WINTACT WT8811 User manual

A
1
2
3
4
5
6
A
DOCUMENT NO.: QR-208/A
B C D E
B C D E
1
2
3
4
5
6
SCALE
SIZE
DATENAME
APPROVALS
APP. BY
CUSTOMTER
DRAWN BY
CHECKED BY
1:1
A4
更改记录
次 号
1.
2.
3.
VER.A0
SHEET OF
PART Number: X-XXX-XXX-XX 1 1
WT8811 (WINTACT) 中 文有 唛说 明书 示意 图
日 期
更 改 内 容
71688811001
MJP 2018-04-09
SHENZHEN JUMAOYUAN SCIENCE AND TECHNOLOGY CO., LTD.
71688811001
WT8811 中文有唛说明书
材料:105G双铜;
页数： ( )
成品尺寸:190*130MM; 公差:+-1.0MM;
工艺:单色双面印刷,加工:装订成册说明书;骑马钉
20P 封二及封三留空白
130.00 mm
95.00 mm
Version：WT8811-EN-00
MODEL: WT8811
Compound Gas Monitor
Instruction Manual
WT8811
Standard:Q/HTY 010-2018 Q/HTY 011-2018
Q/HTY 012-2018 Q/HTY 007-2018
Any queries,kindly contact us feel free.
Contact Email: [email protected]
Tel: [phone](Wechat&WhatsApp)
Skype: raymondzheng2014

A
1
2
3
4
5
6
A
DOCUMENT NO.: QR-208/A
B C D E
B C D E
1
2
3
4
5
6
SCALE
SIZE
DATENAME
APPROVALS
APP. BY
CUSTOMTER
DRAWN BY
CHECKED BY
1:1
A4
更改记录
次 号
1.
2.
3.
VER.A0
SHEET OF
PART Number: X-XXX-XXX-XX 1 1
WT8811 (WINTACT) 中 文有 唛说 明书 示意 图
日 期
更 改 内 容
71688811001
MJP 2018-04-09
SHENZHEN JUMAOYUAN SCIENCE AND TECHNOLOGY CO., LTD.
71688811001
WT8811 中文有唛说明书
材料:105G双铜;
页数： ( )
成品尺寸:190*130MM; 公差:+-1.0MM;
工艺:单色双面印刷,加工:装订成册说明书;骑马钉
20P 封二及封三留空白
130.00 mm
95.00 mm
-01-
1.Before use
Thanks for your purchasing our product, please check the following
components after you unpacking the box. If there is any missing or
wrong page manual,please contact the local dealer.
Check up
Compound Gas Monitor（Contain Alligator clips） 1PCS
Charger 1 PCS
Transparent trachea 1PCS
Cover (with screws) 1PCS
Manual 1PCS
Data line 1PCS
When you are ready to use this product, please make sure to read this
manual first, and follow the relevant operations in usage so that you can
fully understand the company's products and services while also avoiding
unnecessary man-made damage or other accidents.
Contents
1.Before use
2.Operation manual
Check up-------------------------------------------------- (01)
Introduction----------------------------------------------- (02)
Name of parts---------------------------------------------(03)
Functions--------------------------------------------------(04)
Specifications-------------------------------------------- (0 5)
Main Menu Interface------------------------------------ (06)
Single Measurement Interface ------------------------ (07)
Multiple Measurement Interface---------------------- (08)
Record Checking Interface-----------------------------(08)
Alarm Setting Interface----------------------------------(11)
System settings interface-------------------------------(11)
3.Calibration Interface (ONLY FOR PROFESSIONAL)
Sensor Calibration Selection Interface---------------(12)
Three Sensor Calibration Methods------------------- (13)
4.Others
Charging function description------------------------- (14)
Warnings and Precautions----------------------------- (15)
Compound Gas Monitor（Contain Alligator clips）1PCS
Charger 1 PCS
Transparent trachea 1PCS
Cover (with screws) 1PCS
Manual 1PCS
Colorful package 1PCS
Guaranty card 1PCS
Data line 1PCS
Packing box 1PCS

A
1
2
3
4
5
6
A
DOCUMENT NO.: QR-208/A
B C D E
B C D E
1
2
3
4
5
6
SCALE
SIZE
DATENAME
APPROVALS
APP. BY
CUSTOMTER
DRAWN BY
CHECKED BY
1:1
A4
更改记录
次 号
1.
