Windsor Dri-Matic User manual

DRI – MATIC
For commercial use only
Pour usage commercial uniquement
86269880-H 06/01/11
PRV NO. 98062

Preparation – Messa in funzione – Preparation - Inbetriebnahme
86269880 10/01/07
2
Preparation Messa in funzione Preparation Inbetriebnahme
1) Handle
2) On - off switch
3) Cable hook
4) Handle connector
5) Swivel neck
6) Brush
7) Storage tray
8) Spot cleaning brush
1) Manico
2) Interruttore
3) Gangio portacavo
4) Spina manico
5) Snodo
6) Spazzolino elicoidale
7) Vaschetta Base
8) Spazzolino smacchiatore
1) Manche
2) Interrupteur mise en marche
3) Support de câble
4) Prise de connexion
5) Nez d’articulation
6) Brosses (2)
7) Couvercle de rangement
8) Brosse manuelle
1) Stiel
2) EIN - Schalter
3) Leitungshaken
4) Stielstecker
5) Gelenk
6) Rundburste
7) Bodenschale
8) Fleckenburste
Press the plunger (11) and
insert the handle into the
swivel neck (12). With the
plunger released the handle
should remain firmly en-
gaged. Pushing the handle
forward sets the handle into
the storage position. Pulling
back releases the handle
into to the operating position.
Spingere il bottone di
blocco (11) e inserire il manico
nello snodo (12).
Il pulsante di blocco deve
scattare all’esterno appena il
blocco e effettuato.
Snodo e mainco si bloccano in
posizione veticale.
Per l’uso spinger sempli-cemente
il manico idietro.
Enfoncer le bouton poussoir (11) pour
connecter le manche sur la rotule
Mobile (12) du carter.
Rastktknopf (11)
drücken und Stiel in das
Gelenk (12) stecken.
Der Rastknopf muß
sichtbar nach auß
kommen, wenn der
Stiel arretiert ist. Inder
senkrecheten stellumg
rastet der Stiel ein. Zum
Abeiten den Stiel
einfach nach hinten
drücken.
The cable (13) should be
stored on the cable cleats.
The lower swivels (14) for
quick release of the cable.
Per svolgere il filo (13) ruotare il
gancio portacavo (14) veso il
basso. Nel riavolgere il cavo non
tenderlo troppo.
Défaire le câble électrique (13) en
faisant pivoter le support supérieur.
Zum Abnehmen der
Anshclußleitung (13)
vom Stiel, den unteren
Leitungshaken (14)
nach open drehen.
Beim Aufwickeln die
leitung night zu stark
spannen.
To remove the machine from
the storage tray (8) press
down the catch (15) and lift
the machine upwards by the
handle.
Per togliere l’apparecchio dalla
vaschetta base (8) agire con la
punta del piede sulla apposita
sporgenza (15) e sollevare verso
l’alto l’apparecchio.
A l’aide du pied dégager le couvercle
de rangement (8) en appuyant sur le
rebord (15).
Beim Entnehmen des
Gerates aus der
Bodenschale (8) mit der
Fußspitze auf die lashe
(15) treten und dad
Gerat am Stiel nach
oben ziehen.
After use replace the
machine in the storage tray.
Dopo l’uso riporre l’apparecchio
nella vaschetta base inserendo la
parte anteriore dell’attrezzo sotto
la sporgenza (16) e spingere
l’apparecchio con il manico veso
il basso. Nella vaschetta base gli
spazzolini ruotano sollevati ed i
residui di polvere restano
raccolto.
Sortir l’appareil verticalement.
Nach Bebrauch das
Gerat wiede in die
Bodenschale stellen.
Gehausevorderkanta
unter die Lasche (16)
schieben und Gerat am
Teiel leicht nach unten
drucken. Durch die
Bodenschale werden
die Bursen entlastet
und Reste des
Reinigungs-pulvers
aufgefangen.

