Winmate M101EKB User manual

M101EKB
Rugged Windows Tablet
Intel® Celeron® N6211 @ 1.2 GHz (up to 3.00 GHz)
Intel® Pentium® N6415 @ 1.2GHz (up to 3.00 GHz) (Optional)
User Guide
Document Part Number: 9152111I1158
Version 1.0

1
8-inch Rugged Windows Tablet PC M101EKB
Content
CHAPTER 1: READ ME FIRST....................................................................................................................................................2
1.1 ADVISORY CONVENTIONS........................................................................................................................................................... 2
1.2 SAFETY INFORMATION............................................................................................................................................................... 3
1.3 HANDLING AND MAINTENANCE................................................................................................................................................... 5
1.4 DECLARATION OF CONFORMITY................................................................................................................................................... 6
1.5 COPYRIGHT NOTICE .................................................................................................................................................................. 6
1.6 TRADEMARK ACKNOWLEDGEMENT .............................................................................................................................................. 6
1.7 DISCLAIMER ............................................................................................................................................................................ 7
CHAPTER 2: GETTING STARTED...............................................................................................................................................8
2.1 UNPACKING ............................................................................................................................................................................ 8
2.2 DESCRIPTION OF PARTS ............................................................................................................................................................. 9
2.3 HOT KEYS FOR SPECIFIC FUNCTIONS........................................................................................................................................... 11
2.4 INDICATORS........................................................................................................................................................................... 11
2.5 FIRST-TIME OPERATION........................................................................................................................................................... 12
2.5.1 Installing SIM card (For WWAN Equipped Devices) (Optional) ............................................................................... 12
2.5.2 Installing a Micro SD Card ........................................................................................................................................ 13
2.5.3 Installing Battery ...................................................................................................................................................... 13
2.5.4 Charging Your Tablet................................................................................................................................................ 13
2.5.5 Starting the Tablet.................................................................................................................................................... 14
CHAPTER 3: SETTING UP WINDOWS FOR THE FIRST TIME ....................................................................................................15
3.1 OS INTRODUCTION................................................................................................................................................................. 15
3.2 SETTING UP WINDOWS 10 IOTENTERPRISE ................................................................................................................................ 15
CHAPTER 4: OPERATING THE DEVICE....................................................................................................................................18
4.1 WINSET UTILITY..................................................................................................................................................................... 18
4.1.1 System Information .................................................................................................................................................. 18
4.1.2 WinSet Shortcut Setting............................................................................................................................................ 19
4.2 BUILT-IN DEVICES ON/OFF ...................................................................................................................................................... 20
4.2.1 Using the Wireless LAN (WLAN) ............................................................................................................................... 20
4.2.2 Using the Wireless WAN (WWAN) ........................................................................................................................... 21
4.2.3 Using the GPS............................................................................................................................................................ 21
4.2.4 Using the BT .............................................................................................................................................................. 21
4.2.5 Turning On/Off LED Indicators ................................................................................................................................. 22
4.3 USING THE BARCODE READER (OPTIONAL).................................................................................................................................. 22
4.4 USING CAMERA ..................................................................................................................................................................... 34
4.5 USING THE HF RFID READER ................................................................................................................................................... 35
4.6 REPLACING HOT SWAPPABLE BATTERY ....................................................................................................................................... 41
4.7 DOCKING CONNECTOR PIN DEFINITION ...................................................................................................................................... 41
4.8 EXPANSION PORT PIN DEFINITION ............................................................................................................................................. 41
4.9 COM PORT DEFINITION .......................................................................................................................................................... 42
4.10 ADJUSTING LED BRIGHTNESS ................................................................................................................................................. 45
CHAPTER 5: FREQUENTLY USED SETTINGS............................................................................................................................49
5.1 SCREEN RESOLUTION SCALING AND SETTING................................................................................................................................ 49
5.1 Changing Display Scaling Setting (Recommended) .................................................................................................... 49
5.1.2 Changing Resolution................................................................................................................................................. 51
5.2PAIRING WITH A WIRELESS BLUETOOTH BARCODE SCANNER WITH BLUETOOTH SERIAL PORT PROFILE .................................................... 53
5.2.1 Setup Computer for Bluetooth Pairing..................................................................................................................... 53
5.2.2 Set up the Barcode Scanner for Bluetooth Pairing .................................................................................................. 56
5.2.3 Bluetooth Pairing...................................................................................................................................................... 56
5.3 USING RECOVERY WIZARD TO RESTORE COMPUTER...................................................................................................................... 58
APPENDIX.............................................................................................................................................................................60
APPENDIX A: TROUBLESHOOTING.................................................................................................................................................... 61
APPENDIX B: TECHNICAL SPECIFICATION........................................................................................................................................... 63

