Winmate S430T2-C User manual

0
Winmate S430T2-C PDA
Windows CE 6.0
User Guide
Version 1.1
February 2017

Winmate S430T2-C Series PDA
User Guide
1
Contents
Chapter 1: Safety Information
Exposure to Radio Use ........................................................................................3
RF Exposure Information ......................................................................................3
Battery Safety Information.....................................................................................4
Electrostatic Discharge .........................................................................................4
Driving...................................................................................................................4
Chapter 2: About Winmate S430T2-C
About S430T2-C ..................................................................................................5
Features ...............................................................................................................5
Getting started.......................................................................................................6
SD Card Installation.........................................................................................6
Battery Installation...........................................................................................7
Battery Charging .............................................................................................8
Turning On and Off the Device..............................................................................9
Turning the S430T2-C On ...............................................................................9
Turning the S430T2-C Off ...............................................................................9
Resetting to Factory Default............................................................................9
Chapter 3: Using Windows CE 6.0 Operating System
Desktop ..............................................................................................................11
Desktop Icon ................................................................................................11
To generate Left/Right click...........................................................................12
Adding New Folder........................................................................................12
Personalizing Home screen...........................................................................13
Task Bar .............................................................................................................13
Start Menu ....................................................................................................13
Status Icon ...................................................................................................15
Clock ............................................................................................................16
Return to Desktop .........................................................................................16
Chapter 4: Configuration

Winmate S430T2-C Series PDA
User Guide
2
Remote Desktop Connection ..............................................................................17
Control Panel .....................................................................................................17
Control Panel Icon ..............................................................................................17
Basic Setup.........................................................................................................19
Display properties .........................................................................................19
Keyboard properties .....................................................................................19
Key repeat.....................................................................................................20
Volume and Sound properties.......................................................................20
Power Management properties .....................................................................21
Stylus properties ...........................................................................................22
Calibration ....................................................................................................22
Storage Manager ................................................................................................22
Formatting Memory Card...............................................................................22
Creating Partitions ........................................................................................23
Partitions Management .................................................................................23
Chapter 5: Connecting to Network and Devices
Connecting to Network .......................................................................................24
Connecting to WLAN.....................................................................................24
Bluetooth ............................................................................................................24
Bluetooth Setup.............................................................................................25
Pairing Bluetooth Device ..............................................................................25
GPS Setup....................................................................................................26
Chapter 6: Accessories
S430T2-C Standard Accessories .......................................................................28
S430T2-C Optional Accessories .........................................................................28

Winmate S430T2-C Series PDA
User Guide
3
Chapter 1: Safety Information
Exposure to Radio Use
S430T2-C is equipped with Bluetooth, WI-Fi and Cellular modem radio. In some situation or
area, user may be required to turn off the radios. For example;
User’s needs to turn the phone OFF when in an area posted “TURN OFF RADIO
SIGNAL.” to avoid interfering with blasting operations.
User needs to turn OFF the radio signal in health care facilities. Hospitals or health
care facilities may be using devices that sensitive to Radio Frequency energy.
Aviation authority regulations prohibit user from using phone while in the aircraft.
In order to prevent the handheld from emitting radio signals, do the following step:
To turn off the device:
Press and hold Power OFF button to display the Power OFF menu then tap it
To turn off the Communication options e.g. Bluetooth, Wi-Fi, cellular modem radio:
Go to control panel, select Network and Dial-up Connections, tap and hold to disable
the connection
RF Exposure Information
This Handheld device meets the government’s requirement for exposure to radio waves.
This device is designed and manufactured not to exceed the emission limits for exposure to
radio frequency (RF) energy set by the Federal Communications Commission of the U.S.
Government. The exposure standard for wireless devices employs a unit of measurement
known as the Specific Absorption Rate (SAR). The SAR limit set by the FCC is 1.6W/Kg.
Test for SAR are conducted using standard operating positions accepted by the FCC with
the device transmitting at its highest certified power level in all tested frequency bands.
Although SAR is determined at the highest certified power level, the actual SAR level of the
device while operating can be well below the maximum value. This is because the device is
designed to operate at multiple power levels so as to use only the poser required to reach
the network. In general, the closer user to a wireless base station antenna, the lower the
power output.
For body worn operation, this PDA has been tested and meets the FCC RF exposure
guidelines for use with an accessory that contains no metal and the positions of the handset

