WiSilica Lumos Controls Catron V User manual

Wireless 5 Button Remote
Catron V
WARNING AND GUIDELINES!!!
DO NOT INSTALL DAMAGED PRODUCT! This product has been properly packed
so that no parts should have been damaged during transit. Inspect to confirm.
Any part damaged or broken during or after assembly should be replaced.
WARNING :TURN THE POWER OFF AT THE CIRCUIT
BREAKER BEFORE WIRING
Required tools &supplies
INSTALLATION INSTRUCTIONS
Installation Steps
Read and follow all safety instructions!!
Do’s
Installation should be performed by
a qualified electrician
Don'ts
Don't use outdoors
Installation shall be in accordance with
all applicable local and NEC codes
Avoid input voltage exceeding
maximum rating
Turn the power OFF at circuit
breakers before wiring Don't dissemble the products
Observe the correct polarity of
output terminal
Electrostatic Discharge (ESD): ESD can damage product(s). Personal grounding
equipment should be worn during all installation or servicing of the unit
Do not stretch or use cable sets that are too short or are of insucient length
Do not modify the product
Do not mount near gas or electric heater
Do not change or alter internal wiring or installation circuitry
Do not use product for anything other than its intended use
WARNING: Risk of Product Damage
Screwdriver Screws Wall plates
Find a suitable place to fix the wall bracket using screws.
I. Using a level and a pencil, lightly mark 2 small dots to align the top edge of the
mounting plate.
II. Mark the mounting screw drill points and drill holes for the wall anchors with a
3/16” drill bit and insert wall anchors.
III. Insert the top screw(s) loosely and level the back plate.
IV. Insert the bottom screw(s), and then hand tighten the top screw(s).
V. Attach the wall plate on top of the rocker pad using the two screw holes.
Ensure optimal communications with other system components
Pick a convenient location, perhaps near a door where occupants enter and exit
Consider the construction materials in the space and remove the obstacles that
may interfere with RF signals
Verify that supply voltage is correct by comparing it with the product
information
Make all electrical and grounded connections in accordance with the National
Electrical Code (NEC) and any applicable local code requirements
All wiring connections should be capped with UL approved recognized wire
connectors
All unused wiring must be capped
WARNING - Risk of Electric Shock
Specifications TypeMin Max Remarks
Input Voltage
Frequency Range 2483.5
8
2400
105x40x12
4.1x1.6x0.47
3 3.3 VDC CR 2032 battery
6
-25
±225
MHz
dBmTx Power _
_ _
_
Frequency Drift(Max) _25 kHz
kHz
kHz
mA
in
mA
mm
48
°C
Frequency Deviation
Carrier
Frequency Oset
_
_
±275
°C
%95
dBm
30 150
_ _
_
dF2
Conductive
Tx Current
Rx Current 37
0
-10 60
50
__
_ _
_
_ _
_
Total current
@MaxTx power
Total current @Rx
mode
Non-condensing
L x W x H
L x W x H
Operating Temperature
Storage Temperature
Relative Humidity
Receiver Sensitivity
Dimension
Dimension
_ _
_
_ _
_ _
_
-75-86
INSTALLATION AND QUICK START SHEET
Product Overview
Catron V is a battery-powered switch that configures ON/OFF, intensity, and
Correlated Color Temperature of an individual or group of luminaires.
This compact device is designed for maximum longevity. It is part of Lumos
Controls ecosystem, which includes controllers, sensors, switches, modules,
drivers, gateways, and analytical dashboards.

Device Controls
Intensity Operation

Please visit - Help center for more details
Problem Solution Checklist
Put the device in commissioning mode by pressing the ON and OFF buttons for 10 seconds. A
green LED will lit up when the device goes to commissioning mode. Choose the zone from the
top right corner in the app to which you want to commission the device. Go to the 'Devices' tab
in the app. Click on the + button and choose the option 'Add device'. Click on 'Tap here' and the
device will be listed. Press + button corresponding to the device and the device will be
successfully commissioned.
Commissioning
Troubleshooting
The rocker pad does not
generate a message Verify the rocker pad is installed properly
The linked device does
not respond to wireless
messages
Check for environment or range issues
Verify the devices is linked
Check the transceiver connection and
the wiring of errors
Check if appropriate devices are linked
All Rights Reserved WiSilica Inc
[phone]
5-year limited warranty
Please find warranty terms and conditions
Note: Specifications may change without notice
Actual performance can vary due to end-user environment and application
Warranty
