Winegard HD7084P User manual

VHF/UHF MODEL
HD7084P & HD7697P
Winegard Company • 3000 Kirkwood Street • Burlington, IA 52601-2000
NOTE
To prevent damage in shipping, the second set of elements from the rear of the
boom are folded to the reverse side. You can identify these elements by the tags
attached to them. Follow the directions on the tags carefully.
WARNING
INSTALLATION OF THIS ANTENNA NEAR POWER LINES IS DANGEROUS.
FOR YOUR SAFETY, FOLLOW THE INSTALLATION INSTRUCTIONS.
VHF/UHF
MODEL HD7697P
769 Series Antennas
Digital/High Denition
VHF/UHF
MODEL HD7084P
POINT THIS END
TOWARDS STATIONS
POINT THIS END
TOWARDS STATIONS
90 DAY LIMITED WARRANTY
Winegard Company warrants this Winegard product against any defects in materials or work-
manship within 90 (ninety) days from date of purchase. No warranty claim will be honored unless
at the time the claim is made, you present proof of purchase to an authorized Winegard dealer (if
unknown, please contact Winegard Company, 3000 Kirkwood Street, Burlington, IA 52601-2000,
Telephone [phone]).
Winegard Company (at its option) will either repair or replace the defective product at no charge
to you. This warranty covers parts, but does not cover any costs incurred in removal, shipping or
reinstallation of the product. This limited warranty does not apply if the product is damaged, deterio-
rates, malfunctions or fails from: misuse, improper installation, abuse, neglect, accident, tampering,
modication of the product as originally manufactured by Winegard, usage not in accordance with
product instructions or acts of nature such as damage caused by wind, lightning, ice or corrosive
environments such as salt spray and acid rain.
The 90 Day Warranty is provided on the condition that the equipment is properly delivered with all
handling and freight charges prepaid to your Winegard dealer for return to our factory for repair or
replacement. Winegard dealers will arrange for the replacement or repair and return to you without
charge the product which failed due to defective material or workmanship.
WINEGARD COMPANY WILL NOT ASSUME ANY LIABILITIES FOR ANY OTHER WARRANTIES,
EXPRESS OR IMPLIED, MADE BY ANY OTHER PERSON.
ALL OTHER WARRANTIES WHETHER EXPRESS, IMPLIED OR STATUTORY INCLUDING
WARRANTIES OF FITNESS FOR A PARTICULAR PURPOSE AND MERCHANTABILITY ARE
LIMITED TO THE 90-DAY PERIOD OF THIS WARRANTY.
The foregoing shall be the sole and exclusive remedy of any person, whether in contract, tort or
otherwise, and Winegard shall not be liable for incidental or consequential damage or commercial
loss, or from any other loss or damage except as set forth above.
Some states do not allow limitations on how long an implied warranty lasts, or the exclusion of
limitation of incidental or consequential damages, so the above limitations or exclusions may not
apply to you.
This warranty gives you specic legal rights and you may also have other rights which vary from
state to state.
Printed in U.S.A. © Winegard Company 2002 Rev3 12-13 1450291
Rev. 2/08
Fig. 10
HOW TO PROVIDE LIGHTNING
PROTECTION FOR TV ANTENNA
AND SET
Step 1. Mount the lightning arrestor
or 75 ohm coaxial grounding block as
close as possible to where the 75 ohm
coaxial cable downlead enters the
house. See Figure10.
Step 2. The ground wires for both
the mast and the downlead should
be copper or aluminum wire, number
eight (8) or larger. See Figure 10.
Step 3. The downlead wire from
the antenna to the lightning arrestor
and the mast ground wire should be
secured to the house with stand-off
insulators, spaced from four (4) to six
(6) feet apart. See Fig. 10.
NOTE: In the case of a “ground up”
antenna installation, it may not be
necessary to ground the mast if the
mast extends four or more feet int the
earth. Consult a TV serviceman for the
proper depth in your location.
Antenna Lead
In Wire
Ground
Clamp
Electric
Service
Equipment
Antenna
Discharge Unit
(NEC Section 810-20)
Power Service Grounding
Electrode System
(NEC Art 250, Part H)
Ground
Clamps
Grounding Conductors
(NEC Section 810-21)
NEC - National Electrical Code
Example of antenna grounding as per
National Electrical Code, ANSI/NFPA 70
(May substitute a 75 ohm
Coax Grounding Block)
Register your product at winegard.com/myantenna

