Windsor VOYAGER E User manual

ToOrderPartsCall1-888-702-5326-https://monsterfloorequipmentparts.com
MODELS: POWER SOURCE
VGRE – 10086090 115V ELECTRIC
BEGINNING WITH SERIAL # 1000081026
Operating Instructions (ENG)
86039020 08/20/07
PRV NO. 98954
J
Read instructions before operating the machine.

ToOrderPartsCall1-888-702-5326-https://monsterfloorequipmentparts.com
86039020 VOYAGER E 08/20/07
2
OVERVIEW
The Voyager E is 115V electric powered, self-propelled, hard floor scrubber intended for
commercial use. The appliance applies a cleaning solution onto a hard floor, scrubs the floor with
brushes or pads, and then vacuums the soiled water back into the recovery tank.
INSPECTION
Carefully unpack and inspect your machine for shipping damage. Each unit is operated and
thoroughly inspected before shipping, and any damage is the responsibility of the carrier, who
should be notified immediately.
YOUR DEALER
Name: __________________________________________________________________________________________________
Address: _______________________________________________________________________________________________
Phone Number: _________________________________________________________________________________________
MODEL _______________________________________
DATE OF PURCHASE __________________________
SERIAL NUMBER ______________________________
SALES REPRESENTATIVE # _____________________
Copyright 1995 Windsor Industries, Printed in USA

ToOrderPartsCall1-888-702-5326-https://monsterfloorequipmentparts.com
TABLE OF CONTENTS
86039020 VOYAGER E 08/20/07
3
Machine Data Log/Overview................................2
Table of Contents.................................................3
HOW TO USE THIS MANUAL
How to use this Manual........................................1-1
SAFETY
Important Safety Instructions ...............................2-1
Hazard Intensity Level..........................................2-2
OPERATIONS
Technical Specifications.......................................3-1
Components.........................................................3-3
Drive Controls ......................................................3-3
Filling the Voyager ...............................................3-3
Chemicals.............................................................3-3
Operating the Machine.........................................3-4
MAINTENANCE
Emptying And Cleaning The Tanks .....................4-1
Vac Shoe Tracking...............................................4-2
Vac Shoe Downpressure .....................................4-2
Vac Shoe Angle ...................................................4-2
Changing The Vac Motor.....................................4-3
Changing The Vacuum Motor Brushes................4-3
Micro Switch Replacement...................................4-3
Troubleshooting ...................................................4-4
Service Schedule.................................................4-5
GROUP PARTS LIST
Handle Assembly ...............................................5-1
Drive Assembly ..................................................5-3
Brush Assembly .................................................5-5
Pump, Manifold And Vac Assemblies...............5-7
Rear Tower Mechanical Assembly.....................5-9
Rear Tower Valve, Electrical Assemblies ..........5-11
Vac Shoe Assembly...........................................5-15
Tank Assembly...................................................5-17
Dome And Float Assemblies..............................5-19
Wiring Diagram...................................................5-21
Suggested Spare Parts......................................5-22
Warranty.............................................................5-24

ToOrderPartsCall1-888-702-5326-https://monsterfloorequipmentparts.com
HOW TO USE THIS MANUAL
86039020 VOYAGER E 08/20/07
1
-
1
This manual contains the following sections:
- HOW TO USE THIS MANUAL
- SAFETY
- OPERATIONS
- MAINTENANCE
- PARTS LIST
The HOW TO USE THIS MANUAL section will tell
you how to find important information for ordering
correct repair parts.
Parts may be ordered from authorized Windsor
dealers. When placing an order for parts, the
machine model and machine serial number are
important. Refer to the MACHINE DATA log which is
filled out during the installation of your machine. The
MACHINE DATA log is located on the inside of the
front cover of this manual.
The model and serial number of your machine is on
the back of the machine.
SAFETY section contains important information
regarding hazard or unsafe practices of the
machine. Levels of hazards is identified that could
result in product or personal injury, or severe injury
resulting in death.
The OPERATIONS section is to familiarize the
operator with the operation and function of the
machine.
The MAINTENANCE section contains preventive
maintenance to keep the machine and its
components in good working condition. They are
listed in this general order:
- Emptying And Cleaning Tanks
- Vac Shoe Adjustment
- Service Schedule
- Machine Troubleshooting
The PARTS LIST section contains assembled parts
illustrations and corresponding parts list. The parts
lists include a number of columns of information:
- REF – column refers to the reference
number on the parts illustration.
- PART NO. – column lists the part
number for the part.
- PRV NO. - reference number.
- QTY – column lists the quantity of the
part used in that area of the machine.
- DESCRIPTION – column is a brief
description of the part.
- SERIAL NO. FROM – column indicates
the first machine the part number is
applicable to. When the machine design
has changed, this column will indicate
serial number of applicable machine.
The main illustration shows the most
current design of the machine. The
boxed illustrations show older designs. If
column has an asterisk (*), call
manufacturer for serial number.
-NOTES – column for information not
noted by the other columns.
NOTE: If a service or option kit is installed on your
machine, be sure to keep the KIT INSTRUCTIONS
which came with the kit. It contains replacement
parts numbers needed for ordering future parts.
NOTE: The number on the lower left corner of the
front cover is the part number for this manual.
MODEL _____________________________________
DATE OF PURCHASE ________________________
SERIAL NUMBER ____________________________
SALES REPRESENTATIVE # ___________________
Copyright 1995 Windsor Industries, Printed in USA