2
Chapter 1: Read Me First
Chapter 1: Read Me First
1.1 Advisory Conventions
Four types of advisories are used throughout the user manual to provide helpful
information or to alert you to the potential for hardware damage or personal injury. These
are Notes, Important, Cautions, and Warnings. The following is an example of each type of
advisory.
Note:
A note is used to emphasize helpful information
Important:
An important note indicates information that is important for you to know.
Caution/ Attention
A Caution alert indicates potential damage to hardware and explains how to avoid
the potential problem.
Unealerted’attentionindique un dommage possible à l’équipement et explique
comment éviter le problèmepotentiel.
Warning! Avertissement!
An Electrical Shock Warning indicates the potential harm from electrical hazards and
how to avoid the potential problem.
Un Avertissement de Choc Électriqueindique le potentiel de chocssur des
emplacements électriques et comment évitercesproblèmes.

3
8-inch Rugged Windows Tablet PC M101EKB
1.2 Safety Information
Precaution on Battery Pack
Pré caution avec le bloc-
pile
Do Not Expose the Battery Pack to Excessive
Heat, or Extreme Heat (Near Fire, in Direct
Sunlight for example)
Generation of heat, ignition or rupture may
result
Ne pas exposer le bloc-pile à une Chaleur
Excessive, ou une Chaleur Extrême (Près
d'un feu, sous la lumière du soleil par
exemple)Une production de chaleur,
l'amorçage ou la rupture peuvent être
occasionnés
Do Not Disassemble, Modify, or Insert Sharp
Objects Into the Battery Pack. Electrolyte
leakage, generation of heat, ignition or rupture
may result.
Ne pas démonter, modifier, ou insérer des
objets pointus à l'intérieur du bloc-pile. Une
fuite d'électrolyte, la génération de chaleur,
l'amorçage ou la rupture peuvent être
occasionnés.
Do Not Short the Positive (+) and Negative (-)
Terminals of the Battery. Generation of heat,
ignition or rupture may result. When carrying or
storing the device, do not place the battery
pack together with articles that may contact
electricity.
Ne pas court-circuiter les bornes Positive (+) et
Négative (-) de la pile, la génération de
chaleur, l'amorçage ou la rupture peuvent être
occasionnés. Lors du transport et du
rangement de l'appareil, ne pas placer le bloc-
pile en même temps que des articles pouvant
créer un contact électrique.
Do Not Apply Shocks to the Battery by
Dropping It or Applying Strong Pressure to It.
Electrolyte leakage, generation of heat, ignition
or rupture of battery may occur.
Ne pas faire subir de choc à la pile en la
laissant tomber ou en appliquant une forte
pression dessus. Une fuite d'électrolyte, la
génération de chaleur, l'amorçage ou la
rupture peuvent être occasionnés.
Do Not Charge the Battery Other Than
Methods Those Specified In This Manual. If the
battery is not charged using one of the
specified methods, electrolyte leakage,
generation of heat, ignition or rupture may
result.
Ne pas charger la pile par d'autres méthodes
que celles spécifiées dans ce manuel. Si la pile
n'est pas chargée en utilisant l'une des
méthodes spécifiées, une fuite d'électrolyte, la
génération de chaleur, l'amorçage ou la
rupture peuvent être occasionnés.
When the Battery Pack Has Deteriorated,
Replace It with a New Battery. Continued use
of a damaged battery pack may result in heat
generation, ignition or battery rupture.
Lorsque la pile est détériorée, la remplacer par
une nouvelle pile. L'utilisation continue d'une
pile endommagée peut occasionner une
génération de chaleur, l'amorçage ou la
rupture de la pile.
Do Not Use the Battery Pack With Any Other
Products. The battery pack is rechargeable
and is only designed for this specific product. If
it is used with a product other than the
specified product, electrolyte leakage,
generation of heat, ignition or rupture may
result.
Ne pas utiliser avec un autre produit La
batterie est rechargeable et a été
conçue pour un produit spécifique. Si
elle est utilisée sur un produit différent
de celui pour lequel elle a été conçue,
des pertes d’électrolytes et une production
de chaleur sont possibles, elle
risque également de prendre feu ou de
casser.
Do Not Use This Product With Battery Other
Than the One Specified.
Ne pas utiliser ce produit avec une batterie
autre que celle spécifiée
Discontinue using device immediately if you
notice the battery is swelling or looks puffy or
misshapen. Do not attempt to charge or use
the device. Do not handle a damaged or
leaking battery. Do not let leaking battery fluid
come into contact with your eyes, skin or
clothing.
Si vous remarquez une pile gonflée, élargie ou
anormale, cesser l’utilisation de l’appareil
immédiatement. N’essayez pas de recharger
l’appareil ou de l’utiliser. Ne pas manipuler
une pile qui fuit ou qui est endommagée. Ne
laissez pas de liquide qui fuit entrer en contact
avec vos yeux, votre peau ou vos vêtements.