Maintenance – Manutenzione – Ebtretien - Wartung
86269880 10/01/07
3
Maintenance Manutenzione Entretien Wartung
To change the brush (7) first
remove the two screws (17)
from the Bearing Block (18)
then push forward the top of
the brush together with the
block.
Per sostituire le spazzole tonde
(7)) sitare le viti (17) del
supostrare spazzolino e bronzina
dalla sede.
Pour sortir les brosses (7)
dévisser les vis (17) et enlever
les plaquettes (18).
Zum Wechsein der Rund-
burste (7) die beiden
Schrauben (17) am
Burstenlager (18) losen und
das Lager mit der Burste
etwas aus dem Gehause
schwenken.
Take the block off the brush
then lift the brush upwards
out of the brush housing.
To thoroughly clean the
DUO and the brush it is
recommended that the
brushes are taken out to of
the machine.
Togliere il supporto bronzina e
sfilare la spazzola il senso
longitudinale da telaio.
Si consiglia l’asportazione
delle due spazzole per
effettuare la pulizia a fondo del
DUO.
Sortie la brosse en la tirant
vers soi sans forcer sur
l’entraîneur, la secouer et la
frotter.
Das Burstenlager abnehmen
und die Burste in
Langsrichtung aus dem
Gehause ziehen.
Zur grundlichen Reinigung
das DUO und der Bursten,
empfiehlt es sich, die
Rundbrusten aus dem Gerat
zu nehmen!
To replace the brush insert
the slotted end into the
housing first and locate the
slots over the drive cog (19)
by turning the brush. With
the brush located pull the
brush forward slightly to
enable the bearing block to
be replaced then push the
block back into its place in
the brush housing and
replace the two screws.
Per rimontare le spazzole:
spingere il lato spazzola con
incastro sul transinatore (19))
ruotando la spazzola fino a farli
conbaciare, rimontare il supporto
bonzina sulla spazzola ed iserirlo
nell’apposita scanalatura.
Pour le remontage, enfoncer le
guide de la brosse dans son
entraineur (19) et positionner
en faisant pivoter légèrement
celle-ci. Remettre la plaque e
visser.
Beim Wiedereinsetzen der
Rundburste die Mitnahmeseite
der Burste auf den Mitnehmer
(19) stecken und durch
Drehen beide Teile
miteinander verrasten. Das
Burstenlager wieder
aufstecken und in das
Gehause schwenken, der Steg
auf dem lager muß dabei ub
due Gehauserille geschoben
werden.

Parts List
86269880 10/01/07
4
23
2
9
3
2
1
11
12
13
21
20
19
2
17
7
16
15
14
50
49
48
47
44
45
22
30
29
26
25
27
2
28
31
2
32
50
41
40
26
33
13
35
38
39
22
71
52
56
58
53
61
60
58
59
13
58
72
54
61
56
56
57
55
62
63
2
64
54
65
22
69
66
67
68
70
37
51
34