2.
3.
VER.A0
SHEET OF
PART Number: X-XXX-XXX-XX 1 1
WT8811 (WINTACT) 中 文有 唛说 明书 示意 图
日 期
更 改 内 容
71688811001
MJP 2018-04-09
SHENZHEN JUMAOYUAN SCIENCE AND TECHNOLOGY CO., LTD.
71688811001
WT8811 中文有唛说明书
材料:105G双铜;
页数： ( )
成品尺寸:190*130MM; 公差:+-1.0MM;
工艺:单色双面印刷,加工:装订成册说明书;骑马钉
20P 封二及封三留空白
130.00 mm
95.00 mm
-03--02-
2
1
34
5
6
7
8
10
9
(Figure 1)
11
Compound Gas Monitor adopts high-quality gas sensors,which displays
safety and reliability with accurate measurement and stable performance.
It has excellent sensitivity and repeatability, easy to use and maintain, and
meets the requirements by safety monitoring in industrial site for high
reliability of the equipment. The shell is made of high-strength engineering
plastics and compound non-slip rubber, dust and explosion-proof, with high
strength and smooth handfeel.
Compound Gas Monitor is widely used in petroleum, chemical, environ-
ental protection, metallurgy, refining, gas transmission and distribution,
biochemical medicine, agricultural research, etc.
This indstrument conforms with the following procedures and calibration
standards:
Gb3836.1—2010 Explosive Atmospheres Part 1: General Requirements
for Equipment.
GB3836.4—2010 Explosive Atmospheres Part 4: Equipment with
Intrinsically Safe “I” Protection.
GB15322.3—2003 Portable Combustible Gas Detectors Part 3: Portable
Combustible Gas Detectors with a Measurement Range of (0~100) %LEL.
JJG693—2011 Verification Standards for Combustible Gas Detection Alarm.
JJG 365 — 2008 Verification Procedures for Electrochemical Oxygen Tester
JJG695-2003 Verification Procedure for Hydrogen Sulfide Gas Detector
JJG915-2008 Verification Procedures for Carbon Monoxide Detection Alarm
Introduction Name of parts
1. Alligator clips on the back.
2.Transparent window for alarm indicator.
3.LCD display.
4.DC adaptor socket.
5.Return button: long press on/off button, short press to return.
6.Left button: left forward, upward, decrease.
7.Right button: right forward, downward, increase.
8.Confirm button: confirmation.
9.Buzzer alarm hole.
10.Gas sensing hole.
11.Gas calibration cover.

A
1
2
3
4
5
6
A
DOCUMENT NO.: QR-208/A
B C D E
B C D E
1
2
3
4
5
6
SCALE
SIZE
DATENAME
APPROVALS
APP. BY
CUSTOMTER
DRAWN BY
CHECKED BY
1:1
A4
更改记录
次 号
1.
2.
3.
VER.A0
SHEET OF
PART Number: X-XXX-XXX-XX 1 1
WT8811 (WINTACT) 中 文有 唛说 明书 示意 图
日 期
更 改 内 容
71688811001
MJP 2018-04-09
SHENZHEN JUMAOYUAN SCIENCE AND TECHNOLOGY CO., LTD.
71688811001
WT8811 中文有唛说明书
材料:105G双铜;
页数： ( )
成品尺寸:190*130MM; 公差:+-1.0MM;
工艺:单色双面印刷,加工:装订成册说明书;骑马钉
20P 封二及封三留空白
130.00 mm
95.00 mm
-05-
%LEL
%VOL
μmol/mol
μmol/mol
0~100
0~30
0~100
0~1000
0.1
0.1
0.1
1
≤±5%FS
6~8h
71*153*49mm
-04-
Functions
Color-screen display, user-friendly interface.
Bilingual choices: Chinese/English.
Measurement of four gas concentrations: Combustible gas (LEL),
Oxygen (O ),Hydrogen sulfide (H S), Carbon monoxide (CO)
22
Three alarm forms: sound/light/vibration.
Data recording and review function, continuously record 120,000 data
Charging function.
.
