WisyCom MRK16 Instruction manual

QUICK USER GUIDEQUICK USER GUIDE
This guide is intended to assist you with initial quick setup and
operation for your Wisycom product.
You can refer to Wisycom Autorized Distributors for technical Sup-
port and information about service and repairs available in your
area or contact us directly by email.
Serial Number: Purchase Date:
WISYCOM S.r.l.
Via Tiepolo 7/E
35019 Tombolo (PD) - ITALY
[phone]
[email protected]
[email protected]
WISYCOM INC.
14301 Sullyeld Circle
Suite C
Chantilly, VA 20151 - USA
[phone]
[email protected]
[email protected]
Download Documentation and Firmware
Get declaration, user manual, tips, speci-
cations, software on the download page:
wisycom.com/products/d/MRK16
Keep up with Wisycom online
Follow us on Facebook and Instagram. You
can also subscribe on Youtube for more.
wisycom.com/social
Product Registration and Warranty
Register your product to extend your warranty
and receive update on latest rmware:
wisycom.com/products/my-account
EU DECLARATION OF CONFORMITY
Manufacturer’s Name: WISYCOM S.r.l.
Manufacturer’s Address: via Tiepolo , 7/E- 35019 Tombolo (PD) - Italy
declare under our sole responsibility that the product
Model MRK16
Description Wireless Receiver Accessory
conforms to the essential requirements of the RADIO Directive 2014/53/EU
– Radio Equipment Directive (RED):
EN 300 422-1 v2.1.2
EN 301 489-1 v1.9.2
EN 301 489-9 v1.4.1
EN 62368-1 2014
EN 50581 2012
USA and CANADA
This device complies with part 15 of the FCC Rules. Operation is subject to
the following two conditions:
1 - This device may not cause harmful interference, and
2 - This device must accept any interference received, including interfer-
ence that may cause undesired operation.
In compliance with:
USA FCC 47 CFR 15 Subpart B
CAN RSS-Gen/CNR-Gen
CABS30: RF cable 30cm(12inch)
BNC-M to SMA-M 50Ω
BFLT1/BFLR1:Single laser RF
over FIber transmitter/receiver
with BT.
MAIN ACCESSORIES (for an updated and exhaustive list visit www.wisycom.com)
EX3: Epansion board version 3
- Optical inputs (SC/APC)
- BNC outputs
POE1: Power Over Ethernet board
- Dual POE++ input on Eth 2/4
LFA/ADFA/BFA: smart anten-
nas and booster/lters remotely
controllable
ISTR-MRK16 #MRK16 Quick user guide v3
MRK16MRK16
IC

Audio Monitoring
6.35mm plug mono to
listen any of the 16 RX
ON/OFF
Switch and
Led
Antenna Outputs
Daisy chain output (up to
4 MRK16 - 64 channels)
Antenna Inputs
Dual zone antenna
inputs A1A2/B1B2
Fan Module
Next generation
silent fan
EX3 Antenna outputs
Chain the RFoF signal
with the desired input
Optical connector
RF over ber conenctor
SC/APC - Singlemode
Bluetooth 5 long range
Class 1 (100mW)
remote control
Antenna Matrix
Green when area is active
Red if RF overload
Off is area in not active
Rotary Knob
• Rotate to adjust volume
• Quick push to select RX and conrm
• Long push to enter MRK16 setup
menu
AB
ON
1
3
2
4
PWR
EXIT
MENU
SEL
SYNC
SCAN
fn
BT
B
2
4
SYNC
SCAN
fn
T
Antenna Booster
Green if booster on
Red if antenna fault
Off if booster off
Power Supply
Green if present
Blue if used
Red if voltage fault
Off if no power
AES59
DB25 connection
AES72
Dual Cat5 connection
Analogue
Dual DB25 connector
(Tascam standard):
Left: Rx 1 to 8
Right: Rx 9 to 16
Dual redundant
DC power input
• XLR-4M
9-28Vdc
Power Over Ethernet (PoE)
• Dual input (ETH2 & ETH4)
• Output (ETH1) to supply
external device (i.e. Wi)
USB-C
Charging
5 ports manageable Gbit switch
• ETH1/3 control via Wisycom
Manager
• ETH2/4 Dante audio
• ETH5 internal optical SFP slot
(with MRK-SFP accessory )
GPIO
General purpose
input/output
(optional)
