Winegard AIR 360+ User manual

Winegard AIR 360+
OMNIDIRECTIONAL TV/FM ANTENNA
+WIFI + 4G EXTENDER*
*when paired with compatible Winegard Gateway (GW-1000)
Amplified Local HD & Digital Broadcast TV/FM Antenna
for VHF & UHF Digital and HD TV Channels
Long range WiFi + 4G Antennas
Operation Guide
Models AR-1035, AR-2035, AR-360J
For help, email [e-mail]
or call 1-800-320-9992
2452434
Rev1 7-19
ATSC 3.0 Ready
HD Ready

Specifications / Features
• Designed for RV use
• Durable UV and weather resistant
• 360° Signal Reception
• High Definition VHF/UHF Digital Signals
• ATSC 3.0 Ready
• Amplified
• State of the art pHEMT technology with
4G LTE Filter
• Range – Up to 55 miles*
• Height – 8.05"
• Diameter of dome – 18.2"
*Antenna mileage figures based on average
terrain. Actual receiving distance will vary
based on transmitting power, transmitting
antenna tower height, global pattern of
transmitter, height of receiving antenna,
weather conditions, & terrain between receiving
path including trees, buildings, hills,
mountains, etc.
Scan monthly
for programming
updates.
Perform Channel Scan:
Select Menu, then
Channel Search
Scan. Watch.
• Frequency Range:
– VHF 54 to 216 MHz
– UHF 470 to 700 MHz
– FM 87.5-108 MHz
– AM 520-1710 KHz (Model AR-360J only)
• Gain – 18 dB
• Noise – 1 dB
• Impedance – 75 ohms
• Power Supply – DC 12V
• (1) WiFi antenna**
• (2) LTE antennas**
** For use with the Winegard Gateway
WINEGARD COMPANY
Tolerances
unless noted:
18.20
8.05
AIR 360 PLUS DIMENSIONS
TRADE SECRET
The information and data contained herein is secret and shall not be disclosed,used or duplicated
for any purpose whatsoever without written permission of WINEGARD COMPANY, 3000 Kirkwood ST.,
Burlington, Iowa 52601. This legend shall be marked on any reproduction hereof in whole or in part.
Reciept of this document shall be deemed acceptance of the conditions specified herein.
.XX
.XXX
HOLE
ANGLE
ECN NO. DATE REV DESCRIPTION BY
P/N: CONNECT_2_PREWIRE_BASE_DOME_2 DRAWN BY: D. NEUWEG
SCALE: 0.200 DATE: Mar-28-19
SHEET 1of 1
DWG: AIR_360_PLUS_DIMENSIONS
8.05” Ht.
18.2” Dia.
First time users must run a channel
scan to receive maximum programming.
Ensure the antenna power supply (wall plate)
is in the “ON” position and the green indicator
light is illuminated.
A new scan will find any new channels that
have been added in your area as well as finding
any channels that have changed or moved
since the last scan.
While the steps to perform a channel scan may
vary between televisions or compatible devices,
on the following page are some general
guidelines to follow.
Power indicator light is
green when power is on.
Power button

How to Run a Channel Scan
Using the television remote, select “Menu” and then “Settings.”
Select “Channel Setup.”
Select “Antenna” or “Air,” depending on your TV. Make sure you are not on “Cable.”
Select “Channel Search” or “Channel Scan.” Keep in mind that steps to perform
a channel scan may vary. If the wording in your TV differs from the options shown,
refer to your TV user manual for help.
Running a channel scan is NOT the same as pressing Channel UP/
DOWN on your remote.
To receive maximum programming, you have to run a channel scan after setting
up the antenna. To keep your channel line-up up-to-date, it is a good idea to run a
channel scan monthly, anytime a channel is lost, and anytime you change locations.
Winegard App TV Signal Finder with AR
FREE DOWNLOAD
Finding your favorite TV programming has never been easier! Using
your current location, the app searches for all available signals and
determines the correct antenna positioning.
Antenna Pointer – Use the top-down map view to locate all HDTV
towers closest to your address or GPS location. Eliminate signal
obstructions such as trees, hills, and buildings by switching to
the AR view. Simply point your phone to the horizon and rotate 360 degrees to
bring into view your desired TV tower and find where the local channels are in your
location. The number displayed above a tower indicates the number of channels
available. Tap the tower icon to see full channel details.
Avoid obstructions with the augmented reality (AR)* view.
*May not work on smartphones without sensors.
Winegard Gateway
The Winegard Gateway is compatible with
the Winegard Air 360+ONLY. It is the
accompanying piece to take your Air 360+
to the next level in Connectivity.
For more information please visit
www.winegard.com/gateway or visit
www.winegard.com/find-a-dealer to find
a dealer in your area.
GW-1000

