Williams Sound PERSONAL PA T35 Guide

PERSONAL PA®T35 Transmitter
Wireless FM Listening System
Manual and User Guide
Transmitter Model PPA T35
Optional Receiver Models PPA R37, PPA R35-8
MAN 160D

2
PERSONAL PA®T35 Transmitter
MAN 160D

3
PERSONAL PA®T35 Transmitter
MAN 160D
PERSONAL PA®T35 Transmitter
Manual and User Guide
Contents
System Overview ............................................................................................................................................................... 4
Quick Setup Instructions.................................................................................................................................................. 5
Detailed Installation Instructions.................................................................................................................................... 6
Select a Location ............................................................................................................................................................. 6
Installing the Antenna ....................................................................................................................................................... 6
Wiring and Connections ................................................................................................................................................... 7
Rear Panel ....................................................................................................................................................................... 7
Connecting the Power Supply.......................................................................................................................................... 7
Audio Source Connections............................................................................................................................................... 7
Choosing an Audio Source for the Hearing Impaired ........................................................................................................ 8
Avoiding Ground Loops.................................................................................................................................................... 9
Connecting to a Recording Device ................................................................................................................................... 9
Controls and Features .................................................................................................................................................... 10
Front Panel Controls....................................................................................................................................................... 10
LCD Screen Menus........................................................................................................................................................ 12
Application Presets ........................................................................................................................................................ 13
Bandwidth ..................................................................................................................................................................... 14
Frequency...................................................................................................................................................................... 14
Audio Source ................................................................................................................................................................. 15
High Pass Filter .............................................................................................................................................................. 15
Low Pass Filter............................................................................................................................................................... 16
Compressor Slope ......................................................................................................................................................... 16
Compressor Gain........................................................................................................................................................... 17
RF Output ...................................................................................................................................................................... 18
Safety Information ........................................................................................................................................................... 19
Recycling Instructions .................................................................................................................................................... 19
Receiver Instructions ...................................................................................................................................................... 20
Receiver Management ................................................................................................................................................... 23
Battery Information......................................................................................................................................................... 23
Trouble-Shooting Guide.................................................................................................................................................. 24
Warranty............................................................................................................................................................................. 27
System Specications .................................................................................................................................................... 28

4
PERSONAL PA®T35 Transmitter
MAN 160D
LOUDSPEAKER
LINE-LEVEL
OUTPUT
SOUND SYSTEM
AMPLIFIER
MICROPHONE
PPA T35 TRANSMITTER FM RECEIVERS
A100
System Overview
The PPA T35 is an FM Wide-Band / Narrow-Band transmitter operating in the 72-76MHz bandwidth. Compatible Williams
Sound receivers include PPA R37, PPA R35-8 and the PPA R1600 remote speaker.
Developed for hearing assistance in places of public access, the PPA T35 is designed for those who need help overcoming
background noise, reverberation, or distance from the sound source. It includes a complete audio processor optimized for the
needs of hearing impaired persons and is easily integrated with your existing sound system. The PPA T35 can also be used with
a microphone as a stand-alone system.
Your PPA T35 transmitter operates just like an FM radio station. The transmitter takes audio directly from a microphone or sound
system. This audio is then broadcast over an FM radio signal. FM radios can be worn by listeners or AC powered amplied
speaker with built in radio can be utilized as needed. The broadcast can be received up to 1000ft from the transmitter *. This
allows listeners to sit anywhere in the area and listen to the broadcast at the level they need without disturbing others around
them.
Please read through this manual carefully. It includes important setup procedures and guidelines for proper operation. If at any
time you are having problems with this product, please contact Williams Sound toll free for assistance: 800-843-3544.
NOTE: FCC regulations, section 15.21, requires the user to comply with the rules of transmitter operation. Any changes or
modications made by the user not expressly approved for compliance may result in the loss of all privileges and
authority to operate the equipment.
*Range is dependant upon the environment.
Figure 1: Overall System Diagram