4
Chapter 1: Read Me First
General Product Safety
Sé curité gé né rale des
produits
This product should not be used near water
such as bathtubs, sinks, swimming pools, wet
basement, etc.
Ce produit ne dois pas être utilisé près de l'eau
comme les baignoires, les éviers, les piscines,
les sous-sols humides, etc.
Do not block any ventilation openings. Do not
place the product against a wall or in an
enclosed space as doing so might impede the
flow of cooling air.
Ne pas bloquer les ouvertures de ventilation. Ne
pas placer le produit contre un mur ou dans un
espace clos de façon à entraver la circulation de
l'air de refroidissement.
Do not place the product near any heat sources
such as radiators, warm air intakes, stoves or
other heat-generating devices (including
amplifiers or other heat producing equipment).
Ne pas placer le produit près d'une source de
chaleur comme des radiateurs, les arrivées d'air
chaud, poêles ou autres produits générant de la
chaleur (y compris les amplificateurs ou autre
équipement produisant de la chaleur.)
Protect the power cord from being crushed or
pinched, particularly in the area of the plugs,
any receptacles used, and the point of exit from
the apparatus. Do not break off the ground pin
of the power cord.
Empêcher le cordon d'alimentation d'être écrasé
ou pincé, en particulier dans les zones de
prises, des containers utilisés, et du point de
sortie de l'appareil. Ne pas casser la broche de
terre du cordon d'alimentation.
Do not disregard the safety that a polarized or
grounded connection can provide. A polarized
connection consists of two plugs, one of which
is larger than the other. A grounded connection
has two blades and a third one that is grounded.
If the main plug provided cannot be inserted into
your outlet, consult an electrician to replace your
obsolete outlet.
Ne pas ignorer la sécurité qu'une prise polarisée
ou une prise de terre peut prévoir. Une prise
polarisée se compose de deux fiches, dont l'une
est plus large que l'autre. Une prise de terre
possède deux lames et une troisième qui est la
terre. Si la fiche principale fournie ne peut être
insérée dans votre prise, consultez un
électricien pour remplacer votre prise obsolète.
Use only accessories specified by the
manufacturer.
Utiliser uniquement les accessoires spécifiés
par le fabricant.
Use only with its transport carriage, stand,
tripod, console or table specified by the
manufacturer or sold with the product. When
using a carriage, move the carriage assembly
with the product carefully to avoid damage from
falling over.
Utiliser uniquement avec son chariot de
transport, support, trépied, console ou table
spécifiés par le fabricant ou vendu avec le
produit. Lors de l'utilisation d'un charriot,
déplacez l'ensemble chariot avec le produit
avec soin pour éviter tout dommage de chute.
Unplug this apparatus during lightning storms or
when it is not being used for long periods.
Débrancher cet appareil durant les orages ou
lorsqu'il n'est pas utilisé pendant de longues
périodes.
Refer all servicing to qualified service personnel.
A technical intervention is required when the
apparatus has been damaged in any way, for
example if the power cord or plug is damaged,
liquid has been spilled or objects have fallen
inside the unit, if the product has been exposed
to rain or moisture, if it does not operate
normally or if it has been dropped.
Confier toute réparation à du personnel qualifié.
Une intervention technique est nécessaire
lorsque l'appareil a été endommagé de quelque
façon, par exemple si le cordon d'alimentation
ou la fiche est endommagé, du liquide a été
renversé ou des objets sont tombés à l'intérieur
de l'unité, si le produit a été exposé à la pluie ou
à l'humidité, s'il ne fonctionne pas normalement
ou s'il a été jeté.
General Guideline
Directive gé né rale
It is recommended to reboot the device when
some functions are defect or inactive. If it still
can't solve the problems please contact your
dealer or agent.
Il est recommandé de redémarrer l'appareil
lorsque certaines fonctions sont défectueuses
ou inactives. Si le problème persiste, veuillez
contacter votre revendeur ou votre agent.