Parts List
86269880 04/05/11 5
Pos
No. Part No. Prv No. Description
1 86139110 1030UL CABLE CLAMP
2 86352670 106ER SCREW 3.9 X 13
3 86142280 3125 HANDLE CABLE DR1
4 - - -
5 - - -
6 - - -
7 86144830 0127ER SCR, M4 X 10
8 - - -
9 86139330 5433DG CABLE
10 - - -
11 86142340 5296EW HANDLE GRIP
12 86000880 0532EW SWITCH / BLUE
13 86147060 0105 SCR, M3.9 X 19 MM DIN7981CPLT
14 86140030 5352HG CLAMP, CPL GREY
15 86147140 0129 SCR, M4 X 12 MM
16 86142260 3115 HANDLE TUBE, DR1
17 86352600 3118hg CABLE HOOK, DR1
18 - - -
19 86142200 3027 HANDLE CONNECTOR COVER
20 86299380 3113hg HANDLE CONNECTOR
21 86140270 1020UL CONTACT COVER , 3 WIRE
22 86016900 0103 SCR, M3,9 X 16 MM DIN 7981
23 86349110 3122/G HANDLE CLP W/BOX
25 86352610 3033hg STORAGE TRAY DRI
26 86352620 2007MG BUMPER DRI
27 86140920 3005 DRIMATIC BRUSH
28 86352630 3002hg BASE PLATE DRI
29 86147080 0112 SCR, M4 X 15 MM
30 86352640 3010hg PLASTIC/MTL AXLE GUIDE, RH
31 86138530 3001bl BRUSH HOUSING
32 86142220 3032 HANDLE STOP SPRING
33 86146170 0502 TERMINAL BLOCK
34 86143540 3049ER MOTOR 115V/200W
- 86143550 3084ER MOTOR, 100V 200W CPL
- 86139380 05095S CARBON BRUSH SET 1210V
35 86144880 0174 SCREW, BRIDGE SR
37 86140930 3038 DRIVE BELT
38 86147170 0176 SCREW M4 X 30
39 86140660 3004bl COVER
40 86146690 0808UL WIRE ASM SWIVEL NECK 2-WIRE
41 86145190 0149 SPACER WASHER
44 86144080 2438hg PLUNGER, VSM 2 PIECE
45 86144070 2423 PLUNGER SPRING
47 86352690 2022hg SWIVEL NECK COVER
48 86352700 3110hg SWIVEL NECK, DRI
49 86352710 3123hg SWIVEL NECK ASM DRI
50 86145960 3051 SWIVEL NECK SUPPORT ASM , DR1
51 86143520 3014 MOTOR PULLEY, DR1
52 86140020 3030 CLAMP
53 86144450 3013 PULLEY
54 86140940 3042 DRIVE BELT
55 86141920 3022 GEAR WHEEL 34
56 86145200 3036 SPACER
57 86145100 3037 SHAFT, LH
58 86352090 0241 BALL BEARING W/RACE
59 86144460 3015 PULLEY
60 86138350 3039 BRIDGE
61 86145090 3035 SHAFT, RH
62 86141910 3021 GEAR WELL
63 86144480 3018 PULLEY
64 86352650 3071 CLIP DRI
65 86141310 3040 END PLATE
66 86144440 3009 PULLEY
67 86352660 3028 SPRING
68 86138550 3007 BRUSH DRIVE COG
69 86352720 3074hg PLASTIC/MTL BRUSHING LH DRI
70 86352730 3052hg PLASTIC BLOCK ASM DRI
71 86144470 3017 PULLEY
72 86144490 3056 PULLEY 12 R/MS

Parti di ricambio
86269880 10/01/07
6
23
2
9
3
2
1
11
12
13
21
20
19
2
17
7
16
15
14
50
49
48
47
44
45
22
30
29
26
25
27
2
28
31
2
32
50
41
40
26
33
13
35
38
39
22
71
52
56
58
53
61
60
58
59
13
58
72
54
61
56
56
57
55
62
63
2
64
54
65
22
69
66
67
68
70
37
51
34

