Operation Manual
Airbrush Compressor AF18-2
ARTICLE 34203
Read and follow the operating instructions and safety information before using for the first time.
Technical changes reserved!
Due to further developments, illustrations, functioning steps and technical data can differ insignificant-
ly.
Updating the documentation
If you have suggestions for improvement or have found any irregularities please contact us.

© by WilTec Wildanger Technik GmbH Seite 12
http://www.WilTec.de
http://www.aoyue.eu Version 3.2016
http://www.teichtip.de
The information contained in this document is subject to change without prior notice. No part of this
document can be copied or duplicated in another form without the prior written consent of WilTec Wil-
danger Technik GmbH. The WilTec Wildanger Technik GmbH assumes no liability for any errors in
this user manual or the connection diagram.
Although WilTec Wildanger Technik GmbH has made every effort to make sure that this user manual
is complete, accurate and updated, errors cannot always be avoided. In the event of problems with
this user manual please complete and send this form back to us.
FAX-notification (+++49 2403 55592-15),
from: ________________________________________
Name: ________________
Firm:_____________________
Tel/Fax:__________________
I would like to report the following mistakes:
___________________________________________________________________
Customer Service WilTec Wildanger Technik GmbH
e-mail: [e-mail]
Tel:++ [phone]
Introduction
Thank you for purchasing this quality product. To minimize the risk of injury by means of fire or
electric shock we urge that our clients take some basic safety precautions when using this
device. Please read the operation instructions carefully and make sure you have understood its
content.
Always use a grounded power connection with the appropriate mains voltage. You can find the corre-
sponding mains voltage on the type plate. If you have any doubts about the connection being ground-
ed, have it checked by a qualified professional. Never use a faulty electric cable.
Do not inspect the electrical part of the pressure pond filter in a wet or damp environment or when you
are wet yourself and protect it from direct sunlight. Install this device in a safe location so that nobody
can step on the cable, fall over or damage it. Disconnect the power plug before cleaning it and use
only a damp cloth for cleaning. Avoid using cleaning agents and make sure that no liquid enters the
electrical part of the pump.
The electric part of the device contains no parts that can be inspected or serviced by the user. Leave
the maintenance, adjustment and repair to qualified technical personnel. In case of unauthorised inter-
vention the 2-year warranty is no longer valid! Keep these operation instructions safe.

© by WilTec Wildanger Technik GmbH Seite 13
http://www.WilTec.de
http://www.aoyue.eu Version 3.2016
http://www.teichtip.de
Safety guideline
BEWARE:
The use of this device is allowed only with fault current protection switch with a triggering nominal
current up to 30mA (according to VDE 0100 Article 702 and 738).
The device is not intended for use by persons (including children) with impaired or limited physical,
sensory and mental abilities or lack of experience and/or real knowledge, unless they are supervised
by a person responsible for their safety or the follow the instructions, made by this person on how to
use the device correctly.
Children should be supervised to make sure that they do not play with the device.
ATTENTION:
•The head of the compressor (with cooling fins) can get very hot.
•Run a visual inspection of the device before every use. Do not use the device if the safety ap-
pliances are damaged or worn out. Never override safety regulations.
•Use the device exclusively according to the intended purpose stated in the instructions for
use.
•You are responsible for the safety of the working environment.
•If the cable or the plug is damaged due to external influences the cable must not be repaired!
It has to be replaced with a new one. This work can be carried out only by an electrician.
•The voltage indicated on the type plate of the device of 230 Volt alternating voltage has to cor-
respond to the existent mains voltage.
•Never lift, carry or fixate the device by using the power cable.
•Make sure that the electrical plug connection is placed in a flood-proof area and is protected
from moisture.
•Disconnect the mains plug before starting the maintenance work at the compressor.
•The user is responsible for complying with the location specific safety and mounting regula-
tions (you can ask an electrician)
•In case of device failure the repairs can be carried out only by an electrician or by the WilTec-
repair service.