STEP 10. To attach the cartridge hous-
ing to the antenna, align the snaps on the
cartridge housing with the snap holes on
the cartridge housing receptacle on the
antenna and push the housing into the
receptacle until it snaps into place. See
Figure 8.
STEP 11. Attach the 75 ohm coaxial cable
to the cartridge housing. See Figure 8.
Slide weather boot over connector and
boot collar.
STEP 12. To mount the antenna on the
mast, loosen nuts on the main boom and
boom brace mast clamps. Slide both mast
clamps over the mast pointing the front of
the antenna (small end) towards stations
and tighten the boom brace mast clamp
securely. Let the main boom mast clamp
slide down the mast until the boom brace
supports the main boom. Tighten the main
boom mast clamp securely. See Figure 9.
STEP 13. The 75 ohm coaxial cable down-
lead may be secured to the mast by either
taping it or use of plastic wire ties.
Fig. 5
STEP 7. Unfold the reector booms
slowly until they lock in place. Then
unfold the elements on the reector
booms. See Figure 6.
STEP 8. To install the boom brace
remove the bolts and hex nuts. Attach
the boom brace to the reector boom
rst, making sure that the mast clamps
are on the same side, see Figure 7. Do
not tighten the bolt and hex nut.
STEP 9. Swing the boom brace down
onto the main boom and insert the bolt
and hex nut, see Figure 7. Tighten both
bolts and hex nuts securely.
Fig. 6
MASTING
2" OD MAX.
MAST CLAMP
MAST CLAMP
INSERT
HEX NUT
U-BOLT
STEP 5. Unfold the elements of the front
section of the antenna. The elements should
be on the top side of the front section of the
antenna. Remove the bolt and hex nut, (see
Fig 4) from the tapered end of the front boom
and slide the tapered end into the front of the
rear boom. The cartridge housing receptacle
on the rear section of the antenna is attached
to the bottom of the rear boom at the factory.
Replace the bolt, and hex nut. Tighten
securely.
STEP 6. Unfold UHF directors, as shown in
Figure 5.
NOTE:
To prevent damage in shipping, the second set of elements from the rear of the
boom are folded to the opposite side.
STEP 2. Grasp both ends of the second element from the rear of the boom. Lift
the ends of the element just enough to slide over the other elements to the front
and rear and ROTATE ABOUT 100° COUNTER CLOCKWISE to lock. See Fig. 1.
STEP 3. Unfold the rest of the elements on this side of the antenna to the lock
position, being sure to alternate the elements. See Figure 2.
STEP 4. Turn the antenna over and repeat steps 1, 2 and 3. Again lift and rotate
the second element just enough to slide over the other elements. See Figure 3.
Fig. 4
Fig. 7
Fig. 8
Fig. 9
Fig. 1 Fig. 3
Fig. 2
Antenna shown from top
side with front of rear sec-
tion pointing away from you.
Antenna shown from under-
side with front of rear section
pointing away from you.
STEP 1. Remove the rear section of antenna from carton (long elements). Lay
it on the ground with the end with the plug pointing toward you. Starting with the
element nearest you, unfold the rst element CLOCKWISE about 80° and click to
lock position. See Figure 1.
CARTRIDGE HOUSING
RECEPTACLE
75 OHM COAXIAL
CABLE (DOWNLEAD)
BOOT
COLLAR
CARTRIDGE
HOUSING
DOWNLEAD
JACK
WEATHER BOOT
MAIN
BOOM
REFLECTOR
BOOM
REFLECTOR
BOOM
ENDS OF CLIPS
SHOULD POINT AWAY FROM MAIN BOOM


Lift and
Rotate

