Winmate S430T2-C Series PDA
User Guide
4
minimum of 1.5 cm from the body. User of other enhancements may not ensure compliance
with FCC RF exposure guidelines. If user do not use a body-worn accessory and are not
holding the PDA at the ear, position the handset a minimum of 1.5 cm from your body when
the device is switched on.
Battery Safety Information
Do not use other battery which is not intended for the product. Use only the
battery compatible for the device and follow battery usage, storage, and charging
guidelines in this user guide.
A damage rechargeable Lithium-ion polymer battery can cause explosion or fire.
To prevent personal injury and/or property damage:
Do not open, disassemble, puncture, or crush the battery
Do not leave or store the PDA in an area which is near a heat source such
as vehicle dashboard, dryer or other heat source.
Do not attempt to insert foreign object into the battery or allow conductive
objects to contact the battery
In the event of battery leak:
Do not have any contact with the battery fluid
If battery fluid leaks onto the skin or cloth, wash the affected area with
clean water
Please contact your current Winmate distributor or local Winmate vendor if you
suspect damage to your PDA or battery for inspection and reparation.
Electrostatic Discharge
Please follow proper electrostatic discharge precaution to prevent static damage
that can harm electronic components inside your device
Driving
Using mobile device or accessory while driving may cause distraction and maybe
illegal in some areas where you drive. Please obey the laws and regulations on
the use of mobile device

Winmate S430T2-C Series PDA
User Guide
5
Chapter 2: About Winmate S430T2-C
About S430T2-C
Winmate's S430T2 rugged handheld PDA integrates the latest Windows CE 6.0 operating
system, along with increased processing power and storage to streamline workflow
efficiencies. The new S430T2 maintains the same popular form factor as the first-generation
model, runs on a 1.0 GHz TI Cortex A8 processor. The 4.3-inch capacitive multi-touch
display offers 480 x 800 pixel WVGA resolution. Other new era tech includes dual cameras,
a micro-SD card slot, speedy 802.11 Wi-Fi, integrated GPS and optional 3G mobile
broadband. This model is equipped with QWERTY Keypad to increase users’ ease of use.
Features
This section provides the features of the S430T2-C series and describes how to set this
device for the first time

Winmate S430T2-C Series PDA
User Guide
6
Features
1
Audio Phone
Emit Sounds
2
Light sensor
Light sensor detect the availability of light and
automatically control the brightness of a screen backlight
intensity
3
Proximity sensor
Proximity function is used specifically towards near field
proximity applications. In mobile phones, the proximity
detection can detect when the user positions of mobile
phone is close to their ear
4
Touch Screen
Resistive touch screen
5
QWERTY Keypad Button
6
Status Indicator
LED indicator indicates the device status
7
RS232
RS232 Connector
8
Mini USB
Use for data transfer via Mini USB cable
9
DC Jack
Use for charging
10
DC Dock
Use it for docking
11
Audio Jack
Headset or Headphone can be connected
12
Built-in 1D/2D Barcode
Barcode Scanner for reading of 1D/2D barcode.
13
Camera
8 megapixel camera
14
Flash
Camera flash for additional light during camera capture
15
18
Hand Strap Fixing Hole
To improve usability and ease of use when using the
product
16
Speaker
Audio speaker provides a variety of sounds when user
operating the device
17
Battery Latch screw
To secure the battery
Getting started
To start using the S430T2-C for the first time:
Install SD Card
Install the battery
Charging the Battery

Winmate S430T2-C Series PDA
User Guide
7
SD Card Installation
To Install the SD Card:
1. Place the S430T2-C facing down and then locate the screws on the backside
2. Unscrew the screws and gently pull the back cover
3. Pull the battery to remove it
4. Locate the SD card holder
5. Insert the SD card accordingly as shown in the figure
6. Locate the SD card holder
7. Push the SD card holder in the direction of the arrow
Battery Installation
1. Reinsert the battery by latching the bottom first and then push it down.
Screw