5
8-inch Rugged Windows Tablet PC M101EKB
1.3 Handling and Maintenance
General Guideline
Guide Gé né ral
Keep the product at least 13 cm (5 inches)
away from electrical appliances that can
generate a strong magnetic field such as TV,
refrigerator, motor, or a large audio speaker.
Garder le produit au moins à 13 cm (5 pouces)
de distance des appareils électriques qui
peuvent générer un fort champ magnétique
comme une télévision, un réfrigérateur, un
moteur, ou un important haut-parleur.
Do not place heavy objects on top of the tablet
computer as this may damage the display.
Ne pas placer d'objets lourds sur le dessus de
l'ordinateur tablette cela peut endommager
l'écran.
The screen surface can be easily scratched.
Use with care. Do not use paper towels to
clean the display but use the included cleaning
cloth. Avoid touching it with a pen or pencil.
La surface de l'écran peut être facilement
rayée. Utiliser avec précaution. Ne pas utiliser
de serviette en papier pour nettoyer l'écran
mais utiliser le chiffon de nettoyage inclus.
Éviter de toucher avec un stylo ou un crayon.
To maximize the life of the backlight in the
display, allow backlight to automatically turn off
as a result of power management. Avoid using
a screen saver or other software that prevents
the power management from working.
Pour maximiser la durée de vie du
rétroéclairage de l'écran, autoriser le
rétroéclairage résultant de la gestion de
l'alimentation. Éviter d'utiliser un économiseur
d'écran ou un autre logiciel empêchant la
gestion de l'alimentation de fonctionner.
Cleaning Guideline
Guide de nettoyage
Use a soft cloth moistened with water or a non-
alkaline detergent to wipe the exterior of the
product.
Utiliser un chiffon doux humidifié avec de l’eau
ou un détergeant non alcalin pour essuyer
l'extérieur du produit.
Gently wipe the display with a soft, lint-free
cloth. Do not use alcohol or detergent on the
product.
Essuyer délicatement l'écran avec un chiffon
doux non pelucheux. Ne pas utiliser d'alcool ou
un détergent sur le produit.
Touchscreen Guideline
Guide de l'é cran tactile
Use your finger or the stylus on the display.
Using sharp or metallic object may cause
scratches and damage the display, thereby
causing errors.
Utiliser votre doigt ou le stylet sur l'écran.
L'utilisation d'un objet pointu ou métallique
peut provoquer des rayures.
Use a soft cloth to remove dirt on the display.
The touchscreen surface has a special
protective coating that prevents dirt from
sticking to it. Not using a soft cloth may cause
damage to the special protective coating on
the touchscreen surface. To clean off hard to
remove dirt, blow some steam on the particular
area and gently wipe away using a soft cloth.
Utiliser un chiffon doux pour enlever la
poussière sur l'écran. La surface de l'écran
tactile a un revêtement protecteur spécial
empêchant la saleté de se coller à lui. Ne pas
utiliser un chiffon doux peut endommager le
revêtement spécial sur la surface de l'écran
tactile. Pour nettoyer les saletés plus difficiles
à enlever, souffler de la buée sur la zone
particulière et essuyer doucement avec un
chiffon doux.
Do not use excessive force on the display.
Avoid placing objects on top of the display as
this may cause the glass to break.
Ne pas utiliser une force excessive sur l'écran.
Éviter de placer des objets au dessus de
l’écran cela pourrait provoquer une cassure du
verre.
When there is a noticeable discrepancy in the
operation of the touchscreen function (your
touch does not correlate to the proper location
on the screen), recalibrate the touchscreen
display.
Lorsqu'il y a un écart sensible dans le
fonctionnement de l'écran tactile (votre contact
ne correspond pas à la bonne position sur
l'écran), recalibrer l'écran tactile.

