Williams Sound WIR RX295 Assembly instructions

FRM 450D ©2005 Williams Sound Corp.
Williams Sound ®
Helping People Hear
WIR RX295 Receiver: 95 kHz, 250 kHz, Stereo
Instructions For Use & Care
SAFETY INFORMATION
Hearing Safety:
This product is designed to amplify
sounds to a high volume level which
could potentially cause hearing dam-
age if used improperly. To protect your
hearing and the hearing of others:
1. Make sure the volume is turned
down before putting on the ear-
phone or headphone before adjust-
ing the volume to a comfortable
level.
2. Set the volume level at the mini-
mum setting that you need to hear.
3. Do not allow children or other
unauthorized persons to have access
to this product.
BATTERY SAFETY & DISPOSAL
Do not attempt to recharge dispos-
able batteries, which may explode,
release dangerous chemicals, cause
burns, or other serious harm to the
user or product.
PACEMAKER SAFETY
1. Beforeusing this product with a pace-
maker or other medical device, con-
sult your physician or the manufactur-
er of your pacemaker or other medical
device.
2. If you have a pacemaker or other med-
ical device, make sure that you are using
this product in accordance with safety
guidelines established by your physician
or the pacemaker manufacturer.
CAUTION!
CAUTION!
CAUTION!

2
Williams Sound ®
Helping People Hear
RECYCLING INSTRUCTIONS
Help Williams Sound protect the environment! Please take the time to dispose of your
equipment properly.
Product Recycling:
Please do NOT dispose of your Williams Sound equipment in the household trash. Please
take the equipment to a electronics recycling center; OR, return the product to the factory
for proper disposal.
Battery Recycling:
Please do NOT dispose of used batteries in the household trash. Please take the batteries
to a retail or community collection point for recycling.
8/23/05

3
Williams Sound ®
Helping People Hear
Before you begin using the RX295 receiver, make sure the IR transmitter being used is
transmitting on 95 kHz or 250 kHz frequencies. Make sure the audio source is on, and the
receiver battery is fully charged (charging time 14 hours).
The RX295 Receiver has an automatic on/off function. When you put the receiver on, it turns
on. When you take the receiver off, it turns off. Use the 3-position selection switch to choose
from 95 kHz, stereo, or 250 kHz mode. Rotate the Volume Control to adjust the volume to a
comfortable listening level.
A dual detector infrared “eye” is located in the front of the receiver. Do not cover it up or
you will lose reception. Make sure the “SOUND PLUS” label is facing away from you
when you put the receiver on.
The RX295 Receiver should be charged when not in use.
Optional chargers: Single unit receiver charger, model CHG 950. Multi-battery (BAT
AP97A) 21 unit charger, model CHG 2100.
Sound Plus
®
BAT AP97A
Rechargeable NiMH Battery
Volume Control Knob
Frequency Selection
Switch: 95 kHz,
Stereo, 250 kHz
Front View
OPERATING INSTRUCTIONS

4
Williams Sound ®
Helping People Hear
Balance Control: Use a small screwdriver to adjust the loudness balance between the Left
and Right earphones.
Tone Control: Use a small screwdriver to adjust the tone between the Left and Right
earphone. Turn the screwdriver clockwise to lower the pitch, counterclockwise to increase
the pitch.
Ear Cushions: Replacement ear cushions are available from your Williams Sound dealer,
Part number EAR 031.
Specifications:
Weight: 2.1 oz (60 g) with batteries
Material and Color: ABS plastic, Black and Grey
Battery Type, Life: BAT AP97A NiMH Battery Pack, 6 hours
Modulation Frequency: 95 kHz or stereo or 250 kHz
Frequency Response: 200 Hz to 8 kHz, ± 5 dB
Signal to Noise Ratio: 60 dB at 10 m
Controls: Volume control thumbwheel; 3-position
selection switch (95 kHz, stereo, 250 kHz);
Screwdriver adjust balance control
Acoustic Output: 112 dB MAX SSPL90 with 2 cc coupler
Compatibility: Compatible with 95 kHz and 250 kHz IR
transmitters: WIR TX95, WIR TX800,
WIR TX850, WIR TX10
Power Switch: Built into receiver “arms”
On Indicator: Green LED
Ear pads: Uses EAR 031 foam cushions
Warranty: 5 years (1 year on battery)
Approvals: CE
BAL
L
L
-
-
R
-
–
+
R
–
+
Tone Controls Balance Control
Rear View

5
Williams Sound ®
Helping People Hear
LIMITED WARRANTY
Williams Sound products are engineered,
designed and manufactured under careful-
ly controlled conditions to provide you
with many years of reliable service.
Williams Sound warrants the WIR RX295
Receiver against defects in materials and
workmanship for FIVE (5) years. During
the first five years from the purchase date,
we will promptly repair or replace the
WIR RX295 Receiver.
Earphones, headphones, batteries, cables,
carry cases, and all other accessory prod-
ucts carry a 90-day warranty.
WILLIAMS SOUND HAS NO CON-
TROL OVER THE CONDITIONS
UNDER WHICH THIS PRODUCT IS
USED. WILLIAMS SOUND, THERE-
FORE, DISCLAIMS ALL WARRANTIES
NOT SET FORTH ABOVE, BOTH
EXPRESS AND IMPLIED, WITH
RESPECT TO THE WIR RX295
RECEIVER, INCLUDING BUT NOT
LIMITED TO, ANY IMPLIED WAR-
RANTY OF MERCHANTABILITY OR
FITNESS FOR A PARTICULAR PUR-
POSE. WILLIAMS SOUND SHALL
NOT BE LIABLE TO ANY PERSON OR
ENTITY FOR ANY MEDICAL
EXPENSES OR ANY DIRECT, INCI-
DENTAL OR CONSEQUENTIAL DAM-
AGES CAUSED BY ANY USE,
DEFECT,
FAILURE OR MALFUNCTION OF THE
PRODUCT, WHETHER A CLAIM FOR
SUCHDAMAGES IS BASED UPON
WARRANTY, CONTRACT, TORT OR
OTHERWISE. THE SOLE REMEDY
FOR ANY DEFECT, FAILURE OR MAL-
FUNCTION OF THE PRODUCT IS
REPLACEMENT OF THE PRODUCT.
NO PERSON HAS ANY AUTHORITY
TO BIND WILLIAMS SOUND TO ANY
REPRESENTATION OR WARRANTY
WITH RESPECT TO THE WIR RX295
RECEIVER. UNAUTHORIZED
REPAIRS OR MODIFICATIONS WILL
VOID THE WARRANTY.
The exclusions and limitations set out
above are not intended to, and should not
be construed so as to contravene mandatory
provisions of applicable law. If any part or
term of this Disclaimer of Warranty is held
to be illegal, unenforceable or in conflict
with applicable law by a court of compe-
tent jurisdiction, the validity of the remain-
ing portions of this Disclaimer of Warranty
shall not be affected, and all rights and
obligations shall be construed and enforced
as if this Limited Warranty did not contain
the particular part or term held to be
invalid.

Williams Sound Corp.
10321 West 70th St., Eden Prairie, MN 55344
U.S.A. 800-843-3544 / 952-943-2252 / FAX: [phone]
If you experience difficulty with your system, call Toll-Free for Customer Assistance:
1-800-843-3544
If it is necessary to return the system for service, your Customer Service Representative
will give you a Return Authorization Number (RA) and shipping instructions.
Pack the system carefully and send it to:
Williams Sound Corp.
Attn: Repair Dept.
10321 West 70th Street
Eden Prairie, MN 55344
FRM 450D ©2005 Williams Sound Corp.
