HYDRO-Trap Operator’s Manual
This manual has been prepared to help you operate your HYDRO-Trap successfully and safely. Should you have
any questions, we ask that you contact a Wilson Trailer factory representative immediately for a clear explanation.
NOTE: Wilson Trailer constantly makes product improvement to its product line. Your trap may
vary slightly from the equipment described and/or pictures in this manual.
We thank you for expressing your confidence in us through the purchase of your new Wilson HYDRO-Trap.
We want you to know that it was designed to meet your specific needs and is built for long life and low cost
operation. With regular, proper maintenance and your common sense, we are confident that it will do so.
Additional manuals and decal kits are available without charge.
MODEL NO. SERIAL NO.
Wilson Trailer Company
Operators Manual for
HYDRO-Trap

HYDRO-Trap Operator’s Manual
This safety alert symbol is to raise your awareness to important messages in this manual. When
you see this symbol, be alert to the possibility of personal injury and carefully read the message
that follows.
GENERAL INFORMATION
General Description .....................................................1-1
SAFETY
Decals and Emblems....................................................2-1
OPERATION
Power Requirements....................................................3-1
Lubrication Requirements ..........................................3-1
HYDRO-Trap Operations.............................................3-2
HYDRO-Trap Manual Operation ..............................3-2
HYDRO-Trap Wireless Operation.............................3-3
HYDRO-Trap Remote & Receiver Information .....3-4
GENERAL MAINTENANCE
Power Requirement Overview .................................4-1
Troubleshooting............................................................4-2
Notes about Oil..............................................................4-2
Potential Issues & Resolution Procedures..............4-2
Schematics.......................................................................4-5
TABLE OF CONTENTS by SECTION
CONSUMER INFORMATION
Warranty Coverage ......................................................5-1
Major Component Coverage ....................................5-1
Limitations and Disclaimers .......................................5-3
Index..................................................................................5-4

HYDRO-Trap Operator’s Manual
The Hydro Trap utilizes hydraulic cylinders to open and close the
traps. The Hydraulic pump is powered by the tractor through
and cab wiring kit with a master disconnect switch. The hydraulic
traps are activated with the control panel located at the center
of the trailer or by the optional remote. The remote is capable of
being programed to operate a Shurco 4500 Series power tarp
and the HYDRO-Traps.
General Description
General Information 1-1

HYDRO-Trap Operator’s Manual
The following section contains the decals and emblems specific
for this HYDRO-Trap.
2-1 Safety
Decals and Emblems
SAFETY
3,1&+32,17
6WD\FOHDURISRZHUWUDSV
ZKLOHWKH\DUHRSHUDWLRQDO
:7&$$$5=
6$)(7<,16758&7,216
&DE:LULQJZ0DVWHU'LVFRQQHFW.LWIRU
+\GUR7UDS2SHQHU:7&$33<=
7KHHQFORVHGSDUWVDUHXVHGWRSURYLGHSRZHU
WRWKH+<'527UDSDQG(OHFWULFWDUSRSWLRQV
,QVWDOOWKHVHFRPSRQHQWVSHUWKHHQFORVHG
LQVWUXFWLRQVIURP6KXU&R7KH0DVWHU
'LVFRQQHFWVKRXOGEHSODFHGLQWKHFDERI
WKHWUXFN7KLVSURYLGHVDVHFXUHORFDWLRQ
WREHDEOHWRGLVFRQQHFW3RZHUIURPWKH
RSWLRQVSURYLGLQJVDIHW\DQGVHFXULW\
ZKHQWKHRSWLRQVDUH127LQXVH
:7&$$$5:
86(3(752&$1$'$+<'5(;09$5&7,&
+<'5$8/,&)/8,'
2UDQ\PLQHUDOEDVHGK\GUDXOLFRLOEHWZHHQF6WDQG
F6WDW\RXUDPELHQWRXWGRRURSHUDWLQJWHPSHUDWXUH
,1)250$7,21
:7&$$$59
AAA06891RV
AAA06891RW
AAA06891RZ