ToOrderPartsCall1-888-702-5326-https://monsterfloorequipmentparts.com
86039020 VOYAGER E 08/20/07 2-1
IMPORTANT SAFETY INSTRUCTIONS
When using an electrical appliance, basic precaution
must always be followed, including the following:
READ ALL INSTRUCTIONS BEFORE USING THIS MACHINE.
To reduce the risk of fire, electric shock, or injury:
Use only indoors. Do not use outdoors or expose to rain.
Use only as described in this manual. Use only manufacturer’s recommended components and attachments.
If the machine is not working properly, has been dropped, damaged, left outdoors, or dropped into water, return
it to an authorized service center.
Do not operate the machine with any openings blocked. Keep openings free of debris that may reduce airflow.
This machine is not suitable for picking up hazardous dust.
Machine can cause a fire when operating near flammable vapors or materials. Do not operate this machine near
flammable fluids, dust or vapors.
This machine is suitable for commercial use, for example in hotels, schools, hospitals, factories, shops
and offices for more than normal housekeeping purposes.
Maintenance and repairs must be done by qualified personnel.
During operation, attention shall be paid to other persons, especially children.
When leaving unattended, secure against unintentional movement.
The machine shall only be operated by instructed and authorized persons.
When leaving unattended, switch off or lock the main power switch to prevent unauthorized use.
Do not handle the plug or machine with wet hands.
Do not unplug machine by pulling on cord. To unplug, grasp the plug, not the cord.
Do not use with damaged cord or plug. Follow all instructions in this manual concerning grounding the machine.
Do not pull or carry by cord, use cord as a handle, close a door on cord, or pull cord around sharp edges or
corners.
Do not pull/run machine over cord. Keep cord away from heated surfaces.
Connect to a properly grounded outlet. See Grounding Instructions.
SAVE THESE INSTRUCTIONS

ToOrderPartsCall1-888-702-5326-https://monsterfloorequipmentparts.com
HAZARD INTENSITY LEVEL
86039020 VOYAGER E 08/20/07
2-2
The following symbols are used throughout this guide as indicated in their descriptions:
HAZARD INTENSITY LEVEL
There are three levels of hazard intensity identified by signal words -WARNING and CAUTION and
FOR SAFETY. The level of hazard intensity is determined by the following definitions:
Hazards or unsafe practices which COULD result in severe personal injury or
death.
Hazards or unsafe practices which could result in minor personal injury or
product or property damage.
FOR SAFETY: To Identify actions which must be followed for safe operation of equipment.
Report machine damage or faulty operation immediately. Do not use the machine if it is not in proper
operating condition. Following is information that signals some potentially dangerous conditions to the
operator or the equipment. Read this information carefully. Know when these conditions can exist.
Locate all safety devices on the machine. Please take the necessary steps to train the machine
operating personnel.
FOR SAFETY:
DO NOT OPERATE MACHINE:
Unless Trained and Authorized.
Unless Operation Guide is Read and understood.
In Flammable or Explosive areas.
In areas with possible falling objects.
WHEN SERVICING MACHINE:
Avoid moving parts. Do not wear loose clothing; jackets, shirts, or sleeves when working on the
machine. Use Windsor/manufacturer approved replacement parts.