Response time (90%)
Less than 30 seconds
Specifications
Indication mode
LCD displays real-time data and system state,
LED, sound, vibration indication alarm
Charging time
Standby time
More than 8h on end (slightly change
with working state)
Working voltage
DC 3.7V (Lithium battery capacity 1800mAh)
Oxygen O2
Carbon monoxide CO
Hydrogen sulfide H S
2
Combustible gas LEL
Measuring item
Unit Range Resolution
Compound Gas Monitor range
Accuracy
Storage Conditions Temperature:-10~55℃; Humidity:＜85%RH
Operation Conditions
Temperature:- 20~50℃;
Humidity:＜ 95%RH non-condensing
Dimensions
Weight
218.7g With battery

A
1
2
3
4
5
6
A
DOCUMENT NO.: QR-208/A
B C D E
B C D E
1
2
3
4
5
6
SCALE
SIZE
DATENAME
APPROVALS
APP. BY
CUSTOMTER
DRAWN BY
CHECKED BY
1:1
A4
更改记录
次 号
1.
2.
3.
VER.A0
SHEET OF
PART Number: X-XXX-XXX-XX 1 1
WT8811 (WINTACT) 中 文有 唛说 明书 示意 图
日 期
更 改 内 容
71688811001
MJP 2018-04-09
SHENZHEN JUMAOYUAN SCIENCE AND TECHNOLOGY CO., LTD.
71688811001
WT8811 中文有唛说明书
材料:105G双铜;
页数： ( )
成品尺寸:190*130MM; 公差:+-1.0MM;
工艺:单色双面印刷,加工:装订成册说明书;骑马钉
20P 封二及封三留空白
130.00 mm
95.00 mm
1. Long press on/off button (back
button) for about 2 seconds. After
powering on, the instrument enters
into the countdown interface (for
the sensor takes about 20 seconds
to stabilize). After the countdown
is over, the main menu screen will
appear, as shown in the right figure.
2. The current date and time are
displayed on the upper left corner.
If the time is incorrect, enter the settings interface to set.
3. The battery level is displayed on the upper right corner. When the
remaining power is low, the battery indicator will turn red. When the
power level is detected to be too low, the instrument will start 10s
countdown for automatic shutdown. The countdown second will be
displayed on the left side of the battery indicator. After the countdown is
over, the instrument will automatically shut down.
4.The main menu has 6 icons, namely, single measurement, multiple
measurement, viewing records, alarm settings, syste settings,
calibration.
5. Functions of Buttons:
1) Back button : When the icon is selected, touch the icon and it will
turn unselected, touch it again to go back to the first icon (unslected).
2) Left/right button / : If an icon is not selected, touch the icon
and it will become selected. Touch it again to select the next icon by
pressing left/ right button.
3) Confirm button : If an icon is not selected, touch it once and th
icon will turn selected; when the icon is selected, press confirm button
to enter the corresponding interface of the icon.
-07--06-
2.Operation manual
Main Menu Interface
单 个 测 量 界 面
Single Measurement Interface
1. This interface only displays single
measurement values; the left side
shows the maximum minimum,
and average value,where the
average value is the value mea-
sured in the last 4 minutes; the right
side shows the high and low alarm
values, and the middle shows
real-time values.
2. When checking oxygen
concentration, if the concentration
value is lower than the low alarm value, the instrument will trigger low
alarm state. If the concentration is greater than the high alarm value,
the instrument will trigger high alarm state; for the concentration of
gas other than oxygen, if the concentration value is greater than the low
alarm value,the instrument will trigger low alarm state. If the
concentration is greater than the high alarm value, the instrument will
trigger high alarm state.
3. In alarm state, Danger icon shows up; otherwise, Safety icon is
displayed.
4. In the alarm state, if the alarm is triggered, an alarm will be issued and
the alarm will be issued when the alarm is high.The alarm in high alarm
state shows more urgency and faster frequency than that of low alarm
state.
5. The alarm has three forms, light flashing alarm, sound alarm and
vibration alarm, which can be turned on/off in the alarm setting.
6. The lower left corner of the screen shows the lower limit of the range,
the lower right corner shows the upper limit of the range, the lowermost
triangle indicates the color of real-time value.