HYDRO-Trap Operator’s Manual
OPERATION
Operation 3-1
Power Requirements
CAUTION
Make sure all power supply to trailer is disconnected
and the ground wire in the nose of the trailer and on
the receiver box is disconnected prior to any welding
on trailer. Failure to do so could result in damage to
receiver control box!
It is required that Cab Wiring w/Disconnect switch be installed
in the Tractor to Power the Hydro-Trap (WTC P/N APP04780YZ).
This kit includes a Master Disconnect. It is recommended this be
installed in the cab of the tractor and turned to the ON position
ONLY when the traps need to be operated. This kit includes a
120 amp Breaker required for the HYDRO-Trap option.
Lubrication Requirements
86(3(752&$1$'$+<'5(;09$5&7,&
+<'5$8/,&)/8,'
2UDQ\PLQHUDOEDVHGK\GUDXOLFRLOEHWZHHQF6WDQG
F6WDW\RXUDPELHQWRXWGRRURSHUDWLQJWHPSHUDWXUH
,1)250$7,21
:7&$$$59

HYDRO-Trap Operator’s Manual
3-2 Operation
OPERATION
HYDRO-Trap Operation
WTC recommends the Cab Wiring w/Disconnect switch be installed in the tractor to power
the HYDRO-Trap (WTC P/N APP04780YZ). This kit includes a Master Disconnect. It is
recommended that this be installed in the cab of the tractor and turned to the ON position
ONLY when the traps need to be operational. It should be turned to the OFF position when
the traps are not required to be operational. This kit includes a 120 amp Breaker required
for the HYDRO-Trap option.
Disconnect power before servicing. Make sure all power supply to trailer is disconnected
and the ground wire in the nose of the trailer and on the receiver box is disconnected prior
to any welding on trailer. Failure to do so could result in damage to receiver control box.
IMPORTANT NOTICE
HYDRO-Trap Manual Operation
1. Turn Master Disconnect Switch in the tractor to the
“ON” position.
2. Make sure tractor is running and all connections to the
trailer are hooked up.
3. Verify that all personnel are clear of the power trap
and tarp (if equipped) before operating either.
4. Press and hold button for desired operation (Open or
Close).
5. Close trap door when finished unloading.
6. When finished operating the traps, turn Master
Disconnect Switch in the tractor to the “OFF”
position.
CAUTION
The hydraulic cylinders and trap doors/frames
may be damaged if trailer is transported with
the doors in the open position.

HYDRO-Trap Operator’s Manual
Operation 3-3
OPERATION
HYDRO-Trap Wireless Operation
NOTE
Shurco Electric Tarp (if equipped) can
also be operated using this wireless
remote.
1. Turn Master Disconnect Switch in the tractor
to the “ON” position.
2. Make sure tractor is running and all connections
to trailer are hooked up.
3. To turn the remote “ON”, press and hold power
button on remote for 3 seconds and release to
turn on remote.
4. Press and hold button for desired operation
(Open or Close). Hopper 1 is the front trap;
Hopper 2 is the rear trap; ACC operates the third
trap if equipped.
5. To turn remote “OFF”, press and hold power
button on remote until the two LED’s (red and
green) turn off to turn off remote. Remote
will automatically turn off after 15 minutes of
inactivity.
6. When finished operating the traps, turn Master
Disconnect Switch in the tractor to the “OFF”
position.
CAUTION
The hydraulic cylinders and trap doors/
frames may be damaged if trailer is
transported with the doors in the open
position.
Remote