Parti di ricambio
86269880 04/05/11 7
Pos.
No. Parti No. Prv No. Description
1 86139110 1030UL Fascetta
2 86352670 106ER Vite 3.9 x 13
3 86142280 3125 Cavo interno
4 - - -
5 - - -
6 - - -
7 86144830 0127ER Vite taptie M4 x 10
8 - - -
9 86139330 5433DG Cavo 2 x 1 (USA)
10 - - -
11 86142340 5296EW Impugnature
12 86000880 0532EW Interrutotore
13 86147060 0105 Vite 3,9 x 19
14 86140030 5352HG Pinza porta accessory
15 86147140 0129 Vite Taptite M4 x 12
16 86142260 3115 Manico
17 86352600 3118hg Gangio portacavo
18 - - -
19 86142200 3027 Coperchio contatti
20 86299380 3113hg Spina manico
21 86140270 1020UL Copertura contatti
22 86016900 0103 Vite 3,9 x 16
23 86349110 3122/G Clp w/box della maniglia
25 86352610 3033hg Vaschetta base
26 86352620 2007MG Paracolpi
27 86140920 3005 Spazzola
28 86352630 3002hg Piastra base
29 86352640 0112 Vite M4 x 12 A2
30 86352640 3010hg Porta cuschinetto destro
31 86138530 3001bl Copri spazzola DUO
32 86142220 3032 Molla
33 86146170 0502 Mammuth 2-ouli
34 86143540 3049ER Motore 200 W/120 V
- 86143550 3084ER Motore 200 W/100 V
- 86139380 05095S Carboncino
35 86144880 0174 Vite 3,9 x 22
37 86140930 3038 Cinghia HTD 3M
38 86147170 0176 Vite 3,9 x 30 A2
39 86140660 3004bl Calotta superiore DUO
40 86146690 0808UL Spina pitta
41 86145190 0149 Spessore 18/25
44 86144080 2438hg Pulsante snudo
45 86144070 2423 Molla pulsante
47 86352690 2022hg Coperchio
48 86352700 3110hg Snodo
49 86352710 3123hg Snodo completa
50 86145960 3051 Bronzina completa
51 86143520 3014 Puleggia motore
52 86140020 3030 Copri cuscinetto
53 86144450 3013 Rondella cinghia 12
54 86140940 3042 Cinchia dentat HTD
55 86141920 3022 Ruota dentat 34 sin.
56 86145200 3036 Anello
57 86145100 3037 Perno dx
58 86352090 0241 Cuscinetto 626
59 86144460 3015 Rondella cinghia 12
60 86138350 3039 Pora bronzina
61 86145090 3035 Perno M6 sin.
62 86141910 3021 Ruota dentate dx
63 86144480 3018 Ronella cinghia 37
64 86352650 3071 Clip
65 86141310 3040 Puleggia cinghia 25
66 86144440 3009 Rondella cinghia 25
67 86352660 3028 Molla
68 86138550 3007 Trascinatore spazzola
69 86352720 3074hg Porta cuscinetto
70 86352730 3052hg Porta cuschinetto sin. Compl.
71 86144470 3017 Rondella cinghia 60
72 86144490 3056 Pullegia 12 r/ms

Pièces détachées
86269880 10/01/07
8
23
2
9
3
2
1
11
12
13
21
20
19
2
17
7
16
15
14
50
49
48
47
44
45
22
30
29
26
25
27
2
28
31
2
32
50
41
40
26
33
13
35
38
39
22
71
52
56
58
53
61
60
58
59
13
58
72
54
61
56
56
57
55
62
63
2
64
54
65
22
69
66
67
68
70
37
51
34