5
PERSONAL PA®T35 Transmitter
MAN 160D
Quick Setup Instructions
1. Position the PPA T35 transmitter near the sound system or mixer from which it will receive audio.
2. Install the ANT 025 whip antenna. Gently thread the ANT 025 onto the stud recessed in the hole on the top of the transmitter.
The antenna length must NOT exceed 28 inches when fully extended. It was found during test that the antenna length, when
the length was greater than 28 inches, the device failed the radiated emissions. It FAILED with the longer length.
3. Connect the power supply to the “Power In” connector (gure 5, page 7) located in the back of the T35. Press in the power
button on the front of the T35. The “On Air” green LED indicator should illuminate. If not, go back and check the power
connections.
4. Select an application. The T35 has three pre-congured Application Presets to choose from: Hearing Assist, Music and Voice.
The performance of the T35 is optimized for each selected application. Using the menu control buttons on the front of the
T35 (Figure 2), press the “ v ” button to access the “Application Presets” LCD screen. Press the “+” and “-” menu buttons to
alternate between Hearing Assist, Music and Voice selection. When the desired Application Preset is displayed, press the “Set”
button to save the change into memory.
5. Congure the T35 for the appropriate audio source. Using the menu control buttons on the front of the T35 (Figure 2), press the
“ v ” button to access the “Audio Source” LCD screen. Using the “+” and “-” menu buttons (Figure 2), choose between MIC,
SIMPLEX-MIC, or LINE. When the desired audio input is displayed, press the “Set” button to save the change into memory.
Lastly, connect the audio source to the audio input jack in the rear of the T35 transmitter.
6. With the audio source playing, adjust the Audio Level control on the T35 so that the green “0 dB” LED generally lights and the
red “+9 dB” LED lights occasionally: Press the Audio Level “+” button to increase the audio level in .5dB steps. Press the Audio
Level “-” button to decrease the audio level in .5dB steps. See Figure 2.
7. The T35 is shipped from the factory in wideband mode with the frequency set to 72.900 MHz. To change the frequency or bandwidth
on the T35, refer to the instructions on page 14.
8. Listen with an FM receiver (see pages 20-21 for compatible Williams Sound receivers). Install the batteries, plug in the
earphone, turn on the receiver and walk around the listening area. The signal should be clear and quite loud when the volume is
turned up.
IMPORTANT: The FM receiver being used with the T35 transmitter will need to be on the same frequency and
bandwidth as the transmitter. To change receiver channels, see pages 20-21.
Please read through this manual carefully for detailed instructions and setup procedures.
Figure 2: LCD Menu and Audio Input Controls
AUDIO INPUT
CONTROLS
LCD MENU
CONTROL BUTTONS
–
+
V
–
–
+
+
V
Set
A101

6
PERSONAL PA®T35 Transmitter
MAN 160D
Remote Antenna:
FCC rules allow only the use of antennas provided by Williams Sound. To use a remote antenna supplied by Williams Sound, the
antenna cap may be removed by turning it counter-clockwise with a pliers or wrench. Please call customer service 800.843.3544
if you have any questions.
The external antenna impedance is 75 Ohms.
Setting up the PPA T35 - Detailed Instructions
Select a Location
The transmitter is usually located near the sound system amplier or mixer for easy access to an audio output signal. Position the
transmitter on a level surface. It should be free from metallic objects that might interfere with the antenna signal.
For permanent installation, the PPA T35 transmitter can be rack mounted. Use the Williams Sound RPK 005 or RPK 006 rack
mount kits. Make sure there is good electrical contact between the transmitter chassis and the rack cabinet.
Install the ANT 025 Whip Antenna
NOTE: If the T35 is going to be rack mounted, you will not be able to install the ANT 025 whip antenna. For rack mounting,
consider installing a remote antenna (see following section).
The PPA T35 is shipped standard with a single ANT 025 whip antenna. The ANT 025 threads on to a stud recessed in a hole
on the top of the transmitter. Screw the antenna clockwise until the connection is secure (Figure 3). Do not use excessive force
to tighten the antenna. The antenna length must NOT exceed 28 inches when fully extended. It was found during test that the
antenna length, when the length was greater than 28 inches, the device failed the radiated emissions. It FAILED with the longer
length.
ANT 025 ANTENNA
(INCLUDED)
ANT 005
COAXIAL ANTENNA
OR
ANT 024 WALL MOUNT
DIPOLE ANTENNA
(OPTIONAL)
A102
Figure 3: Installing the ANT 025 Antenna (rear view)