Single Measurement Interface Display
(Figure 3)
Main Menu Interface Display
(Figure 2)

A
1
2
3
4
5
6
A
DOCUMENT NO.: QR-208/A
B C D E
B C D E
1
2
3
4
5
6
SCALE
SIZE
DATENAME
APPROVALS
APP. BY
CUSTOMTER
DRAWN BY
CHECKED BY
1:1
A4
更改记录
次 号
1.
2.
3.
VER.A0
SHEET OF
PART Number: X-XXX-XXX-XX 1 1
WT8811 (WINTACT) 中 文有 唛说 明书 示意 图
日 期
更 改 内 容
71688811001
MJP 2018-04-09
SHENZHEN JUMAOYUAN SCIENCE AND TECHNOLOGY CO., LTD.
71688811001
WT8811 中文有唛说明书
材料:105G双铜;
页数： ( )
成品尺寸:190*130MM; 公差:+-1.0MM;
工艺:单色双面印刷,加工:装订成册说明书;骑马钉
20P 封二及封三留空白
130.00 mm
95.00 mm
-09--08-
1) Back button : back to main menu interface.
2) Left/right button / : Switch measurement items (oxygen,
carbonmonoxide, hydrogen sulfide, combustible gases).
3) Confirm button : No use.
单个测量界面
Multiple Measurement Interface
1. The interface displays the real-time
values of four items simultaneously,
when the value exceeds the range,
the number will flash; if alarm is on,
an alarm will be triggered.
2. Button function:
1) Back button : Back to main
menu interface.
2) Left/right buttons / : no
use.
3) Confirm button : no use.
Multiple Measurement Interface Display
(Figure 4)
单个测量界面
Record Checking Interface
1. After entering record checking interface, as shown in Figure 5.1. From
left to right shows the number of each record, start time of record,
number of record groups, record interval (seconds); each record can
store 1019 pieces of data, and a total of 125 groups of records can be
stored. When the stored data is full, the indicator “FULL” will appear at
the top of screen.
The bottom shows the selected page number and total page number;
which is page selection interface. Press “ ”button to return to main
menu,and press“ / ”button to choose previous or next page.
After selecting page number, press“ ”button to choose one record
and enter into record selection
interface, as shown in Figure 5.2.
3. In record selection interface
shown in Figure 5.3, press “ ”
button to return to record
selection state; Press “ ” /
“ ” button to check, delete,
and choose which data to be
deleted. Press“ ” button to
enter into interface for checking
(Figure 5.4), deleting (Figure 5.5)
and selected deletion (Figure 5.6).
2. In record selection interface
shown in Figure 5.2, press “ ”
button to return to page
selection interface. Press “ ” /
“ ” button to choose previous
or next page .Press “ ”
button to check, delete, and
choose which data to be delete,
as shown in Figure 5.3.
Page selection interface(Figure 5.1)
Record Checking Interface(Figure 5.2)
Checking delete interface(Figure 5.3)

A
1
2
3
4
5
6
A
DOCUMENT NO.: QR-208/A
B C D E
B C D E
1
2
3
4
5
6
SCALE
SIZE
DATENAME
APPROVALS
APP. BY
CUSTOMTER
DRAWN BY
CHECKED BY
1:1
A4
更改记录
次 号
1.
2.
3.
VER.A0
SHEET OF
PART Number: X-XXX-XXX-XX 1 1
WT8811 (WINTACT) 中 文有 唛说 明书 示意 图
日 期
更 改 内 容
71688811001
MJP 2018-04-09
SHENZHEN JUMAOYUAN SCIENCE AND TECHNOLOGY CO., LTD.
71688811001
WT8811 中文有唛说明书
材料:105G双铜;
页数： ( )
成品尺寸:190*130MM; 公差:+-1.0MM;
工艺:单色双面印刷,加工:装订成册说明书;骑马钉
20P 封二及封三留空白
130.00 mm
95.00 mm
-11--10-
4. The interface shown in Figure 5.4 is
reviewing interface of recorded data,
and the concentration value displa-
yed on the right side is the value of
data point pointed out by red line;
1/997 is displayed in the lower right
corner, where 1 is the data point
number and 997 is the group num-
ber of recorded data; is an
icon back to the start point, select
the icon and press the“ ”
button, the data point number will
return to 1, and the red line goes
back to the beginning; is an
icon for starting, after selecting it,
the recorded data will automati-
cally start reviewing, and the icon
will turn into , after selecting
it, the automatic review will stop,
the icon will turn into ; is
an icon for moving leftwards, after
selecting it and confirming, the red
line will move to the left; is an
icon for moving rightwards, after
selecting it, the red line will move
to the right; is an icon for fast
moving leftwards; is an icon
for fast moving rightwards.