ToOrderPartsCall1-888-702-5326-https://monsterfloorequipmentparts.com
GROUNDING INSTRUCTIONS
86039020 VOYAGER E 08/20/07 2-3
THIS PRODUCT IS FOR COMMERCIAL USE
ONLY.
ELECTRICAL:
In the USA this machine operates on a standard 15
amp 115V, 60 hz, A.C. power circuit. The amp,
hertz, and voltage are listed on the data label found
on each machine. Using voltages above or below
those indicated on the data label will cause serious
damage to the motors.
EXTENSION CORDS:
If an extension cord is used, the wire size must be at
least one size larger than the power cord on the
machine, and must be limited to 50 feet (15.5m) in
length.
GROUNDING INSTRUCTIONS:
This appliance must be grounded. If it should
malfunction or break down, grounding provides a
path of least resistance for electric current to reduce
the risk of electric shock. This appliance is equipped
with a cord having an equipment-grounding
conductor and grounding plug. The plug must be
inserted into an appropriate outlet that is properly
installed and grounded in accordance with all local
codes and ordinances.
This appliance is for use on a nominal 120-volt
circuit, and has a grounded plug that looks like the
plug in “Fig. A”. A temporary adaptor that looks like
the adaptor in “Fig. C” may be used to connect this
plug to a 2-pole receptacle as shown in “Fig. B”, if a
properly grounded outlet is not available. The
temporary adaptor should be used only until a
properly grounded outlet (Fig. A) can be installed by
a qualified electrician. The green colored rigid ear,
lug, or wire extending from the adaptor must be
connected to a permanent ground such as a
properly grounded outlet box cover. Whenever the
adaptor is used, it must be held in place by a metal
screw.
Improper connection of the equipment-grounding
conductor can result in a risk of electric shock.
Check with a qualified electrician or service person if
you are in doubt as to whether the outlet is properly
grounded. Do not modify the plug provided with the
appliance - if it will not fit the outlet, have a proper
outlet installed by a qualified electrician.

ToOrderPartsCall1-888-702-5326-https://monsterfloorequipmentparts.com
NOTES
86039020 VOYAGER E 08/20/07
2-4

ToOrderPartsCall1-888-702-5326-https://monsterfloorequipmentparts.com
TECHNICAL SPECIFICATIONS
86039020 VOYAGER E 08/20/07 3-1
ITEM DIMENSION/CAPACITY
Electrical 115V, 15A, 60HZ
Electric Propelling Motor (1)-1/4 hp DC (186 watts) with variable speed forward and
reverse, with safety shut-off.
Drive System Belt Drive w/ manual clutching mechanism. Operating speed”
0-100 ft/min (30 m/min)
Electric Vacuum Motor (1)-3 stage, 1 hp (746 watts), 99 cfm (2.80 m³/min.)
Waterlift 117” (397 cm). Electric float shut-off.
Electric Brush Motor (1)-0.4 hp (298 watts) permanent magnet, DC.
Brush Speed 1000 RPM
Solution Pump 100 psi, diaphragm style pump
Solution Capacity 40 Gallons (151 ltr)
Recovery Capacity 35 Gallons (132 ltr)
Vacuum Shoe 28” (71 cm) wide, cast aluminum, adjustable floating and
pivoting.
Wheels
- Front (2)
- Rear (2)
10” dia. (25 cm) by 2.5” wide (6.4 cm)
4” dia. (10cm) casters
Dimensions – Weight (empty) 280 lbs. (127 kg)
Dimensions
- Length
- Storage Position
60” (152 cm)
52” (132 cm)
Dimensions - Height 43” (109 cm)
Dimensions - Width 30” (76 cm)
SIDE VIEW TOP VIEW

ToOrderPartsCall1-888-702-5326-https://monsterfloorequipmentparts.com
COMPONENTS
86039020 VOYAGER E 08/20/07
3-2
1. Brush Height Adjustment – Raises and
adjusts the height of the brush.
2. Vac Shoe Lift Lever – Lifts the vac shoe up
or down and switches vac motor off and on.
2nd slot for accessory tool use.
3. Electrical Power Cord
4. Main Power Switch – Turns On and Off the
machine and pump.
5. Drive Handle Control and Connection –
This is where the handle controls are
connected electrically to the drive.
6. Drive Motor Circuit Breaker – 3 amp,
protects the drive motor mechanism.
7. Vac Motor Circuit Breaker – 13 amp,
protects the vacuum motor.
8. Brush Motor Circuit Breaker – 4 amp,
protects the brush motor.
9. Accessory Tool Hookup – Used for
various auxiliary cleaning tools.
10. Hour Meter – Displays the running time for
the machine.
11. Belt Tension Handle – Puts machine into
“Dirve” or “Neutral” engagement.
12. Data Plate Label – Shows serial number,
model and voltage information.
13. Height Adjustment Handle – Adjusts the
handle height for comfortable operation.
14. Accessory Tool Hose Attachment – To
use accessory tool, remove hose from vac
shoe and attach to accessory tool adapter.
15. Sight fill tube.
16. Drain hose.
8
16
15
13
9
4 2
1
3
5
12
14
10
11
6 7