7
PERSONAL PA®T35 Transmitter
MAN 160D
NOTE: The T35 will not be activated until the power button on the front of the T35 is pressed into the “on” position.
Audio Source Connections
The T35 transmitter will accept the following audio sources:
1. Balanced Microphone on a 3-pin (XLR) connector without simplex power.
2. Balanced Microphone with 12 volt simplex power (DIN 45596) on a 3-pin (XLR) connector.
3. Balanced/Unbalanced microphone without power on 1/4 inch jack
4. Balanced/Unbalanced Line on a 3-pin (XLR) connector.
5. Balanced/Unbalanced Line on 1/4 inch jack.
WARNING:
The T35 is not designed to accept 70 volt speaker signals! This may result in damage to your system. The
sound source should come directly from the system mixer or amplier as an unprocessed signal.
IMPORTANT: When a suitable audio source has been selected, you MUST congure the audio source controls on the
front panel of the T35.
There are three possible selections to choose from: MIC, SIMPLEX-MIC and LINE.
SEE PAGE 15 FOR AUDIO SOURCE CONTROLS. After the audio source selection has been made, plug in the
appropriate audio source into the “Audio Input” jack in the rear of the T35.
POWER
SUPPLY
A103
Figure 4: Rear View of T35
Wiring and Connections
Power Supply Connection for U.S. Application
Connect the TFP 016 power supply to the “Power In” jack located on the rear of the T35 transmitter.

8
PERSONAL PA®T35 Transmitter
MAN 160D
BALANCED LINE USING 1/4" CONNECTOR
IN PHASE
A106
UNBALANCED LINE USING 1/4" CONNECTOR
A107
4.7 K
4.7 K
SOURCE A
SOURCE B
CONNECTING TO A MULTI-CHANNEL OR STEREO SOURCE
A109
BALANCED LINE USING 3–PIN CONNECTOR
IN PHASE
1 2
3
3 PIN CONNECTOR
A108
IN PHASE
FROM MICROPHONE
1 2
3
3 PIN CONNECTOR
LOW IMPEDANCE MICROPHONE
A104 UNBALANCED LINE USING 3–PIN CONNECTOR
1 2
3
3 PIN CONNECTOR
A105
Figure 5: Audio Source Connectors
Multi–Channel Sources
By constructing a simple resistive mixer, stereo (or 3 channel) sources can be connected to the T35. Additional channels can be
accommodated by adding a resistor for each source. Necessary resistors can be obtained from Williams Sound (Part Number
RFC 472) or from any local electronics parts supplier. See Figure 5.
Selecting an Audio source Appropriate for Hearing Impaired Listeners
If the T35 is going to be used specically for the accommodation of hearing impaired listeners, we recommend following these
general guidelines:
The PPA T35 transmits audio with excellent delity. Therefore, the audio source signal should be of the highest audio quality
and not subject to a compressor, limiter, reverberation, or other signal processing equipment. The T35 has an effective audio
processor. If compression is desired in the audio, refer to page 16-17 for features and controls. Excessive compression is not
helpful to the hearing impaired and can contribute to excessive noise in the receiver outputs.
The T35 audio source signal is usually connected to a mixer’s “line output” signal which is behind the mixer’s parametric equalizers
but ahead of any equalization used for house loudspeakers.
If audio delay is available for use in large auditoriums, it’s usually best to use it. Because radio signals travel faster than sound,
delaying the transmitted audio so that an average listener (in the middle of the listening area) hears the transmitted audio a few
milliseconds after audio from the main sound reinforcement system speaker is helpful. This will also help audience members who
lip read.

9
PERSONAL PA®T35 Transmitter
MAN 160D
Avoiding Hum in the Audio (as a Result of a Ground Loop)
A hum created by a ground loop can often be eliminated by connecting a capacitor in series with the audio line shield to the
transmitter’s ground. This method also maintains good RF shielding. Determining the effectiveness of this method for your
installation usually requires some experimentation. See Figure 6.
IN PHASE
1 2
3
3-PIN
CONNECTOR
BREAKING A GROUND LOOP WHEN
CONNECTING TO A UNBALANCED LINE
BREAKING A GROUND LOOP WHEN
CONNECTING TO A BALANCED LINE
.01 uF CERAMIC DISC
CAPACITOR .01 uF CERAMIC
DISC CAPACITOR
A110
Figure 6: Connecting to a Balance/Unbalanced Line
Figure 7: Audio Line Output
PPA T35 RECORDING DEVICE
AUDIO LINE OUT AUDIO LINE IN
A111
Connecting the T35 to a Recording Device
Use the Audio Line Out jack for monitoring, recording, or routing processed audio to another sound system.