© by WilTec Wildanger Technik GmbH Seite 14
http://www.WilTec.de
http://www.aoyue.eu Version 3.2016
http://www.teichtip.de
SAFETY GUIDELINES:
•The user should choose the right compressor with the appropriate air volume and air pressure
to correspond to the actual work requirements.
•Never expose the device to dust, acid, steam, explosive or flammable gases or atmospheric
influences (rain, sun, fog, snow).
•The vacuum pump can be operated only in an appropriate environment (well ventilated, ambi-
ent temperature +5 - +40 degrees C).
•Never use the compressor barefoot or with wet hands or feet.
•Never allow children to touch the switched-on compressor or to insert the plug. It may cause
burns or electric shocks.
•Do not open or damage any part of the compressor. If necessary please contact your seller.
•Release the water by opening the drain valve. Always do so before not using the compressor
for a long time. Store the compressor in a well ventilated place.
•Always wear goggles. Under no circumstances should you direct the airflow towards your
body or other persons’ bodies.
•Never use in areas with steam or moisture or close to water.
•Switch off the compressor if you do not use it. Disconnect from mains before you repair, re-
condition, maintain, clean or replace parts. Never use the power cable as handle. Keep the
power cable away from hot objects, oil and sharp edges. Protect it against breakage. Do not
pull the power cable in order to unplug it from the power socket.
•If the compressor is used outdoors, only approved extensions may be used. Every wire of the
extension cable must have at least 1, 5 mm2cross- section.
•Do not store the compressor with the plug inserted into the plug. Do not allow children or any
other people who are not able to handle this device to play or work with it.
•Be very careful when you are working with the compressor. Do not use it if you are tired. Per-
sons under the influence of alcohol, drugs or medication are not allowed to use this device.
•When you start working make sure that all screws are tightened.
•Do not use the compressor if it is damaged. If the compressor generates unusual noises and
strong vibrations or if other unusual signs occur that indicate some damage you should turn
off the compressor immediately. For repairs please use only original spare parts. Do not make
any technical modifications to the compressor. In case you cannot eliminate the malfunction
hand over the device to your seller.
•Sie das Gerät Ihrem Verkäufer.
Properties
1. Compressor with pressure regulator, condensate drain and manometer
2. Oil free, piston compressor, no polluted air
3. With water filter, pressure adjustment and manometer
4. Overtemperature protection
5. Very low noise level
Field of application
The AF18-2 Airbrush compressor is among others suitable for the operation in the following areas:
Crafts, hobby, modelling, tattoos and body art, make-up and nail design, as a source of air in the med-
ical field, food and chemical industries, laboratories etc.

© by WilTec Wildanger Technik GmbH Seite 15
http://www.WilTec.de
http://www.aoyue.eu Version 3.2016
http://www.teichtip.de
Specification
Type: Piston compressor
Power: 150W (1/5-PS)
Rotation speed: 1450 / 1700 rpm
Standard volume: 20 – 23 l/min
Presssure adjustment range: 0 – 4 bar
Air tank: 3,9 kg
Dimensions: 255x135x205 mm
Suitable for all airbrush types with nozzles from 0,2 bis 1,0 mm
Users notice
The compressor has a 1/8 inch outlet (9,51 mm /male thread), which can be effortlessly changed to ¼
inch. The matching adapter is not included in the supply.
When the compressor is connected by the hose to the airbrush gun, the compressor can be connected
to the mains and be switched on.
The maximum pressure is displayed by the pressure gauge, the operating pressure can be adjusted
by the pressure regulator.
The hose that is included in the supply is air-impermeable. If the auto-stop mode is activated (repeat-
edly switch on/off) any and all screw fittings and connections should be sealed by a tape made teflon.
Testing of leakage
Switch on the compressor and wait until the maximum pressure has built up and the auto-stop function
has been activated.
If there is no leakage, the pressure gauge should display nearly constantly the same range of pres-
sure.
A quick decrease of the range of pressure suggests that there is in fact a leakage.
It is of great importance to seal any leak as soon as possible in order to avoid any impact on the ca-
pacity and efficiency of the compressor.
A leak causes the auto-stop and auto-start function to be carried out permanently.
The difference between maximum pressure and operating pressure
The maximum pressure is the highest possible pressure a compressor is able to generate.
Once the maximum pressure has been reached, the compressor switches off (auto-stop). As soon as
the pressure starts to decrease, it switches on again (auto-start).
The maximum pressure is defined to be the pressure that is measured only inside the compressor
itself.
There is a lower pressure on the outlet of the compressor. What remains, is the pressure you actually
work with. The operating pressure may vary according to the connected airbrush gun.