ToOrderPartsCall1-888-702-5326-https://monsterfloorequipmentparts.com
OPERATION
86039020 VOYAGER E 08/20/07 3-3
1
4
2
3
DRIVE CONTROLS
1. The speed the machine will travel is
regulated by knob located on the controls
which are found on the main handle. Turn
the knob to the right to increase the speed
of the machine.
2. Squeezing one or both of the control levers
will propel the machine forward at the
selected speed.
3. Releasing both control levers will stop the
machine.
4. Pressing forward on the levers moves the
machine backwards at the selected speed
FILLING THE VOYAGER
NOTE: If a bucket is used to fill the tank, be
sure it is clean.
DO NOT PUT
DEFOAMER,
SOLVENTS, SPOTTER OR PRE-SPRAY
CHEMICALS IN THE SOLUTION TANK.
CHEMICALS
SUITABLE CHEMICALS NON-COMPATIBLE
CHEMICALS
Alkalis Aldehydes
Detergents Aromatic Hydrocarbons
Hydroxides SP Butyls
Soaps Carbon Tetrachloride
Vinegar Chlorox*
Chlorinated Bleaches
Chlorinated Hydrocarbons
Lysol*
Methyl Ethel Ketone
(MEK)
Perchorethylene (perc)
Phenolics
D-Limonene@
@When properly
diluted
* Registered
Trademark
Trichlorethyelene
NOTE: The internal parts of the pump used
in the extractor are suitable for use with
most carpet cleaning chemicals. However, it
is susceptible to chemical attack from
cleaning substances, such as hydrocarbon
solvents and chlorinated bleaches. These
noncombustible materials are not of the
type normally used for carpet cleaning.

ToOrderPartsCall1-888-702-5326-https://monsterfloorequipmentparts.com
OPERATION
86039020 VOYAGER E 08/20/07
3-4
1. Remove dome lid.
4. Replace dome lid.
3. Add cleaning chemical.
2. Add water.

ToOrderPartsCall1-888-702-5326-https://monsterfloorequipmentparts.com
OPERATION
86039020 VOYAGER E 08/20/07 3-
5
STEP 1
A
DJUST
1. Remove cord from storage bin.
2. Adjust handle to operating position.
3. Plug cord into grounded outlet.
4. Turn Main Power Switch “ON” – “I”

ToOrderPartsCall1-888-702-5326-https://monsterfloorequipmentparts.com
OPERATION
86039020 VOYAGER E 08/20/07
3-6
5. Lift belt tension handle to “Drive” position.
6. Adjust speed control knob to desired speed.
7. Turn vacuum motor on by lowering right hand
lever all the way down.
8. Lower brush to correct setting using left hand
lever, listening for low hum of brush.
INCORRECT
CORRECT

ToOrderPartsCall1-888-702-5326-https://monsterfloorequipmentparts.com
OPERATION
86039020 VOYAGER E 08/20/07 3-7
9. Depress speed lever to propel machine
forward. Pressing forward on levers moves
machine in reverse.
CLEANING PROCEDURE
1. Operate machine in parallel passes. Clean
perimeter last.
2. Use right side of machine for cleaning against
walls.
Foam! Turn off machine and add
defoamer.

ToOrderPartsCall1-888-702-5326-https://monsterfloorequipmentparts.com
OPERATION
86039020 VOYAGER E 08/20/07
3-8
3. To speed drying, use a WINDBLOWER™fan.
4. Empty recovery tank by releasing dump hose.
5. Turn Main Power Switch “OFF” – “O”.
6. Unplug machine. Return cord to storage bin.

ToOrderPartsCall1-888-702-5326-https://monsterfloorequipmentparts.com
OPERATION
86039020 VOYAGER E 08/20/07 3-9
ACCESSORY TOOL USAGE
1. Insert collar over fitting.
2. Insert adapter into vac shoe hose, then insert
accessory tool cuff onto adapter.
4. Turn Main Power Switch “ON” – “I”
Lower vacuum lever to intermediate position.
REMOVE
3. Squeeze handle on accessory tool to begin
cleaning.