10
PERSONAL PA®T35 Transmitter
MAN 160D
Power Button
Push-button switch turns the transmitter on or off. The wall mounted power supply stays on at all times.
On Air Indicator
Indicates when power is on and radio frequency is transmitting.
Audio Level Indicator
The bar graph indicator shows audio level in 3dB steps at the input of the audio level processing circuit. The indicator is peak
responding and is calibrated so that optimum level is reached when the 0dB LED generally lights and +9dB lights occasionally.
Use the Audio Level controls to set the audio levels.
Input Overload Indicator
A red LED indicator will illuminate each time the audio signal exceeds the capacity of the input circuit. (The source of the audio
coming in to the T35 needs to be adjusted to correct this.)
NOTE: Direct Access Buttons (Figure 8) allow the user to change congurations on the transmitter immediately without having
to scroll through the menu controls (Page 12). When a direct access button is pressed, the change is immediately
displayed on the LCD Menu Display.
Audio Level (direct access)
Pressing or holding down the Audio Level “+” button increases the audio input level in .5dB steps. Pressing or holding down
the audio level “-” button decreases the audio input level in .5dB steps. Holding down an Audio Level button continuously will
automatically increase or decrease the audio input in .5dB increments until the button is released or the upper and lower limits are
reached. Each action is immediately displayed on the LCD default display (Figure 9).
POWER
BUTTON
DIRECT ACCESS
BUTTONS
DIRECT ACCESS
BUTTONS
LCD MENU
DISPLAY
MENU CONTROL
BUTTONS
–
+
V
–
–
+
+
V
Set
A112
Figure 8: PPA T35 Front View
Controls & Features

11
PERSONAL PA®T35 Transmitter
MAN 160D
OPERATING
FREQUENCY
AUDIO
INPUT LEVEL
MENU SCREEN
NUMBER
TRANSMITTING
POWER
MENU
LOCK ICON
APPLICATION
PRESET
A113
Phones Jack and Source Button
A headset plugged into the “Phones” jack allows monitoring either the audio output as it is processed and transmitted by the
T35 or the T35 audio input before it gets processed. By default, the phone jack audio is set for “TRANSMITTED” audio. Pressing
and holding down the “Source” button will select “INPUT” audio. The setting is immediately displayed on the LCD menu screen.
Releasing the “Source” button will immediately return the selection to “TRANSMITTED” audio. If there is no further action by the
user, after ve seconds, the LCD menu screen will return to the default display (Figure 9).
Headphone Volume (Direct Access)
The headphone level can be increased or decreased by using the “Volume” direct access buttons next to the headphone jack.
Pressing or holding down the volume control “+” button increases the headphone level in +0.5dB steps. Pressing or holding down
the volume control “-” button decreases the headphones level in -0.5dB steps. Holding down a Volume button continuously will
automatically increase/decrease the input level in .5dB increments until the button is released or the limit is reached. Each action
is immediately displayed on the LCD menu screen as the buttons are pressed. If there is no further action by the user, after ve
seconds, the LCD menu screen will return to the default display (Figure 9).
LCD Menu Display
The LCD display is used with the menu control buttons for conguring and setting up the T35. When the power of the unit is
rst turned on, the LCD screen displays a “Williams Sound” start-up screen. (NOTE: If the transmitter is not fully functional,
the transmitter will stay on the start-up screen and the transmitter will not transmit.) After seven seconds, the “On Air” LED will
illuminate and the default screen will be displayed (Figure 9). The T35 is now fully operational. If the “On Air” indicator does not
illuminate, go back and double-check the connections (page 7). Make sure the power supply is properly installed, and the power
button is in the “on” position.
Figure 9: Default Display Menu
The default display will always show the following information: Operating Frequency, Bandwidth, Audio Input Level,
Transmitting Power and Application Preset. In some cases the Menu Lock Icon will be displayed. This indicates that the
menu screens (page 12) are locked, which prevents any functions from being accidentally changed (except for the direct
access functions). To lock or unlock the menu screens, press and hold the SET button on the front of the T35 for ve
seconds.
NOTE: This will only work from the default display.