© by WilTec Wildanger Technik GmbH Seite 16
http://www.WilTec.de
http://www.aoyue.eu Version 3.2016
http://www.teichtip.de
Operation of the pressure relief station with filter
a) Pressure regulator
b) Manometer
c) Water drain plug
Product name:Pressure regulator with filter and manometer
Typ: AFR-2000
Specifications:
The AFR-2000 is an in-line low pressure regulator with 9 bar (100 psi) manometer and water drain
plug. This regulator allows you to control the pressure and helps generating clean, dry, pressure-
stable air. The regulator can be used only according to the operating instructions.
Operation:
oThe manometer reports the working pressure of the air tool.
oPull up the adjusting knob; its clockwise rotation increases the pressure, and a counter-clockwise
rotation reduces the pressure.
oRotate the adjusting knob to achieve the right working pressure and fixate it downwards by click-
ing it into place.
oDo not rotate the knob against high resistance. If necessary the height and the position of the of
the knob can vary slightly.
oFor emptying the condensed water collector use the water drain plug.
Assembly

© by WilTec Wildanger Technik GmbH Seite 17
http://www.WilTec.de
http://www.aoyue.eu Version 3.2016
http://www.teichtip.de
Part List
INDE
X NO
PARTS NO DESCRIPTION Q
T
Y
IND
EX
NO
PARTS
NO DESCRIPTION Q T
Y
1 AF18-#01 SCREW 8 24 AF18-#25 CYLINDER BLOCK 1
2 AF18-#03 BLOCK 1 25 AF18-#26 O-RING 1
3 AF18-#04 REAR BODY 1 26 AF18-#27 CYLINDER HEAD 1
4 AF18-#05 SCREW 1 27 AF18-#28 CAP SCREW 4
5 AF18-#06 STATIONARY MOTOR 4 28 AF18-#29 FILTER 1
6 AF18-#07 BEARING 1 29 AF18-#30 HANDLE 1
7 AF18-#08 ROTARY MOTOR 2 30 AF18-#31 PRESSURE SWITCH 1
8 AF18-#09 FRONT BODY 1 31 AF18-#32 WATER RELEASE
NEDDLE 1
9 AF18-#10 COUNTERWEIGHT 1 32 AF18-#33 CONDENSER 1
10 AF18-#11 MANOMETER 1 33 AF18-#34 POWER SWITCH 1
11 AF18-#12 BEARING 1 34 AF18-#35 WIRE 1
12 AF18-#13 RETAINIER RING 1 35 AF18-#36 RUBBER PAD 4
13 AF18-#14 COMPRESSION RING 1 36 AF18-#37 HEXAGON NUT 1
14 AF18-#17 CYLINDER 1 37 AF18-#38 CONNECTOR 2
17 AF18-#18 VALVE PLATE 1 38 AF18-#39 CONNETCTION ROD 1
18 AF18-#19 VALVE 1 39 AF18-#41 PRESSURE
REGULATOR 1
19 AF18-#20 SCREW 2 40 AF18-#46 FAN 1
20 AF18-#21 FRONT GASKET 1 41 AF18-#47 HOLDER SUPPORT 1
21 AF18-#22 COVER 1 42 AF18-#48 COVER 1
22 AF18-#23 FILTER 1 43 AF18-#49 AIRBRUSH HOLDER 1
23 AF18-#24 O-RING 1 44

© by WilTec Wildanger Technik GmbH Seite 18
http://www.WilTec.de
http://www.aoyue.eu Version 3.2016
http://www.teichtip.de
Disposal regulations
EU guidelines regarding the disposal of scrap electric appliances (WEEE, 2002/96/EC) were imple-
mented in the law related to electrical and electronic equipment and appliances.
All WilTec electric devices that fall under the WEEE regulations are labelled with the crossed-out
wheeled waste bin logo. This logo indicates that this electric equipment must not be disposed with the
domestic waste.
The company WilTec Technik GmbH has been registrated in the German registry EAR under the
WEEE-registration number DE45283704.
Disposal of used electrical and electronic appliances
(intended for use in the countries of the European
Union and other European countries with a separate
collection system for these appliances).
The logo on the article or on its packaging points out
that this article must not be treated as normal house-
hold waste but must be disposed to a recycling collec-
tion point for electronic and electrical waste equip-
ment. By contributing to the correct disposal of this
article you protect the environment and the health of
your fellow men. Environment and health are threat-
ened by inappropriate disposal.
Materials’ recycling helps reduce the consumption of raw materials.
Additional information on recycling this article can be provided by your local community, municipal
waste disposal facilities or the store where you purchased the article.
Address:
WilTec Wildanger Technik GmbH
Königsbenden 12 / 28
D-52249 Eschweiler
Important notice:
The reprint or reproduction, even of excerpts, and any commercial use, even in part of this instructions
manual require the written permission of WilTec Wildanger Technik GmbH.