6
Chapter 1: Read Me First
1.4 Declaration of Conformity
FCC Statement
This device complies with part FCC Part 2. 1092 rules.
Operation is subject to the following two conditions:
This device may not cause harmful interference.
This device must accept any interference received including
interference that may cause undesired operation
This equipment has been tested and found to comply with the limits for a class "B" digital device, pursuant
FCC Part 2. 1092. These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications. Operation of this equipment
in a residential area is likely to cause harmful interference in which case the user will be required to
correct the interference at him own expense.
CE Notice (European Union)
This equipment is in conformity with the requirement of the following EU legislations and harmonized
standards. Product also complies with the Council direct.
Electromagnetic Compatibility Directive (2014/30/EU)
EN55024: 2010/ A1: 2015
oIEC61000-4-2: 2009
oIEC61000-4-3: 2006+A1: 2007+A2: 2010
oIEC61000-4-4: 2012
oIEC61000-4-5: 2014
oIEC61000-4-6: 2014
oIEC61000-4-8: 2010
oIEC61000-4-11: 2004
EN55032: 2012/AC:2013
EN61000-3-2:2014
EN61000-3-3:2013
Low Voltage Directive (2014/35/EU)
EN 60950-1:2006/A11:2009/A1:2010/A12:2011/ A2:2013
1.5 Copyright Notice
No part of this document may be reproduced, copied, translated, or transmitted in any form or by any
means, electronic or mechanical, for any purpose, without the prior written permission of the original
manufacturer.
1.6 Trademark Acknowledgement
Brand and product names are trademarks or registered trademarks of their respective owners.

7
8-inch Rugged Windows Tablet PC M101EKB
1.7 Disclaimer
Winmate Inc. reserve the right to make changes, without notice, to any product, including circuits and/or
software described or contained in this manual in order to improve design and/or performance. We
assume no responsibility or liability for the use of the described product(s) conveys no license or title
under any patent, copyright, or masks work rights to these products, and make no representations or
warranties that these products are free from patent, copyright, or mask work right infringement, unless
otherwise specified. Applications that are described in this manual are for illustration purposes only. We
make no representation or guarantee that such application will be suitable for the specified use without
further testing or modification.

8
Chapter 2: Getting Started
Chapter 2: Getting Started
This chapter tells you step by step how to get the Tablet Computer up and running. You will find instructions
for the following procedures:
Unpacking
Description of Parts
First Time Operations
Powering On/Off
2.1 Unpacking
Thank you for purchasing the M101EKB Rugged Windows Tablet Computer. The rugged design allows you
to use it in harsh outdoor environments.
Check and identify the supplied accessories:
Tablet Computer
Quick Start Guide
Standard Battery
•Power Adapter
•Power Cord and Plugs
•Stylus
Your package may include other optional accessories based on your order.
•Desk Dock
•Shoulder Strap
•Vehicle Dock (without VGA output)
•Carry Bag
•Vehicle Cradle
•Micro HDMI Cable
•Vehicle Charger
•USB-C to Ethernet Adapter
•Battery Charger
•USB-C to RS232 Adapter
•Hand Strap
•USB-C to USB-A Hub