12
PERSONAL PA®T35 Transmitter
MAN 160D
DEFAULT
AUDIO SOURCE
HIGH PASS FILTER
LOW PASS FILTER
COMPRESSOR SLOPE
COMPRESSOR GAIN
RF OUTPUT
FREQUENCY
BANDWIDTH
APPLICATION PRESETS
LCD MENU
CONTROL BUTTONS
–
+
V
–
–
+
+
V
Set
A114
Figure 10: Selecting an LCD menu
LCD Screen Menus (Quick Reference)
The rst screen (M0) gives important overall system settings. The following nine menu screens (M1-M9) are used to congure and
setup the T35. To make a screen selection, navigate to the desired LCD menu by pressing the “ v ” (down) button on the front of
the T35. Press the “Set” button to save the change into memory. Any changes not “set” will be lost. After 30 seconds of inactivity,
the LCD will return to the default display.

13
PERSONAL PA®T35 Transmitter
MAN 160D
LCD Screen Menus (Detailed)
Application Presets (M1)
The Application Presets screen allows the user to quickly and easily congure the T35 for common applications. In some cases,
the Application Presets will be the only setup needed for properly conguring the T35 transmitter.
There are three Application Presets to choose from: Hearing Assist, Music and Voice. When one of these selections is “set,”
the performance of the T35 is immediately optimized for the needs of that application (an adjustment is automatically made to
the Low/High Pass Filter, and Compressor Slope control). Refer to the chart below for a comparison of the Application Preset
congurations.
By default, the T35 is shipped in the Music mode. For music, concerts, and other applications where the highest audio quality is
desirable, Music is the recommended mode of operation. For hearing assistance applications, or applications where the message
is critical for listening, Hearing Assist is the recommended mode of operation. For speaking and other voice applications, Voice
is the preferred mode of operation.
To select an Application Preset:
1. Press the “ v ” menu button (Figure 11) to access the LCD “Application Presets” screen (M1).
2. Press the “+” or “-” menu buttons to select between Hearing Assist, Music and Voice.
3. When the desired Application Preset is displayed, press the “Set” button to save the change
into memory.
No additional action is necessary. After 30 seconds of inactivity, the LCD screen will return to the
default screen, where the selected Application Preset will be displayed.
NOTE: After an Application Preset has been selected, any of the congurations can manually
be changed if necessary.
Application Preset Conguration Table
RF Output = Full Power, Compressor Gain = Normal
Wide Band Narrow Band
Parameters: Hearing Assist Music Voice Hearing Assist Music Voice
Low Pass Filter 8.0 kHz 16 kHz 6.3 kHz 6.3 kHz 6.3 kHz 6.3 kHz
High Pass Filter 500 Hz 22 Hz 125 Hz 500 Hz 22 Hz 125 Hz
Compressor Slope 2:1 1:1 1:1 2:1 1:1 1:1
The Application Presets are designed to take the guess work out of common setup procedures. There will be times when manual
adjustments will need to be made (i.e. to select a different operating frequency, bandwidth, to adjust the compression ratio, etc.).
For these requirements, please read through the manual and follow the corresponding menu control instructions. If you are unsure
of how these changes will impact the performance of the T35 transmitter, or how it will affect your hearing assistance application,
please contact Williams Sound for assistance at 800-843-3544.
Figure 11: LCD Menu Controls
V
– +
V
Set
A115