Pièces détachées
86269880 04/05/11 9
No. Part No. Prv No. Description
1 86139110 1030UL Bride de serrage
2 86352670 106ER Vis 3.9 x 13
3 86142280 3125 Protégé câble
4 - - -
5 - - -
6 - - -
7 86144830 0127ER Vis Taptite M4 x 10
8 - - -
9 86139330 5433DG Cable électrique (USA)
10 - - -
11 86142340 5296EW Poignée plastique
12 86000880 0532EW Interrupteur
13 86147060 0105 Vis 3,9 x 19
14 86140030 5352HG Clips de brosse manuelle
15 86147140 0129 Vis Taptite M4 x 12
16 86142260 3115 Tube alu
17 86352600 3118hg Support de câble
18 - - -
19 86142200 3027 Plaquette AR de marche
20 86299380 3113hg Embase plastique
21 86140270 1020UL Connexion électrique plastique
22 86016900 0103 Vix 3,9 x 16
23 86349110 3122/G Clp w/box de poignée
25 86352610 3033hg Couvercle inferier de rangement
26 86352620 2007MG Pare-chocs
27 86140920 3005 Brosse
28 86352630 3002hg Plaque centrale
29 86147080 0112 Vis M4 x 12 A2
30 86352640 3010hg Plaque de brosse gauche
31 86138530 3001bl Plaque centrale
32 86142220 3032 Plaquette de blocage
33 86146170 0502 Domino
34 86143540 3049ER Moteur 200 w/120 V
- 86143550 3084ER Moteur 200 w/100 V
- 86139380 05095S Charbon moteur de brosse
35 86144880 0174 Vis 3,9 x22
37 86140930 3038 Courroie crantée moteur
38 86147170 0176 Vis M4 x 30 A2
39 86140660 3004bl Carter supérieur
40 86146690 0808UL Fil électrique
41 86145190 0149 Rondelle 18/25
44 86144080 2438hg Bouton poussoir fixation manche
45 86144070 2423 Ressort
47 86352690 2022hg Plaquette AR de rotule
48 86352700 3110hg Net d’articulation
49 86352710 3123hg Rotule complet de manche
50 86145960 3051 Palier complet de fixation
51 86143520 3014 Poulie motrice 19
52 86140020 3030 Palier support
53 86144450 3013 Poulie 12 RH
54 86140940 3042 Courroie crantée secondaire
55 86141920 3022 Pignon blanc dentèle 34 LH
56 86145200 3036 Axe
57 86145100 3037 Axe M6 RH
58 86352090 0241 Roulement 626
59 86144460 3015 Pignon crantée 12 LH
60 86138350 3039 Fixation supérieure
61 86145090 3035 Axe M6 LH
62 86141910 3021 Pignon blanc dentèle 34 RH
63 86144480 3018 Pignon noir dentèle 37
64 86352650 3071 Agrafe
65 86141310 3040 Plaquette d’entraînement
66 86144440 3009 Pignon d’entraînement dentèle 25
67 86352660 3028 Ressort
68 86138550 3007 Entraînement plastique
69 86352720 3074hg Entraînement de brosse
70 86352730 3052hg Entraînement cpl de brosse
71 86144470 3017 Pignon dentèle 60
72 86144490 3056 Poulie 12 R/Ms

Teileverzeichnis
86269880 10/01/07
10
23
2
9
3
2
1
11
12
13
21
20
19
2
17
7
16
15
14
50
49
48
47
44
45
22
30
29
26
25
27
2
28
31
2
32
50
41
40
26
33
13
35
38
39
22
71
52
56
58
53
61
60
58
59
13
58
72
54
61
56
56
57
55
62
63
2
64
54
65
22
69
66
67
68
70
37
51
34

Teileverzeichnis
86269880 04/05/11 11
Pos. Teil-Nr. Prv No. Benennung
1 86139110 1030UL Zugentlastungsschelle
2 86352670 106ER Schraube 3,9 x 13
3 86142280 3125 Stielleitung
4 - - -
5 - - -
6 - - -
7 86144830 0127ER Schraube Taptite m4x10
8 - - -
9 86139330 5433DG AnschluBleitung (USA)
10 - - -
11 86142340 5296EW Griff
12 86000880 0532EW Schalter
13 86147060 0105 Schraube 3,9 x 19
14 86140030 5352HG Zubehorklammer
15 86147140 0129 Schraube Taptite M4x12
16 86142260 3115 Stiel
17 86352600 3118hg Leitungshaken
18 - - -
19 86142200 3027 Stielstecker-Abdeckung
20 86299380 3113hg Stielstecker
21 86140270 1020UL Kontaktabdeckung
22 86016900 0103 Schraube 3,9 x 16
23 86349110 3122/G Handgriff clp w/box
25 86352610 3033hg Bodenschale
26 86352620 2007MG StoBbandage
27 86140920 3005 Rundburste
28 86352630 3002hg Bodenplatte
29 86147080 0112 Schraube M4 x 10 A2
30 86352640 3010hg Lager, rechts
31 86138530 3001bl Unterteil duo
32 86142220 3032 Rastfeder
33 86146170 0502 Reihenklemme 2-polig
34 86143540 3049ER Motor 200 W/120 V
- 86143550 3084ER Motor 200 W/100 V
- 86139380 05095S Kohleburstenset
35 86144880 0174 Schraube 3,9 x 22
37 86140930 3038 Zahnriemen HTD 3M
38 86147170 0176 Schraube M4 x 30 A2
39 86140660 3004bl Oberteil, duo
40 86146690 0808UL Flachstecker, kpl.
41 86145190 0149 PaBscheibe 18/25
44 86144080 2438hg Rastknopf, kpl.
45 86144070 2423 Druckfeder
47 86352690 2022hg Deckel
48 86352700 3110hg Gelenk
49 86352710 3123hg Gelenk, kpl.
50 86145960 3051 Gelenklager, kpl.
51 86143520 3014 Motorritzel 19
52 86140020 3030 Lagerdeckel
53 86144450 3013 Riemenscheibe
54 86140940 3042 Zahnriemen HTD 5M
55 86141920 3022 Stirnrad 34 L
56 86145200 3036 Lagerring
57 86145100 3037 Rizelwelle M6 re
58 86352090 0241 Kugellager 626
59 86144460 3015 Riemenscheibe 12L
60 86138350 3039 Lagerbrucke
61 86145090 3035 Ritzelwelle M6 li
62 86141910 3021 Stirnrad 34 R
63 86144480 3018 Riemenscheibe 37
64 86352650 3071 Klipp
65 86141310 3040 Scheibenmit-nehmer
66 86144440 3009 Riemenscheibe 25
67 86352660 3028 Frűhling
68 86138550 3007 Burstenmitnehmer
69 86352720 3074hg Burstenlager, links
70 86352730 3052hg Lager, links, kpl.
71 86144470 3017 Riemenscheibe 60
72 86144490 3056 Riemenscheibe 12 R/Ms