Winmate S430T2-C Series PDA
User Guide
8
2. After battery installation, put back the back cover and make sure all the screw
fit with the hole. Screw and fix the back cover.
Battery charging
Please charge the battery before using the device for the first time, charge the battery
until the LED indicator turns solid green. To charge the S430T2-C, use a cable or a
docking with appropriate power supply. For more information about the S430T2-C
accessories, see chapter 6.
To charge the battery using USB/ Charge cable:
1. Connect the power supply output connector to the input power port on the
USB/Charge cable.
2. Connect the USB/ Charge cable to the bottom of S430T2-C. The battery charge LED
indicates the battery charging status
LED Status
Indication
OFF
S430T2-C is not charging
S430T2-C is not properly connected to power source
Solid orange
S430T2-C is in charging process
Solid Green
Charging complete

Winmate S430T2-C Series PDA
User Guide
9
This product uses a non-removable battery. The battery should
only be removed when you want to change the SD Card
Turning On and Off the Device
Turning the S430T2-C On
1. Press and hold the power button for 3 seconds, located on the right side of the
unit
2. When the device vibrates and the indicator light flashes green, release the
power button. The desktop screen is displayed
Turning the S430T2-C Off
1. Select windows > programs > Power Off. Tap Power Off button to turn it off
2. To turn off the device, press and hold the power button until the indicator light
flashes green,
Resetting to Factory Defaults
1. Make sure the SD card has no image file inside.
2. To reset to factory default, long press and hold the power button for 8 second, until the
resetting page is up.

Winmate S430T2-C Series PDA
User Guide
10
3. Wait until the process is finished. The device will reset to factory default.

11
Chapter 3: Using Windows CE 6.0 Operating System
Desktop
If you do not use the phone for a while, the screen dims and then darkens to conserve the
battery. To wake up the phone:
1. Press the Power button located on the keypad.
Desktop is used as a shortcut to launch activities such as using My Device, Camera, Internet
Explorer.
Desktop Icon
There are 6 icons on Desktop such as My Device, Recycle Bin, Camera, Internet
Explorer, Media Player and Remote Desktop connection
Show all folders in S430T2-C such as Documents and Setting, My
Documents, Program Files, and Storage Card.
The deleted files will be located here, user can restore it or delete it
permanently
Select and open camera application to take a picture. Detail
content about camera feature and application will be available in
chapter 3
To launch the Internet Explorer
To launch or play Video or music
To communicate with a remote desktop PC

Winmate S430T2-C Series PDA
User Guide
12
To Generate Left / Right Click
To generate Right Click press anywhere on the screen and leave it there for a few
seconds. Opens a menu specific to what you are doing
Adding New Folder
To add a new folder on desktop:
1. Generate Right click and select New Folder
2. Rename the folder
Personalizing Home Screen
User can personalize their home screen and change the wallpaper, to change it:
1. Generate Right click and select properties
2. In the background tab select browse to find the picture file that user want to change
3. Select the image and then apply it

Winmate S430T2-C Series PDA
User Guide
13
Task Bar
Task Bar is located at the bottom of the screen and these icons will provides user quick view
and links to the Wi-Fi, Bluetooth and Clock settings. It also gives short cut to window
selection
Start Menu
The left Windows icon is Start menu which contains Programs, Favorites,
Documents, Settings, Help and Run.
a. Programs

Winmate S430T2-C Series PDA
User Guide
14
Camera
Select Camera icon in the programs or in the desktop to open camera application
Shutter
to take a picture
Menu
to open the menu
to change photo resolution:
2560 x 1920 in 5 MP
2560 x 1536 in 4 MP (wide)
2048 x 1536 in 3.2 MP
1600 x 1200 in 2 MP
1600 x 960 in 2 MP (wide)
800 x 480 in 0.4 MP
640 x 480 in 0.3 MP
to change the flash setting:
On : Always turn on flash when capture a
OFF: Always turn off flash when capture a
Auto: adjust automatically to the environment
brightness when capture a picture
to select the folder to save the file
Exit
to close camera application
Command Prompt
To access the DOS command prompt, at the prompt user can type DOS
commands such as dir to display all the directories in the drive.
Internet Explorer
This device is equipped with Internet Explorer for Windows CE 6.0. User can
access it through the Start menu under the control panel or double tap the Internet
Explorer icon
Remote Desktop Connection
To connect to a Windows Terminal server so user can run a session on the server
using the Windows CE 6.0 device
Power Off
To turn off the device
Winmate Data Capture
This data capture only for S430T2-C with Barcode reader or RFID
b. Favorites
The favorites list which has been added in the IE will be listed here

