winholt NHPL-1834-KD User manual

SHEET OF
DWG NO
PROPRIETARY
EXCEPT AS OTHERWISE AGREED TO IN WRITING. THE INFORMATION AND DESIGN
DISCLOSED HEREIN ARE THE PROPERTY OF WIN-HOLT EQUIPMENT CORP. AND
MUST NOT BE COPIED OR DISTRIBUTED OUTSIDE WIN-HOLT EQUIPMENT EXCEPT
TO AUTHORIZED PERSONS WITH A GENUINE NEED-TO-KNOW WHO BY THE USE
HEREOF ACKNOWLEDGE WIN-HOLT EQUIPMENT OWNERSHIP AND AGREE TO
MAINTAIN THIS INFORMATION AND DESIGN IN STRICT CONFIDENCE.
FINISH
DO NOT SCALE DRAWING
TOLERANCES ARE:
3 PLACE DECIMAL .032
FRACTIONAL 1/16
ALL SURFACES TO BE
BREAK SHARP CORNERS
MATERIAL
ANGULAR 2
DIMENSIONS ARE IN INCHES
UNLESS OTHERWISE SPECIFIED
QA:
SCALE
CHK:
1/8/2018
SIZE REV
WIN-HOLT EQUIPMENT CORP.
ENGINEERING
PHONE: [phone] FAX: [phone]
TITLE
ITEM:
IBM #:
ER#:
CUSTOMER:
1 5
A
DWN:
SHT LENGTH:
SHT WIDTH:
LENGTH:
1056410 ALDK NHPL-1834-KD PACKAGE
0.750"
0.344"
0.043"
0.583"
0.322"
0.056"
0.984"
0.551"
0.709"
0.472"
0.182"
0.157"
0.472"
0.374"
0.136"
0.118"
0.630"
0.394"
0.136"
0.118"
0.116" 0.156"
0.195"
(1) LEFT SIDE (1) TOP
(1) BOTTOM
(1) SPREADER
(1) RIGHT SIDE (1) BACK (1) DOOR (1) AIR DUCT (2) MALE DOOR HINGE
(2) FEMALE CABINET HINGE
(4) CASTERS
(16) M8 BH SCREWS (16) LOCK WASHERS (16) FLAT WASHERS (19) M6 FH SCREWS (8) M5 BH SCREWS (5) M5 FH SCREWS
(16) M8 SCREW CAPS
(19) M6 SCREW CAPS
(15) M5 SCREW CAPS
(1) PAN
(1) M3 ALLEN (1) M4 ALLEN (1) M5 ALLEN
HINGE MOUNTS
RT SIDE ONLY

SHEET OF
DWG NO
PROPRIETARY
EXCEPT AS OTHERWISE AGREED TO IN WRITING. THE INFORMATION AND DESIGN
DISCLOSED HEREIN ARE THE PROPERTY OF WIN-HOLT EQUIPMENT CORP. AND
MUST NOT BE COPIED OR DISTRIBUTED OUTSIDE WIN-HOLT EQUIPMENT EXCEPT
TO AUTHORIZED PERSONS WITH A GENUINE NEED-TO-KNOW WHO BY THE USE
HEREOF ACKNOWLEDGE WIN-HOLT EQUIPMENT OWNERSHIP AND AGREE TO
MAINTAIN THIS INFORMATION AND DESIGN IN STRICT CONFIDENCE.
FINISH
DO NOT SCALE DRAWING
TOLERANCES ARE:
3 PLACE DECIMAL .032
FRACTIONAL 1/16
ALL SURFACES TO BE
BREAK SHARP CORNERS
MATERIAL
ANGULAR 2
DIMENSIONS ARE IN INCHES
UNLESS OTHERWISE SPECIFIED
QA:
SCALE
CHK:
1/8/2018
SIZE REV
WIN-HOLT EQUIPMENT CORP.
ENGINEERING
PHONE: [phone] FAX: [phone]
TITLE
ITEM:
IBM #:
ER#:
CUSTOMER:
2 5
A
DWN:
SHT LENGTH:
SHT WIDTH:
LENGTH:
1056410 ALDK NHPL-1834-KD ASSEMBLY
INSTRUCTIONS
M6 FH SCREW
BOTTOM
RIGHT SIDE
LEFT SIDE
SPREADER
M5 FH SCREW
ORIENT AS SHOWN
ASSEMBLE RIGHT SIDE
TO BOTTOM WITH M6
SCREWS. DO NOT
TIGHTEN.
ORIENT AS SHOWN
ASSEMBLE LEFT SIDE
TO BOTTOM WITH M6
SCREWS. DO NOT
TIGHTEN.
SPREAD SIDES APART
ENOUGH TO ASSEMBLE
SPREADER. TIGHTEN
WITH M5 FH SCREWS.