HYDRO-Trap Operator’s Manual
OPERATION
3-4 Operation
HYDRO-Trap Remote & Receiver Information
1. When turned on the green LED on remote will flash
rapidly if the remote is connected to the receiver. If the
remote is not connected to the receiver then the green
LED on remote will blink slowly. This may be caused by
the receiver not having power.
2. The red LED will blink (once/second) when the remote
battery gets low.
3. If connection between receiver and remote is lost
you can synchronize the remote and receiver by the
following steps:
• Make sure the receiver and remote are off
• Press and hold the power button on the remote for
more than 10 seconds. The red and green LEDs will
start flashing.
• Apply power to the receiver by connecting your 7
way with hot center pin to trailer.
• Wait for a few seconds until only the green LED
begins to blink on the remote
4. When receiver has power only the red LED on the
receiver will blink. When the remote is connected to
receiver the green LED on the receiver will blink.
Remote
Receiver
RED (Error Code LED)
GREEN (Signal LED)

HYDRO-Trap Operator’s Manual
TROUBLESHOOTING
General Maintenance 4-1
Power Requirement Overview
In order to operate, this system requires two power supplies:
1. The control system logic power is supplied a constant
nominal 12v by the 7-way center pin (blue wire) and
grounded by the bottom (larger) ground pin (white
wire). These connections must be kept in good repair.
Chassis ground is not adequate or reliable. The ground
connection of the 7-way must have a good connection to
the tractor ground.
2. Pump motor power and ground are supplied via a
heavy gauge high current Shurco 2 pin connector at the
front the trailer. Tractor wiring kits are available from
Wilson Trailer and are the only approved system for
powering this unit. Note: Previously installed cab
wiring kits for powering Shurco power tarp or trap
openers use the same connector but do not supply
adequate power to operate the unit when loaded.
It is possible to retrofit these tractor systems. (Contact WTC
service for details.) The cab wiring kit must be installed
per instructions (including the Master Disconnect Switch
and 120 amp slow-trip circuit breaker module). The
installation should use sufficient cable to comfortably
reach components and support maintenance, but avoid
coiling up excess as any extra cable length reduces power
available to the motor. Chassis ground is not adequate or
reliable, ensure that the ground cable is connected to a
tractor battery cable. All high power connections need to
be kept in good repair. For maximum door opening
force, the trap should be operated with the tractor
running.

HYDRO-Trap Operator’s Manual
4-2 General Maintenance
TROUBLESHOOTING
Notes About Oil
• Hydraulic oil must be kept clean and dry to work
correctly. Contamination causes wear and can
cause valves to stick. Do not remove fill plug without
cleaning the area around the hole. In wet conditions
use a rag to wipe excess water off the top of the plug
and reservoir before operating traps.
• For oil to go out to the cylinders air needs to be
allowed to enter the reservoir through the fill plug
vent. Keep the top of the reservoir clear of debris and
wipe clean often. Remove fill plug and clean vent as
needed.
• Correct oil must be used for acceptable performance
and system life. Oil must be mineral based with
a viscosity and must be between 10 and 100 cSt
(mm^2/s) at ambient outdoor operating temperatures.
Oil thinner than 10 cSt will damage the pump. Oil
thicker than 100 cSt will reduce power available to
open traps and can cause the power breaker to trip.
Your system is supplied pre-filled with Petro-Canada
Hydrex MV Artic 15 hydraulic fluid, which should give
good performance from -20 to 120º F (-30 to 50º C)
for operation outside this temperature range, or with
other fluids, consult with Wilson Trailer Co. Service
department.
Potential Issues & Resolution Procedures
No traps operate with remote or
switches on the side of the trailer.
Locate the receiver (small black box with an antenna).
Does the red light in the upper corner flash on and off?
If nothing lights up:
• Check for 12v on the center pin of the 7-way
connector to the front of the trailer.
• Check that the ABS system is getting power. The ABS
light at the rear of the trailer should power on for a
few seconds when the 7-way is connected to power.
If ok:
• Check for 12v to the receiver power connection.
Follow the in-board harness from the bottom of the
receiver to where it divides into several wires. The red
wire with a male pin should be connected to a wire
that leads to the connection that taps into the ABS
power (blue wire) near where the valve control plugs
into the harness. If ok:

HYDRO-Trap Operator’s Manual
General Maintenance 4-3
TROUBLESHOOTING
Potential Issues & Resolution Procedures
No traps operate with remote or
switches on the side of the trailer. • Check receiver ground connection. Follow the in-
board harness from the bottom of the receiver to
where it divides into several wires. The black wire with
a male pin should be connected to a wire that leads to
a main harness ground (white wire) at the front of the
trailer. If ok:
• Connect the receiver power and ground connections
(red and black) directly to a known good power
source, if nothing lights up replace receiver.
If the red light is blinking go to the next step:
Do you hear anything when you try to operate the traps?
If you don’t hear any sounds:
• Check that the purple wire from the receiver to the
pump motor solenoid is supplying 12v when the trap
function is pressed.
If you hear a click but no motor noise when a trap function
is pressed or released:
• Check the high current power and ground
connections from the tractor kit to the 2-pole
connector and up to the motor solenoid.
If the pump motor is making a whirring whine noise
(indicating spinning up and pumping) go to the next step.
Is there adequate oil of the correct viscosity in the
reservoir?
• If low add. Repair any leaks promptly.
Is the fill plug vent plugged?
• Clean top of reservoir and remove fill plug. Attempt to
operate. If a difference is noted then clean vent on fill
plug.

HYDRO-Trap Operator’s Manual
TROUBLESHOOTING
4-4 General Maintenance
Check connections at directional control valve solenoids.
(Each double stack of solenoids controls a single trap.
Individual solenoids in the stack energize to shift the valve
to open or close functions.) Each solenoid connection
should have a constant ground (black), and a colored wire
(white, blue, brown, or green) that supplies 12v when a
trap function is activated.
To isolate the problem temporarily swap solenoid
connections on one stack with the connections on the
other. Attempt to operate the traps.
• If the failure stays with the same trap one of the
solenoids has failed, or the valve is stuck. Remove the
nut on top of the solenoid stack and slide solenoids
off. Temporarily reinstall them with the top one on the
bottom. Do not overtighten nut. Attempt to operate
the trap.
• If the trap still fails to go in the same direction as before
replace the valve cartridge.
• If the direction of the failure has changed replace the
bad solenoid. (A good solenoid can be borrowed from
the other stack to verify correct function with a known
good solenoid.)
• If the failure moved to the other trap the receiver is
faulty and should be replaced.
An individual trap fails to operate in
one or both directions with remote or
switches on the side of the trailer.
Trap function operates continuously,
comes on by itself or one or more
switch on the side of the trailer fails
to operate a function that can be
operated with the remote.
Check for defects in connections between switches and
receiver harness. (The connection will be in split loom on
the inboard side of the trailer rubrail behind the switch
panel.) Each switch is supplied 12v from the receiver
Each switch connection should have a constant 12v power
(red), and a colored wire (white, blue, brown, or green) for
the switched signal (normally open, 12v when the switch
is pressed). Replace any defective switches.
Note: These connections must be free from
corrosion, individually sealed, and dry. (Individual
sealed connections can be bundled together)
Seal with appropriate adhesive lined heat shrink
tubing after any repairs or inspections that require
connection disassembly. Shorts or moisture
bridging between red and colored wires may
actuate trap functions.
Potential Issues & Resolution Procedures

HYDRO-Trap Operator’s Manual
General Maintenance 4-5
Schematic
SCHEMATICS
3.00" SQR
2.59"
Ø0.19"
3 FT
3 FT
12"
RED (Error Code LED)
GREEN (Signal LED)

