Winegard FreeVision User manual

Register your product at winegard.com/myantenna
Instruction Manual
For help, email [email protected] or call 1-800-788-4417
2452285
Rev3 7-16
U.S. Patent D612,370 & Patent Pending
For Sales Information Please Contact RoadTrucker Inc (www.RoadTrucker.com)
8312 Sidbury Rd.; Wilmington, NC 28411 - [phone] / [phone]

Antenna Assembly
Orient the antenna so that the Winegard logo is facing forward. Flip the
forward elements to the front until the holes in the elements align.
With the holes lined up, install the UHF elements by inserting the
threaded posts into the holes in the forward elements. The threaded posts
should extend down towards the body of the FreeVision®antenna.
Thread the supplied 10-32 hex flange nuts on the back of the threaded
posts. Do not tighten at this time.
Remove and dispose of the rubber boot on the matching transformer.
With the logo facing up, thread coaxial cable through the bottom of the
FreeVision antenna. Connect the coax cable to the matching transformer
(A). Insert the coaxial cable and matching transformer into the installation
place (B).
Coax Cable
Installation Place for
Matching Transformer
Matching Transformer
A B
Forward
Elements
Winegard logo
UHF Elements
2
4
1
3
5
1 2
For Sales Information Please Contact RoadTrucker Inc (www.RoadTrucker.com)
8312 Sidbury Rd.; Wilmington, NC 28411 - [phone] / [phone]

Antenna Assembly, Cont.
Then, slide one of the forks of the matching transformer between the
two forward elements on the threaded post. Repeat this process for the
other post. Tighten the nuts, making sure the matching transformer is still
connected.
Remove the backing from the ‘HD’ label, and carefully place the label
over the front of the UHF element so that it covers the center block of
the elements.
Check that you are within a 35 mile range of the stations that you want to
receive. For a listing of likely channels available in your area, go online to
dtv.gov/maps.
Position the antenna toward the broadcast tower for optimal reception. For
most locations, stations will only come from one or two directions. If the
compass headings are similar (<30° apart), the FreeVision antenna can be
aimed between the two areas and receive signals from each location.
Run a channel scan. If not satisfied with the channels found, try
repositioning the antenna and running another channel scan.
Forward Elements
HD Label
1 2
7
6
9
8
10
For Sales Information Please Contact RoadTrucker Inc (www.RoadTrucker.com)
8312 Sidbury Rd.; Wilmington, NC 28411 - [phone] / [phone]

Mounting the Antenna: Mounting Options
The FreeVision antenna is designed to be mounted either of two ways:
Wall Mounting—The FREEVISION has been designed with holes to allow
it to hang on a wall from a nail.
Mast Mounting—The FreeVision antenna comes with a bracket and U-bolt
to allow for mounting to a pipe or mast. For mounting to a pipe or mast,
first insert the (yellow) 1-3/4” screw into the bracket and through the
mounting hole. Attach the bracket to the back of the FreeVision antenna.
Thread a 10-32 hex flange nut onto the screw, and tighten it.
Once the clamp is attached, assemble the U-bolt around the mast or
pipe, and install the nuts securely to keep the antenna in place.
Hole for Nail
Hole for Nail
Mast U-Bolt
Back Side
of Antenna
3 4
2
1
For Sales Information Please Contact RoadTrucker Inc (www.RoadTrucker.com)
8312 Sidbury Rd.; Wilmington, NC 28411 - [phone] / [phone]

Tips
Consider using an existing satellite or cable coax connection. At the point
where cables enter your home (the grounding box), the antenna can be
hooked up to an existing coax connection. From the grounding box, a coax
cable should run to the TV or power supply (if using an amplifier).
If replacing an existing antenna with the FreeVision antenna, simply
disconnect the coax cable from the existing antenna, and connect the
coax cable to the FreeVision antenna.
If there is a weak or intermittent signal when using an existing coax cable,
there may be a problem with the existing coax cable. Connect one end
of a different coax cable to the antenna and the other end directly to
the TV. If the signal improves, there may be a problem with the existing
coax cable. If you have any questions, please contact Winegard Technical
Services at [email protected] or 1-800-788-4417.
Determine the best mounting location for the antenna—keep in mind that
the higher the antenna is mounted, the better signal you will receive.
Avoid obstructions (such as buildings, trees or hills) between the antenna
and the broadcast tower—these can block signal.
Distance, obstructions and compass heading all play a role in deciding on a
location to permanently mount the antenna. For this reason, try the antenna
in several locations, checking signal on multiple channels to determine the
location that will provide the best signal. Moving the antenna three feet in
one direction is often enough to change the reception.
Refer to wiring diagrams at www.winegard.com/freevision for details on
how to wire the FreeVision antenna so that it enhances your existing cable
or satellite package.
ATTIC
This is the best mounting
option when you want
the antenna to be out of
sight. Signal loss may be
experienced.
OUTDOOR
(roof, side of house, deck)
Direct line of sight from the
antenna to the broadcast
tower provides the strongest
signal strength and maximum
channel reception.
GOOD BETTER
3 4
For Sales Information Please Contact RoadTrucker Inc (www.RoadTrucker.com)
8312 Sidbury Rd.; Wilmington, NC 28411 - [phone] / [phone]