9
8-inch Rugged Windows Tablet PC M101EKB
2.2 Description of Parts
Front:
Left: Right:
No
Item
Description
1
Touch Screen
Displays and acts as
one of the inputs for the
computer.
2
Power Button
Power on/off computer.
3
LED
Indicators:
Shows the current
status of the computer.
4
Function
Buttons
Programmable function
keys configured by
Winset utility.
5
I/O Cover
Protects I/O ports.
6
QWERTY
Keypad
Input characters using
the QWERTY keypad.
Front LED Indicators Details:
Left side
No
Item
Description
9
Micro HDMI
HDMI output to
external display.
10
Clear CMOS
Hardware reset button.
11
MicroSD
Card Reader
Memory card reader
port for MicroSD Card
12
USB 3.0
Type-C
support PD
20V In
A high-speed USB port
connects to USB
devices, such as a
USB flash drive,
mouse, keyboard,
printer, etc.
Note: The USB Type-C
connector follows USB
3.0 standards, not
supporting Alternate
Mode (ALT)
13
USB 3.0
Type A
USB 3.0 port connects
to USB devices, such
as USB flash drive,
mouse, keyboard,
printer, etc.
14
Mic In/Line
Out
Headset or headphone
can be connected (Mic
is only supported with
3.5mm 4-pin headset)
15
Power Jack
DC power input jack.
Right side

10
Chapter 2: Getting Started
Rear:
No
Item
Description
13
Expansion
Port
Provide optional
connectivity to custom
modules for special
application (USB2.0 x 1,
RS232 x 1).
14
Rear Camera
5MP Autofocus
Camera. Captures
photos and videos.
15
Battery
Release
Slider
Spring-loaded slider
that latches the battery
in.
16
Touch Pen
Slot
Pen holder slot to store
touch pen.
17
Battery Lock
Latch
Latch to lock the battery
in place once battery is
inserted. Not spring-
loaded.
18
Speakers
Emit sounds.
19
Battery
7.4V, typ. 5140 mAh Li-
Polymer Battery
(2S1P).
7.4V, typ. 10280 mAh
Li-Polymer Battery
(2S2P, optional).
20
LTE Module
/ SIM card
slot
Service window to
insert Micro SIM card.
Also provide access to
LTE Module.
21
Volume
Buttons
Volume Control.
(+) Raise volume,
(-) Lower volume.
22
Fn2 Button
Toggles Barcode
Scanner
23
Optional HF
RFID Reader
Scans HF RFID tags.
Top:
Bottom:
No
Item
Description
24
Optional
Barcode
Reader
Barcode Scanner for
reading of 1D/2D
barcode.
25
Kensington
Lock Port
Provides lock access
for Kensington Lock.
26
Docking
Connector
Port to docking
solutions such as
vehicle docking to
provide power and
external antenna

11
8-inch Rugged Windows Tablet PC M101EKB
2.3 Hot Keys for Specific Functions
For the physical buttons on the tablet computer, in addition to its dedicated functions detailed in the
previous section, it can also be used to emulate commonly used keyboard key strokes. Under different
scenario, a single physical button or a combination of physical buttons provide different keyboard key
strokes, which are specified below:
In POST (before Windows boots up):
Buttons
Keystroke
F7
Enters BIOS
Setup Screen.
Fn2
ESC
Volume Up (+)
Up
Volume Down (-)
Down
In Windows:
Buttons
Keystroke
Fn + F1
Opens Winset application
Fn + F4
RF Power
(Wifi/BT/WWAN/GPS Ant.)
Fn + F5
Camera(Call Winset Cam)
Fn + F7
Zoom +
Fn + F8
Zoom -
Fn + F10
Increase size of on-screen
keyboard
Volume Up (+)
Brightness or Volume
(Default Brightness)
Volume Down (-)
Brightness or Volume
(Default Brightness)
Fn2
Default: Barcode Scan
(Configurable)
2.4 Indicators
Item
Description
Power Indicator
Blue–Tablet is ON
No light–Tablet is OFF
Battery Status
Orange–AC adapter is plugged in and charging
Green–AC adapter is plugged in and battery is full charged
Solid Red - Low battery (<10%)
Blinking Red –Battery is being hot swapped.
No light –Battery is in use and more than 10%
Light Sensor
Light sensor automatically adjusts the panel brightness based on
the light settings.
Disk Activity Indicator
Green - Disk Activity
No light - Disk Idling
RF Communications
Green - WLAN/BT/WWAN/GPS ON
No light - WLAN/BT/WWAN/GPS are all OFF

