all other accessory
products carry a 90-day warranty.
WILLIAMS SOUND HAS NO CONTROL OVER THE CONDITIONS UNDER WHICH
THIS PRODUCT IS USED. WILLIAMS SOUND, THEREFORE, DISCLAIMS ALL
WARRANTIES NOT SET FORTH ABOVE, BOTH EXPRESS AND IMPLIED, WITH
RESPECT TO THE INFRARED RECEIVER, INCLUDING BUT NOT LIMITED TO, ANY
IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR
PURPOSE. WILLIAMS SOUND SHALL NOT BE LIABLE TO ANY PERSON OR
ENTITY FOR ANY MEDICAL EXPENSES OR ANY DIRECT, INCIDENTAL OR
CONSEQUENTIAL DAMAGES CAUSED BY ANY USE, DEFECT, FAILURE OR
MALFUNCTION OF THE PRODUCT, WHETHER A CLAIM FOR SUCH DAMAGES
IS BASED UPON WARRANTY, CONTRACT, TORT OR OTHERWISE. THE SOLE
REMEDY FOR ANY DEFECT, FAILURE OR MALFUNCTION OF THE PRODUCT IS
REPLACEMENT OF THE PRODUCT. NO PERSON HAS ANY AUTHORITY TO BIND
WILLIAMS SOUND TO ANY REPRESENTATION OR WARRANTY WITH RESPECT TO
THE INFRARED RECEIVER. UNAUTHORIZED REPAIRS OR MODIFICATIONS WILL
VOID THE WARRANTY.
The exclusions and limitations set out above are not intended to, and should not be
construed so as to contravene mandatory provisions of applicable law. If any part
or term of this Disclaimer of Warranty is held to be illegal, unenforceable or in conict
with applicable law by a court of competent jurisdiction, the validity of the remaining
portions of this Disclaimer of Warranty shall not be affected, and all rights and
obligations shall be construed and enforced as if this Limited Warranty did not contain
the particular part or term held to be invalid.

Printed in the USA
©2012 Williams Sound, LLC
All Rights Reserved MAN162B
10300 Valley View Rd • Eden Prairie, MN 55344
800-328-6190 / 952-943-2252 • FAX: [phone]
www.williamssound.com
Customer Service
If you experience difculty with your system, call Toll-Free for Customer Assistance:
1-800-843-3544
If it is necessary to return the system for service, your Customer Service
Representative will give you a Return Authorization Number (RA) and shipping
instructions.
Pack the system carefully and send it to:
Williams Sound
Attn: Repair Dept.
10300 Valley View Rd
Eden Prairie, MN 55344