5. Figure 5.5 shows deletion interface.
After selecting "Yes" and confirm,the recorded data will be deleted.
6. Figure 5.6 shows selected deletion interface. Pressing“ ”/“ ”
button and“ ” button to input the serial number to be deleted, select
Deletion Interface (Figure 5.5)
Selected Deletion Interface (Figure 5.6)
“OK” and press “ ”button. After that, the data within the range of
serial number will be deleted.
单 个 测 量 界 面
Alarm Setting Interface
1. The alarm settings for each sensor
can be set separately under this
interface.
2. There are three alarm modes: light,
sound, and vibration, which can be
respectively set to be on or off.
When the real-time measured value
is greater than the high alarm
value or low alarm value (for oxygen
when it is lower than the low alarm value), the alarm which is set to be on
will be triggered.
Alarm Setting Interface (Figure 6.1)
单 个 测 量 界 面
System settings interface
1. There are six setting items under the
interface: language, date and time,
auto storage, auto power off, back-
light setting, and reset default.
2. The language can be Chinese or
English; date and time can be set
as year, month, day, hour, minute;
if auto storage is on, the measured
data will be automatically saved
according to the set recording interval. If not, it will not be stored
automatically; if the auto off is on, if there is no button operation within
the set shutdown time, it will automatically shut down. If auto off is not
on,it will not automatically shut down; in the backlight setting, there are
three levels of backlight brightness; all parameters except for date and
Checking Interface ( Figure 5.4 )
System settings interface Figure 7.1)(

A
1
2
3
4
5
6
A
DOCUMENT NO.: QR-208/A
B C D E
BCD E
1
2
3
4
5
6
SCALE
SIZE
DATENAME
APPROVALS
APP. BY
CUSTOMTER
DRAWN BY
CHECKED BY
1:1
A4
更改记录
次 号
1.
2.
3.
VER.A0
SHEET OF
PART Number: X-XXX-XXX-XX 1 1
WT8811 (WINTACT) 中 文有 唛说 明书 示意 图
日 期
更 改 内 容
71688811001
MJP 2018-04-09
SHENZHEN JUMAOYUAN SCIENCE AND TECHNOLOGY CO., LTD.
71688811001
WT8811 中文有唛说明书
材料:105G双铜;
页数： ( )
成品尺寸:190*130MM; 公差:+-1.0MM;
工艺:单色双面印刷,加工:装订成册说明书;骑马钉
20P 封二及封三留空白
130.00 mm
95.00 mm
-13--12-
time (including calibration parameters) in the instrument can be restored
to factory state;
1. First enter the sensor calibration selection interface shown in Figure
8.1. Press“ ”/“ ” button to select a sensor; then press “ ” to
enter the single sensor calibration interface, as shown in Figure 8.2;
2. In the interface of Figure 8.2, the left side is the calibration point option,
the right side is the calibration parameter corresponding to each
calibration point, and the lower right area shows real-time value,
minimum value, maximum value, average value and curve of the sensor
signal; the concentration setting refers to setting the concentration value
to be calibrated; calibration AD value refers to the signal value output by
the sensor corresponding to the set concentration value; offset
adjustment refers to the reading plus or minus the set deviation on the
basis of the calibration point; timing calibration means that after the
timing calibration is on, the countdown of the set timing starts. When the
countdown reaches 0, the measured signal value is automatically stored
in the calibration AD value. Manual calibration means that when the
manual calibration is on, the real-time signal value is stored in the
3.Calibration Interface (ONLY FOR PROFESSIONAL)
Sensor Calibration Selection Interface
Sensor Calibration Selection
Interface (Figure 8.1)
calibration AD value by pressing “ ”button; the value between manual
calibration icon and ENTER icon is the real-time measured concentration
value.
Three Sensor Calibration Methods
1. there are three kinds of calibration methods:
1) Input the calibration AD value directly: a. Set concentration value;
b.Open to calibration gas which has set concentration value; c. Wait for
the signal curve at the lower right of screen to be stable; d. After the
signal is stable,input the real-time signal value to calibration AD value.