DETAIL A
SCALE .75
A
SHEET OF
DWG NO
PROPRIETARY
EXCEPT AS OTHERWISE AGREED TO IN WRITING. THE INFORMATION AND DESIGN
DISCLOSED HEREIN ARE THE PROPERTY OF WIN-HOLT EQUIPMENT CORP. AND
MUST NOT BE COPIED OR DISTRIBUTED OUTSIDE WIN-HOLT EQUIPMENT EXCEPT
TO AUTHORIZED PERSONS WITH A GENUINE NEED-TO-KNOW WHO BY THE USE
HEREOF ACKNOWLEDGE WIN-HOLT EQUIPMENT OWNERSHIP AND AGREE TO
MAINTAIN THIS INFORMATION AND DESIGN IN STRICT CONFIDENCE.
FINISH
DO NOT SCALE DRAWING
TOLERANCES ARE:
3 PLACE DECIMAL .032
FRACTIONAL 1/16
ALL SURFACES TO BE
BREAK SHARP CORNERS
MATERIAL
ANGULAR 2
DIMENSIONS ARE IN INCHES
UNLESS OTHERWISE SPECIFIED
QA:
SCALE
CHK:
1/8/2018
SIZE REV
WIN-HOLT EQUIPMENT CORP.
ENGINEERING
PHONE: [phone] FAX: [phone]
TITLE
ITEM:
IBM #:
ER#:
CUSTOMER:
3 5
A
DWN:
SHT LENGTH:
SHT WIDTH:
LENGTH:
1056410 ALDK NHPL-1834-KD ASSEMBLY
INSTRUCTIONS
BACK
GROOVE SLIDE
M5 FH SCREW
M6 CAP
ORIENT AS SHOWN
AND SLIDE BACK INTO
GROOVES (DETAIL A) ON
SIDES. SLIDE ALL THE
WAY TO BOTTOM. TIGHTEN
M5 FH SCREWS. TIGHTEN
M6 FH SCREWS ON BOTTOM
AND APPLY M6 CAPS.

SHEET OF
DWG NO
PROPRIETARY
EXCEPT AS OTHERWISE AGREED TO IN WRITING. THE INFORMATION AND DESIGN
DISCLOSED HEREIN ARE THE PROPERTY OF WIN-HOLT EQUIPMENT CORP. AND
MUST NOT BE COPIED OR DISTRIBUTED OUTSIDE WIN-HOLT EQUIPMENT EXCEPT
TO AUTHORIZED PERSONS WITH A GENUINE NEED-TO-KNOW WHO BY THE USE
HEREOF ACKNOWLEDGE WIN-HOLT EQUIPMENT OWNERSHIP AND AGREE TO
MAINTAIN THIS INFORMATION AND DESIGN IN STRICT CONFIDENCE.
FINISH
DO NOT SCALE DRAWING
TOLERANCES ARE:
3 PLACE DECIMAL .032
FRACTIONAL 1/16
ALL SURFACES TO BE
BREAK SHARP CORNERS
MATERIAL
ANGULAR 2
DIMENSIONS ARE IN INCHES
UNLESS OTHERWISE SPECIFIED
QA:
SCALE
CHK:
1/8/2018
SIZE REV
WIN-HOLT EQUIPMENT CORP.
ENGINEERING
PHONE: [phone] FAX: [phone]
TITLE
ITEM:
IBM #:
ER#:
CUSTOMER:
4 5
A
DWN:
SHT LENGTH:
SHT WIDTH:
LENGTH:
1056410 ALDK NHPL-1834-KD ASSEMBLY
INSTRUCTIONS
TOP
M6 FH SCREWS M6 CAPS
M8 CAPS
M8 BH SCREWS
LOCK WASHERS
CASTERS
WASHERS
ORIENT AS SHOWN
ASSEMBLE TOP TO
SIDES WITH M6 SCREWS.
TIGHTEN AND APPLY
SCREW CAPS.
ORIENT AS SHOWN
ASSEMBLE CASTERS TO
BOTTOM WITH M8 SCREWS,
LOCK WASHER AND FLAT
WASHER. TIGHTEN AND APPLY
SCREW CAPS.

DETAIL A
SCALE .5
SHEET OF
DWG NO
PROPRIETARY
EXCEPT AS OTHERWISE AGREED TO IN WRITING. THE INFORMATION AND DESIGN
DISCLOSED HEREIN ARE THE PROPERTY OF WIN-HOLT EQUIPMENT CORP. AND
MUST NOT BE COPIED OR DISTRIBUTED OUTSIDE WIN-HOLT EQUIPMENT EXCEPT
TO AUTHORIZED PERSONS WITH A GENUINE NEED-TO-KNOW WHO BY THE USE
HEREOF ACKNOWLEDGE WIN-HOLT EQUIPMENT OWNERSHIP AND AGREE TO
MAINTAIN THIS INFORMATION AND DESIGN IN STRICT CONFIDENCE.
FINISH
DO NOT SCALE DRAWING
TOLERANCES ARE:
3 PLACE DECIMAL .032
FRACTIONAL 1/16
ALL SURFACES TO BE
BREAK SHARP CORNERS
MATERIAL
ANGULAR 2
DIMENSIONS ARE IN INCHES
UNLESS OTHERWISE SPECIFIED
QA:
SCALE
CHK:
1/8/2018
SIZE REV
WIN-HOLT EQUIPMENT CORP.
ENGINEERING
PHONE: [phone] FAX: [phone]
TITLE
ITEM:
IBM #:
ER#:
CUSTOMER:
5 5
A
DWN:
SHT LENGTH:
SHT WIDTH:
LENGTH:
1056410 ALDK NHPL-1834-KD ASSEMBLY
INSTRUCTIONS
A
AIR DUCT
STAND CABINET UPRIGHT
AND MANEUVER AIR DUCT
UP AND OVER SPREADER
AND ASSEMLE HOLE SLOTS
IN AIR DUCT TO ALUMINUM
DIE BUTTONS SHOWN IN
DETAIL A. AIR DUCT WILL
SLIDE DOWN UNTIL SLOTS
BOTTOM OUT ON DIE BUTTONS.
ALUMINUM
BUTTON
M5 BH SCREW
CABINET FEMALE HINGE
DOOR MALE HINGE
ASSEMBLE CABINET FEMALE HINGE
TO RIGHT SIDE USING M5 BH SCREWS.
ASSEMBLE DOOR MALE HINGES TO
DOOR USING M5 BH SCREWS. APPLY
SCREW CAPS. ASSEMBLE DOOR TO
CABINET.
SCREW CAPS
PAN
APPLY REMAINING SCREW CAPS.
SLIDE PAN INTO BOTTOM PAN
BRACKET.
SCREW CAPS
