WindRider 5-1 Manual


Build Instruction Manual
Wingspan: 2.2 meter
Length: 1.2 meter
Airfoil: RSB22
Wing Area: 330 sq.cm.
Weight: 880 grams
Wing Loading: 2.6g/sq.cm.
Material: EPO Foam
Radio: 3 to 4 channels
Servo: 4 to 7 mini size servos
Receiver Battery: AA X 4 pcs
CG: 7cm behind the wings leading edge
Rudder +/- 12mm
Elevator +/- 8mm
Aileron up 6mm, down 10mm
http://www.windrider.com.hk

1Gluethecarbonsparandribbonintowingslot. 2Installtheailerionservoandpushrod.
GluetheairbrakeORfoampartsonthewingtop. InstalltheairbrakeservoORgluefoamparts
Gluetherectangleplywoodonthewingjoin. underthewing.
3Gluetheribbonintotheslotonelevator. 4Installtheretractorgluefoampartsunderthebay.
Installtheelevatorandrudderservo,alsotheInstallthemotorbyprovidedcrossplywoodorgluethenosefoampartsinsidethenose.
pushrod.Gluetheelevatortothetailbyhotglue. Gluetwofuselagehalvestogetherandholdthetailsection.
5TapetheclearPVCcanopytothecockpit. 6Slideinthe8mmcarbonsparintoonewingjoin
Gluethe8pcsmagnetstofuselageandcokpit. channel,slideintheanothersideofwings.All
Installtheretractservoandlinkthepushrodtotheservocablegointothecokpit.Slideinthe
retractsystem. providedplywoodkeytolockbothsideofwingsfixedtothefuselage.