14
PERSONAL PA®T35 Transmitter
MAN 160D
Bandwidth (M2)
The default LCD menu screen (as shown on page 11, Figure 9) will always display the user selected bandwidth as “Wideband” or
“Narrowband.” The T35 is shipped from the factory in Wideband mode. First determine the bandwidth of the associated receiver,
then set the T35 to that bandwidth:
1. Press the “ v ” menu button (Figure 11) to access the LCD “Bandwidth” (M2) screen.
2. Press the “+” or “-” menu buttons to select between Narrowband and Wideband.
3. When the desired bandwidth is displayed, press the “Set” button to save the change into memory.
No additional action is necessary. After 30 seconds of inactivity, the LCD screen will return to the default screen, where the
selected bandwidth will be displayed.
Frequency (M3)
First determine the bandwidth and frequency of the associated receiver, then set the T35 to that bandwidth (see
above) and frequency:
Available Frequencies:
If the wideband operation is selected, 17 wideband frequencies are available:
72.100 (CH A), 72.300 (CH B), 72.500 (CH C), 72.700 (CH D), 72.900 (CH E), 74.700 (CH I), 75.300 (CH J), 75.500 (CH F),
75.700 (CH G), 75.900 MHz (CH H), 72.200 (CH K), 72.400 (CH N), 72.600 (CH 0), 72.800 (CH P), 75.400 (CH R), 75.600 (CH S),
75.800 (CH T).
If the narrowband operation is selected, 77 narrowband frequencies are available:
72.025, 72.050, 72.075, 72.100, 72.125, 72.150, 72.175, 72.200, 72.225, 72.250, 72.275, 72.300, 72.325, 72.350, 72.375, 72.400,
72.425, 72.450, 72.475, 72.500, 72.525, 72.550, 72.575, 72.600, 72.625, 72.650, 72.675, 72.700, 72.725, 72.750, 72.775, 72.800,
72.825, 72.850, 72.875, 72.900, 72.925, 72.950, 72.975, 74.625, 74.650, 74.675, 74.700, 74.725, 74.750, 74.775, 75.225, 75.250,
75.275, 75.300, 75.325, 75.350, 75.375, 75.400, 75.425, 75.450, 75.475, 75.500, 75.525, 75.550, 75.575, 75.600, 75.625, 75.650,
75.675, 75.700, 75.725, 75.750, 75.775, 75.800, 75.825, 75.850, 75.875, 75.900, 75.925, 75.950, and 75.975 MHz.
The T35 is shipped from the factory with the frequency pre-set to wideband (CH E) 72.900 MHz.
To change the frequency:
1. Press the “ v ” menu button to select the LCD “Frequency” (M3) screen.
2. To increase the frequency, press the “+” menu button. To decrease the frequency,
press the “-” menu button.
3. Holding down the “+” or “-” menu buttons will change the frequency automatically until the highest or lowest available
frequency has been met.
When the desired frequency is displayed, press the “Set” button to save the change into memory.
No additional action is necessary. A new adjustment may now be made, or after 30 seconds of inactivity, the LCD screen will
return to the default screen, where the selected frequency will
be displayed.
NOTE: The T35 will not broadcast on the newly selected frequency until the “set” button has been pressed.
REMINDER: If the lock icon is displayed on the default display, the menu screens are locked, and you will not be
able to make changes. To unlock the menu screens, refer to the instructions on page 11.

15
PERSONAL PA®T35 Transmitter
MAN 160D
Audio Source (M4)
The Audio Source control menu is used to congure the T35 for a proper audio source connection. The transmitter will accept the
following audio sources:
1. Balanced Microphone on a 3-pin (XLR) connector without simplex power.
2. Balanced Microphone with 12 volt simplex power (DIN 45596) on a 3-pin (XLR)�connector.
3. Balanced/Unbalanced microphone without power on 1/4 inch jack
4. Balanced/Unbalanced Line on a 3-pin (XLR)�connector.
5. Balanced/Unbalanced Line on 1/4 inch jack.
The Audio Source menu has three possible selections to choose from: MIC, SIMPLEX-MIC, or LINE.
To select the audio input:
1. Press the “ v ” menu button (Figure 11) to access the LCD “Audio Source” (M4) screen.
2. Press the “+” or “-” menu buttons to select between MIC, SIMPLEX-MIC, or LINE.
3. When the desired audio input is displayed, press the “Set” button to save the change into memory.
No additional action is necessary. After 30 seconds of inactivity, the LCD screen will return to the
default display.
High Pass Filter (M5)
The high pass lter will help to remove low frequency “noise” from the transmitted audio signal. This is typically used when there is
room noise, a line hum, or breath accents picked up from an improperly
installed microphone.
To select a High Pass Filter cutoff frequency:
1. Press the down “ v ” menu button (Figure 11) to select the LCD “High Pass Filter” (M5) screen.
2. Press the “+” menu button to increase the cutoff frequency. Each time the “+” button is pressed, the cutoff frequency will
be raised by 1/2 octave. This can be repeated until the cutoff frequency reaches the maximum 700 Hz.
Press the “-” menu button to decrease the cutoff frequency. Each time the “-” button is pressed, the cutoff frequency will
be lowered by 1/2 octave. This can be repeated until the cutoff frequency
reaches the minimum 22 Hz.
3. When the desired cutoff frequency is displayed, press the “Set” button to save the change into memory.
No additional action is necessary. After 30 seconds of inactivity, the LCD screen will return to the default display.
IMPORTANT: Listen to the transmitted audio through the headphone jack, especially
when deciding on an appropriate high pass lter. This is a good way to ensure the
listening audience is going to receive the highest audio quality.