HYDRO-Trap Operator’s Manual
CONSUMER INFORMATION
5-1 Consumer Information
(Rev. 10-18)
GRAIN TRAILER
WARRANTY
3
YEAR
LIMITED
Warranty Coverage
Wilson Trailer will repair or replace, at its option, any factory-installed part that is defective in material or
factory workmanship under normal use, maintenance and service. Normal use excludes any operation in
excess of GVWR (gross vehicle weight rating) and any use the Owner’s Manual states is not recommended.
Warranty repairs will be made and adjusted in accordance with the Extended Warranty Schedule. Any
repaired or replaced parts are covered only for the remainder of this warranty. All parts replaced under this
warranty become the property of Wilson Trailer. This warranty begins on the date the trailer is delivered to
the FIRST RETAIL PURCHASER or the date it is first placed into service as a demonstrator or leased trailer,
whichever comes first and continues for a period of (3) three years.
Non-Coverage Items
Tires: Wilson Trailer provides no warranty coverage on tires. Tires are covered under the manufacturer’s
warranty.
Axles, wheels, tires, suspension, trailer frame and other components and structure damaged through the
use of single axle dump valves.
Non-standard features or items specified by the purchaser.
Parts that fail due to lack of required maintenance or use of non-equivalent parts.
Normal wear or deterioration on any part.
Any trailer normally driven outside the United States or Canada.
The replacement of expendable maintenance items when the replacement is not due to a defect in material
or factory workmanship.
Any pre-owned trailer.
Major Component Coverage
1 Year Coverage
• Coating on Steel Parts – Parts and Labor Covered
• 18 oz Shurco Tarps – Parts Only
• Cleveland Vibrators
• Air Springs - Parts and ½ Hour Labor 1-12 Months
• Suspension Major Structural Components – Parts and Labor
• Wheel Seals – 1-6 Months Parts and $150 labor per wheel end – 6-12 months Parts
and $75 per wheel end
• Cylinders, HYDRO-Trap
• Receiver & Remote, HYDRO-Trap
• KTI - Pump, Motor, and Solenoids, HYDRO-Trap

HYDRO-Trap Operator’s Manual
Consumer Information 5-2
CONSUMER INFORMATION
(Rev. 10-18)
Major Component Coverage
2 Year Coverage
• Shurco Diamond Core Tarp – Parts Only
• Shocks – Parts and ½ Hour labor
• Air Springs – Parts and ½ Hour Labor 1 year - Parts only through year 2
• Pivot Bolts/Alignment Components – 1 year Parts and Labor – Parts only through year 2
3 Year Coverage
• All components manufactured by Wilson Trailer
• Shurco 4500 Electric Tarp Motor – Parts Only
• Shurco Protrap Electric Motor – Parts Only
5 Year Coverage - Vendor only coverage
• Landing Legs – Parts and Labor
• 2-Speed Gear Box - Parts and Labor
• Aluminum Wheels – Parts
• Steel Wheels – Parts
6 Year Coverage - Vendor only coverage
• Slack Adjusters – Parts
7 Year Coverage - Vendor only coverage
• 7-way receptacle
• Wiring Harnesses - Parts and Labor covered for 3 years – parts only coverage thereafter
through year 7
10 Year Coverage - Vendor only coverage
• Grote LED lights (Parts and Labor covered for 3 years – parts only coverage thereafter
through year 10)
To Get Warranty Service
Parts claimed to be defective in material or workmanship must be brought to the attention of Wilson
Trailer or the selling dealer by taking the trailer to the dealer or by written notification within ten (10) days
of discovery, and any repairs or replacement must be commenced within forty-five (45) days thereafter.
Wilson Trailer has the right to inspect the claimed defect and determine whether the part is covered by
this warranty. If you cannot get warranty service, or you are dissatisfied with the service or with a warranty
decision, contact Technical Service and Claims Manager, 1-800-798-2002, Wilson Trailer, P.O. Box 6300,
Sioux City, IA 51106.
Owner’s Responsibility
As the FIRST RETAIL PURCHASER of the trailer, you have the responsibility to perform the required
maintenance at the proper intervals and make reasonable and normal use of the trailer.
The FIRST RETAIL PURCHASER needs to contact Wilson Trailer’s Warranty Department at the 1st sign of a
defect in material or workmanship at 1-800-798-2002 to get the claim on record.