Attachments – Accessori - Accessoires - Zubehör
86269880 10/01/07
12
Attachments
(1) duo-P Cleaning Powder
(2) Spot Cleaning brush
(3) Storage Tray
Accessori
(1) duo-P Polvere
(2) Spazzola smacchiatore
(3) Vaschetta base
Accessoires
(1) Poudre duo-P
(2) Brosse manuelle
(3) Couvercle de rangement
Zubehör
(1) duo-P Reinigungspulver
(2) Fleckenbürste
(3) Bodenschale
Never run the machine over the
cable.
Non passare con l’apparecchio
sul cavo.
Ne jamais passer sur le
cable avec la machine.
Mit dem Gerät nicht über
die Anschlußeitung
fahren!
CAUTION: Always unplug the
machine at the mains outlet
before dismantling any part of
the machine.
Per tutti I lavori di riparazione e
manutenzione togliere la spina
dalla presa.
ATTENTION: Toujours
débrancher la machine au
niveau de la prise secteur
avant de demonter quelque
partie que ce soit.
Bei allen Reinigungs-und
Wartungs-arbeiten am
Gerät Stecker aus der
Steckendose ziehen!
Technical Details Dati tecnici Détails techniques Technische Daten
Width . . . . . . . . 355 mm Larghezza . . . . . 355 mm Largeur . . . . . . 355 mm Breite . . . . . . 355 mm
Height . . . . . . . . 119 mm Altezza . . . . . . . 119 mm Hauteur . . . . . . 119 mm Höhe . . . . . . . 119 mm
Weight . . . . . . . . . 5 kg Peso . . . . . . . . . . 5 kg Poids . .. . . . . . . . 5 kg Gewicht . . . . . . . 5 kg
Brush Motor . . . . .200 Watt Motore Trascinamento
200 Watt
Moteur de brosses
200 Watts
Antriebsmotor. . .200 Watt
Cable . . . . . . . . 12,2 m Cavo alimentazione . 12,2 m Longueur du cable . 12,2 m Anschlußleitung. . . 12,2 m
2 Brush System Numero giri spazzola Vitesse de rotation Bürstendrehzahl 400U/min
Brush Revolutions 400 rpm 400/min Des 2 brosses 400 tr/min 2-Bürstensystem
2 Spazzola controrotanti
Approvals