16
PERSONAL PA®T35 Transmitter
MAN 160D
Low Pass Filter (M6)
The low pass lter will help to remove high frequency “noise” from the transmitted audio signal. This is typically used when there is
a hiss in the audio line as a result of room noise, speech sibilants, or other high frequency unpleasantries.
To select a Low Pass Filter cutoff frequency:
1. Press the down “ v ” menu button (Figure 11) to select the LCD “Low Pass Filter” (M6) screen.
2. Press the “+” menu button to increase the cutoff frequency selection. The cutoff frequency can be increased to a
maximum of 16.0 kHz.
Press the “-” menu button to decrease the cutoff frequency selection. The cutoff frequency can be decreased to a minimum of
3.2 kHz.
3. When the desired cutoff frequency is displayed, press the “Set” button to save the change into memory.
No additional action is necessary. After 30 seconds of inactivity, the LCD screen will return to the
default display.
Compressor Slope (M7)
Compression is typically used for voice and hearing assistance applications. It reduces the dynamic range: For a listener who has
difculty hearing the quiet sounds of an audio broadcast, compression will boost the quiet sounds to louder listening levels. For
listening to music programs, concerts, etc., lower compression ratios or no compression is generally used.
The Compressor Slope has the following selectable compression ratios:1:1 and 2:1
NOTE: The T35 is shipped from the factory at a 1:1 compression ratio (no compression).
To select a compression ratio:
1. Press the “ v ” menu button (Figure 11) to select the LCD “Compressor Slope” (M7) screen.
2. Press the “+” menu button to increase the compression to 2:1. This produces generally loud out put, even at very low
audio level signals.
Press the left “-” menu button to decrease the compression to 1:1, which is no compression.
3. When the desired compression ratio is displayed, press the “Set” button to save the change into memory. No additional
action is necessary.
NOTE: The installer of the T35 needs to take care in using compression, because some hearing impaired people cannot
tolerate as loud of a sound as those with normal hearing.
IMPORTANT: Listen to the transmitted audio through the headphone jack, especially
when deciding on an appropriate high pass lter. This is a good way to ensure the
listening audience is going to receive the highest audio quality.

17
PERSONAL PA®T35 Transmitter
MAN 160D
Compressor Gain (M8)
The T35 has two selectable modes of compressor gain: Normal and Reduced. For applications such as music and voice, where
high audio quality is desirable, Reduced is the recommended mode of operation. Reduced compression gain minimizes the
amount of low input level boost and alteration in the sound which compression can cause.
For hearing assistance or applications where the transmitting message is critical for listening, the T35 can be set to Normal
Compression gain. Normal compression gain boosts the “soft” audio sounds for a more understandable, consistent delivery.
This may be appropriate for applications where the listening audience has moderate to severe hearing loss. Compression
is generally not desirable for applications such as music, concerts, etc. In this case, compression can be turned off by setting the
compression “slope” to 1:1.
NOTE: The T35 is shipped from the factory in the Reduced mode.
To select Reduced or Normal Compression:
1. Press the “ v ” menu button (Figure 11) to access the LCD “Compressor Gain” (M8) screen.
2. Press the “+” or “-” menu buttons to select between Reduced and Normal compressor gain.
3. When the desired compressor gain is displayed, press the “Set” button to save the change into memory.
No additional action is necessary. After 30 seconds of inactivity, the LCD screen will return to the
default display.
NOTE: The installer must take care in using compression. Compression may contribute to excessive noise in the listener’s
receivers.
IMPORTANT: Listen to the transmitted audio through the headphone jack, especially
when deciding on an appropriate high pass lter. This is a good way to ensure the
listening audience is going to receive the highest audio quality.