Winegard Company • 2736 Mt. Pleasant Street • Burlington, IA 52601 • 1-800-288-8094
• Fax [phone] • www.winegard.com
Apple and the Apple logo are trademarks of Apple Inc., registered in the U.S. and other countries. App Store
is a service mark of Apple Inc., registered in the U.S. and other countries. Google Play and the Google Play
logo are trademarks of Google LLC. Winegard is a registered trademark of Winegard Company.
Printed in U.S.A. ©2019 Winegard Company Rev1 7-19 2452434
WINEGARD MOBILE PRODUCTS LIMITED WARRANTY
(2 YEARS PARTS; 1 YEAR LABOR)
Winegard Company warrants this product against defects in materials or workmanship for a period of two (2) years from
the date of original purchase. During year one (1) of such warranty, Winegard Company will also pay authorized labor
costs to an authorized Winegard dealer to repair or replace defective products. No warranty claim will be honored unless
at the time the claim is made, Customer presents proof of purchase to an authorized Winegard dealer (to locate the
nearest authorized Winegard dealer, contact Winegard Company, 3000 Kirkwood Street, Burlington, Iowa 52601, Telephone
800-288-8094 or visit www.winegard.com). Customer must provide proof of purchase with a dated sales receipt for the
Winegard product to verify the product is under warranty. If the date of purchase cannot be verified, the warranty period
shall be considered to begin thirty (30) days after the date of manufacture.
If a defect in material or workmanship is discovered, Customer may take the product to an authorized Winegard dealer
for service. Customer must provide proof of purchase to verify the product is under warranty. If the product is brought to
an authorized Winegard dealer for service prior to expiration of year one (1) of the warranty period and a defect in material
or workmanship is verified by Winegard Technical Services, Winegard Company will cover the Winegard dealer’s labor
charges for warranty service. The Winegard dealer must contact Winegard Technical Services in advance for pre-approval
of the service. Approval of the service is at the sole discretion of Winegard Company.
Alternatively, Customer may ship the product prepaid to Winegard Technical Services (located at 2736 Mt. Pleasant
Street, Burlington, Iowa 52601, Telephone [phone]). Customer must return the product along with a brief
description of the problem and provide Winegard Technical Services with Customer’s name, address, and phone number.
Customer must also provide proof of purchase to verify the product is under warranty. If the product is returned before the
expiration of the warranty period, Winegard Company will (at its option) either repair or replace the product.
This Limited Warranty does not apply if the product has been damaged, deteriorates, malfunctions or fails
from: improper installation, misuse, abuse, neglect, accident, tampering, modification of the product as originally
manufactured by Winegard in any manner whatsoever, removing or defacing any serial number, usage not in accordance
with product instructions or acts of nature such as damage caused by wind, lightning, ice or corrosive environments
such as salt spray and acid rain. This Limited Warranty also does not apply if the product becomes unable to perform its'
intended function in any way as a result of the television signal provider making any changes in technology or service.
RETURN AUTHORIZATION POLICY
A Return Material Authorization (RMA) is required prior to returning any product to Winegard Company or Winegard
Warranty Services under this warranty policy. Please call our Technical Services Department at 800-788-4417 or send an
email to [email protected] to obtain the RMA number. Please furnish the date of purchase when requesting an
RMA number. Enclose the product in a prepaid package and write the RMA number in large, clear letters on the outside
of the package. To avoid confusion or misunderstanding, a shipment(s) without an RMA number(s) or an unauthorized
return(s) will be refused and returned to Customer freight collect.
WINEGARD COMPANY DOES NOT ASSUME ANY LIABILITIES FOR ANY OTHER WARRANTIES, EXPRESS OR IMPLIED, MADE BY
ANY OTHER PERSON.
ALL OTHER WARRANTIES WHETHER EXPRESS, IMPLIED OR STATUTORY INCLUDING WARRANTIES OF FITNESS FOR A
PARTICULAR PURPOSE AND MERCHANTABILITY ARE LIMITED TO THE TWO YEAR PERIOD OF THIS WARRANTY.
In states that do not allow limitations on implied warranties, or the exclusion of limitation of incidental or consequential
damages, the above limitations or exclusions do not apply.
Some states do not allow limitations on how long an implied warranty lasts, or the exclusion of limitation of incidental
or consequential damages, so the above limitations or exclusions may not apply to you.
This warranty gives Customer specific legal rights. Customer may also have other rights that may vary from state to
state.
SATELLITE RECEIVER WARRANTY
See manufacturer’s limited warranty policy. WS-MOBWARREV3
