Winegard HD6055P User manual

High Denition (HD)
Platinum Antennas
The Winegard Company warrants this product against any defects in materials
or workmanship within 90 (ninety) days from date of purchase. No warranty claim
will be honored unless at the time the claim is made, you present proof of purchase
to an authorized Winegard dealer (if unknown, please contact Winegard Company,
3000 Kirkwood St., Burlington, IA 52601-2000, 800-288-8094).
Winegard Company (at its option) will either repair or replace the defective
product at no charge to you. This warranty covers parts, but does not cover any
costs incurred in removal, shipping or reinstallation of the product. The warranty
does not extend to products which have been subjected to misuse, improper
installation, or damage caused by wind, lightning, ice or other occurrences over
which the manufacturer has no control.
The 90 Day Warranty is provided on the condition that the equipment is properly
delivered with all handling and freight charges prepaid to your Winegard dealer for
repair or return to our factory at the above address. Winegard dealers will arrange
for the replacement or repair and return to you, without charge, the product which
failed due to defective material or workmanship.
WINEGARD COMPANY WILL NOT ASSUME ANY LIABILITIES FOR ANY
OTHER WARRANTIES, EXPRESS OR IMPLIED, MADE BY ANY OTHER
PERSON.
ALL OTHER WARRANTIES WHETHER EXPRESS, IMPLIED, OR STATUTORY
INCLUDING WARRANTIES OF FITNESS FOR A PARTICULAR PURPOSE
AND MERCHANTABILITY ARE LIMITED TO THE 90-DAY PERIOD OF THIS
WARRANTY.
The foregoing shall be the sole and exclusive remedy of any person,whether
in contract, tort or otherwise, and Winegard shall not be liable for incidental or
consequential damage or commercial loss, or from any other loss or damage
except as set forth above.
Some states do not allow limitations on how long an implied warranty lasts, or
the exclusion of limitation of incidental or consequential damages, so the above
limitations or exclusions may not apply to you.
This warranty gives you specic legal rights and you may also have other rights
which vary from state to state.
90 DAY LIMITED WARRANTY
WARNING
INSTALLATION OF THIS ANTENNA NEAR POWER LINES IS DANGEROUS.
FOR YOUR SAFETY, FOLLOW THE INSTALLATION INSTRUCTIONS.
NOTE
In order to prevent damage in shipment, the second element set of elements from
the rear of the boom are folded to the reverse side. You can identify the elements
because they are tagged. Follow the directions carefully.
Winegard Company • 3000 Kirkwood Street • Burlington, IA 52601-2000
Printed in U.S.A. © Winegard Company 2002 1450169 Rev. 7/08
INSTRUCTIONS
FM MODEL HD6055P
FM
MODEL HD6055P
Rev. 2/08
POINT THIS END TOWARDS
STATIONS

HOW TO PROVIDE
LIGHTNING PROTECTION
FOR TV ANTENNA AND SET
Step 1. Mount the grounding block
as close as possible to where the
75 ohm coaxial cable downlead
enters the house. See Figure 3.
Step 2. The ground wires for both
the mast and the downlead should
be copper or aluminum wire,
number eight (8) or larger. See
Figure 3.
Step 3. The downlead wire from
the antenna to the grounding block
and the mast ground wire should
be secured to the house spaced
from four (4) to six (6) feet apart.
See Figure 3.
NOTE: In the case of a “ground
up” antenna installation, it may not
be necessary to ground the mast
if the mast extends four or more
feet into the earth. Consult a TV
serviceman for the proper depth in
your location.
Fig. 3
STEP 1. Remove antenna from carton
and unfold elements, making certain the
elements lock tightly into place and are
at and parallel to each other.
STEP 2. To attach the cartridge hous-
ing to the antenna, align the snaps
on the cartridge housing with the
snap holes on the cartridge housing
receptacle on the antenna and push
the housing into the receptacle until it
snaps into place. See Figure 1.
STEP 3. Slide weather boot over the
75 ohm coaxial cable. Install connec-
tor and attach the "downlead " to the
connector on cartridge housing. Slide
weather boot over connectors and
boot collar. See Figure 1.
STEP 4. Mount antenna on mast, point front
(smallend) towards stationsand tighten mast
clamp securely. See Figure 2.
STEP 5. The 75 ohm coaxial cable
downlead may be secured to the mast by
taping or use of plastic wire ties.
Fig. 2
1/4" HEX
NUTS
MASTING
2" OD MAX.
Fig. 1
CARTRIDGE HOUSING
RECEPTACLE
75 OHM COAXIAL
CABLE (DOWNLEAD)
BOOT
COLLAR
CARTRIDGE
HOUSING
DOWNLEAD
JACK
WEATHER BOOT
Antenna Lead
In Wire
Ground
Clamp
Electric
Service
Equipment
Antenna
Discharge Unit
(NEC Section 810-21)
Power Service Grounding
Electrode System
(NEC Art 250, Part H)
Ground
Clamps
NEC - National Electrical Code
Example of antenna grounding as per
National Electrical Code, ANSI/NFPA 70
Grounding Conductor
(NEC Art 250, Part H)
Antenna Mast