North American New Machine Warranty
Effective on all products shipped AFTER February 28, 2011
Windsor reserves the right to change its warranty policy without notice.
Windsor • 1351 West Stanford Avenue • Englewood, CO 80110 USA
Tel [phone] • Financial Service 800-804-6804 • Fax [phone] • email: [email protected] • www.windsorind.com
A
member of KÄRCHER North America 86019540 REV 11
Limited Warranty
Windsor warrants new machines against defects in material and workmanship under normal use and service to the original purchaser. Any
statutory implied warranties, including any warranty of merchantability or fitness for a particular purpose, are expressly limited to the
duration of this written warranty. Windsor will not be liable for any other damages, including but not limited to indirect or special
consequential damages arising out of or in connection with the furnishing, performance, use or inability to use the machine. This remedy
shall be the exclusive remedy of the buyer. The warranty period is subject to the conditions stated below.
10 / 3 Warranty: 10 Years Polyethylene (PE) Housings, 3 Years Parts, and Service Labor
Subject to conditions outlined below, Windsor warrants rotationally molded PE housings and parts on all of its machines to be free from
defects in material and workmanship, under normal use and service for ten (10) years to the original owner.
Under this warranty we guarantee the performance of non-polyethylene parts and components to be free from defects for up to three (3)
years to the original end user. Parts replaced or repaired under this warranty are guaranteed for the remainder of the original warranty
period. (See table below)
Service labor charges are covered for up to three (3) years from the date of purchase through authorized Windsor service provider. No
travel coverage is extended for cord-electric models. See table below for each general product model warranty coverage.
Upright Vacuums:
Upright Vacuums Exceptions and Exclusions:
Normal wear items not limited to brushes, foot pedal, cords, clutches, filters, gaskets, hoses, and bearings will be warranted for
manufacturing defects for 90 days from the purchase date. All other items are 1 year parts and labor.
All Other Products:
Product exceptions and Exclusions:
•Extractor brush motors, ALL pump motors, ALL PC boards and electronics, ALL Vacuum motors, ALL pumps, and diaphragms/Tank
bags carry a one (1) year parts and service labor warranty.
Product Non- PE Parts Service Labo
r
Belts Lifetime 1 year
Vacuum Motor, Swivel Neck and Chassis 3 years 3 years
Versamatic®/Flexamatic®/Axcess
Brush Motor, and Bag Housing 5 years 5 years
Belts Lifetime 1 year
Vacuum Motor and Chassis 2 years 2 years
Sensor®
Bag Housing 5 years 5 years
Product PE Housing & Parts Non- PE Parts Service Labo
r
Travel
Rider / Stand up Scrubbers 10 years 3 years or 2000 hours 3 years or 2000 hours 6 Months
Rider/ Stand-up Vacuum, Burnishers 10 years 3 years or 2000 hours 3 years or 2000 hours 6 Months
Rider Sweepers/Escalator Cleaner 10 years 3 years 3 years 6 Months
Walk Behind Scrubbers 10 years 3 years or 2500 hours 3 years or 2500 hours 6 Months
Walk Behind Sweepers 10 years 3 years 3 years 6 Months
Battery Burnishers 10 years 3 years 3 years 6 Months
Extractors / Compass 10 years 3 years 3 years -
Polishers / Elec. Burnishers / GH/iCapsol Mini 10 years 3 years 3 years -
Wide Areas Vacuums 10 years 3 years 3 years -
VacPac Vacuums/Recovery 18 10 years 1 year 1 year -
Tracer/Flex Sweepers/ Scrubbers 10 years 3 years 3 months 90 days
Air Movers/Dri-matic/ TITAN™/Rombus/Priza 1 year 1 year 1 year -
Canister Vacuum 1 year 1 year 1 year -
Wet/Dry Vacuum 1 year 1 year 1 year -
Broom/Steamer 1 year 1 year 1 year -
Propane Burnishers / Strippers - 2 years 1 year -