ToOrderPartsCall1-888-702-5326-https://monsterfloorequipmentparts.com
MAINTENANCE
86039020 VOYAGER E 08/20/07
4-1
EMPTYING AND CLEANING THE TANKS
Empty the Recovery Tank directly into the floor
drain via drain hose. After each use, rinse tank
(including the float shut-off) with fresh water.
Periodically inspect the recovery tank and
decontaminate if necessary, using a Hospital
Grade Virucide or a 1-10 bleach to water
solution. This will dissipate the exposure to
blood born or infectious contamination. Waste
water should be disposed of properly. Clean the
inside of the recovert dome also.
Empty the Solution Tank by detaching the sight
hose and empty directly into the floor drain.
Flush the Solution System with 1 gallon of
CLEAN water.
NEVER ALLOW
RECOVERED
SOLUTION TO REMAIN IN TANK WHEN NOT
IN USE; NOR ALLOW UNUSED SOLUTION
TO REMAIN IN THE SOLUTION TANK WHEN
IN STORAGE. INSPECT AND CLEAN THE
FILTER LOCATED UNDER THE MACHINE
NEAR THE PUMP. REMOVE AND RINSE
WITH HOT WATER.
To prevent clogged jets due to alkaline build-up,
the spray system should be flushed with 1
gallon of clean hot water at the end of each
work day. The VOYAGER-E is equipped with
“quick change” jets that can be easily removed
for cleaning. To remove – push jet in and rotate.
Do not use pins or wire to remove obstruction
as this will damage jet and alter spray pattern.
QUICK CHANGE JETS
MANIFOLD ASSEMBLY

ToOrderPartsCall1-888-702-5326-https://monsterfloorequipmentparts.com
MAINTENANCE
86039020 VOYAGER E 08/20/07 4-2
VAC SHOE TRACKING
To adjust vac shoe tracking, move eyebolts in
or out to increase or decrease spring force,
respectively, until desired tracking is reached.
VAC SHOE DOWNPRESSURE
NOTE:Downpressure is factory set and
should not require adjustment.
If adjustment of downpressure is required, turn
nut on top of vac shoe clockwise to increase
downpressure and counterclockwise to
decrease downpressure.
VAC SHOE ANGLE
NOTE: The angle of the vac shoe is factory
set and should not require adjustment.
Periodically inpsect the vac shoe angle by
resting it on a hard flat surface. Use a square
to verify 90° angle between the floor and
veritcal surface of the vac shoe.
If adjustment is required, remove one socket on
each lower arm (from the vac shoe or bracket)
and turn clockwise or counterclockwise to
change the angle to the recommended 90°.
Attach the socket on each arm to its respective
location and recheck the angle using the
square. Repeat if necessary.
VAC SHOE
PIVOT ASM. VERTICAL
SURFACE
OF VAC
90°
SQUARE
A
DJUSTMENT
NUTS. REF.
SOCKET
ARM REF.
VAC SHOE TRACKING
EYEBOLTS
(
REF.
)
SIDE VIEW OF VAC
DOWN
PRESSURE
NUT
VAC SHOE
CABLE ASM.
(REF.)
NOTE: USE 90° TOOL
TO VERIFY THAT VAC
SHOE IS ADJUSTED
CORRECTLY TO 90°
ANGLE.
NOTE: ANGLE
ADJUSTMENT
NUTS FOR VAC
SHOE
NOTE: SPRING ATTACHES
FROM CASTER TO VAC SHOE
BRACKET (BOTH SIDES).

ToOrderPartsCall1-888-702-5326-https://monsterfloorequipmentparts.com
MAINTENANCE
86039020 VOYAGER E 08/20/07
4-3
HOLD
BEND UP
ALIGN
&
Do not use a
pressure washer to
clean around the vacuum motors. Use tap
pressure only. Care must be taken so that
water is not directed into vacuum motor air
intakes.
CHANGING VACUUM MOTOR
1. Tip the tank forward for access to the
vacuum motor.
2. Disconnect electrical connector to the
vacuum motor.
3. Loosen clamp and disconnect hose from
vacuum intake.
4. Remove vacuum motor mounting bracket
bolts, which are located on the frame.
5. Remove vacuum motor from mounting
bracket assembly.
6. Reverse steps to install.
MICRO SWITCH REPLACEMENT
1. For brush and reverse switches, align the
two switches and check to see that the
actuator tabs are even to within 1/16 inch. If
required, bend the lower tab up to match the
higher tab.
2. Install the switches with the screws loose
enough to allow the top screw to slide in the
mounting slot.
3. With the lever in the top position, slide the
switches back until they both click, tighten
the switches in this position.
Important:
These brushes wear quicker as the length shortens
due to increased heat. Spring inside brush housing
will damage motor if brushes are allowed to wear
away completely.
Periodically check the length of the carbon brushes.
Replace both carbon brushes when either is less than
3/8" (9.5mm) long.
3/8 (9.5mm)
Vacuum Motor Carbon Brushes Replacement (Ametek)
End Cap
Carbon
Brushes
If armature commutator is grooved, extremely pitted or
not concentric, the motor will need to be replaced or
sen
t to a qualified service center
.
Note:
Place
stop in
groove.
BRUSH & REVERSE SWITCH