HYDRO-Trap Operator’s Manual
5-3 Consumer Information
CONSUMER INFORMATION
Serial Number
G.V.W. Rating
Purchased By
Date In Service
Selling Dealer
By
(Authorized Signature)
(Rev. 10-18)
Warranty Work
All warranty work must preformed at a repair shop approved in advance by Wilson Trailer Company.
Limitations and Disclaimers
Wilson Trailer disclaims any responsibility for any loss of time or use of the parts or trailers in which the
parts are installed, transportation, cargo loss, or other incidental or consequential damage. Any implied
warranties, including the implied warranty of merchantability and fitness for a particular purpose, are limited
to the duration of this written warranty. Wilson Trailer makes no warranty as to quality or performance of
its trailer other than set forth above. Some states do not allow limitations on how long an implied warranty
lasts, or the exclusion or limitation of incidental or consequential damages, so the above limitations or
exclusions may not apply to you. This warranty gives you special legal rights, and you may also have other
rights which vary from state to state.
To file a claim or if you need answers to questions about this warranty,
contact the Wilson Trailer Warranty Department:
Wilson Trailer, PO Box 6300, Sioux City, IA 51106
800-798-2002
www.wilsontrailer.com
email: [email protected]

HYDRO-Trap Operator’s Manual
Consumer Information 5-4
INDEX
A
Adjustment, Door Lock Collar......................................5-4
Alerts, Keypad....................................................................3-3
B
C
Consumer Information...................................................5-1
Coverage, Warranty ........................................................5-1
D
Decals and Emblems.......................................................2-1
Description, General .......................................................1-1
Disclaimers, Limitations and .........................................5-3
E
Emblems, Decals and .....................................................2-1
F
G
General Description ........................................................1-1
H
HYDRO-Trap Manual Operation .................................3-2
HYDRO-Trap Operation .................................................3-2
HYDRO-Trap Remote & Receiver Information ........3-4
HYDRO-Trap Wireless Operation................................3-3
I
Index.....................................................................................5-4
Information, Consumer..................................................5-1
Information, HYDRO-Trap Remote & Receiver .......3-4
Issues & Resolution Procedures, Potential................4-2
J
K
L
Limitations and Disclaimers ..........................................5-3
Lubrication Requirements .............................................3-1
M
Manual Operation, HYDRO-Trap ................................3-2
N
Notes about Oil.................................................................. 4-2
O
Oil, Notes about................................................................4-2
Operation, HYDRO-Trap ................................................3-2
Operation, HYDRO-Trap Manual ................................3-2
Operation, HYDRO-Trap Wireless...............................3-3
Overview, Power Requirement ...................................4-1
P
Potential Issues & Resolution Procedures.................4-2
Power Requirements.......................................................3-1
Power Requirement Overview ....................................4-1
Q
R
Remote & Receiver Information, HYDRO-Trap .......3-4
Requirement Overview, Power ...................................4-1
Requirements, Lubrication ............................................3-1
Requirements, Power......................................................3-1
Resolution Procedures, Potential Issues....................4-2
S
Schematics..........................................................................4-5
T
Troubleshooting...............................................................4-2
U
V
W
Warranty Coverage .........................................................5-1
Wireless Operation, HYDRO-Trap...............................3-3
XYZ



HYDRO-Trap Operator’s Manual
www.wilsontrailer.com
E-Mail: [email protected]
HYDROTrapOM1.001 Printed February 2019
WILSON TRAILER COMPANY
4400 So. Lewis Boulevard Sioux City, Iowa 51106
Telephone 712-252-6500 800-798-2002
Other manuals for HYDRO-Trap
1
Table of contents
Popular Control Unit manuals by other brands

Hyperion
Hyperion HY-DH144P8 installation manual

Watts
Watts e-ultramix Series Installation and operation manual

Flowstar
Flowstar CT5-1 Installation and operating manual

Dometic
Dometic Elite Control Series Installation and operating manual

Civacon
Civacon NV4000 Installation & maintenance manual

Pilz
Pilz PSEN cs 4.2p/M12 operating manual