12
Chapter 2: Getting Started
2.5 First-Time Operation
2.5.1 Installing SIM card (For WWAN Equipped Devices) (Optional)
To install the SIM card:
Tools Needed:
Service Windows
Screw: M2x5, 4 pc
Screwdriver: Philips Type, Size #0, for
M2 screws, torque: 2.0 ± 0.5 kgf.cm
WWAN Module
Screw: M2x3.5, 1 pc
Screwdriver: Philips Type, Size #0, for M2
screws, torque: 2.0 ± 0.5 kgf.cm
❶Remove four screws and remove the service
window.
❷Remove the one screw that secures the WWAN
module. Carefully lift the module. Do not disconnect
cables.
❸Carefully flip and move the WWAN module and to
the right. Do not disconnect cables!
❹Insert SIM-Card all the way in. Chip/ contact facing
down.
❺Use your hand to carefully pull the cable outside
the module card. Re-insert the WWAN module
and fasten one screw. Accurately route the
cables. Do not bend, pinch, or squeeze the
cable.
❻Re-insert the service window and fasten with the four
screws.
Caution When re-inserting WWAN module, please pay attention to cable routing. Make sure
the cable module connects properly and does not get squeezed.
Attention Notez l'acheminement du câble lorsque vous réinstallez le module WWAN.
Assurez - vous que les modules de câble sont correctement connectés et qu'ils ne sont pas
pincés.

13
8-inch Rugged Windows Tablet PC M101EKB
2.5.2 Installing a Micro SD Card
Your tablet supports up to 128GB additional storage with an optional microSD card slot.
To install Micro SD Card:
1. Open I/O protective cover by pulling out the latch.
2. Insert the microSD card into a slot with contacts
facing down.
3. Press the card in to ensure that it is seated properly.
4. Close I/O protective cover.
To remove Micro SD Card:
1. Open I/O protective cover by pulling out the latch.
2. Push and release the microSD card to unlock it.
3. Pull out the microSD card.
2.5.3 Installing Battery
To install the battery pack:
1. Disconnect any cords connected to the tablet computer.
2. Turn the tablet over, back facing up.
3. Locate the Battery Lock Latch and push it to the “Unlocked”position.
4. Locate the Battery Release Slider that is spring-loaded. Pull back and hold.
5. Insert the battery with the connector-pins side first, and then lower the battery into the battery
compartment. Continue to hold the Battery Release Slider until the battery is fully inserted.
6. Make sure the battery is completely lowered into the compartment before letting go of the Battery
Release Slider. Battery will be flat against the housing once fully inserted.
To remove the battery pack:
1. Shut down the tablet (or put into sleep mode). Disconnect any cords connected to the computer.
2. Turn the tablet computer over, back facing up.
3. Locate the Battery Lock Latch and push it to the “Unlocked”position.
4. Locate the Battery Release Slider that is spring-loaded. Pull back and hold.
5. Lift the battery out using the opening on the side of battery compartment.
2.5.4 Charging Your Tablet
The Tablet operates either on external AC power or internal battery power. It is recommended to use AC
power when you start up the Tablet for the first time.
Caution: Use only the AC adapter included with your Tablet Computer. Using other AC
adapters may damage the Tablet Computer and the Battery.
To connect a tablet to AC power:

14
Chapter 2: Getting Started
1. Open I/O protective cover by pulling out the latch.
2. Plug the DC cord of the AC adapter into the power jack of the tablet computer.
3. Plug the AC power cord into the AC adapter.
4. Plug the AC power cord into the electrical outlet.
The battery LED indicator shows different battery states:
Orange - AC adapter is plugged in and battery is charging.
Green - AC adapter is plugged in and battery is fully charged.
Solid Red - Low battery level (<10%).
No light –Battery is in use and charged (>10%).
2.5.5 Starting the Tablet
Important: When powering on the device for the first time, please make sure there’s no
interruption during the Windows setting up process, for example, accidentally powering off. If
it happened, please access the recovery menu by pressing F6 button on the front bezel to
initiate recovery process.
Press and hold the power button for 3 seconds until the blue LED power indicator light up.
Note: Do not press the power button repeatedly.
Do not perform the following operations until the Disk Activity Indicator off
Connecting or disconnecting the AC adapter
Pressing the power button
Touching the tablet buttons, screen, or external keyboard/mouse
To power off the Tablet Computer:
1. Make sure you have closed any programs that are open on the Desktop. Start Screen apps don’t
need to be closed.
2. Tap on the Settings charm.
3. Tap on Power.
4. Tap on Shut Down.
5. Wait for Tablet Computer to power off.
Note: The computer will forcibly be powered off if the power button is pressed and held
for 6 seconds or longer.

15
8-inch Rugged Windows Tablet PC M101EKB
Chapter 3: Setting Up Windows for the First Time
This chapter details how to setup the Windows that may be installed on the tablet for the first time.
3.1 OS Introduction
The M101EKB Tablet Computer operates on Windows 10 IoT Enterprise operating system.
Caution: Make sure the battery is full charged before starting the Tablet Computer for
the first time with internal battery power.
Public network: Select this location if you do not recognize all the computers on the network. (For
example, you are in a coffee shop or airport, or you have mobile broadband.) This is a public
network and is not trusted. Select the location where you will most often use the computer.
3.2 Setting up Windows 10 IoT Enterprise
Follow the steps below to complete the Windows 10 IoT Enterprise setup process.
1. Press the power button to turn on the computer.
2 .First, select your country/region, your preferred app language, your preferred keyboard layout, and your
time zone, then tap Next.
3. On the Here's the legal stuff screen, read through the disclosures, then tap Accept.

16
Chapter 3: Setting Up Windows for the First Time
4. Windows will then try to connect to network. Tap Skip this step to continue without a wireless
connection as you can then set up the network later.
5. On the Get going fast screen, click Use Express settings for the fastest setup. If you would like
more information, tap Learn more, or if you would like to select your own options, click Customize
settings.

17
8-inch Rugged Windows Tablet PC M101EKB
6. To create a local account, type your User name, password, and Password hint in the fields provided,
then tap Next.
7. The initial setup screens are complete, and the desktop is displayed.
8. Read any introductory screens describing features of your computer, and tap Next upon completing
each. You are now done with the initial setup process.

18
Chapter 4: Operating the Device
Chapter 4: Operating the Device
4.1 Winset Utility
Winset ® is a program to control the main functions of the M101EKB. In Winset ® , users can check
system information, control function button settings, and configure blanking function, scanner wedge
and settings.
Long-press Fn + F1 function key to open Winset® . You can open Winset ® by double-clicking
on the Winset icon on the desktop.
The Fn key is located on the bottom right of the keypad
4.1.1 System Information
System information menu displays main information about this computer.
Note: Please download the Software Development Kit (SDK) from Winmate Download Center
(the QR code in the cover page).
Please notice that HF RFID reader, Barcode reader are optional module, please make sure user
have ordered the module before using the SDK.

19
8-inch Rugged Windows Tablet PC M101EKB
4.1.2 WinSet Shortcut Setting
Long-press Fn + F1 function key to open Winset. In Function Buttons, submenu users can set
up functions of the function keys F1~F10.
Press the button next to F1; user will see the window show up just like the below picture. Then
choose a program to be opened by just pressing F1 next ti