18
PERSONAL PA®T35 Transmitter
MAN 160D
RF Output (M9)
The T35 has three selectable transmitter power levels: FULL, MEDIUM, LOW POWER, or OFF AIR. By default the T35 is set to
“Full” power mode. For general listening applications, FULL power is the preferred mode of operation. “Full power” provides the
T35 with an operating range of up to 1000 ft.
For special listening applications, it may be desirable to reduce the overall operating range on the T35 if:
1) The audio transmission is to be contained to a “smaller” listening area; 2) The signal is too strong and it is overloading the
receiver; or 3) Multiple T35 transmitters are used in adjacent classrooms where the FM signals overlap each other. In these
cases, the power level on the T35 can be reduced to MEDIUM or LOW. The RF output may be set to OFF AIR (no power) to help
troubleshoot interfering or overlapping RF signals.
To select a power level:
1. Press the “ v ” menu button (Figure 12) to access the “RF Output” (M9) screen.
2. Press the “+” and “-” menu button to select between: FULL POWER, MEDIUM POWER, LOW POWER and OFF AIR.
3. When the desired power level is displayed, press the “Set” button to save the change into memory.
No additional action is necessary. After 30 seconds of inactivity, the LCD screen will return to the default display, where the
selected power level will be displayed.

19
PERSONAL PA®T35 Transmitter
MAN 160D
Receiver Safety Information
HEARING SAFETY
CAUTION!
This product is designed to amplify sounds to a high volume level which could potentially cause hearing damage if used
improperly. To protect your hearing and the
hearing of others:
1. Make sure the volume is turned down before putting on the earphone or headphone before adjusting the volume to a
comfortable level.
2. Set the volume level at the minimum setting that you need to hear.
3. If you experience feedback (a squealing or howling sound), reduce the volume setting and move the microphone away from the
earphone or headphone.
4. Do not allow children or other unauthorized persons to have access to this product.
BATTERY SAFETY AND DISPOSAL
CAUTION!
This product may be supplied with alkaline batteries. Do not attempt to recharge alkaline batteries, which may explode, release
dangerous chemicals, cause burns, or other serious harm to the user or product.
PACEMAKER SAFETY
CAUTION!
1. Before using this product with a pacemaker or other medical device, consult your physician or the manufacturer of your
pacemaker or other medical device.
2. If you have a pacemaker or other medical device, make sure that you are using this product in accordance with safety
guidelines established by your physician or the pacemaker manufacturer.
Recycling Instructions
Help Williams Sound protect the environment! Please take the time to dispose of your equipment properly.
Product Recycling:
Please do NOT dispose of your Williams Sound equipment in the household trash. Please take the equipment to a
electronics recycling center; OR return the product to the factory for proper disposal.
Battery Recycling:
Please do NOT dispose of used batteries in the household trash. Please take the batteries to a retail or community
collection point for recycling.

20
PERSONAL PA®T35 Transmitter
MAN 160D
Operating the receiver
1. Insert two (2) AA batteries ensuring correct polarity. If rechargeable NiMH batteries are to be used with the receiver and a
Williams Sound charger, make sure the Alkaline/NiMH switch inside the battery compartment is set to NiMH before charging.
See FIG 13.
2. Insert the headphone, earphone or neckloop into the stereo output jack.
3. Turn receiver on by turning up the volume control. The green power LED will turn on.
4. Press the Channel Seek button inside the battery compartment once to seek an active transmitter. See Figure 13. If more than
one transmitter is being used, push the seek button additional times until you locate the signal you want to hear. The receiver
will retain the channel setting when the unit is turned off.
5. To lock or unlock a selected channel, turn the power off. While holding the seek button, turn the power back on. When locked,
the receiver will remain on the current channel regardless of channel seek button presses.
Wideband FM Receivers (Optional)
Receiver Model PPA R37
PPA R37 is a 17-channel receiver operating on the 72-76 MHz bandwidth. Features include, seek-button channel selection,
channel-lock capability, battery-saving Sleep Mode, on/off volume control, power/low battery indicator, and stereo/mono
earphone jack.
ON/OFF, VOLUME
CONTROL SWITCH
EARPHONE
JACK
"ON" / LOW BATTERY/
FLASH CODE INDICATOR
OFF
A116
Figure 12: PPA R37 controls
LED Flash Codes
Light Code Indicates Description
1 blink Channel locked Seek press remains on current channel
2 blinks Channel unlocked See press tunes to next channel present
3 blinks Channel unlocked; no other channels present Seek press attempts to nd another cha.nnel
On-Off-On-Off...(continuous) Batteries are low Batteries need to be replaced or recharged
Fade-on, Fade-off... (continuous) No transmitter present on current channel Sleep/Power Save mode (extends battery life)
Figure 13: Battery and channel selections
ALKALINE/
NiMH SWITCH
CHANNEL
SEEK BUTTON
AA
AA
–
+
+
–
Channel
Seek
A117