Winmate S430T2-C Series PDA
User Guide
15
c. Settings
There are 3 items in settings such as Control Panel, Network and Dial-up
connections, Taskbar and Start Menu. The Taskbar and start menu is able to set
some properties. In General tab, choose Auto Hide to hide the taskbar and choose
Show clock to turn on / off the clock. In advance tab user can remove the contents of
the documents menu by tapping the clear button
d. Run
To open the name of the program, folder, or document by typing the keywords
Status Icon
On the right side of taskbar shows some status icon as below:
This icon shows the internet is not connected
This icon shows the device is in charging mode
This icon shows the device is connecting to PC

Winmate S430T2-C Series PDA
User Guide
16
Clock
The clock shows on the right side of taskbar, double click the clock to open Date/Time.
User can also set the Time Zone.
Return to Desktop
User can switch to another window by tapping icon on the taskbar and tap desktop

Winmate S430T2-C Series PDA
User Guide
17
Chapter 4: Configuration
Remote Desktop Connection
Remote desktop connection is a Windows application which enable user to connect to PC
through internet using S430T2-C with WinCE 6.0. Please refer to the following link from
Microsoft Windows for step by step information to set up this connection.
http://www.microsoft.com/windowsxp/using/mobility/getstarted/remoteintro.mspx
Control Panel
Control panel is the center of Windows CE 6.0. To open control panel
1. Tap My Device on the Desktop and select control panel, or
2. Tap Start menu on the task bar and then tap settings, select control panel
Control Panel Icon
Bluetooth Devices
Manage Bluetooth pairing and devices.
BSP Information
CPU speed, Memory size, OS version, Eboot version, XLDR version and MCU
version information.
Certificates
The public key is transmitted as part of Certificate. In Certificates client can check
the certificates which has been digitally signed by a certification authority that the
client explicitly trust.
Date/Time
Setting Year, Month, Date, Time and Time Zone.
Dialing
Dialing Properties setting such as local area code, country code and region code.

Winmate S430T2-C Series PDA
User Guide
18
Display
Change background, Appearance and Backlight on S430T2-C.
Input Panel
Change input method and option setting.
Internet Options
Settings about IE browser such as Start Page, Privacy, Security and Search
Page.
Keyboard
Setting about character repeat, repeat delay and repeat rate.
Mouse
Setting the double-click sensitivity for both the speed and physical distance
between clicks.
Network and Dial-up Connections
Some setting about Wi-Fi connection and USB serial connection.
Owner
User can specify owner information in here. In Notes User can see and add
additional information. In Network ID, Win CE uses this information to gain
access to network resources. Enter the user name, password and domain
provided by network administrator.
Password
User can assign a password to restrict access to elements of S430T2-C. Note
that after user assigned the password, it can’t be circumvented.
PC Connection
Setting direct connections to desktop computer. Press Change Connection to
change the type of direct connection to PC.
Power
Here shows some information about remaining power and device power level
status. In schemes User can adjust power settings.
Regional Settings
Setting the region, language and input for S430T2-C.
Remove Programs
Here shows all the programs can be removed. Select it and press Remove to
remove it.
Storage Manager
Shows information about storage and some function to format, dismount and
change partitions.
Stylus
Includes the function in Mouse and with Calibration function which can recalibrate
screen.
System
User can see system information here such as processor, memory.
In Memory menu User can allocate memory between storage and program
memory.
In Device Name menu User can change device name and description.

Winmate S430T2-C Series PDA
User Guide
19
Terminal Server Client Licenses
User can see all the stored licenses here. User can store or delete it from this list.
Volume & Sounds
User can change the volume and the sounds to indicate events like menu pop,
menu selection.
Basic Setup
Display Properties
Go to Control Panel and tap Display icon and then open Display properties, user can
obtains
Display Backlight
User can set the condition to turn off backlight to save battery life, these conditions
are depend on using battery power or external power
Display Appearance
At appearance tab user can change the scheme and select the scheme, tap apply to
change the display appearance
Keyboard Properties
To set character repeat rate and repeat delay, tap keyboard icon in setting panel