North American New Machine Warranty
Effective on all products shipped AFTER February 28, 2011
Windsor reserves the right to change its warranty policy without notice.
Windsor • 1351 West Stanford Avenue • Englewood, CO 80110 USA
Tel [phone] • Financial Service 800-804-6804 • Fax [phone] • email: [email protected] • www.windsorind.com
A
member of KÄRCHER North America 86019540 REV 11
•The Eagle-Robin®engines have three (3) year manufacturer’s warranty. The Honda®and Kawasaki®engines have two (2) year
manufacturer’s warranty. NOTE: The engine warranty is administered through the engine manufacturer and must be repaired at an
authorized service center.
Normal wear items and accessories including, but not limited to, belts, brushes, carbon brushes, clutches, cords, filters, finishes, gaskets,
hoses, light bulbs, squeegees, bearings, actuating cables, tires, and propane tanks will be warranted for manufacturing defects for 90-days
from the purchase date.
The warranty commences on the purchase date by the original end user from an authorized Windsor agent, subject to proof of purchase.
The Machine Registration Card must be completed and returned immediately at the time of purchase. If proof of purchase cannot be
identified, the warranty start date is 90 days after the date of sale to an authorized Windsor distributor. Parts replaced or repaired under
warranty are guaranteed for the remainder of the original warranty period.
90 Day Warranty Extension Available
Upon receipt of the Machine Registration Card, Windsor will extend by 90 days, from the date of purchase, all items included under the
one-year provision. This applies only to one-year items and does not include 90-day wear items.
This Warranty Shall Not Apply To:
1. Any product that has been subject to abuse, misuse, neglect or unauthorized alteration (including the use of incompatible or
corrosive chemicals or overloading of capacity).
2. Products that have experienced shipping or freight damage.
3. Repairs necessary to correct any failure due to improper pre-delivery service and inspection by the selling dealer.
4. Excessive time for cleaning units in preparation for repair.
5. Any repairs resulting from poor initial service work or improper diagnosis.
6. Tune-up parts such as plugs, plug wires and condensers.
7. Any design alterations performed by an organization not authorized or specified by Windsor.
8. Battery and charger warranties are handled directly with the manufacturer (Trojan®batteries and Lester®chargers).
9. High-pressure washing.
10. Electrical components exposed to moisture.
If difficulty develops during the warranty period, contact the authorized Windsor agent from whom the product was purchased. Windsor
Industries may elect to require the return of components to validate a claim. Any defective part to be returned must be shipped freight
prepaid to an authorized Windsor Distributor/Service Center or to the Windsor factory.
Use Of Parts Not Approved By Windsor Will Void All Warranties
This warranty is valid only for all products Shipped/Sold AFTER February 28, 2011. A product sold before that date shall be covered by the
limited warranty in effect at the date of sale to the original purchaser.

DRI-MATIC
Warranty Registration
Thank you for purchasing a Windsor product. Warranty registration is quick and easy.
Your registration will allow us to serve you better over the lifetime of the product.
To register your product go to:
www.windsorind.com/WarrantyRegistration.aspx
For customer assistance:
1-888-444-7654
Enregistrement de Garantie
Merci d'acheter un produit de Windsor. L'enregistrement de garantie est rapide et facile.
Votre enregistrement nous permettra de vous servir mieux au-dessus de la vie du produit.
Pour enregistrer votre produit allez :
www.windsorind.com/WarrantyRegistration.aspx
Pour l'aide de client :
1-888-444-7654
Registro Rella Garanzia
Grazie per l'acquisto del prodotto di Windsor. Il registro della garanzia è rapido e
facile. Il vostro registro permetterà che noi lo serviamo più meglio sopra il corso
della vita del prodotto. Per registrare il vostro prodotto vada:
www.windsorind.com/WarrtyRegistration.aspx
Per assistenza del cliente:
1-888-444-7654
Garantie-Ausrichtung
Danke für den Kauf eines Prochem Produktes. Garantieausrichtung ist schnell und
einfach. Ihre Ausrichtung erlaubt uns, Sie über der Lebenszeit des Produktes besser zu
dienen. Um Ihr Produkt zu registrieren gehen Sie:
www.prochem.com/WarrantyRegistration.aspx
Für Kundenunterstützung:
1-800-776-2436

86269790-E 05/25/11 06636 05/25/11