Painting the FreeVision Antenna
The FreeVision antenna can be painted as long as the metal prongs of the
forward elements and the matching transformer forks are not painted. If
you choose to paint the antenna, cover the two circled areas with tape
before painting. If these areas are painted, your antenna will NOT work,
and you will void your warranty.
To prevent paint from easily flaking, use a primer when painting the antenna.
Troubleshooting
Issue Possible Cause
I am not getting channels. Try running a new channel scan
on the TV. Try the antenna in a
new location. Something may be
obstructing the signal.
One channel is missing. Try turning the antenna 10 or 20
degrees in either direction to avoid
reflection or to better optimize the
signal, or try moving the antenna
to a new location.
Try running a new channel scan on
the TV. Refer to the channel scan
insert for more information.
The picture or sound freezes
while I am watching a channel,
or there are boxes in the picture.
This is often caused by a weak
or intermittent signal. Try moving
the antenna to a better location or
aiming it directly at the tower for
this channel.
For help, email [email protected] or call 1-800-788-4417
Forward
Elements Matching
Transformer
5 6
For Sales Information Please Contact RoadTrucker Inc (www.RoadTrucker.com)
8312 Sidbury Rd.; Wilmington, NC 28411 - [phone] / [phone]

5 6
WINEGARD COMPANY ONE YEAR LIMITED WARRANTY
Winegard Company provides a warranty to the original purchaser of new Winegard Products
against proven defects in materials or workmanship for a period of one (1) year from date of
purchase, subject to the terms herein. If a Product covered under this warranty is determined to
be defective within the warranty period, Winegard will, unless otherwise required by applicable
law, either repair or exchange the Product at its sole discretion. This Warranty is non-
transferable, and does not cover products purchased, services or used outside the United States
or Canada. This Warranty does not extend to the elimination of externally generated static or
noises, or use of the products in a location without sufcient signal strength.
How to Obtain Warranty Service (Pre-authorization is required)
To obtain warranty service, contact Winegard Company Technical Support via email: help@
winegard.com or via phone at 800-788-4417 from 7:30 AM to 5:30 PM Monday through
Friday and 8:00 AM to 3:30 PM Saturday, Central Standard Time, or visit www.winegard.com.
PRE-AUTHORIZATION MUST BE OBTAINED BEFORE SENDING ANY PRODUCT TO
WINEGARD. Proof of purchase in the form of a purchase receipt or copy thereof is required to
show that a Product is within the warranty period.
Winegard Company will (at its option) repair or replace the defective product at no charge to
you. This warranty does not cover any costs incurred in removal or reinstallation of the product.
This limited warranty does not apply if the product is damaged, deteriorates, malfunctions or
fails from: misuse, improper installation, abuse, neglect, accident, tampering, modication of
the product as originally manufactured by Winegard Company, usage not in accordance with
product instructions or acts of nature such as damage caused by wind, lightning, ice or corrosive
environments.
WINEGARD COMPANY WILL NOT ASSUME ANY LIABILITIES FOR ANY OTHER
WARRANTIES, EXPRESS OR IMPLIED, MADE BY ANY OTHER PERSON.
THE FOREGOING WARRANTY SHALL BE THE SOLE AND EXCLUSIVE REMEDY OF
ANY PERSON, WHETHER IN CONTRACT, TORT OR OTHERWISE, AND WINEGARD
COMPANY SHALL NOT BE LIABLE FOR INCIDENTAL OR CONSEQUENTIAL
DAMAGE OR COMMERCIAL LOSS, OR FROM ANY OTHER LOSS OR DAMAGE
EXCEPT AS SET FORTH ABOVE. ANY ACTION FOR ANY BREACH OF WARRANTY
HEREUNDER MUST BE BROUGHT WITHIN TWENTY-FOUR (24) MONTHS FROM THE
DATE OF ORIGINAL PURCHASE. IN NO EVENT SHALL WINEGARD COMPANY’S
LIABILITY HEREUNDER EXCEED THE PURCHASE PRICE PAID FOR THE PRODUCT.
Some states do not allow limitations on how long an implied warranty lasts, or the exclusion of
limitation of incidental or consequential damages, so the above limitations or exclusions may
not apply to you.
This warranty gives you specic legal rights and you may also have other rights which vary
from state to state.