2) Manual Calibration: a. Set concentration value; b. Open to the
calibration gas which has set the concentration value; c. Wait for the
signal curve at the lower right of screen to be stable; d. After the signal
is stable, select manual calibration. Press “ ” button to confirm that
the icon will be selected. Press “ ” button again and the real-time
signal value will be added to the calibration AD value.
3) Timing calibration: a. Set the concentration value; b. Open to the
calibration gas with the set concentration value; c. Select timing
calibration, press “ ” button, input the timing, then countdown
starts, when the countdown reaches 0, the real-time signal value will
be added to the calibration AD value.
4) If the calibration is wrong, you can recalibrate or restore to factory
settings in system settings.
2. When calibrating the zero point of carbon monoxide, hydrogen sulfide,
and combustible gas, you can increase the calibration AD value by 5~9
to prevent the readings from appearing unrecoverable.
Sensor Calibration Interface
(Figure 8.2)

A
1
2
3
4
5
6
A
DOCUMENT NO.: QR-208/A
B C D E
B C D E
1
2
3
4
5
6
SCALE
SIZE
DATENAME
APPROVALS
APP. BY
CUSTOMTER
DRAWN BY
CHECKED BY
1:1
A4
更改记录
次 号
1.
2.
3.
VER.A0
SHEET OF
PART Number: X-XXX-XXX-XX 1 1
WT8811 (WINTACT) 中 文有 唛说 明书 示意 图
日 期
更 改 内 容
71688811001
MJP 2018-04-09
SHENZHEN JUMAOYUAN SCIENCE AND TECHNOLOGY CO., LTD.
71688811001
WT8811 中文有唛说明书
材料:105G双铜;
页数： ( )
成品尺寸:190*130MM; 公差:+-1.0MM;
工艺:单色双面印刷,加工:装订成册说明书;骑马钉
20P 封二及封三留空白
130.00 mm
95.00 mm
-15--14-
4.Others
Charging function description
When the power is insufficient or the voltage cannot be turned on
due to undervoltage, please charge in time and charge it.During the
charging process, the alarm light will flash and the meter will no longer
detect the gas concentration and display the number of battery packs
dynamically. When the number of battery packs is full and no longer
changes dynamically, charging is completed.Then you can unplug the
charger, the meter can be used normally.To speed up charging process,
the screen will turn black after 10s of no operation.At this time, the
charging interface can be resumed by pressing any button. When the
power reaches 80% and there is no operation in 2 mins, the instrument
will automatically shut down for charging.
Warnings and Precautions
Improper operation or environment may cause accidents.
1. The instrument is strictly prohibited from collision, falling from high
places or violent vibration.
2. If there is gas of high concentration, the instrument may not work
properly.
3. Please operate and use strictly in accordance with the instructions,
otherwise it may result in inaccurate test results or damage to the
instrument.
4. Do not store the instrument in the following environments:
a. Places that may have water or heavy dust.
b. The instrument must not be stored and used in environments that
contain corrosive gases (such as salt or sulfur in high concentration,
etc.).
c. Air with other gases or chemicals.
d. Places of high temperature, high humidity or direct sunlight, including
environments of too high and low temperatures, high humidity,
electromagnetic fields, and strong sunlight.
5. Cleaning of the instrument’s surface:
a. The window of the sensor must be kept clean. If it is dirty, the
measurement will be inaccurate.
b. Please wipe it gently with a clean, soft cloth dampened with water
(do not use alcohol, diluent, etc. to clean the case, especially for
the LCD window.).
6. In order to ensure accuracy, the instrument should be calibrated
regularly, and the period can not exceed one year.
7. If the instrument breaks down, please contact our professional
personnel to repair it. Other people shall not change components
and wiring.
Warning: prohibit charging or disassembling batteries in an
explosive environment.
TIPS: This device is equipped with rechargeable battery. If you
receive the product and cannot start up, please connect with the
adapter for charging before use.
Special Statement:
Our company shall hold no any responisibility resulting from
using output from this product as an direct or indirect evidence.
this company reserves the right of changing the product design
and contents of instruction if changed the separate,notice isn’t given.
